Masterizing php data structure 102

  1. 1. Masterizing PHP Data Structure 102 Patrick AllaertPHPBenelux Conference Antwerp 2012
  2. 2. About me● Patrick Allaert● Founder of Libereco● Playing with PHP/Linux for +10 years● eZ Publish core developer● Author of the APM PHP extension● @patrick_allaert● patrickallaert@php.net● http://github.com/patrickallaert/● http://patrickallaert.blogspot.com/
  3. 3. Masterizing = Mastering + Rising
  4. 4. PHP native datatypes● NULL (IS_NULL)● Booleans (IS_BOOL)● Integers (IS_LONG)● Floating point numbers (IS_DOUBLE)● Strings (IS_STRING)● Arrays (IS_ARRAY, IS_CONSTANT_ARRAY)● Objects (IS_OBJECT)● Resources (IS_RESOURCE)● Callable (IS_CALLABLE)
  5. 5. Wikipedia datatypes● 2-3-4 tree ● Bit field ● Directed acyclic ● Hashed array tree Map/Associative ● ● Rapidly-exploring ● Suffix tree graph array/Dictionary random tree Symbol table● 2-3 heap ● Bitmap Hash list ● ● Directed graph Matrix Record (also called Syntax tree 2-3 tree BK-tree ● ● ● Hash table ●● ● Disjoint-set tuple or struct) Tagged union (variant ● Metric tree AA tree ● Bloom filter record, discriminated ● ●● Distributed hash Hash tree Red-black tree ● ● Minimax tree ● union, disjoint union) Abstract syntax tree ● ●● ● Boolean table Hash trie Min/max kd-tree ● Rope Tango tree (a,b)-tree ● ● ●● Bounding interval Double Routing table Ternary heap ● ● Heap M-tree ● Adaptive k-d tree ● hierarchy ● ●● Doubly connected R-tree Ternary search tree ● Heightmap Multigraph ● ●● Adjacency list B sharp tree edge list ● ● R* tree Threaded binary tree ● Multimap ● ●● Adjacency matrix BSP tree ● Doubly linked list ● Hilbert R-tree ● R+ tree Top tree Multiset ● ● ● AF-heap Dynamic array Treap Hypergraph ● B-tree Scapegoat tree ● Octree● ● ● ● ● Tree Alternating decision Enfilade ● Scene graph Iliffe vector ●● tree ● B*-tree ● ● Pagoda ● Trees Enumerated type ● Segment tree ● B+ tree ● Image Pairing heap ● Trie And-inverter graph ● Expectiminimax tree ● ● ●● Self-balancing T-tree Implicit kd-tree Parallel array ● And–or tree ● B-trie Exponential tree ● ● ● binary search tree ●● UB-tree Parse tree ●● Array ● Bx-tree Fenwick tree ● Interval tree ● ● Self-organizing list ● Union Plain old data ● ● AVL tree Cartesian tree Fibonacci heap Int ● Set Unrolled linked list● ● ● ● structure ● ●● Beap ● Char ● Finger tree ● Judy array Prefix hash tree ● Skew heap ● Van Emde Boas tree ● Skip list Variable-length array● Bidirectional map ● Circular buffer ● Float Kdb tree Priority queue ● ● ● ● VList Bin Compressed suffix FM-index Soft heap ●● ● ● Kd-tree ● Propositional ● VP-tree ● Binary decision array Fusion tree directed acyclic Sorted array ●● ● Koorde ● Weight-balanced tree diagram Gap buffer graph Spaghetti stack ● ● Container ● ● ● Winged edge Binary heap Generalised suffix Leftist heap Quad-edge Sparse array ●● ● Control table ● ● ● ● X-fast trie Quadtree ● Binary search tree tree Lightmap Sparse matrix Xor linked list Cover tree ●● ● ● ● Binary tree ● Graph Queap Splay tree X-tree● Ctrie ● ● Linear octree ● ● ● Binomial heap ● Graph-structured Queue SPQR-tree Y-fast trie● Dancing tree ● stack Link/cut tree ● ● ● ● Radix tree Zero suppressed Stack ● Bit array ● ●● D-ary heap Hash ● Linked list Randomized binary ● decision diagram Bitboard ● ● ● String Zipper Hash array mapped Lookup table search tree● ● Decision tree ● ● Suffix array ● ● trie Z-order Deque ● Range tree ● ● ●
  6. 6. Game:Can you recognize some structures?
