<ul><li>Peter Conradie  |  Joel Laumans  | Hans Kemp  |  Rolf den Otter  |  Rest of the IAD Team </li></ul>that is  NOT a ...
part 1 Wireframes and Interaction Design Documents
wireframes? Wireframes and Interaction Design Documents
Wireframes and Interaction Design Documents These are NOT good wireframes
Not everyone knows  exactly  what they are doing Wireframes and Interaction Design Documents
wireframes? <ul><li>Illustration of the content </li></ul><ul><ul><li>Hierarchy </li></ul></ul><ul><ul><li>Relationships <...
types of wireframes <ul><li>Sketches </li></ul><ul><ul><li>Quick, experimental </li></ul></ul><ul><ul><li>Good for feedbac...
types of wireframes <ul><li>Sketches </li></ul><ul><ul><li>Quick, experimental </li></ul></ul><ul><ul><li>Good for feedbac...
types of wireframes <ul><li>Sketches </li></ul><ul><ul><li>Quick, experimental </li></ul></ul><ul><ul><li>Good for feedbac...
Wireframes and Interaction Design Documents
DESIGN TIMELINE Wireframes and Interaction Design Documents
<ul><li>Experience at CMD </li></ul>Wireframes and Interaction Design Documents “ Real world” you you you friend (maybe) y...
goals of wireframes <ul><li>Communicate solutions for design problems </li></ul><ul><li>Communicate fundamental design cho...
goals of wireframes <ul><li>Different wireframes for different goals:  Flows, user testing, content overview, etc </li></u...
basic requirements <ul><li>Title + Description </li></ul><ul><li>Page number </li></ul><ul><li>Diagram of content </li></u...
Wireframes and Interaction Design Documents
Wireframes and Interaction Design Documents
Wireframes and Interaction Design Documents
part 2 Wireframes and Interaction Design Documents
Interaction design documents Wireframes and Interaction Design Documents Interaction Design Documents
what are they? Wireframes and Interaction Design Documents A document containing a  collection   of high fidelity  wirefra...
<ul><li>Cover page </li></ul><ul><li>Table of Contents </li></ul><ul><li>Descriptions </li></ul><ul><li>Wireframes </li></...
components / elements? Wireframes and Interaction Design Documents
<ul><li>Describe functionality by </li></ul><ul><li>illustrating scenarios/flows </li></ul>‘ wireflows’ Wireframes and Int...
<ul><li>Lorem ipsum dolor sit atem… </li></ul><ul><li>Text goes here. Text goes here. Text goes here. Text goes here. Text...
<ul><li>Forget color! </li></ul><ul><li>( Unless of course it is essential to the user experience) </li></ul><ul><li>Try a...
<ul><li>Points and vectors may be misleading when translating to pixels, don’t make texts too long! </li></ul>scale / prop...
<ul><li>“ re-usable  solution to a commonly occurring problem” </li></ul><ul><li>http://developer.yahoo.com/ypatterns/ </l...
<ul><li>They are specific </li></ul><ul><li>More usable and easier to understand </li></ul><ul><li>It will save you time! ...
<ul><li>ajax, javascript, flash, etc </li></ul><ul><li>sometimes hard to illustrate in wireframes  </li></ul>rich internet...
<ul><li>Frame-by-frame </li></ul><ul><li>Lo-fi Animations </li></ul><ul><li>Wireframes with keyframes </li></ul>dynamics i...
Wireframes and Interaction Design Documents Frame-by-frame
Wireframes and Interaction Design Documents Lo-fi animation http://developer.yahoo.com/ypatterns/pattern.php?pattern=carou...
Wireframes and Interaction Design Documents Wireframes with keyframes
<ul><li>Clear enough to develop from </li></ul><ul><li>Serve as a blueprint for final product </li></ul><ul><li>Get everyo...
<ul><li>Visio </li></ul><ul><li>OmniGraffle </li></ul><ul><li>InDesign </li></ul><ul><li>Illustrator </li></ul><ul><li>Fir...
<ul><li>Cross-platform (Windows & OS X) </li></ul><ul><li>Templates, elements, components library </li></ul><ul><li>Pagina...
resources (online) <ul><li>http://userpathways.com/2008/06/26/the-what-when-and-why-of-wireframes/ </li></ul><ul><li>http:...
resources (offline) <ul><li>Designing for Interaction – Dan Saffer </li></ul><ul><ul><li>Chapter 5 </li></ul></ul><ul><li>...
Assignment (groups of 3-4 people) <ul><li>Pick a webpage which contains several RIA elements. </li></ul><ul><li>As a group...
