PHP Oracle Web Applications:

PHP Oracle Web Applications:
Best Practices and Caching Strategies
by Kuassi Mensah, Server Technologies, Oracle

Talk presented at PHP Barcelona Conference 2009.

Statistics

Views

Total Views
26,946
Views on SlideShare
26,935
Embed Views
11

Actions

Likes
4
Downloads
188
Comments
1

1 Embed 11

http://www.slideshare.net 11

Accessibility

Categories

Upload Details

Uploaded via as Adobe PDF

Usage Rights

© All Rights Reserved

Report content

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
  • Full Name Full Name Comment goes here.
    Are you sure you want to
    Your message goes here
    Processing…
Post Comment
Edit your comment

PHP Oracle Web Applications by Kuassi Mensah PHP Oracle Web Applications by Kuassi Mensah Presentation Transcript

  • © 2009 Oracle Corporation
  • <Insert Picture Here> PHP Oracle Web Applications: Best Practices and Caching Strategies Kuassi Mensah Server Technologies Oracle Mensah, Technologies,
  • Agenda • ► PHP, the OCI8 Extension and Oracle Database • Scaling Database Connectivity • Database Resident Connection Pool – Solving the C20K Problem • Logon Storm Shield • Scaling Database Operations • Bind Variables, Statement Caching, Row Prefetching • Scaling Very Complex Queries • Scaling with Stored Procedures • Caching Strategies • Resultset Caching • Continuous Query Notification and Mid-tier Cache Invalidation • I Memory Database Cache In M D t b C h © 2009 Oracle Corporation
  • PHP and the OCI8 Extension © 2009 Oracle Corporation
  • Three Tier Web Model © 2009 Oracle Corporation
  • What is OCI8? • Main Oracle Database extension for PHP • Open source and part of PHP • Current version is OCI8 1.3 – in PHP 5.3 and in PECL <?php $c = oci_connect('un', 'pw', 'localhost/orcl'); $s = oci_parse($c, 'select * from employees'); oci_execute($s); while (($row = oci_fetch_array($s, OCI_ASSOC)) != false) foreach ($row as $item) ( ) print $item; ?> © 2009 Oracle Corporation
  • Get the Latest OCI8 1.3 • php.net • PHP 5 3 Source code Windows binaries 5.3 code, • PECL - PHP Extension Community Library • For updating PHP 4 - 5.2 with OCI8 1.3 • htt // http://oss.oracle.com/projects/php l / j t / h • RPMs for Linux with OCI8 • Unbreakable Linux Network • Oracle's Linux Support program • OCI8 RPM available for PHP • Zend Se e e d Server • Linux, Windows, Mac • Support from Zend © 2009 Oracle Corporation
  • Oracle Database 11.1 and PHP • Oracle 11.1 was released August 2007 • Connection Pooling - DRCP • Server (database) Query Result Cache • Client Query Result Cache • Query Annotation • Continuous Query Notification • Cube Organized Materialized Views • Total Recall • ... © 2009 Oracle Corporation
  • Oracle Database 11.2 and PHP • Oracle 11.2 was released September 2009 • Many new features building on 11gR1 innovations • Improved views for DRCP connection pooling • Continuous Query Notification for Views • Client Query Result Cache • Table Annotation • View Annotation • Client query result cache (CQRC) supported with DRCP • Pre-fetching supported in more places • Edition Based Redefinition • RAC One Node option • ... © 2009 Oracle Corporation
  • Agenda • PHP, the OCI8 Extension and Oracle Database • ►Scaling Database Connectivity • Database Resident Connection Pool – Solving the C20K Problem • Logon Storm Shield • Scaling Strategies • Bind Variables, Statement Caching, Row Prefetching • Scaling Very Complex Queries • Scaling with Stored Procedures • Caching Strategies • Resultset Caching • Continuous Query Notification and Mid-tier Cache Invalidation • I Memory Database Cache In M D t b C h © 2009 Oracle Corporation
  • Database Resident Connection Pool - Solving the C20K problem © 2009 Oracle Corporation
  • Standard OCI8 connections $c = oci_connect($un, $pw, $db); • High CPU Overhead • Connection establishment slow • Frequent connect and disconnect • Does not scale in web environments • One database server process per PHP user • Maxes out database server memory • Cannot handle the Digg effect © 2009 Oracle Corporation