  7. 7. Array: PHPs untruthfulnessPHP “Arrays” are not true Arrays!
  8. 8. Array: PHPs untruthfulnessPHP “Arrays” are not true Arrays!An array is typically implemented like this: Data Data Data Data Data Data
  9. 9. Array: PHPs untruthfulnessPHP “Arrays” can be iterated both directions (reset(),next(), prev(), end()), exclusively with O(1) operations.
  10. 10. Array: PHPs untruthfulnessPHP “Arrays” can be iterated both directions (reset(),next(), prev(), end()), exclusively with O(1) operations.Implementation based on a Doubly Linked List (DLL): Head Tail Data Data Data Data DataEnables List, Deque, Queue and Stackimplementations
  11. 11. Array: PHPs untruthfulnessPHP “Arrays” elements are always accessible using akey (index).
  12. 12. Array: PHPs untruthfulnessPHP “Arrays” elements are always accessible using akey (index).Implementation based on a Hash Table: Head Bucket pointers array Tail 0 1 2 3 4 5 ... nTableSize -1 Bucket * Bucket * Bucket * Bucket * Bucket * Bucket * Bucket * Bucket Bucket Bucket Bucket Bucket Data Data Data Data Data
  13. 13. Array: PHPs untruthfulnesshttp://php.net/manual/en/language.types.array.php: “This type is optimized for several different uses; it can be treated as an array, list (vector), hash table (an implementation of a map), dictionary, collection, stack, queue, and probably more.”
  14. 14. Optimized for anything ≈ Optimized for nothing!
  15. 15. Array: PHPs untruthfulness● In C: 100 000 integers (using long on 64bits => 8 bytes) can be stored in 0.76 Mb.● In PHP: it will take ≅ 13.97 Mb!● A PHP variable (containing an integer) takes 48 bytes.● The overhead of buckets for every “array” entries is about 96 bytes.● More details: http://nikic.github.com/2011/12/12/How-big-are-PHP-arrays-really-Hint-BIG.html
  16. 16. Data Structure
  17. 17. Structs (or records, tuples,...)● A struct is a value containing other values which are typically accessed using a name.● Example: Person => firstName / lastName ComplexNumber => realPart / imaginaryPart
  18. 18. Structs – Using array$person = array( "firstName" => "Patrick", "lastName" => "Allaert");
  19. 19. Structs – Using a class$person = new PersonStruct( "Patrick", "Allaert");
  20. 20. Structs – Using a class (Implementation)class PersonStruct{ public $firstName; public $lastName; public function __construct($firstName, $lastName) { $this->firstName = $firstName; $this->lastName = $lastName; }}
  21. 21. Structs – Using a class (Implementation)class PersonStruct{ public $firstName; public $lastName; public function __construct($firstName, $lastName) { $this->firstName = $firstName; $this->lastName = $lastName; } public function __set($key, $value) { // a. Do nothing // b. trigger_error() // c. Throws an exception }}
  22. 22. Structs – Pros and Cons Array Class+ Uses less memory (PHP < 5.4) - Uses more memory (PHP < 5.4)- Uses more memory (PHP = 5.4) + Uses less memory (PHP = 5.4)- No type hinting + Type hinting possible- Flexible structure + Rigid structure+|- Less OO +|- More OO+ Slightly faster - Slightly slower
  23. 23. “true” Arrays● An array is a fixed size collection where elements are each identified by a numeric index.
