ANATOMY OF SPINE Dr Pankaj N Surange MBBS, MD, FIPP Interventional Pain and Spine specialist
Anatomical Planes A-P X-ray of a scoliotic spine in the coronal plane. The  CORONAL PLANE , also called the  FRONTAL PLANE...
Anatomical Planes Lateral X-ray of a kyphotic spine in the sagittal plane. The  SAGITTAL  or  MEDIAN PLANE  is a vertical ...
Anatomical Planes CT Scan of a thoracic vertebra in the axial plane. The  AXIAL  or  TRANSVERSE PLANE  is a horizontal cut...
<ul><li>Protection of   </li></ul><ul><ul><li>spinal cord and nerve roots </li></ul></ul>Functions of the Spine <ul><ul><l...
<ul><li>Flexibility of motion in six degrees of freedom </li></ul>Functions of the Spine Left and Right Side Bending Flexi...
<ul><li>Structural support and balance for upright posture </li></ul><ul><li>  The spine is the axle bearing the load of t...
<ul><li>To achieve these functions, the spine must have: </li></ul><ul><li>Resistance  to axial loading forces, accomplish...
<ul><li>The  FUNCTIONAL UNIT  of the spine </li></ul>The Motion Segment <ul><li>Composed of: </li></ul><ul><ul><li>Connect...
Sagittal Plane Curves <ul><li>Primary Curves </li></ul><ul><li>Secondary Curves </li></ul>
Sagittal Plane Curves Cervical  Lordosis  20°- 40° Sacral  Kyphosis Lumbar  Lordosis   30°- 50° Thoracic  Kyphosis   20°- ...
<ul><li>Cervical </li></ul><ul><ul><li>Upper cervical: C1-C2 </li></ul></ul><ul><ul><li>Lower cervical: C3-C7  </li></ul><...
<ul><li>Line of gravity </li></ul>Regions of the Spine Auricle of the ear Odontoid  Body of C7 Anterior to thoracic spine ...
Basic Vertebral Structures Cervical Thoracic Lumbar
<ul><li>There are two types of bone tissue: </li></ul><ul><li>Cortical bone :  dense, outer shell of the vertebra </li></u...
Vertebral Structures Vertebral  Body Pedicle Lamina Superior Articular Process Spinous Process Transverse Process Vertebra...
Vertebral Structures Superior  Articular  Process Inferior  Articular  Process Zygapophyseal  Joint (Facet Joint) Pars
Vertebral Structures <ul><li>Pedicle notches </li></ul>Slight Notch Deep Notch Intervertebral Foramen <ul><li>INTERVERTEBR...
<ul><li>Anterior Arch </li></ul><ul><ul><li>Comprised of: </li></ul></ul><ul><ul><li>Vertebral body  </li></ul></ul><ul><u...
The Atlas (C1) Transverse Process Transverse Foramen Anterior Tubercle Articular Facet for Dens Lateral Mass Lamina Poster...
The Axis (C2) Odontoid Process (Dens) Body Transverse Process Inferior Articular Facet Superior Articular Facet Anterior V...
Lower Cervical Vertebrae <ul><li>C3 to C7 </li></ul><ul><ul><li>May be referred to as the  subaxial   region </li></ul></u...
Lower Cervical Vertebrae  C3 - C7 Transverse Process Body Sulcus for Spinal Nerve Lateral Mass Lamina Pedicle Superior Art...
Lower Cervical Vertebrae  C3 - C7 Sulcus for Spinal Nerve Uncinate Process Uncovertebral Joint (Joint of Luschka) Anterior...
Vertebra Prominens (C7) Spinous Process Axial View C7 is referred to as the  VERTEBRA PROMINENS  because it has a longer a...
Thoracic Vertebrae <ul><li>Body  -  progressive increase in mass from T1 to T12 </li></ul><ul><li>Pedicles  -  small diame...
Thoracic Vertebrae, T1-T12 <ul><li>Body  - heart shaped when viewed superiorly. </li></ul><ul><li>Vertebral foramen  - rou...
<ul><li>Articular processes </li></ul>Thoracic Vertebrae, T1-T12 Superior Articular Process Inferior Articular Process
Lumbar Vertebrae, L1-L5 <ul><li>Body  - L1 to L5 progressive increase in mass </li></ul><ul><li>Pedicles  - longer and wid...
The Sacrum Sacral Horns Sacral Ala Pedicles Dorsal Foramina Sacral Hiatus Coccyx Posterior View Inverted triangle shape
The Sacrum Coccyx Lateral View Sacral Promontory Sacral Tilt 30°-60° Sacral Canal 1 2 3 4 5 Sacral Hiatus
<ul><li>Intervertebral disc </li></ul>Intervertebral Disc <ul><li>End plate </li></ul><ul><li>Apophyseal  ring </li></ul><...
<ul><li>Fibrocartilaginous joint of the motion segment </li></ul><ul><li>Make up ¼ the length of the spinal column </li></...
Intervertebral Disc <ul><li>Annulus Fibrosus </li></ul><ul><ul><li>Outer portion of the disc </li></ul></ul>Lamellae <ul><...
Intervertebral Disc <ul><li>Nucleus Pulposus </li></ul>Nucleus Pulposus <ul><ul><li>Inner structure </li></ul></ul><ul><ul...
