Secrets of Best MySQL
Optimization
presented by
Sonali Minocha
OSSCube
Who Am I?
Why Tune a Database?
Who Tunes?
What is Tuned?
How much tuning is enough?
Application Development
(Optimizing Queries)
Index Optimizations
EXPLAIN Types
system

The table has only one row

const

At the most one matching row, treated as a
constant

eq_ref

One ...
EXPLAIN Extra
Using index

The result is created straight from the index

Using where

Not all rows are used in the result...
Optimizer Hints
STRAIGHT_JOIN

Forces the optimizer to join the tables in the
given order

SQL_BIG_RESULTS

Together with ...
Selecting Queries to Optimize
• The slow query log
– Logs all queries that take longer than
long_query_time
– Can also log...
• The general query log can be use to analyze:
– Reads vs. writes
– Simple queries vs. complex queries
– etc
Database Designing
(Optimizing Schemas)
Normalization
Table Optimizations
Choosing Best Suited Storage Engine

• Understanding benefits and drawbacks of
each storage engine is very important while...
MyISAM-Specific Optimizations
InnoDB-Specific Optimizations
• InnoDB uses clustered indexes
– The length of the PRIMARY KEY is extremely
important

• Th...
Monitoring Threads in MySQL
MEMORY-Specific Optimizations
Optimizing the Server
Performance Monitoring
Tuning MySQL Parameters
• Some MySQL options can be changed online
• The dynamic options are either
– SESSION specific
• C...
• Online changes are not persistant over a
server restart
– The configuration files have to be changed as well

• The curr...
Status Variables
SQL/Parser Model
Client1

Client2

ClientN

MySQL Server
Connection Thread Pool

Query Cache
Parser

Query

Optimizer

Sto...
Query Cache
• Stores SELECT queries and their results
• Purpose: improve performance for
frequently requested data
• The d...
• The Qcache_% status variables help
monitoring the cache
– The utilisation ratio: Qcache_hits vs.
Com_select

• The query...
Some Thread Specific Options
• read_buffer_size (default 128Kb) and
read_rnd_buffer_size (default 256Kb)
– Size of cache u...
Some Global Options
• table_cache (default 64)
– Cache for storing open table handlers
– Increase this if Opened_tables is...
• max_connections (default 100)
– The maximum allowed number of simultaneous
connections
– Very important for tuning threa...
MyISAM Global Options
• key_buffer_size (default 8Mb)
– Cache for storing indices
– Increase this to get better index hand...
MyISAM Thread-Specific Options
• myisam_sort_buffer_size (default
8Mb)
– Used when sorting indexes during
REPAIR/ALTER TAB...
InnoDB-Specific Optimization
• innodb_buffer_pool_size (default
8Mb)
– The memory buffer InnoDB uses to cache both
data an...
• innodb_flush_log_at_trx_commit
(default 1)
– 0 writes and sync’s once per second (not ACID)
– 1 forces sync to disk afte...
InnoDB-Specific
Optimization
• innodb_log_buffer_size (default
1Mb)
– Larger values allows for larger transactions to be
l...
QnA
Thank you for your time and attention

www.osscube.com

For more information, please feel free to drop in a line to
sonali...
MySQL Performance Tuning - GNUnify 2010
MySQL Performance Tuning - GNUnify 2010
MySQL Performance Tuning - GNUnify 2010
MySQL Performance Tuning - GNUnify 2010
MySQL Performance Tuning - GNUnify 2010
MySQL Performance Tuning - GNUnify 2010
Upcoming SlideShare
Loading in...5
×

MySQL Performance Tuning - GNUnify 2010

7,649

Published on

Presnetation on MySQL Performance Tuning Best Practices,
presented by Sonali Minocha, OSSCube
at GNUnify 2010

Published in: Technology
0 Comments
21 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
7,649
On Slideshare
0
From Embeds
0
Number of Embeds
5
Actions
Shares
0
Downloads
460
Comments
0
Likes
21
Embeds 0
No embeds

No notes for slide
  • NEW/UPDATED
  • UPDATED
    changed sort_buffer to sort_buffer_size (typo? or change to variable?)
    added defaults
  • UPDATED
    moved defaults to title line
  • UPDATED
    moved defaults to title line
  • MySQL Performance Tuning - GNUnify 2010