  24. 24. “true” Arrays● An array is a fixed size collection where elements are each identified by a numeric index. 0 1 2 3 4 5 Data Data Data Data Data Data
  25. 25. “true” Arrays – Using SplFixedArray$array = new SplFixedArray(3);$array[0] = 1; // or $array->offsetSet()$array[1] = 2; // or $array->offsetSet()$array[2] = 3; // or $array->offsetSet()$array[0]; // gives 1$array[1]; // gives 2$array[2]; // gives 3
  26. 26. “true” Arrays – Pros and Cons Array SplFixedArray- Uses more memory + Uses less memory+|- Less OO +|- More OO+ Slightly faster - Slightly slower
  27. 27. Queues● A queue is an ordered collection respecting First In, First Out (FIFO) order.● Elements are inserted at one end and removed at the other.
  28. 28. Queues● A queue is an ordered collection respecting First In, First Out (FIFO) order.● Elements are inserted at one end and removed at the other. Data Dequeue Data Data Data Data Data Data Enqueue Data
  29. 29. Queues – Using array$queue = array();$queue[] = 1; // or array_push()$queue[] = 2; // or array_push()$queue[] = 3; // or array_push()array_shift($queue); // gives 1array_shift($queue); // gives 2array_shift($queue); // gives 3
  30. 30. Queues – Using SplQueue$queue = new SplQueue();$queue[] = 1; // or $queue->enqueue()$queue[] = 2; // or $queue->enqueue()$queue[] = 3; // or $queue->enqueue()$queue->dequeue(); // gives 1$queue->dequeue(); // gives 2$queue->dequeue(); // gives 3
  31. 31. Queues – Pros and Cons Array SplQueue- Uses more memory + Uses less memory(overhead / entry: 96 bytes) (overhead / entry: 48 bytes)- No type hinting + Type hinting possible+|- Less OO +|- More OO
  32. 32. Stacks● A stack is an ordered collection respecting Last In, First Out (LIFO) order.● Elements are inserted and removed on the same end.
  33. 33. Stacks● A stack is an ordered collection respecting Last In, First Out (LIFO) order.● Elements are inserted and removed on the same end. Data Push Data Data Data Data Data Data Pop Data
  34. 34. Stacks – Using array$stack = array();$stack[] = 1; // or array_push()$stack[] = 2; // or array_push()$stack[] = 3; // or array_push()array_pop($stack); // gives 3array_pop($stack); // gives 2array_pop($stack); // gives 1
  35. 35. Stacks – Using SplStack$stack = new SplStack();$stack[] = 1; // or $stack->push()$stack[] = 2; // or $stack->push()$stack[] = 3; // or $stack->push()$stack->pop(); // gives 3$stack->pop(); // gives 2$stack->pop(); // gives 1
  36. 36. Stacks – Pros and Cons Array Class- Uses more memory + Uses less memory(overhead / entry: 96 bytes) (overhead / entry: 48 bytes)- No type hinting + Type hinting possible+|- Less OO +|- More OO
  37. 37. Sets● A set is a collection with no particular ordering especially suited for testing the membership of a value against a collection or to perform union/intersection/complement operations between them.