  • Persistent OCI8 Connections $c = oci_pconnect($un, $pw, $db); • Not closable (prior to OCI8 1.3) • Fast for subsequent connections • Some control configurable in php.ini oci8.max_persistent oci8.persistent_timeout oci8.ping_interval © 2009 Oracle Corporation
  • Database Resident Connection Pool Solving the C20K Problem Dedicated servers Connection Connection ( DB handle) Broker Session Session Session (User Handle) 1 Session S i (User Handle) (User Session Handle) (User Handle) Oracle Net (User Handle) 2 • Pool of dedicated servers • (1) Server allocated/locked on Appl Connect Appl. • (2) Direct server access after handoff • (3) Server released on Appl. ConnClose . • N man-in-the-middle, l No i th iddl low l t latency © 2009 Oracle Corporation
  • DRCP: System Overview © 2009 Oracle Corporation
  • PHP DRCP Benchmark • See PHP DRCPC Whitepaper • 2GB RAM • 1 connection broker • 100 pooled servers © 2009 Oracle Corporation
  • Sample Sizing for 5000 Users Dedicated DRCP Servers Servers (Pool of 100) Database Servers 5000 * 4 MB 100 * 4 MB Session Memory 5000 * 400 KB 100 * 400 KB DRCP Connection 5000 * 35 KB Broker Overhead Total Memory 21 GB 610 MB © 2009 Oracle Corporation
  • DRCP in PHP • DRCP support is available in OCI8 1.3 • Developer decision to use it or not • DRCP functionality available when linked with Oracle 11g client libraries and connected to Oracle 11g • OCI8 1.3 is included in PHP 5.3 and PHP 6 • For PHP 4.3.9 – 5.2 use PECL OCI8 1.3 © 2009 Oracle Corporation
  • Configuring and Starting the POOL • Install PHP OCI8 1.3 and Oracle 11g • Configure the pool (optional) SQL SQL> execute dbms connection pool.configure pool( dbms_connection_pool.configure_pool( pool_name => 'SYS_DEFAULT_CONNECTION_POOL', minsize => 4, maxsize => 40, incrsize => 2, session_cached_cursors => 20, inactivity_timeout => 300, max_think_time max think time => 600 600, max_use_session => 500000, max_lifetime_session => 86400); • Sart the pool: SQL> execute dbms_connection_pool.start_pool(); • Set oci8.connection_class in php.ini oci8.connection_class MY_PHP_APP oci8 connection class = MY PHP APP © 2009 Oracle Corporation
  • Using the Pool 1/ Changing the Connect String in PHP Applications <?php $c = oci_pconnect("phpweb", "phpweb", "//localhost/orcl:pooled"); $s = oci_parse($c, 'select * from employees'); oci_execute($s); oci_fetch_all($s, $res); var_dump($res); var dump($res); ?> 2/ Zero Code Change Change the TNS alias in tnsnames.ora configuration file © 2009 Oracle Corporation
  • Some DRCP recommendations. • Read the PHP DRCP whitepaper http://www.oracle.com/technology/tech/php/index.html • Make sure oci8.connection_class is set • Have > 1 Broker, but only a few • Close connections when doing non-DB processing • Explicitly control commits and rollbacks • Avoid unexpectedly open transactions when an oci_close() or end- of-scope of scope occurs • Scripts coded like this can use oci_close() to take advantage of DRCP but still be portable to older versions of the OCI8 extension • Monitor V$CPOOL STATS view to determine best pool size V$CPOOL_STATS © 2009 Oracle Corporation
  • Logon Storm Shield © 2009 Oracle Corporation
  • Logon Storm Shield • Logon Storm • On Mid-tier Reboot • DoS Attack • Logon Storm Shield: Connection Rate Limiter g • configured in LISTENER.ORA LISTENER=(ADDRESS_LIST= (ADDRESS=(PROTOCOL=tcp)(HOST=sales)(PORT=1521)(RATE_LIMIT=3)) (ADDRESS=(PROTOCOL=tcp)(HOST=lmgmt)(PORT=1522)(RATE_LIMIT=no))) • Set the Rate Limit to a value that matches your machine capabilities. biliti © 2009 Oracle Corporation
  • Agenda • PHP, the OCI8 Extension and Oracle Database • Scaling Database Connectivity • Database Resident Connection Pool – Solving the C20K Problem • Logon Storm Shield • ►Scaling Database Operations • Bind Variables, Statement Caching, Row Prefetching g g • Scaling Very Complex Queries • Scaling with Stored Procedures • Caching Strategies • Resultset Caching • Continuous Query Notification and Mid-tier Cache Invalidation • In Memory Database Cache © 2009 Oracle Corporation
  • Bind Variables © 2009 Oracle Corporation
  • Not Binding Literals in SQL statements disable sharing Poor use of cache © 2009 Oracle Corporation
