Taming theMobile BeastPatrick Meenan   Matt Welsh@patmeenan       @mdwelsh                                http://www.flick...
Mobile is huge!2.25B Global Internet Users    1.1B Mobile Users                              Source: UN/ITU internetworlds...
For many, a mobile device is the                                                        only way to access the Internet   ...
... and growing with respect to desktop
Desktop Web Performance Optimization
Mobile Web Performance Optimization
What well cover today: Getting a handle on mobile web performance How to collect measurements on mobile devices Deep dive ...
Measurement Tools
Mobitest - www.blaze.io/mobile/
WebPageTest - www.webpagetest.org Web Page Test nowsupports Android and        iOS!
Waterfall Basics
Waterfall Components
Waterfalls as seen by HARViewer              DNS TCP       Waiting       Receiving              Lookup Connect for respons...
Studying Mobile Waterfalls
Visualizing a mobile website load (brown.edu)                                                75 seconds!
brown.edus mobile home page124 KB, 1800x800background image that is completely          obscured
The web was not designed for mobile Huge disparity between modern web design and mobile devices...  ●   Increasingly rich ...
Here Be Dragons● Making a mobile connection: Radio Resource Control● Browser connection limits● HTTP Pipelining● Caching: ...
Making a Mobile Connection
Typical Mobile Network Performance   Country         Average RTT   Average Downlink   Average Uplink Throughput           ...
Typical Mobile Network Performance   Country        Average RTT   Average Downlink   Average Uplink Throughput            ...
Bandwidth Impact         3G                       LTE                   20 Top sites measured in October, 2011
Latency Impact                                     3G                  LTE          DSL/                        Dial   20 ...
Making a Radio ConnectionBefore a cellular device can transmit or receive data, it has toestablish a radio channel with th...
Probing the Radio State MachineTry this sometime:Build a webpage that loads a small (1KB) image at increasingintervals. Wa...
Probing the Radio State MachineTry this sometime:Build a webpage that loads a small (1KB) image at increasingintervals. Wa...
The same thing on T-Mobile:                              1 sec delay                                  2 sec delay         ...
The same thing on T-Mobile:                              Between 2 and 3 sec,                              huge increase i...
Example 3G Radio Resource Control State Machine  No radio  connection                       Idle for 12 sec               ...
Browser Connection Limits
Browser Connection LimitsThe number of parallel connections varies tremendously acrossmobile browsers.brown.edu on Android...
Browser Connection LimitsThe number of parallel connections varies tremendously acrossmobile browsers.brown.edu on Android...
Browser Connection LimitsThe number of parallel connections varies tremendously acrossmobile browsers.brown.edu on iOS 5: ...
Browser Connection LimitsThe number of parallel connections varies tremendously acrossmobile browsers.brown.edu on Chrome ...
Browser Connection Limits - Summary         Browser                  Connections Per Domain   Total Connections         An...
Are more connections always better?Parallel TCP connections are typically used for two purposes:  1) Saturate the network ...
HTTP Pipelining
HTTP Pipelining  Been in the spec since HTTP/1.1, but largely ignored by desktop browser vendors  Originally thought it wo...
Carrier Network Proxies
Carrier network proxiesMost large carriers do transparent web proxyingSimple page with a 1MB JavaScript file, loaded over ...
Carrier network proxiesMost large carriers do transparent web proxyingSimple page with a 1MB JavaScript file, loaded over ...
JavaScript Execution Time
JavaScript Execution TimeJavaScript is typically a lot slower on mobile devices.       SunSpider benchmark results:Dual Co...
Browser Caching Behavior
Not all caches are created equalMobile browsers have small caches:Android 2.3:        8 MBiOS 5:              100 MB, but ...
Browsers != Embedded HTTP LibrariesCommon embedded HTTP libraries often have broken cachebehavior!java.net.URLConnectionja...
SummaryMobile networks have high round-trip-times: hundreds of ms.Mobile connections can take several seconds to get estab...
Roadmap Getting a handle on mobile web performance How to collect measurements on mobile devices Deep dive into mobile web...
Remote DebuggingChrome on Android
Remote Debugging Chrome on AndroidChrome on Android has full support for Chrome Developer Tools                           ...
Getting Started1) Fire up Chrome on your device2) Settings > Developer Tools > Enable USB Web debugging
Getting Started3) On desktop, run:   adb forward tcp:9222 localabstract:chrome_devtools_remote4) On desktop, visit:   http...
Getting Started5) Pick the tab you want to debug:
Getting Started6) Youll initially see a blank window:
Getting Started7) Hit reload on the phone to get a timeline:
So what can you do with this?Anything you can do with Chrome Dev Tools on desktop! ●   Network events timeline ●   Inspect...
Network events timelineEach resource is   one line                                                        Timeline        ...
Exploring a single request / response                                         Request Headers                             ...
Exploring the DOM Mouse over a DOM element                      Element is                    highlighted on              ...
CPU and memory profiling
CPU and memory profiling                           CPU profile of each                              JS function
CPU and memory profiling                           Timeline of page                            memory usage               ...
SummaryChrome for Android gives you tremendous visibility and controlthrough its remote debugging interface.Inspect and co...
Mobile Bookmarklets
Meta Bookmarklet               http://stevesouders.com/mobileperf/mobileperfbkm.php
Firebug Lite               http://getfirebug.com/firebuglite#Stable
YSlow Mobile               http://yslow.org/mobile/
Page Resources                 http://stevesouders.com/mobileperf/pageresources.php
Jdrop        http://jdrop.org
Page Resources - Jdrop
DOMMonster             http://mir.aculo.us/dom-monster/
Docsource            http://stevesouders.com/mobileperf/docsource.php
cssess         https://github.com/driverdan/cssess
Snoopy         http://snoopy.allmarkedup.com/
SpriteMe           http://spriteme.org/
Navigation timing bookmarklets       https://github.com/Yottaa/NavigationTimingBookmarklet       http://code.google.com/p/...
webkit Resource Timing                    Watch this space:      https://bugs.webkit.org/show_bug.cgi?id=61138
Other Tools
PageSpeed Insights               https://developers.google.com/speed/pagespeed/insights
PCAP Web Performance Analyzer                                     Web            tcpdump/packet capture                   ...
icy      http://calendar.perfplanet.com/2011/i-see-http/
iWebInspector                http://www.iwebinspector.com/
winre        http://people.apache.org/~pmuellr/weinre/docs/latest/
User Agent Switcher Extensions            https://chrome.google.com/webstore/detail/djflhoibgkdhkhhcedjiklpkjnoahfmg
WebPagetest User-Agent SpoofingsetUserAgent ...setViewportSize <width> <height>navigate www.cnn.com                      h...
Monitoring
Measuring mobile web behavior is hard! Most mobile browsers have no instrumentation interface. But, things are improving: ...
Know WHAT and HOW you are measuringKnow thy Browser● Real Device  ○ Native Browser  ○ App with embedded UIWebView● Simulat...
Latency Impact
Real-User Measurement                        dvcs.w3.org/hg/webperf/raw-file/tip/specs/NavigationTiming/Overview.html
Google Analytics
TakeawaysDecide what and how you want to measureMobile performance deeply impacted by network and browser architectureMobi...
Google Booth - TalksTuesday, June 26 - Morning Break       10:15 – 10:30 : Site Speed Reports in Google Analytics: Measuri...
Google Booth - Office HoursTuesday, June 25 - Morning Break    10:30 - 10:30 : Q&A: Mobile Web Measurement with Matt and P...
Thank You!PatMeenan@gmail.com   @PatMeenanmdw@mdw.la            @mdwelsh
