10 Steps to Simplify SOA Governance February 29, 2012

Agenda
Introduction
SOA Governance Overview
Ten Steps to Simplify SOA Governance
Align SOA projects with business goals
Develop a collaborative organization for SOA governance
Define organizational roles and responsibilities
Establish the SOA lifecycle process and policies
Adjust your software development lifecycle for SOA
Define SOA foundational standards
Define run-time processes
Determine the role of technology in your governance processes
Establish SOA measurements and monitoring techniques
Evolve and improve SOA governance over time
Steps are non-linear Eric Roch Chief Technologist

About Perficient Perficient is a leading information technology consulting firm serving clients throughout North America. We help clients implement business-driven technology solutions that integrate business processes, improve worker productivity, increase customer loyalty and create a more agile enterprise to better respond to new business opportunities.

Perficient Profile
Founded in 1997
Public, NASDAQ: PRFT
2010 Revenue of $215 million
Major market locations throughout North America
Atlanta, Austin, Charlotte, Chicago, Cincinnati, Cleveland, Columbus, Dallas, Denver, Detroit, Fairfax, Houston, Indianapolis, Los Angeles, Minneapolis, New Orleans, Northern California, Philadelphia, San Francisco, San Jose, Southern California, St. Louis and Toronto
Global delivery centers in China, Europe and India
1,700+ colleagues
Dedicated solution practices
85% repeat business rate
Alliance partnerships with major technology vendors
Multiple vendor/industry technology and growth awards

Our Solutions Expertise & Services
Business-Driven Solutions
Enterprise Portals
SOA and Business Process Mgmt
Business Intelligence
User-Centered Custom Applications
Interactive Design
CRM Solutions
Enterprise Performance Management
Customer Self-Service
eCommerce & Product Information Management
Enterprise Content Management
Management Consulting
Industry-Specific Solutions
Mobile Technology
Security Assessments
Perficient brings deep solutions expertise and offers a complete set of flexible services to help clients implement business-driven IT solutions
Perficient Services
End-to-End Solution Delivery
IT Strategic Consulting
IT Architecture Planning
Business Process & Workflow Consulting
Usability and UI Consulting
Custom Application Development
Offshore Development
Package Selection, Implementation and Integration
Architecture & Application Migrations
Education
Interactive Design

IT Governance
Asset and Portfolio Management
Business Technology Optimization
Performance and Service Management
Security and Access Control
Enterprise Architecture
Project lifecycle management
IT already practices governance such as quality control, change management and service level agreements.

IT Governance Frameworks
The IT Infrastructure Library (ITIL) is a detailed framework with hands-on information on how to achieve a successful governance of IT, developed and maintained by the United Kingdom's Office of Government Commerce, in partnership with the IT Service Management Forum.
Control Objectives for Information and related Technology (COBIT) is another approach to standardize good information technology security and control practices. This is done by providing tools to assess and measure the performance of 34 IT processes of an organization. The ITGI (IT Governance Institute) is responsible for COBIT
The ISO/IEC 27001 (ISO 27001) is a set of best practices for organizations to follow to implement and maintain a security program. It started out as British Standard 7799 ([BS7799]), which was published in the United Kingdom and became a well known standard in the industry that was used to provide guidance to organizations in the practice of information security.
The Information Security Management Maturity Model ISM3 is a process based ISM maturity model for security.
AS8015-2005 Australian Standard for Corporate Governance of Information and Communication Technology
We have a wealth of knowledge and processes to leverage for SOA.

What is SOA governance?
Because services are intrinsically distributed and reusable they introduce new governance challenges
SOA governance is an extension of IT governance that focuses on:
lifecycle of services and composite applications
the decision rights for the development, deployment and management of new services
monitoring and reporting processes for capturing and communicating SOA results and process improvement
SOA governance mission: To create policies, principles, standards, procedures and processes that will realize the full business benefit of service orientation
Perficient’s SOA governance design goals:
Keep the process and deliverables lightweight
To manage change, build consensus and roll out governance processes iteratively shifting software-engineering culture over time
Mature SOA governance over time through measurements and process improvement
Keep the process and deliverables lightweight, easy to follow and add value.