  • Binding Scalars © 2009 Oracle Corporation
  • Binding Scalars <?php $c = oci_connect('hr', 'hrpwd', 'localhost/orcl'); $s = oci_parse($c,'insert into employees values (:bv)'); $name = ‘Mensah'; oci_bind_by_name($s, :bv oci bind by name($s ':bv', $name); oci_execute($s); ?> • Associates PHP variable $name with placeholder :bv • Similar to JDBC PreparedStmt • No SQL Injection worry • Easier to write than adding quote escaping © 2009 Oracle Corporation
  • DB Statistics Without and With Binding From a query example by Tom Kyte: Not Binding Binding Parse time elapsed 485 36 Parse count (hard) 5,000 1 Latches 328,496 118,614 • Overall system is more efficient • PHP user elapsed time directly benefits © 2009 Oracle Corporation
  • Binding Best Practices • Set length parameter to your upper data size for re- executed IN binds oci_bind_by_name($s, “:b”, $b, 40); _ _ y_ ( ) • Don't bind constants • Let the optimizer see them • Long running unique queries may not benefit • Parse time is a relatively small cost • CURSOR_SHARING parameter • S in “ Set “session” or database init.ora • Makes every statement appear to have bound data, but optimizer now doesn't see constants • For bind-unfriendly applications bind unfriendly • Oracle 11g has Adaptive Cursor Sharing • Can have multiple execution plans for same statement © 2009 Oracle Corporation
  • Statement Caching © 2009 Oracle Corporation
  • Client (aka PHP) Statement Caching Less traffic and DB CPU © 2009 Oracle Corporation
  • OCI8 Uses the Statement Cache. • No PHP code change needed • Oracle Client library cache of statement text & meta data • On by default in php.ini oci8.statement_cache_size oci8 statement cache size = 20 Unit is number of statements • Set it big enough for working set of statements • Reduces network traffic and context switches ff • Moves cache management load from DB to PHP side • Uses memory on PHP side for cached statement handles • Uses memory on DB for per-session cursors © 2009 Oracle Corporation
  • Row Prefetching © 2009 Oracle Corporation
  • Prefetching Reduces Roundtrips • Temporary buffer cache for query duration No DB access for next fetch Reduces round trips © 2009 Oracle Corporation
  • Prefetching Improves Query Times Your results will vary © 2009 Oracle Corporation
  • Prefetching is Enabled by Default • Enabled by default • Can tune per statement: $s = oci_parse($c, 'select city from locations'); oci_set_prefetch($s, 200) i t f t h($ 200); oci_execute($s); while (($row = oci_fetch_array($s, OCI_ASSOC)) != false) foreach ($row as $item) print $item; Each database “round trip” prefetches 200 rows © 2009 Oracle Corporation
  • PHP OCI8 Row Prefetching. • No need to change PHP application • Rows are cached internally by Oracle client libraries • php.ini oci8.default_prefetch = 100 rows • Was 10 rows in OCI8 1.2 • Oracle 11.2 supports REF CURSOR prefetching too • Tuning goal: • R d Reduce round t i d trips • For big data sets: transfer reasonable chunks, not huge sets © 2009 Oracle Corporation
  • Scaling Very Complex Queries © 2009 Oracle Corporation
  • Scaling Very Complex SQL Queries Problem to Solve: Query Sales and Quantity by Year,Department, Class and Country The SQL Query: SELECT SUM(s.quantity) AS quantity, SUM(s.sales) AS sales, t.calendar_year_name, p.department_name, c.class_name, t calendar year name p department name c class name cu.country_name FROM times t, products p, channels c, customers cu, sales_fact s WHERE p.item_key = s.product AND s.day_key = t.day_key AND s.channel = c.channel_key AND s.customer = cu.customer_key GROUP BY p.department_name, t.calendar_year_name, c.class_name, cu.country_name; cu country name; © 2009 Oracle Corporation
  • Cube Organized Materialized Views Transparent to SQL Queries SQL Query Materialized Views Region R i Date D t Query Rewrite Product Channel Automatic OLAP Cube Refresh © 2009 Oracle Corporation
  • Scaling with Stored Procedures © 2009 Oracle Corporation
  • Scaling with Stored Procedures Java or PL/SQL Client Client Any Language Any Language Stored Procedure Call Multiple Unique SQL Calls Java or PL/SQL Calls SQL SQL Up to 10 x Faster! © 2009 Oracle Corporation
