Building DASH7 Apps with OpenTag

‣ Some information about DASH7 (for noobs) ‣ What you get [with OpenTag] OpenTag: Ofﬁce Hours ‣ Where to get it JP Norair ‣ What you can do to help 12 May 2011 jpnorair@indigresso.com ‣ Project Roadmaps skype: jpnorair ‣ Answering your QuestionsCopyright © DASH7 Alliance

DASH7 Mode 2 is a 2nd Generation WSN/IoT/RFID Technology 433 MHz band 8 channels Optimized for Optimized for Low Latency Micro Power (Bursty Data) Mode 2 Universal Adaptive Data Rate Interoperability 28 - 200 kbps Very Fast Compact Stack Multicast typ. 16KBCopyright © DASH7 Alliance

About DASH7 Alliance Next Meeting: 21 June • Speciﬁcation Development in San Francisco ‣ Mode 2 (basically done) ‣ “DNA” Middleware layer ‣ NFC integration ‣ More • Market Development • ISO Stewardship • Go to dash7.org to see new membership terms, and other information.Copyright © DASH7 Alliance

What You Get [with OpenTag] OpenTag is a very purpose-built OS that uses DASH7 I/O OpenTag Component What it Does Low Level Radio Driver PHY & MAC Control System Event and Session Manager (OS-like) Network Protocols (M2NP, M2DP, M2AdvP) Routing, Raw Data, Group Synchronization Transport Protocols (M2QP) Query / Data Acquisition, Data Transfer Filesystem Read, Write, Create, Delete, Etc. Application Modules Built-in Apps (none yet) C API Library functions (Programming apps in C on the same device) Serial API(s) Client-Server (Communicating the apps via another device)Copyright © DASH7 Alliance

Where to Get it Signup, Forums, Mailing List, other support http://sourceforge.net/projects/opentag Latest Code Download (use Git) git clone git://opentag.sourceforge.net/gitroot/opentag/OpenTag_M2 OpenTag and Mode 2 Wiki (in continuous development) http://www.indigresso.com/wikiCopyright © DASH7 Alliance

Where to Get it Signup, Forums, Mailing List, other support http://sourceforge.net/projects/opentag Latest Code Download (use Git) Don’t understand Git? git clone git://opentag.sourceforge.net/gitroot/opentag/OpenTag_M2 Google is your friend (Git documentation is good) OpenTag and Mode 2 Wiki (in continuous development) http://www.indigresso.com/wikiCopyright © DASH7 Alliance

How You Can Help Core Beta Testing Development Documenting • Currently about 3 Beta testers (you know who you are: if you want to be recognized, email me) • Download the code, compile, and play with it. You will ﬁnd bugs and have questions. ‣ Send messages on developers mailing list (sourceforge). ‣ Skype me, for quick infoCopyright © DASH7 Alliance

How You Can Help Core Beta Testing Development Documenting • Currently about 3 Beta testers • Currently just me (officially) (you know who you are: if you want to be recognized, email me) • Requires a good understanding of the code and specification • Download the code, compile, ‣ My estimation: will take you and play with it. You will find 3-6 weeks to get here bugs and have questions. ‣ Send messages on developers • Two possibilities mailing list (sourceforge). ‣ OT library development ‣ Skype me, for quick info ‣ Porting to other platformsCopyright © DASH7 Alliance

How You Can Help Core Beta Testing Development Documenting • Currently about 3 Beta testers • Currently just me (officially) • Currently just me (you know who you are: if you want to be recognized, email me) • Requires a good understanding • Requires a good understanding of the code and specification of the code or specification • Download the code, compile, ‣ My estimation: will take you and play with it. You will find 3-6 weeks to get here • Many possibilities bugs and have questions. ‣ Wiki ‣ Send messages on developers • Two possibilities ‣ Formal documents mailing list (sourceforge). ‣ OT library development ‣ Academic research papers ‣ Skype me, for quick info ‣ Porting to other platformsCopyright © DASH7 Alliance

Feature Roadmap: Now it is a Race SS Pre-alpha & Alpha: Module testing and simulation (usually on PC) SS Beta 0 (current): Initial Platform Testing (CC430) without Serial API, not all features are completeCopyright © DASH7 Alliance

Feature Roadmap: Now it is a Race SS Pre-alpha & Alpha: Module testing and simulation (usually on PC) SS Beta 1: Testing platform(s) using Serial API, and completion of all features for version 1.0 SS Beta 0 (current): Initial Platform Testing (CC430) without Serial API, not all features are completeCopyright © DASH7 Alliance