  38. 38. Sets● A set is a collection with no particular ordering especially suited for testing the membership of a value against a collection or to perform union/intersection/complement operations between them. Data Data Data Data Data
  39. 39. Sets – Using array$set = array();$set[] = 1;$set[] = 2;$set[] = 3;in_array(2, $set); // truein_array(5, $set); // falsearray_merge($set1, $set2); // unionarray_intersect($set1, $set2); // intersectionarray_diff($set1, $set2); // complement
  40. 40. Sets – Using array$set = array();$set[] = 1;$set[] = 2;$set[] = 3;in_array(2, $set); // true Truein_array(5, $set); // false performance killers!array_merge($set1, $set2); // unionarray_intersect($set1, $set2); // intersectionarray_diff($set1, $set2); // complement
  41. 41. Sets – Using array (simple types)$set = array();$set[1] = true; // Any dummy value$set[2] = true; // is good but NULL!$set[3] = true;isset($set[2]); // trueisset($set[5]); // false$set1 + $set2; // unionarray_intersect_key($set1, $set2); // intersectionarray_diff_key($set1, $set2); // complement
  42. 42. Sets – Using array (simple types)$set = array();$set[1] = true; // Any dummy value$set[2] = true; // is good but NULL!$set[3] = true;isset($set[2]); // trueisset($set[5]); // false$set1 + $set2; // unionarray_intersect_key($set1, $set2); // intersectionarray_diff_key($set1, $set2); // complement● Remember that PHP Array keys can be integers or strings only!
  43. 43. Sets – Using array (objects)$set = array();$set[spl_object_hash($object1)] = $object1;$set[spl_object_hash($object2)] = $object2;$set[spl_object_hash($object3)] = $object3;isset($set[spl_object_hash($object2)]); // trueisset($set[spl_object_hash($object5)]); // false$set1 + $set2; // unionarray_intersect_key($set1, $set2); // intersectionarray_diff_key($set1, $set2); // complement
  44. 44. Sets – Using SplObjectStorage (objects)$set = new SplObjectStorage();$set->attach($object1); // or $set[$object1] = null;$set->attach($object2); // or $set[$object2] = null;$set->attach($object3); // or $set[$object3] = null;isset($set[$object2]); // trueisset($set[$object2]); // false$set1->addAll($set2); // union$set1->removeAllExcept($set2); // intersection$set1->removeAll($set2); // complement
  45. 45. Sets – Using QuickHash (int)$set = new QuickHashIntSet(64,QuickHashIntSet::CHECK_FOR_DUPES);$set->add(1);$set->add(2);$set->add(3);$set->exists(2); // true$set->exists(5); // false● No union/intersection/complement operations (yet?)● Yummy features like (loadFrom|saveTo)(String|File)
  46. 46. Sets – With finite possible valuesdefine("E_ERROR", 1); // or 1<<0define("E_WARNING", 2); // or 1<<1define("E_PARSE", 4); // or 1<<2define("E_NOTICE", 8); // or 1<<3$set = 0;$set |= E_ERROR;$set |= E_WARNING;$set |= E_PARSE;$set & E_ERROR; // true$set & E_NOTICE; // false$set1 | $set2; // union$set1 & $set2; // intersection$set1 ^ $set2; // complement
  47. 47. Sets – With finite possible values (function features)Instead of:function remove($path, $files = true, $directories = true, $links = true,$executable = true){ if (!$files && is_file($path)) return false; if (!$directories && is_dir($path)) return false; if (!$links && is_link($path)) return false; if (!$executable && is_executable($path)) return false; // ...}remove("/tmp/removeMe", true, false, true, false); // WTF ?!
  48. 48. Sets – With finite possible values (function features)Instead of:define("REMOVE_FILES", 1 << 0);define("REMOVE_DIRS", 1 << 1);define("REMOVE_LINKS", 1 << 2);define("REMOVE_EXEC", 1 << 3);define("REMOVE_ALL", ~0); // Setting all bitsfunction remove($path, $options = REMOVE_ALL){ if (~$options & REMOVE_FILES && is_file($path)) return false; if (~$options & REMOVE_DIRS && is_dir($path)) return false; if (~$options & REMOVE_LINKS && is_link($path)) return false; if (~$options & REMOVE_EXEC && is_executable($path)) return false; // ...}remove("/tmp/removeMe", REMOVE_FILES | REMOVE_LINKS); // Much better :)
  49. 49. Sets: Conclusions● Use the key and not the value when using PHP Arrays.● Use QuickHash for set of integers if possible.● Use SplObjectStorage as soon as you are playing with objects.● Dont use array_unique() when you need a set!