  • Agenda • PHP, the OCI8 Extension and Oracle Database • S li Scaling D t b Database C Connectivity ti it • Database Resident Connection Pool – Solving the C20K Problem • Logon Storm Shield • Scaling Database OPerations • Bind Variables, Statement Caching, Row Prefetching • Scaling Very Complex Queries • Scaling with Stored Procedures • ►Caching Strategies • Resultset Caching • Continuous Query Notification and Mid-Tier Cache Invalidation • In Memory Database Cache © 2009 Oracle Corporation
  • Resultset Caching © 2009 Oracle Corporation
  • Oracle 11g Client & Server Result Caches • Results of queries can be cached • Server and client (aka PHP) have caches • Recommended for small lookup tables • Client cache is per-process • Caches automatically invalidated by server data changes • Feature can be configured globally or per client • DB parameter: CLIENT_RESULT_CACHE_SIZE Per-client i sqlnet.ora: OCI RESULT CACHE MAX SIZE P li t in l t OCI_RESULT_CACHE_MAX_SIZE • Has a configurable 'lag' time • If no roundtrip within defined time, cache assumed stale © 2009 Oracle Corporation
  • Oracle 11g Client & Server Result Caches • With Oracle 11.2 Table or View Annotation, developer or DBA choose tables or view to be cached: alter table last_name result_cache create view v2 as select /*+ result cache */ col1, coln from t1 No need to change PHP application • With Oracle 11 1 Query Annotation need to add hint 11.1 Annotation, to queries instead: select /*+ result_cache */ last_name from employees • V$RESULT_CACHE_* views show cache usage © 2009 Oracle Corporation
  • No DB Access When Client Cache Used SQL> select parse_calls, executions, sql_text from v$sql where sql_text like '%cjcrc%'; PARSE_CALLS PARSE CALLS EXECUTIONS SQL TEXT SQL_TEXT ----------- ---------- ----------------------------------- 2 100 select * from cjcrc 2 2 select /*+ result_cache */ * from cjcrc © 2009 Oracle Corporation
  • Result Caching Test. $c = oci_pconnect('hr', 'hrpwd', 'localhost/orcl'); $tbls = array('locations', 'departments', 'countries'); foreach ($tbls as $t) { $s = oci_parse($c, "select /*+ res lt cache */ * from $t") oci parse($c result_cache $t"); oci_execute($s, OCI_DEFAULT); while ($row = oci_fetch_array($s, OCI_ASSOC)) { foreach ($row as $item) {echo $item "n";}}} $item. n ;}}} $ siege -c 20 -t 30S http://localhost/clientcache.php Without result cache: select * from $t Transaction rate: 32.02 trans/sec With result cache cache: select /*+ result cache */ * from $t result_cache Transaction rate: 36.79 trans/sec Result Caching was approx. 15% better © 2009 Oracle Corporation
  • Continuous Query Notification and Mid Tier Cache Invalidation Mid-Tier © 2009 Oracle Corporation
  • Continuous Query Notification Problem to solve: Be notified when changes in the database invalidates an existing query result set 2.Upon Change ( p (DMLImpacting g <?php the result set) … Callout 4.Invalidate cache 5.repopulate cache p p … ?> 1. Register 3.Automatic the query Custom cache Notification (Java or PL/SQL database job as noificaion callback) © 2009 Oracle Corporation
  • Example - The Cache Depends On This Table $ sqlplus cj/cj create table cjtesttab ( group_id number, name varchar2(20) ); insert into cjtesttab values (1, 'alison'); insert into cjtesttab values (2, 'pearly'); insert into cjtesttab values (2, 'wenji'); © 2009 Oracle Corporation
  • Example - The PHP Cache-Updating Code <?php // cache.php $g = date('Y-m-d H:i:s').": Table was: ".$_GET[tabname]; file_put_contents( /tmp/cqn.txt file put contents('/tmp/cqn txt', $g); // In reality query the table and update the cache: // $s = oci_parse($c, "select * from ".$_GET[tabname]); // . . . // $ $memcache->set('key', ...); ?> © 2009 Oracle Corporation
  • Example - Create 'mycallback' PL/SQL Procedure create or replace procedure mycallback ( ntfnds in cq_notification$_descriptor) is req utl_http.req; resp utl_http.resp; begin if (ntfnds.event_type = dbms_cq_notification.event_querychange) then f( f f ) req := utl_http.begin_request( 'http://mycomp.us.oracle.com/~cjones/cache.php&tabname=' || ntfnds.query_desc_array(1).table_desc_array(1).table_name); tf d d (1) t bl d (1) t bl ) resp := utl_http.get_response(req); utl_http.end_response(resp); end if; end; / © 2009 Oracle Corporation