Feature Roadmap: Now it is a Race SS Pre-alpha & Alpha: Module testing and simulation (usually on PC) SS Beta 1: Testing platform(s) using Serial API, and completion of all features for version 1.0 SS Beta 2: Feature complete debug and ofﬁcial compliance testing SS Beta 0 (current): Initial Platform Testing (CC430) without Serial API, not all features are completeCopyright © DASH7 Alliance

Feature Roadmap: Now it is a Race SS Pre-alpha & Alpha: Module testing and simulation (usually on PC) SS Beta 1: Testing platform(s) using Serial SS Version 1.0: API, and completion of all Bundling of ofﬁcial code features for version 1.0 packages for platforms SS Beta 2: Feature complete debug and ofﬁcial compliance testing SS Beta 0 (current): Initial Platform Testing (CC430) without Serial API, not all features are completeCopyright © DASH7 Alliance

Feature Roadmap: Now it is a Race SS Pre-alpha & Alpha: Module testing and simulation (usually on PC) SS Beta 1: Testing platform(s) using Serial SS Version 1.0: API, and completion of all Bundling of ofﬁcial code features for version 1.0 packages for platforms SS Beta 2: Feature complete debug and ofﬁcial compliance testing position SS Beta 0 (current): Initial Platform Testing (CC430) without Serial API, not all features are completeCopyright © DASH7 Alliance

Planned Platform Support (Official) Beta 0: CC430, POSIX Simulator Beta 1: Beta 0 + ADuCRF101 + SX1231 Module “Official” just means that I personally know it works. If you develop a Beta 2: working platform and send one to No additional, planned me, I will make it official “official” platformsCopyright © DASH7 Alliance

Case Studies (Comprehensive Answers to Recently Asked Questions) ‣ How does OpenTag enable location derivation? ‣ Can OpenTag do multihop and mesh? ‣ How are events processed? ‣ How many simultaneous connections are supported? ‣ How is data stored and logged? ‣ What is the deal with wireless regulations at 433 MHz?Copyright © DASH7 Alliance

DASH7 Mode 2 Has Two Features that Enable Location Derivation Feature 1: Normalized RSSI Without Normalized RSSI With Normalized RSSI Devices need to know Devices in a network are free to conﬁgurations of all other use different power outputs devices in the network Open Loop Closed LoopCopyright © DASH7 Alliance

DASH7 Mode 2 Has Two Features that Enable Location Derivation Feature 1: Normalized RSSI DASH7 Mode 2 Foreground Frame Architecture Length TX EIRP Subnet Frame Other Data Footers CRC (Bytes) (0.5 dBm) Filter Control Headers Payload (crypto) 1 Byte 1 Byte 1 Byte 1 Byte 0-52 Bytes 0-249 Bytes 0-40 Bytes 2 Bytes 0-255 -40 to 23.5 — — (optional) — (optional) — Mode 2 transmissions tell the receiver how much power was used, so the receiver can normalize the RSSI dynamicallyCopyright © DASH7 Alliance

DASH7 Mode 2 Has Two Features that Enable Location Derivation Feature 1: Normalized RSSI DASH7 Mode 2 Foreground Frame Architecture Length TX EIRP Subnet Frame Other Data Footers CRC (Bytes) (0.5 dBm) Filter Control Headers Payload (crypto) 1 Byte 1 Byte 1 Byte 1 Byte 0-52 Bytes 0-249 Bytes 0-40 Bytes 2 Bytes 0-255 -40 to 23.5 — — (optional) — (optional) — Mode 2 transmissions tell the This feature can be used to enable receiver how much power was used, location derivation and also to ﬁlter so the receiver can normalize the out transmissions that are too far RSSI dynamically away (conﬁgurable)Copyright © DASH7 Alliance

DASH7 Mode 2 Has Two Features that Enable Location Derivation (2) Buferring Location Data Location can be derived from Location List an algorithm that uses data Flags Device ID Loc. Data from multiple coordinates coord 1 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data Location Coordinate coord 2 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data coord 3 1 Byte 2/8 Bytes 3 Bytes … Data may contain normalized RSSI’s Flags Device ID Loc. Data from 1 to 3 antennas, and also angle coord N 1 Byte 2/8 Bytes 3 Bytes of incidence informationCopyright © DASH7 Alliance

