Learning Lessons: Building a CMS on top of NoSQL technologies Presentation Transcript

  • 1. Learning Lessons Building a content repository on top of NoSQL Technologies IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org
  • 2. hello, I’m @stevenn from @outerthought IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 2
  • 3. This story is about IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 3
  • 4. Complexity complexity software architecture 3.0 2.0 1.0 age IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 4
  • 5. Complexity complexity user interest 3.0 2.0 1.0 age IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 5
  • 6. We Prefer Sophistication » the challenge for us was to scale ... without dropping features IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 6
  • 7. The typical CMS ‘architecture’ database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 7
  • 8. The typical CMS ‘architecture’ application cache database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 8
  • 9. The typical CMS ‘architecture’ more cache application cache database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 9
  • 10. The typical CMS ‘architecture’ even more cache more cache application cache database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 10
  • 11. The typical CMS ‘architecture’ client even more cache more cache application cache database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 11
  • 12. The typical CMS ‘architecture’ client (+cache) even more cache more cache application cache database (+opt. filesystem) (+ opt. full-text indexes) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 12
  • 13. What we found hard to scale » access control » facet browsing » all the nifty stuff people were using our software for » ... anything that required random access to in-memory-cache data for computations IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 13
  • 14. Beyond the ‘scaling’ problem » three-prong data layer fs » result set merging (between MySQL & Lucene) » happened in appcode/memory » ‘transactions’, set operations = hard IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 14
  • 15. Beyond the three-prong problem » errrr..... “Failover” ..... ? IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 15
  • 16. If we would be able to add more nodes ... scalability » True Distribution availability performance ... in the line of fire IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 16
  • 17. Solution 1 » do MORE inside the database IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 17
  • 18. Functional IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 18
  • 19. Functional IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 19
  • 20. Infrastructural e ! a s ta b d a o re m IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 20
  • 21. e ! a s tab d a o re n m eve IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 21
  • 22. s ! u s se e b sa g m es d d ’s a l et IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 22
  • 23. f f! ! s tu B C J D r e ! ov 0t S 0 J M w M I! R IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 23
  • 24. http://bigdatamatters.com/bigdatamatters/2010/04/high-availability-with-oracle.html IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 24
  • 25. Business Development 101 user interest budget IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 25
  • 26. Solution II sophistication ability to cope 3.0 mysql nosql? 2.0 1.0 IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 26
  • 27. Enter The Cambrian Explosion Cassandra NoSQL neo4j IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 27
  • 28. Requirements, phase I » automatic scaling to large data sets » fault-tolerance: replication, automatic handling of failing nodes » a flexible data model supporting sparse data » runs on commodity hardware » efficient random access to data » open source, ability to participate in the development thus drive the direction of the project » some preference for a Java-based solution IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 28
  • 29. Requirements, phase II » After careful consideration, we realized the important choices were also: » consistency: no chance of having two conflicting versions of a row » atomic updates of a single row, single-row transactions » bonus points for MapReduce integration » e.g. full-text index rebuilding IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 29
  • 30. That brought us to HBase, which bought us: » a datamodel where you can have column families which keep all versions and others which do not, which fits very well on our CMS document model » ordered tables with the ability to do range scans on them, which allows to build scalable indexes on top of it » HDFS, a convenient place to store large blobs » Apache license and community, a familiar environment for us IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 30
  • 31. » OK, so now we had a data store ! IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 31
  • 32. » However, content repository = store + search ! u ch o IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 32
  • 33. a s w at ! h sy T a .. .) e ver we h o ( IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 33
  • 34. Search ponderings » CMS = two types of search » structured search » numbers, strings » based on logic (SQL, anyone?) » information retrieval (or: full-text search) » text » based on statistics IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 34
  • 35. Search ponderings » All of that, at scale IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 35
  • 36. Structured Search » HBase Indexing Library » idea from Google App Engine datastore indexes » http://code.google.com/appengine/articles/ index_building.html rowkey col col rowkey col order A val3 foo6 val2-B B val2 foo7 val3-A content table index table A IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 36
  • 37. Full-text / IR search » Lucene? » no sharding (for scale) » no replication (for availability) » batched index updates (not real-time) IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 37
  • 38. Beyond Lucene » Katta » scalable architecture, however only search, no indexing » Elastic Search » very young (sorry) » hbasene et al. » stores inverted index in HBase, might not scale all features » SOLR » widely used, schema, facets, query syntax, cloud branch More info: http://lilycms.org/lily/prerelease/technology.html IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 38
  • 39. ? + = r ? ! O a sy E IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 39
  • 40. Remember distribution ? Remember secondary indexes ? ➙ Need for reliable queuing IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 40
  • 41. Connecting things » we needed a reliable bridge between our main storage (HBase) and our index/search server(s) (SOLR) » indexing, reindexing, mass reindexing (M/R) » we need a reliable method of updating HBase secondary indexes » all of that eventually to run distributed » distribution means coping with failure IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 41
  • 42. Solution » ACMEMessageQueue ? Bzzzzzt. We wanted fault-safe HBase persistence for the queues. Also for ease of administration. » ➙ WAL & Queue implemented on top of HBase tables IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 42
  • 43. WAL / Queue » WAL » Queue » guaranteed execution » triggering of async of synchronous actions actions » call doesn’t return before » e.g. (re)index (updated) secondary action finishes record with SOLR back-end » e.g. update secondary actions » size depends on speed of » if all goes well, back-end process size = #concurrent ops » will be useful/made available outside of Lily context as well! IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 43
  • 44. The Sum » Lily model (records & fields) » mapped onto HBase (=storage) » indexed and searchable through SOLR » using a WAL/Queue mechanism implemented in HBase » runtime based on Kauri » with client/server comms via Avro IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 44
  • 45. Architecture IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 45
  • 46. Architecture IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 46
  • 47. Roadmap » Today = release of learning material (architecture, model, API, Javadoc) ➥ www.lilycms.org ➥ bit.ly/lilyprerelease » Mid July = ‘proof of architecture’ release e re! th early N » from there on, ca. 3-monthly releases leading up to Lily 1.0 IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 47
  • 48. bit.ly/lilyprerelease IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 48
  • 49. License » Apache IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 49
  • 50. Business model » Consulting, mentoring, turn-key projects » Strong focus on partner relations » targeting vertical markets » geographic coverage » SaaS offerings » Markets: media, finance, insurance, govt, heritage ... LOTS of semi-structured data » Not: OLAP IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 50
  • 51. More ? » @outerthought » www.lilycms.org/lily/prerelease.html IIC » TECHNOLOGIEPARK 3 » B-9052 ZWIJNAARDE (GENT) » www.outerthought.org 51
