Indexing Thousands of  Writes per Second      with Redis          Paul Dix      paul@pauldix.net          @pauldix      ht...
I’m Paul Dix
I wrote this   book
Benchmark Solutions*                                         who I work for* we’re hiring, duh! email: paul@benchmarksolut...
had a spiel about thesuit..Before we get to the       talk...
That bastard stole my      thunder!
You don’t think of suit                   wearing badassSeñor Software Engineer
I work
Finance
the janitors, cleaning          staff, and the 18 year          old intern get this title          too...Vice President
How could I wear               anything but a suit?Finance + VP + Suit =     douchebag
Distractionhttp://www.flickr.com/photos/33562486@N07/4288275204/
Bethttp://www.flickr.com/photos/11448492@N07/2825781502/
Barhttp://www.flickr.com/photos/11448492@N07/2825781502/
@flavorjones coauthor        of Nokogiricredit: @ebiltwin
JSON vs. XML
XML Sucks Hard
JSON is teh awesome
XML parsing S-L-O-W
10x slower
Mike called BS
A bet!
and I was like: “sure, for        a beer”
and Mike was all like:“ok, but that’s lame”
“let’s make itinteresting. Loser wears   my daughter’s fairy wings during your talk”
Sure, that’ll be funny   and original...
Dr. Nic in fairy wings
That bastard stole my      thunder!
Nic may have done it as       part of the talk, but he       didn’t lose a bet...       put wings on in red-faced       sh...
credit: @jonathanpberger
Nokogiri ~ 6.8x slower
REXML(ActiveRecord.from_xml)      ~ 400x slower
Lesson:Always use JSON
Lesson:Don’t make bar bets
However, the bet saidnothing about my slides
Aaron Patterson father of nokogiri 3 slides with @tenderlove’s picture? wtf?!!
Called Mike:“Nokogiri’s mother”
Fairy Godmother?
Lesson:     Learn Photoshop(this shit is embarrassing)
Anyway, the point of    the suit...
take me seriously,dammit!
On to the actual talk...
it’s about...
Redis
Sustained write load of   ~ 5k per second
Redis + other datastores = bad assery
@flavorjones   and maybe about Mike   being some kind of virgin   mothercredit: @ebiltwin
Lesson:   Be specific about the      terms of a bet(because at least someone   can use Photoshop)
Who’s used Redis?
NoSQL
Key/Value Store
Created bySalvatore Sanfilippo     @antirez
Data structure store
Basics
Keysrequire redisredis = Redis.newredis.set("mike", "grants wishes") # => OKredis.get("mike")   # => "grants wishes"
Countersredis.incr("fairy_references") # => 1redis.decr("dignity") # => -1redis.incrby("fairy_references", 23) # => 24redi...
Expirationredis.expire("mike", 120)redis.expireat("mike",  1.day.from_now.midnight)
Hashesredis.hset("paul", "has_wings", true)redis.hget("paul", "has_wings") # => "true"redis.hmset("paul",  :location, "Bal...
Listsredis.lpush("events", "first") # => 1redis.lpush("events", "second") # => 2redis.lrange("events", 0, -1) #  => ["seco...
Setsredis.sadd("user_ids", 1)    #   =>   trueredis.scard("user_ids")      #   =>   1redis.smembers("user_ids")   #   =>  ...
Sets Continued# know_paul ["1", "3", "4"]# know_mike ["3", "5"]redis.sinter("know_paul", "know_mike")   # =>["3"]redis.sdi...
Sorted Setsredis.zadd("wish_counts", 2, "paul") # =>  trueredis.zcard("wish_counts") # => 1redis.zismember("paul") # => tr...
Sorted Sets Continuedredis.zadd("wish_counts", 12, "rubyland")redis.zrange("wish_counts", 0, -1) # =>  ["paul", "rubyland"...
Sorted Sets Continuedredis.zrevrangebyscore("wish_counts",  "+inf", "-inf") # =>  ["rubyland", "paul"]redis.zrevrangebysco...