DASH7 Mode 2 Has Two Features that Enable Location Derivation (2) Buferring Location Data Location can be derived from Location List an algorithm that uses data Flags Device ID Loc. Data from multiple coordinates coord 1 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data Location Coordinate coord 2 DASH7 does not specify the 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data algorithm to use, just the way data is stored. The algorithm 1 Byte 2/8 Bytes 3 Bytes Flags Device ID Loc. Data coord 3 is up to you! 1 Byte 2/8 Bytes 3 Bytes … Data may contain normalized RSSI’s Flags Device ID Loc. Data from 1 to 3 antennas, and also angle coord N 1 Byte 2/8 Bytes 3 Bytes of incidence informationCopyright © DASH7 Alliance

OpenTag Implements Normalized RSSI DASH7 Location Usage Features RSSI is implemented in the Radio Driver. During any reception, Normalized RSSI OpenTag buffers the non- Angle of Incidence normalized RSSI value on each antenna (typically 1) You can get it by calling radio_rssi() Requires special HW, not currently tested or implemented in OpenTagCopyright © DASH7 Alliance

OpenTag Implements Normalized RSSI DASH7 Location Usage Features RSSI is implemented in the Radio Driver. During any reception, Normalized RSSI OpenTag buffers the non- Angle of Incidence normalized RSSI value on each antenna (typically 1) You can get it by calling radio_rssi() OpenTag can be conﬁgured to automatically normalize and Requires special HW, not populate the location list. currently tested or implemented in OpenTagCopyright © DASH7 Alliance

OpenTag Implements Normalized RSSI DASH7 Location Usage Features RSSI is implemented in the Radio Driver. During any reception, Normalized RSSI OpenTag buffers the non- Angle of Incidence normalized RSSI value on each antenna (typically 1) You can get it by calling radio_rssi() OpenTag can be conﬁgured to automatically normalize and Requires special HW, not populate the location list. currently tested or implemented in OpenTag Your algorithm needs to read this data and do the restCopyright © DASH7 Alliance

One Example of Using RSSI for Location Using large numbers of low-cost, battery-powered ﬁxed position nodes is cheap and precise Fixed Position Node Node with Location Algorithm (knows positions of ﬁxed nodes) (packet data) Mobile NodeCopyright © DASH7 Alliance

One Example of Using RSSI for Location Using large numbers of low-cost, battery-powered ﬁxed position nodes is cheap and precise (packet data) (location list) (derived location of mobile node)Copyright © DASH7 Alliance

DASH7 Mode 2 & OpenTag Support Limited Multihopping DASH7‘s advanced query functionality and long range deprecate needs for complex hopping One Hop Two Hops 3 to 15 Hops – Anycast Request – Anycast Request Routing Support All – Unicast Response – Unicast Response Built-in, available to Requires 3rd Party Integration Automated application layer routing table algorithmCopyright © DASH7 Alliance

DASH7 Mode 2 & OpenTag Support Limited Multihopping DASH7‘s advanced query functionality and long range deprecate needs for complex hopping One Hop Two Hops 3 to 15 Hops – Anycast Request – Anycast Request Routing Support All – Unicast Response – Unicast Response Built-in, available to Requires 3rd Party Integration Automated application layer routing table algorithm Enables simple repeaters If you want to build a mesh network, you would need to integrate a routing algorithm. RPL is one example.Copyright © DASH7 Alliance

DASH7 Mode 2 Network Routing Template Routable DASH7 Mode 2 frame, as seen by network protocol Data Link Layer Mode 2 Network Protocol M2DLL (M2DLL) (M2NP) Length Data Link M2NLS Routing M2NP M2NLS DLLS (Bytes) Headers Header Header Payload Auth. Data Auth. Data 1 Byte 7-38 Bytes 1-25 Bytes 1-18 Bytes 0-245 Bytes 0-20 Bytes 0-20 Bytes (optional) (optional) (optional) (optional) For Data Link Layer Security For Network Layer SecurityCopyright © DASH7 Alliance

DASH7 Mode 2 Network Routing Template Routable DASH7 Mode 2 frame, as seen by network protocol Data Link Layer Mode 2 Network Protocol M2DLL (M2DLL) (M2NP) Length Data Link M2NLS Routing M2NP M2NLS DLLS (Bytes) Headers Header Header Payload Auth. Data Auth. Data 1 Byte 7-38 Bytes 1-25 Bytes 1-18 Bytes 0-245 Bytes 0-20 Bytes 0-20 Bytes (optional) (optional) (optional) (optional) For Data Link Layer Hop Hop Origin Destination Control Extension Device ID Device ID Security 1 Byte 1 Byte 2/8 Bytes 2/8 Bytes For Network Layer (optional) (optional) (optional) Security The Built-in two hop leverages the Origin and Destination IDs, which are additional to the Data Link Layer addressing (Source and Target)Copyright © DASH7 Alliance