  • Example - Register 'mycallback' for a Query y declare reginfo cq_notification$_reg_info; v_cursor sys_refcursor; y ; regid number; begin reginfo := cq_notification$_reg_info ( 'mycallback', -- callback function dbms_cq_notification.qos_query, -- result-set notification flag 0, 0, 0); regid := dbms_cq_notification.new_reg_start(reginfo); open v_cursor for select name from cjtesttab where group_id = 2; close v_cursor; dbms_cq_notification.reg_end; end; / © 2009 Oracle Corporation
  • Example Recap • Table cjtesttab • PHP script http://.../cache.php to update the cache • PL/SQL callback procedure mycallback() • Registered query select name f l t from cjtesttab where group_id = 2; jt tt b h id 2 • Aim: refresh mid-tier cache when this query results change © 2009 Oracle Corporation
  • Example - In Action • Let's update the table: update cjtesttab set name = 'c' where group_id = 2; p j g p_ ; commit; • Output in /tmp/cqn.txt is: 2009-09-23 2009 09 23 13:11:39: Table was: CJ.CJTESTTAB CJ CJTESTTAB • Update a different group_id: update cjtesttab set name = 'x' where group_id = 1; commit; • No change notification is generated © 2009 Oracle Corporation
  • The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any t t i t it t t d li material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remain at the sole discretion of Oracle. © 2009 Oracle Corporation
  • Challenges with Current Caching Mechanisms • Cache Currency • Content can get stale over time – invalidate or refresh cache • R d O l vs. Updatable C h Read-Only U d bl Cache • Updates require synchronization with Oracle database • Query Capability y p y • Persistence in the Application Tier • Availability • Should access to data be available if back end database is not back-end available? • Significant Development effort © 2009 Oracle Corporation
  • Oracle Database and PHP Roadmap • PHP OCI8 integration with g • TimesTen In Memory Database • A fast in memory, persistent DB • TimesTen In Memory Database Cache • Cache for Oracle Database • No need for separate caching logic © 2009 Oracle Corporation
  • Extra Slides and Free Stuff © 2009 Oracle Corporation
  • DBMS_XA: Transactions Across Requests • Oracle 11gR1 Feature • Can we use it on the web? Upgrading thick client applications? • E Example f l from htt //ti http://tinyurl.com/dbmsxaex l /db HTTP Request #1: rc := DBMS_XA.XA_START(DBMS_XA_XID(123), DBMS_XA.TMNOFLAGS); UPDATE employees SET salary=salary*1.1 WHERE employee_id = 100 l l l *1 1 l id 100; rc := DBMS_XA.XA_END(DBMS_XA_XID(123), DBMS_XA.TMSUSPEND); HTTP Request #2: rc := DBMS_XA.XA_START(DBMS_XA_XID(123), DBMS_XA.TMRESUME); SELECT salary INTO s FROM employees WHERE employee_id = 100; rc := DBMS_XA.XA_END(DBMS_XA_XID(123), DBMS_XA.TMSUCCESS); _ _ ( _ _ ( ) _ ) HTTP Request #3: rc := DBMS_XA.XA_COMMIT(DBMS_XA_XID(123), TRUE); © 2009 Oracle Corporation
  • Hey Look! Free Stuff • Oracle Instant Client • Easy to install • Client libraries for C, C++, Java, .Net access to a remote DB • Oracle Database Express Edition (aka “XE”) XE ) • Same code base as full database • Windows & Linux 32 bit • SQL Developer • Thick client SQL and PL/SQL development tool • Connects to MySQL too • Application Express ( Apex ) (“Apex”) • Web based Application Development tool • Try it at http://apex.oracle.com/ © 2009 Oracle Corporation
  • Some PHP & Oracle Books © 2009 Oracle Corporation
  • Oracle Resources • Free Oracle Techology Network (OTN) PHP Developer Center: otn.oracle.com/php • Free book: Underground PHP and Oracle Manual • Whitepapers, Articles, FAQs, links to blogs, JDeveloper PHP Extension, PHP RPMs • Information kuassi.mensah@oracle.com db360.blogspot.com christopher.jones@oracle.com blogs.oracle.com/opal • SQL and PL/SQL Questions asktom.oracle.com • ISVs and hardware vendors oraclepartnernetwork.oracle.com oraclepartnernetwork oracle com © 2009 Oracle Corporation
  • © 2009 Oracle Corporation