  50. 50. Bloom filters● A bloom filter is a space-efficient probabilistic data structure used to test whether an element is member of a set.● False positives are possible, but false negatives are not!
  51. 51. Bloom filters – Using bloomy// BloomFilter::__construct(int capacity [, doubleerror_rate [, int random_seed ] ])$bloomFilter = new BloomFilter(10000, 0.001);$bloomFilter->add("An element");$bloomFilter->has("An element"); // true for sure$bloomFilter->has("Foo"); // false, most probably
  52. 52. Maps● A map is a collection of key/value pairs where all keys are unique.
  53. 53. Maps – Using array$map = array();$map["ONE"] = 1;$map["TWO"] = 2;$map["THREE"] = 3;// Merging maps:array_merge($map1, $map2); // SLOW!$map2 + $map1; // Fast :)● Dont use array_merge() on maps.
  54. 54. Multikey Maps – Using array$map = array();$map["ONE"] = 1;$map["UN"] =& $map["ONE"];$map["UNO"] =& $map["ONE"];$map["TWO"] = 2;$map["DEUX"] =& $map["TWO"];$map["DUE"] =& $map["TWO"];$map["UNO"] = "once";$map["DEUX"] = "twice";var_dump($map);/*array(6) {["ONE"] => &string(4) "once"● Dont use array_merge() on maps.["UN"] => &string(4) "once"["UNO"] => &string(4) "once"["TWO"] => &string(5) "twice"["DEUX"] => &string(5) "twice"["DUE"] => &string(5) "twice"}*/
  55. 55. Heap● A heap is a tree-based structure in which all elements are ordered with largest key at the top, and the smallest one as leafs.
  56. 56. Heap● A heap is a tree-based structure in which all elements are ordered with largest key at the top, and the smallest one as leafs.
  57. 57. Heap – Using array$heap = array();$heap[] = 3;sort($heap);$heap[] = 1;sort($heap);$heap[] = 2;sort($heap);
  58. 58. Heap – Using Spl(Min|Max)Heap$heap = new SplMinHeap;$heap->insert(3);$heap->insert(1);$heap->insert(2);
  59. 59. Heaps: Conclusions● MUCH faster than having to re-sort() an array at every insertion.● If you dont require a collection to be sorted at every single step and can insert all data at once and then sort(). Array is a much better/faster approach.● SplPriorityQueue is very similar, consider it is the same as SplHeap but where the sorting is made on the key rather than the value.
  60. 60. Other related projects● SPL Types: Various types implemented as object: SplInt, SplFloat, SplEnum, SplBool and SplString http://pecl.php.net/package/SPL_Types
  61. 61. Other related projects● SPL Types: Various types implemented as object: SplInt, SplFloat, SplEnum, SplBool and SplString http://pecl.php.net/package/SPL_Types● Judy: Sparse dynamic arrays implementation http://pecl.php.net/package/Judy
  62. 62. Other related projects● SPL Types: Various types implemented as object: SplInt, SplFloat, SplEnum, SplBool and SplString http://pecl.php.net/package/SPL_Types● Judy: Sparse dynamic arrays implementation http://pecl.php.net/package/Judy● Weakref: Weak references implementation. Provides a gateway to an object without preventing that object from being collected by the garbage collector.
  63. 63. Conclusions● Use appropriate data structure. It will keep your code clean and fast.
  64. 64. Conclusions● Use appropriate data structure. It will keep your code clean and fast.● Think about the time and space complexity involved by your algorithms.
  65. 65. Conclusions● Use appropriate data structure. It will keep your code clean and fast.● Think about the time and space complexity involved by your algorithms.● Name your variables accordingly: use “Map”, “Set”, “List”, “Queue”,... to describe them instead of using something like: $ordersArray.
  66. 66. Questions?
  67. 67. Thanks● Dont forget to rate this talk on https://joind.in/4753