Routing Functions in OpenTag Network Module • Function network_route_ff() is automatically called by OpenTag when parsing an incoming frame ‣ returns 0 if the frame is routed to this device So, to implement sophisticated multihop or ‣ returns positive number (corresponding to mesh routing, you need to integrate your routing table index) if frame is routed to a routing table and routing algorithm into this known device function, network_route_ff() ‣ returns -1 if frame should be discarded • Function m2np_header() writes a properly routed M2NP header to a new frame. ‣ routing algorithm needs to store the routing information in the m2np data structure, so m2np_header() can use it. ‣ m2np data structure is exposed, so you can put routing algorithm anywhere you want.Copyright © DASH7 Alliance

Routing Functions in OpenTag Network Module • Function network_route_ff() is automatically called by OpenTag when parsing an incoming frame ‣ returns 0 if the frame is routed to this device So, to implement sophisticated multihop or ‣ returns positive number (corresponding to mesh routing, you need to integrate your routing table index) if frame is routed to a routing table and routing algorithm into this known device function, network_route_ff() ‣ returns -1 if frame should be discarded • Function m2np_header() writes a properly routed M2NP header to a new frame. Remember, normalized RSSI information is already part of ‣ routing algorithm needs to store the routing DASH7, so routing algorithms information in the m2np data structure, so that use link budget data are m2np_header() can use it. well suited. ‣ m2np data structure is exposed, so you can put routing algorithm anywhere you want.Copyright © DASH7 Alliance

What is an Event? (For those among us who are not software nerds) An event is anything that causes a program to stop doing what it is doing, and start doing something else. Some Examples Pushing a Button An API Call Getting a Sensor A Timer expiring ReadingCopyright © DASH7 Alliance

Events in OpenTag • OpenTag includes an event and task manager that runs parallel to the user’s application • When an event occurs, OpenTag takes control of the system in order to run the task associated with the event. It gives back control when the Task is done (or when it’s idle) Event Associated Tasks Notes (Descending Priority) Internal RF interrupt Low Level Radio Control Transparent to Application API Call Generate new request Application dependent Sensor Detect Generate new request Application dependent Automated tasks: - Listen for data [Mostly] Transparent to System Timer Expires - Prepare response Application - Send BeaconCopyright © DASH7 Alliance

Events in OpenTag • OpenTag includes an event and task manager that runs parallel to the user’s application • When an event occurs, OpenTag takes control of the system in order to run the task associated with the event. It gives back control when the Task is done (or when it’s idle) Event Associated Tasks Notes (Descending Priority) For SoC’s/SiP’s, Internal RF interrupt Low Level Radio Control Transparent to Application totally transparent API Call Generate new request Application dependent Sensor Detect Generate new request Application dependent Automated tasks: - Listen for data [Mostly] Transparent to Needs a dedicated System Timer Expires timer resource. - Prepare response Application - Send BeaconCopyright © DASH7 Alliance

What Actually Happens when an Event Occurs? No Task Automated Tasks Pending (Descending Priority) Event Event Mgr checks Radio RX/TX Occurs what task is pending Activate Session Run Task Initialize Channel Scan Send Beacon • Any event must call sys_event_manager() in the system module (system.c) in order to bind a task to the event that just occurred. ‣ System Timer Events are managed internally by OpenTag, so when the system timer expires, the appropriate task is automatically processed. ‣ The system timer is always running. So events can be queued up during OpenTag tasks (expired events are discarded).Copyright © DASH7 Alliance

How Fast is the Event Timing Resolution? • The OpenTag system timer runs at a resolution The application layer, thus, of “1 tick,” where 1 tick = 1/1024 sec needs to have worst case ‣ Roughly 1 ms latency of 1 tick. ‣ Allows usage of 32768 Hz crystal as source • There is another timer unit called a “short tick” equal to 1/32768 sec (~30.5 µs) ‣ Not used at all in OpenTag library (OTlib) ‣ Used only for internal radio processes, although certain radios have internal timers and don’t need to use an MCU timer at all. ‣ All DASH7 processes are timed in ticks. So Since this is internal, you could use short ticks are only necessary if you are an another clock source and achieve a optimizer and want to establish internal timer higher resolution, but you would need to offsets that are shorter than 1 tick. write some new driver code.Copyright © DASH7 Alliance