Lesson:Keeping examples consistent with a stupid story is hard
pubsub, transactions,more commadnds.not covered here, leave mealone                 There’s more
Crazy Fast
Faster than a greased       cheetah
or a Delorean with 1.21       gigawatts
OMG Scaling Sprinkles!
No Wishes Grantedf-you, f-ball!
Lesson:Getting someone to pose          is easier (also, learn Photoshop)
Still monolithicnot horizontallyscalable, oh noes!
Can shard in client like          memcachedI know haters, you cando this
Still not highly available
Still susceptible to      partitions
However, it’s wicked      cool
Why Index with Redis?
Don’tyou probably don’t needit                          http://www.flickr.com/photos/34353483@N00/205467442/
and you’re all like,“Paul, ...”      But I have to SCALE!
No you don’t
Trust me, I’m wearing a          suit
that means I haveauthority and...                    I know shit
and still you cry:                     But no, really...
Sad SQL is Sadthousands ofwrites persecond? No megusto!
ok, fine.
My Use Cases
40k unique things
Updating every 10    seconds
Plus other updates...
Average write load of  3k-5k writes per      second
LVCredis.hset("bonds|1", "bid_price",   96.01)redis.hset("bonds|1", "ask_price",   97.53)redis.hset("bonds|2", "bid_price"...
Index on the fly
SORTredis.sort("bond_ids",  :by => "bonds|*->bid_price") # => ["2", "1"]redis.sort("bond_ids",  :by => "bonds|*->bid_price...
SORT Continuedredis.sort("bond_ids",  :by => "bonds|*->bid_price",  :limit => [0, 1]) # => ["2"]redis.sort("bond_ids",  :b...
Getting Recordsids = redis_sort_results.map {|id| id.to_i}bonds = Bond.find(ids)           note that prices (high         ...
Getting From Redisredis.hset("bonds|2", "values", data.to_json)raw_json = redis.sort("bond_ids",    However, then you have...
Pre-Indexing
Rolling Index
Last n Events
Activity Log
News Feed
Use a List                                       O(1) constant time                                       complexity to ad...
Indexing Events Since       Time T
Using a Listredis.lpush("bond_trades|1|2011-05-19-10",  trade_id)redis.lrange("bond_trades|1|2011-05-19-10",  0, -1)result...
Rolling the Index# when something tradesredis.sadd("bonds_traded|2011-05-19-10",  bond_id)# cron task to remove old datatr...
Using a Sorted Set# Time based Rolling Index using sorted setredis.zadd("bond_trades|1",      O(log(n)) writes  Time.now.t...
Rolling the Index# cron task to roll the indexbond_ids = redis.smembers("bond_ids")remove_since_time = 24.hours.ago.to_ire...
Or roll on read or           writeredis.zadd("bond_trades|1",  Time.now.to_i, trade_id)redis.zremrangebyscore("bond_trades...
Indexing N Valuesredis.zadd("highest_follower_counts", 2300, 20)redis.zadd("lowest_follower_counts", 2300, 20)# rolling th...
rolling requires moreroundtrips           2 roundtrips        (only with complex             pipelining)
Roll indexes with only       one trip
Tweet to @antirez that  you want scripting
Keeping it Consistent
create/update/destroy
database transactions          can’t help you here, you’ll          have to put them into          your application logicN...
Disaster Recovery
Two failure scenarios
Web app dies
Redis server dies
Could result in index   inconsistency
Simple recovery script
Write Index Timesredis.set("last_bond_trade_indexed",  trade.created_at.to_i)
Restore Each Indextime_int = redis.get("last_bond_trade_indexed").to_iindex_time = Time.at(time_int)trades = Trade.where( ...
Our scale
Single Process
Sets don’t work withintersection, union, ordiff.SORT won’t work unlessall those keys fall on thesame server            Eas...
Works like a champ
Final Thoughts
Use Only if you have        to!
Index the minimum tokeep memory footprint         down use rolling indexes, don’t keep more shit in memory than you need. ...
Plan for disaster andconsistency checking
Finally...
Look at my circle, bitches!
Lesson:Never trust a guy in a suitnot pull a fast one on you
Thanks!    Paul Dixpaul@pauldix.net    @pauldixhttp://pauldix.net