SOA Governance Framework
Managing the portfolio of services: planning development of new services and updating current services
Managing the service lifecycle : meant to ensure that updates of services do not disturb current service consumers
Using policies to restrict behavior: rules can be created that all services need to apply to, to ensure consistency of services
Establish performance monitoring of services: because of service composition, the consequences of service downtime or underperformance can be severe.
Create, communicate and enforce governance policies

SOA Governance Lifecycle
Governance is the combination of people, policies, and processes that an organization leverages to achieve desired behaviors
SOA governance is about achieving the desired behavior associated with SOA adoption
Project governance - the behaviors span the normal software development efforts
Run-time governance - the interaction between service consumers and service providers in production environments
Pre-project governance - processes associated with the proposal, approval, and funding of projects
During each of these efforts, people, policies, and processes must be established and leveraged to ensure that the changes to the culture are successful
Source: SOA Governance by Todd Biske (book)

Governance Process and Artifacts
Policies and Decision Rights
Set of guidebooks to address SOA Governance
Strategy and roadmap
Core Services
Roadmap: Projects and timeline
People and process impact
Technology enablement
Organization
SOA Steering Committee and Competency Center
Create, approve, communicate and enforce the governance framework
Interrelationships and dependences
SOA measurement criteria and process
SOA Architecture
Documented standards
Design review process and checklists
SOA Lifecycle
Design to deploy methodology
Deliverable templates, checklists and samples
Release management
SOA Operations
Policy based monitoring and management
Security policies
Build and deploy standards and process
Administration documentation and processes
Governance should flow smoothly within a lifecycle with everyone working together.

Quick Start Rulebook™ Methodology
Develops SOA strategy and roadmap
Establishes the SOA competency center organizational and maturity model
Define governance model for design, asset management and operations
Develops SOA reference architecture
Addresses SOA project orientated methodology
Establishes the operations and quality assurance strategy processes and procedures
Supported by design patterns and reusable components
Codify common design patterns – e.g. the Exception Handler
Optimize the operational environment

Step 1: Business Alignment
A top-down view of business services by domain identifies core services
Project alignment simplifies funding ensures ROI
Start a SOA program in the context of projects in the portfolio
Identify projects that will benefit from SOA:
Integration
Process automation and improvement
Information access
Multi-channel
APIs

Business Alignment Case Study
Six iterations delivered through the end of 2012
Automates sales role in the overall order process
Features: Visibility to product availability, automated cost estimates, collaborative (with customer) proposal process, capture of information to eliminate downstream duplicate data entry and facilitate process hand-offs
Key benefits: Process improvement and automation results in time savings for sales leads to increased sales
Cost estimate: $$$$

Business Alignment Case Study

Step 2: Organizational Structure
Develop a formal organization for the SOA discipline
Build processes, best practices & internal competencies to best utilize resources
Architect and advise SOA project activities
Standardization of architecture and product roles
Provide a governance role for reusable services
Coordinate with PMO to manage the SOA project lifecycle (process and deliverables)
Through process, standards and governance create continuous and measurable improvements
Accomplish enterprise wide integration through iterations based on reusable artifacts
Evangelize SOA within the IT organization

Governance People, Process, Technology CMDB Plan Lifecycle Roles Disciplines Tools Portfolio Management Visual Modeling Repository Registry Projects & Assets Versioned Source Business Processes & Rules BPM Metrics & History ESB BPM Source Control SOA Management Policy Audit SLA XSD Authoring App Server Registry Release Management Lifecycle Management Policy Management SOA Contract Management Portfolio Mgt Support & Infrastructure SOA Steering Committee Competency Center Enterprise Architecture Business Leaders Application Development Quality Assurance Administration & Operations Specify Provision Orchestrate Test Deploy Run IT Steering Committee Test Tools

Organization Case Study
Structure
Standards
Responsibilities
Escalations
Process Coordination
Collaboration
Change management
Consensus
Long-term manage SOA infrastructure
Work with SOA CC for capacity planning and SLAs
Build business services with SOA CC
Domain/Data subject matters experts
Consult with development to build business services
Support – Monitor Business Services Infrastructure
Liaison business services and technical deployment
Manage infrastructure until formal turnover