Intervertebral Disc <ul><li>Blood Supply  </li></ul><ul><li>Intervertebral discs have no  significant vascular structures....
Occipitocervical  Joint Occipital Condyles Foramen Magnum articulate with C1 superior facets
Atlantoaxial Joint C1 C2 Dens Zygapophyseal joints JOINT  between the atlas (C1) and the axis (C2); has a range of motion ...
The Facet Joints Also called  ZYGAPOPHYSEAL JOINTS . The facet joints are formed by the articular processes of adjacent ve...
Uncovertebral Joints Uncovertebral  Joint The bony elevations on the superior lateral margins of the cervical vertebrae ar...
Costovertebral Joints The T2-T9 thoracic vertebra have facets superiorly and inferiorly at the posterior aspect of the ver...
Costovertebral Joints Lateral View Costovertebral joints Costotransverse joint Rib
Sacroiliac Joint Sacroiliac Ligaments Sacrum Ilium The superior lateral surface on either side of the sacrum articulates w...
Upper Cervical Ligaments <ul><li>Occipitoatlantal  Ligament Complex </li></ul>Anterior occipitoatlantal ligament Posterior...
Upper Cervical Ligaments <ul><li>Occipitoaxial  Ligament Complex </li></ul>Alar ligaments (2) Apical ligament Posterior cu...
Lower Cervical, Thoracic, and Lumbar Ligaments <ul><li>Extending from the axis (C2) anteriorly to the sacrum. </li></ul><u...
Lower Cervical, Thoracic, and Lumbar Ligaments Intertransverse ligaments Costal ligaments The  INTERTRANSVERSE LIGAMENTS  ...
Lower Cervical, Thoracic, and Lumbar Ligaments Posterior longitudinal ligament <ul><li>POSTERIOR  LONGITUDINAL LIGAMENT  (...
Lower Cervical, Thoracic, and Lumbar Ligaments Interspinous ligament Ligamentum nuchae The  INTERSPINOUS LIGAMENT  connect...
<ul><li>The  SUPRASPINOUS LIGAMENT  is a very strong band connecting the tips of contiguous spinous processes. It extends ...
Lower Cervical, Thoracic, and Lumbar Ligaments Ligamentum flavum LIGAMENTUM FLAVUM Also called the  YELLOW LIGAMENT Consis...
<ul><li>The  ILIOLUMBAR LIGAMENTS  extend from the transverse processes of L4 and L5 to the iliac crest. </li></ul>Lumbosa...
Lumbosacral Ligaments Anterior View Lumbosacral ligaments The  LUMBOSACRAL LIGAMENT  is a thick, fibrous band that extends...
Sacroiliac Ligaments Short sacroiliac ligaments Posterior  View Long sacroiliac ligaments <ul><li>The  SACROILIAC LIGAMENT...
Posterior Spinal Muscle Groups <ul><ul><li>Iliocostalis </li></ul></ul>The  superficial posterior muscles  are collectivel...
Posterior Spinal Muscle Groups <ul><ul><li>semispinalis capitis   </li></ul></ul><ul><ul><li>semispinalis cervicis   </li>...
Posterior Spinal Muscle Groups <ul><ul><li>Multifidus   </li></ul></ul><ul><ul><li>Intertransversarii   attachments betwee...
Arteries of the Cranial and Cervical Region Foramen lacerum Vertebral artery Carotid artery Two  VERTEBRAL ARTERIES , one ...
Arteries of the Cranial and Cervical Region Vertebral arteries Basilar artery Circle of Willis Internal carotid arteries
Arteries  of the Thoracic and Lumbosacral Regions Vertebral artery Aortic arch Ascending aorta Descending aorta Thoracic s...
Segmental Arteries  <ul><li>At each vertebral level from T4 to the sacrum, a pair of  SEGMENTAL ARTERIES  branches posteri...
Veins of the Cervical and Thoracic Region The most important venous structures in the cervical spine are the internal and ...
Veins  of the Thoracic and Lumbar Region Internal jugular Superior vena cava Azygos vein Thoracic segmental veins Hemiazyg...
Batson’s Plexus The  AZYGOS SYSTEM  is a large network of veins draining blood from the intestines and other abdominal org...
Batson’s Plexus Because of the azygos system, patient positioning is very important in posterior lumbar spine surgery. The...
Spinal Nerve Structures <ul><li>Spinal Cord </li></ul><ul><li>Contained in epidural space </li></ul><ul><li>Network of sen...
Meninges Dura mater Subdural space Arachnoid layer Subarachnoid space: filled with CSF Pia mater Within the spinal canal, ...
Spinal Nerve Topography <ul><li>31 pairs of spinal nerves </li></ul><ul><li>8 cervical </li></ul><ul><li>12 thoracic </li>...
Spinal Nerves Spinal cord Epidural space Dura mater and Arachnoid layers Subarachnoid space Dorsal root Ventral root Dorsa...
Autonomic Nervous System Independent of voluntary control. Controls glandular and cardiac function and smooth muscle such ...
Autonomic Nervous System The  SYMPATHETIC NERVOUS SYSTEM  consists of a series of ganglia extending from the skull to the ...
Thank You!