    1. 1. Secrets of Best MySQL Optimization presented by Sonali Minocha OSSCube
    2. 2. Who Am I?
    3. 3. Why Tune a Database?
    4. 4. Who Tunes?
    5. 5. What is Tuned?
    6. 6. How much tuning is enough?
    7. 7. Application Development (Optimizing Queries)
    8. 8. Index Optimizations
    9. 9. EXPLAIN Types system The table has only one row const At the most one matching row, treated as a constant eq_ref One row per row from previous tables ref Several rows with matching index value ref_or_null Like ref, plus NULL values index_merge Several index searches are merged unique_subquery Same as ref for some subqueries index_subquery As above for non-unique indexes range A range index scan index The whole index is scanned ALL A full table scan
    10. 10. EXPLAIN Extra Using index The result is created straight from the index Using where Not all rows are used in the result Distinct Only a single row is read per row combination Not exists A LEFT JOIN missing rows optimization is used Using filesort An extra row sorting step is done Using temporary A temporary table is used Range checked for each record The read type is optimized individually for each combination of rows from the previous tables
    11. 11. Optimizer Hints STRAIGHT_JOIN Forces the optimizer to join the tables in the given order SQL_BIG_RESULTS Together with GROUP BY or DISTINCT tells the server to use disk-based temp tables SQL_BUFFER_RESULTS Tells the server to use a temp table, thus releasing locks early (for table-locks) USE INDEX Hints to the optimizer to use the given index FORCE INDEX Forces the optimizer to use the index (if possible) IGNORE INDEX Forces the optimizer not the use the index
    12. 12. Selecting Queries to Optimize • The slow query log – Logs all queries that take longer than long_query_time – Can also log all queries that don’t use indexes with --log-queries-not-using-indexes – To log slow administrative commands use --log-slow-admin-statements – To analyze the contents of the slow log use mysqldumpslow
    13. 13. • The general query log can be use to analyze: – Reads vs. writes – Simple queries vs. complex queries – etc
    14. 14. Database Designing (Optimizing Schemas)
    15. 15. Normalization
    16. 16. Table Optimizations
    17. 17. Choosing Best Suited Storage Engine • Understanding benefits and drawbacks of each storage engine is very important while designing application. • Different storage engine has different index capability ,application need should be kept in mind while choosing storage engine
    18. 18. MyISAM-Specific Optimizations
    19. 19. InnoDB-Specific Optimizations • InnoDB uses clustered indexes – The length of the PRIMARY KEY is extremely important • The rows are always dynamic – Using VARCHAR instead of CHAR is almost always better • Maintenance operations needed after – Many UPDATE/DELETE operations • The pages can become underfilled
    20. 20. Monitoring Threads in MySQL
    21. 21. MEMORY-Specific Optimizations
    22. 22. Optimizing the Server
    23. 23. Performance Monitoring
    24. 24. Tuning MySQL Parameters • Some MySQL options can be changed online • The dynamic options are either – SESSION specific • Changing the value will only affect the current connection – GLOBAL • Changing the value will affect the whole server – Both • When changing the value SESSION/GLOBAL should be specified
    25. 25. • Online changes are not persistant over a server restart – The configuration files have to be changed as well • The current values of all options can be found with SHOW SESSION/GLOBAL VARIABLES
    26. 26. Status Variables
    27. 27. SQL/Parser Model Client1 Client2 ClientN MySQL Server Connection Thread Pool Query Cache Parser Query Optimizer Storage Engines 101101  InnoDB  MyISAM  MERGE  MEMORY  Federated  ARCHIVE  NDBCluster
    28. 28. Query Cache • Stores SELECT queries and their results • Purpose: improve performance for frequently requested data • The data in the query cache is invalidated as soon as a modification is done in the table • Controlled with the query_cache_size variable
    29. 29. • The Qcache_% status variables help monitoring the cache – The utilisation ratio: Qcache_hits vs. Com_select • The query cache can be emptied with RESET QUERY CACHE
    30. 30. Some Thread Specific Options • read_buffer_size (default 128Kb) and read_rnd_buffer_size (default 256Kb) – Size of cache used for table scanning – Not equivalent to block size • The database is not divided into blocks but directly into records – Increase if you do many sequential scans • sort_buffer_size (default 2Mb) – Size of the GROUP BY / ORDER BY cache – If more memory is needed it will be taken from the disk • tmp_table_size (default 32Mb) – Limit after which temporary tables will not be MEMORYs anymore, but MyISAM tables
    31. 31. Some Global Options • table_cache (default 64) – Cache for storing open table handlers – Increase this if Opened_tables is high • thread_cache (default 0) – Number of threads to keep for reuse – Increase if threads_created is high – Not useful if the client uses connection pooling
    32. 32. • max_connections (default 100) – The maximum allowed number of simultaneous connections – Very important for tuning thread specific memory areas – Each connection uses at least thread_stack of memory
    33. 33. MyISAM Global Options • key_buffer_size (default 8Mb) – Cache for storing indices – Increase this to get better index handling – Miss ratio (key_reads/key_read_requests) should be very low, at least < 0.03 (often < 0.01 is desirable) • Row caching is handled by the OS
    34. 34. MyISAM Thread-Specific Options • myisam_sort_buffer_size (default 8Mb) – Used when sorting indexes during REPAIR/ALTER TABLE • myisam_repair_threads (default 1) – Used for bulk import and repairing – Allows for repairing indexes in multiple threads • myisam_max_sort_file_size – The max size of the file used while re-creating indexes
    35. 35. InnoDB-Specific Optimization • innodb_buffer_pool_size (default 8Mb) – The memory buffer InnoDB uses to cache both data and indexes – The bigger you set this the less disk i/o is needed – Can be set very high (up to 80% on a dedicated system)
    36. 36. • innodb_flush_log_at_trx_commit (default 1) – 0 writes and sync’s once per second (not ACID) – 1 forces sync to disk after every commit – 2 write to disk every commit but only sync’s about once per second
    37. 37. InnoDB-Specific Optimization • innodb_log_buffer_size (default 1Mb) – Larger values allows for larger transactions to be logged in memory – Sensible values range from 1M to 8M • innodb_log_file_size (default 5Mb) – Size of each InnoDB redo log file – Can be set up to buffer_pool_size
    38. 38. QnA
    39. 39. Thank you for your time and attention www.osscube.com For more information, please feel free to drop in a line to sonali@osscube.com or visit http://www.osscube.com