Organization Case Study
Long-term manage SOA infrastructure
Work with ICC for capacity planning and SLAs
Build business services with ICC
Domain/Data subject matters experts
Consult with development to build business services
Support – Monitor Business Services Infrastructure
Liaison business services and technical deployment
Manage infrastructure until formal turnover
Legend – R Responsible, A Approve, C Consulted, I Informed Systems Development Teams ICC Systems Administration Applications R C Subsystems R C Business Services R C Application Service & Adapters R A Orchestration C R Common Components I R Metadata I R Logical Bus I R Broker A R BPM Engine A R Physical Bus A R SOA Infrastructure A R Capacity Planning A R Service Level Agreements A R Platforms C R OS C R RDBMS C R Networks C R

Step 4: SOA Lifecycle Process and Policies Reference: SOA for Profit

Lifecycle Case Study – Trouble Spots

What’s in the SDLC to build services?
Contracts are packages of structured and unstructured assets -interfaces, conditional elements, and documentation
Operations available, along with the associated abstract payload definition (both inbound and outbound)
List of potential exception conditions
Functional semantics such as pre- and post-conditions
Business semantics and invariants related to the service
Synchronous or asynchronous access, and other message exchange patterns
Security requirements, including supported credentials, encryption, and signatures
Other important contextual information such as Quality of Service (QoS) that describes performance and availability metrics

Step 5: SDLC Adjustments Add a very simple SOA deliverable templates early and gates to trigger the SOA lifecycle * Note: The Feasibility Phase Project Architecture has a section for conceptual architecture Service Requirements Business Services In Feasibility Architecture* Service Certification

Step 5: SDLC Adjustments Add a very simple SOA deliverables to the Agile approach Business Service Solution Architecture Service Design Test Cases

Step 6: SOA Standards
Architecture Guide
SOA product roles within the organization
Service Decomposition and Design
SOA Design Patterns
SOA Registry Repository
Utility services – e.g. auditing, error handling, transaction monitoring
Non-functional requirements and strategy to meet requirements
Security standards
WSDL, XML and REST standards
Developers Guide
Environment setup
Product usage guidelines
Guidelines for reuse
Common schema usage guidelines
Naming standards
Pattern implementation
QA strategy and tools
Version management strategy
Systems Administration Guide
Build documents
Monitoring and management
Environment management – change control and migration
Directory structure and security
Services are certified to meet standards

Case Study: SOA Standards
JAD Sessions Customize Guidebook Content
Pilot Verifies Guidebooks
Pilot Introduces Methodology

Run-Time Management
The distributed, cross-boundary nature of services and access to them presents new performance, availability and security risks that need to be managed
The rapid deployment and loose coupling of services along with their virtualized application flows present new complexities in key processes
The need to effectively handle the performance and prioritization of virtualized services while efficiently utilizing available resources

SOA Infrastructure and Management
Network Components Configuration: Load balancing, Firewalls, Routers
Impact of messaging
Configurations for application servers, messaging, ESBs, BPM
Virtualization of SOA Components
Virtualized provisioning for fault-tolerance and capacity
Monitoring and Management
SOA management integrated with enterprise management
Exception management and auditing as a service
Scripted ping and alert, shut down and restart
Application servers setup, capacity planning and tuning
Platform for most Portals, ESBs, and BPM software suites
Configuration for load-balancing, fault tolerance, tuning and capacity
SOA Software Suites configuration and automation
Standardized environments with scripted build and deploy
Scripted monitoring and management
Documented administration and operations guides
Everything has to work together !