This Answer Depends on What You Mean by “Connection” Connection Model 1 • Answer: 1 (Isochronous, streaming data) ‣ This is like cable-replacement, which is not something DASH7 is designed to do well. ‣ Requires either complex time-slotting (like GSM, Master Bluetooth) or even more complex MIMO (802.11n, CDMA, OFDM) in order to support multiple isochronous connections via wireless. Slave Slave SlaveCopyright © DASH7 Alliance

This Answer Depends on What You Mean by “Connection” Connection Model 1 • Answer: 1 (Isochronous, streaming data) ‣ This is like cable-replacement, which is not something DASH7 is designed to do well. ‣ Requires either complex time-slotting (like GSM, Master Bluetooth) or even more complex MIMO (802.11n, CDMA, OFDM) in order to support multiple isochronous connections via wireless. Slave Slave Slave In Hardware language, this is usually referred to as a “bus”Copyright © DASH7 Alliance

This Answer Depends on What You Mean by “Connection” Connection Model 2 • Answer: a lot (potentially 1000’s) (Bursty, queued data) ‣ This is broadcast-query-respond, which DASH7 is designed to do especially well. ‣ Basic queries of thousands of devices can be Node accomplished without much overhead. Collector ‣ Follow-up dialogs with queried devices is limited Node by available memory and idle-time conﬁguration Node Node NodeCopyright © DASH7 Alliance

Answer: The Built in Filesystem GFB ISFB (General File Block) (Indexed Short File Block) Functions Read, Write, Create, Delete Security POSIX-like, with optional crypto Max File Size 65 KB 255 Bytes Max Files 256 256 Files used by DASH7 0 33 reserved Searchable No Yes Executable Yes Yes Byte-centric, Big-Endian + some ﬁles File Structure Binary (App. Dependent) have standardized structureCopyright © DASH7 Alliance

Using the OpenTag Filesystem (called Veelite) • In C, it is a lot like using the POSIX C library ‣ FILE* — vlFILE* ‣ fopen() — vl_open(), vl_new() ‣ fclose() — vl_close() ‣ fgetc(), fputc() — vl_read(), vl_write() • You can also access files by DASH7 itself, using an Application Subprotocol (included in OpenTag), as long as you have appropriate user access to the files you want. • The Application Subprotocol for file access is also used over a wire, for the Serial-API, if you Client are connecting an OpenTag module to another HW piece of HW.Copyright © DASH7 Alliance

433 MHz is Usually Available License-free (or cheaply) Plus: no regulations in Antarctica! FCC 15.231 & 240North America uses the FCC part 15 license-free spec Korea & Japan have their own regulations for license-free 433 MHz use Limited ERC 70-03 Some countries use basically the ERC 70-03 spec, but with certain limitations (e.g. small fees) required to use the spectrum. ERC 70-03 (or similar) Most countries in the world use the EU/ISM 433 MHz spec, or something similar.Copyright © DASH7 Alliance

433 MHz Regulatory Policy Summary Regulation Complexity Usage Notes Simpliﬁed Speciﬁcation Spectrum: 420 - 450 MHz (20 MHz) Max EIRP: highly variable, but effectively -2.4 dBm FCC Part 15.231 High General Use Max Duty Cycle: highly variable, but effectively 50% Max TX time: highly variable, but effectively 100 ms Beacons: requires very low duty cycle, or alternatively ! -14.4 dBm Similar to 15.231 but with simpler rules, no allowance for beacons, FCC Part 15.240 Moderate For Containers only and longer TX time permitted. In most cases it does not really improve performance of DASH7 Mode 2 over 15.231. Spectrum: 433.05 - 434.79 MHz (1.74 MHz) ETSI ERC 70-03 Low General Use Class 1: 0 dBm @ 100% duty cycle, max TX 36 sec. Class 2: 10 dBm @ 10% duty cycle, max TX 36 sec, listen before talk Spectrum: 433.67 - 434.17 MHz (500 KHz) Korean ETRI Low General Use Max EIRP: 0 dBm Max Duty Cycle: 100% Max TX time: 100 ms Japanese RR Low Logistics only (Note: for guidance only, I am not an expert on ETRI & RR)Copyright © DASH7 Alliance