SOA Run-time Governance and ITIL
The Information Technology Infrastructure Library ( ITIL ) is a set of concepts and policies for managing information technology (IT) infrastructure, development and operations.. ITIL gives a detailed description of a number of important IT practices with comprehensive checklists, tasks and procedures that can be tailored to support SOA concepts and artifacts.
Service Support
Service Desk / Service Request Management
Incident Management
Software Asset Management
Problem Management
Configuration Management
Change and Release Management
Service Delivery
Service Level Management
Capacity Management
Availability Management
Financial Management for IT Services
Service Level Management
Capacity Management
IT Service Continuity Management
Availability Management
Financial Management for IT Services
ICT (Information and Communication Technology) Infrastructure Management
ICT Design and Planning
ICT Deployment Management
ICT Operations Management
ICT Technical Support

Step 6: Run Time
Involve operations early in a SOA program – organizational structure
Monitoring and Management are SOA standards
Properly plan for infrastructure cost, time, deliverables and dependences as part of the SOA roadmap and project plans
Put the vendor on the hook to support the sizing, architecture, configuration and performance of the infrastructure
Dedicate and train an administrator to the SOA infrastructure early in the project to work with the vendor though the installation, configuration and testing
Do a capacity test on the production environment before deployment and maintain a capacity baseline
Include deployment and the testing of deployments as part of the process and deliverables
Track your systems dependencies and include them in an operations guide as part of project transition

Step 8: Governance Technology
The registry repository supports SOA lifecycle development and run-time management
Evaluation of the registry repository should be on the SOA roadmap
The SOA lifecycle management should fit into your SDLC
The SOA run-time management should fit into your architecture standards

SOA Governance Case Study
Activities
Requirements for governance - steps, policies, metadata
Map metadata and SOA design deliverable templates requirements to registry taxonomy
Customization of the SOA design templates
Definition of Policy Manager and Policy Agents
Configuration of the registry - set up of taxonomy and service entries (for PoC)
To be tested with PoC project lifecycle
Deliverables
SOA design templates for Registry and Policy Manager
Defined and configured Registry and Policy Manager entries (Per POC needs)

Step 9: Measurements and Monitoring
COE Services
Architecture effectiveness
Time required for process change, service reuse, metadata (reuse, coverage, quality, depth)
Service Reuse
Resource demand
Deprecated interfaces
Service Level Agreements (SLA)
Software quality
Finance
ROI for the SOA/integration software
Project cost savings
Source: SOA Governance by Todd Biske (book)

Case Study – Measures / Maturity Models

Step 10: Evolve Over Time
Program Management
Technical Architecture
Business Architecture
Implementation
Quality Assurance
Operations
Support
A SOA Program Requires Activities and Deliverables in the following categories:

Case Study – SOA Program Iterations 1.1 Business Service Specification Analysis Ready for Design Activity Deliverable Milestone Ready for Testing Program Foundation Pilot (GetProvider) Ready for Deployment Business Process Model Non-Functional Requirements Design Architecture Design (Service) Detail Design Construction Test Implementation Technical Architecture Program Management Operations Future State Architecture Standards Templates Support Process Processes Communications Architecture Audit, Logging , & Exception Handling Security Standards Design Patterns Design Operations Repository SLA QA Service Testing Strategy Operations SLA Program Management SLA Prototype 1.2 1.3 Data Virtualization

A Path to SOA Maturity SOA is an incremental journey

Perficient SOA Health Check
Engagement Structure
Get SOA projects on target with actionable and prioritized recommendations
2 Perficient Consultants for 1 week
Fluid engagement pre-planned and coordinated with the client
Facilitated sessions
Document as-is architecture and make best practices recommendations
Review…
IT strategy for SOA including completed projects to date
Organization and governance
Solution architecture and design
Enterprise and reference architecture
Service monitoring, auditing, and exception handling practices
Current staffing roles to support SOA
Existing service level agreements and escalation procedures
Testing and quality assurance
Current change control process
Key deliverables
Findings Presentation
Recommendations Document
Findings, Best Practices, Recommendations, Priorities

http://www.perficient.com	457
http://perficientauth	16
http://perficientauth.perficient.com	4

10 Steps to Simplify and Improve Service-Oriented Architecture Governance

by Perficient, Inc. on Feb 29, 2012

Accessibility

Categories

Upload Details

Usage Rights

3 Embeds 477

Statistics

10 Steps to Simplify and Improve Service-Oriented Architecture Governance Presentation Transcript
