10 May, 2009<br />Inversion Of Control - <br />Spring.NETOverview<br />
Dependencies and Dependency Injection<br />10 May, 2009<br />2<br />Inversion Of Control -  Spring.NET Overview<br />
What is Dependency Injection?<br />Dependency injection (DI) in programming refers to the process of supplying an external...
But … what is Inversion of control?<br />Inversion of control, or IoC, is an abstract principle describing an aspect of so...
IOC Container<br />10 May, 2009<br />5<br />Inversion Of Control -  Spring.NET Overview<br />
Aha…and what is an IOC container?<br />10 May, 2009<br />6<br />Inversion Of Control -  Spring.NET Overview<br />
Spring.NET<br />an application framework for buidling Enterprise .NET applications <br />an IoC Container (Inversion of Co...
And more…<br />10 May, 2009<br />8<br />Inversion Of Control -  Spring.NET Overview<br />
IoC Containers for .NET<br />PicoContainer.NET: lightweight and highly embeddable IoC container<br />StructureMap:  lightw...
Practice First approach - Dependencies<br />public class ExampleObject {<br />  private AnotherObjectobjectOne; // depende...
Configuration I<br />Preferred way to create Object Factories and Application contexts is via configuration:<br />&lt;conf...
Configuration II<br />The configuration tells Spring.NET how objects depend on each other: <br />Object name<br />Object t...
Usage<br />Now instantiating an  <br />ApplicationContext is simple:<br />ID that should appear in object configuration<br...
Example  application<br />10 May, 2009<br />14<br />Inversion Of Control -  Spring.NET Overview<br />
Solve the dependencies with Spring.NET IOC<br />Demo<br />10 May, 2009<br />15<br />Inversion Of Control -  Spring.NET Ove...
16<br />Inversion Of Control -  Spring.NET Overview<br />10 May, 2009<br />http://en.wikipedia.org/wiki/Inversion_of_contr...
17<br />Inversion Of Control -  Spring.NET Overview<br />10 May, 2009<br />
Upcoming SlideShare
Loading in...5
×

Inversion Of Control: Spring.Net Overview

3,315

Published on

Introduction to Spring.NET, Inversion of Control. Spring.NET is an open source application framework that makes building enterprise .NET applications easier.

Published in: Technology
0 Comments
1 Like
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
3,315
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
82
Comments
0
Likes
1
Embeds 0
No embeds

No notes for slide

Inversion Of Control: Spring.Net Overview

  1. 1. 10 May, 2009<br />Inversion Of Control - <br />Spring.NETOverview<br />
  2. 2. Dependencies and Dependency Injection<br />10 May, 2009<br />2<br />Inversion Of Control - Spring.NET Overview<br />
  3. 3. What is Dependency Injection?<br />Dependency injection (DI) in programming refers to the process of supplying an external dependency to a software component. <br />It is a specific form of inversion of control where the concern being inverted is the process of obtaining the needed dependency.<br />10 May, 2009<br />3<br />Inversion Of Control - Spring.NET Overview<br />
  4. 4. But … what is Inversion of control?<br />Inversion of control, or IoC, is an abstract principle describing an aspect of some software architecture designs in which the flow of control of a system is inverted in comparison to the traditional architecture.<br />Control flow is expressed in imperative programming in the form of a series of instructions or procedure calls. Instead of specifying a sequence of decisions and procedures to occur during the lifetime of a process, the user of a IoCframework writes the desired responses linked to particular events or data requests. <br />10 May, 2009<br />4<br />Inversion Of Control - Spring.NET Overview<br />
  5. 5. IOC Container<br />10 May, 2009<br />5<br />Inversion Of Control - Spring.NET Overview<br />
  6. 6. Aha…and what is an IOC container?<br />10 May, 2009<br />6<br />Inversion Of Control - Spring.NET Overview<br />
  7. 7. Spring.NET<br />an application framework for buidling Enterprise .NET applications <br />an IoC Container (Inversion of Control) that manages and injects dependencies on behalf of developers (DI = Dependency Injection)<br />10 May, 2009<br />Inversion Of Control - Spring.NET Overview<br />7<br />
  8. 8. And more…<br />10 May, 2009<br />8<br />Inversion Of Control - Spring.NET Overview<br />
  9. 9. IoC Containers for .NET<br />PicoContainer.NET: lightweight and highly embeddable IoC container<br />StructureMap: lightweight Inversion of Control (IoC) Container written in C#; can improve the architectural qualities of .NET apps by reducing the mechanical costs of good design techniques<br />Castle: Tools for application development including small IoC container<br />Spring.NET: full featured IoC container (port of Java version)<br />10 May, 2009<br />9<br />Inversion Of Control - Spring.NET Overview<br />
  10. 10. Practice First approach - Dependencies<br />public class ExampleObject {<br /> private AnotherObjectobjectOne; // dependencies<br /> private YetAnotherObjectobjectTwo;<br /> private inti; <br /> public AnotherObjectObjectOne {<br /> set { this.objectOne = value; }<br /> }<br /> public YetAnotherObjectObjectTwo {<br /> set { this.objectTwo = value; }<br /> }<br /> public intIntegerProperty {<br /> set { this.i = value; } <br /> } <br />}<br />10 May, 2009<br />10<br />Inversion Of Control - Spring.NET Overview<br />
  11. 11. Configuration I<br />Preferred way to create Object Factories and Application contexts is via configuration:<br />&lt;configuration&gt;<br /> &lt;configSections&gt;<br /> &lt;sectionGroup name=&quot;spring&quot;&gt;<br /> &lt;section name=&quot;context&quot; type=&quot;Spring.Context.Support.ContextHandler, Spring.Core&quot;/&gt;<br /> &lt;section name=&quot;objects&quot; type=&quot;Spring.Context.Support.DefaultSectionHandler, Spring.Core&quot; /&gt;<br /> &lt;/sectionGroup&gt;<br /> &lt;/configSections&gt;<br /> &lt;spring&gt;<br /> &lt;context&gt;<br /> &lt;resource uri=&quot;config://spring/objects&quot;/&gt;<br /> &lt;/context&gt;<br /> &lt;objects&gt;<br /> ...<br /> &lt;/objects&gt;<br /> &lt;/spring&gt;<br />&lt;/configuration&gt;<br />Handlers usedfor Spring configurationsection<br />Where to find object configuration, e.g. file, assembly, config<br />Configurationof Spring managedobjects<br />10 May, 2009<br />11<br />Inversion Of Control - Spring.NET Overview<br />
  12. 12. Configuration II<br />The configuration tells Spring.NET how objects depend on each other: <br />Object name<br />Object type: namespacepath + class, assembly<br />&lt;object id=&quot;exampleObject&quot; type=&quot;Examples.ExampleObject, ExamplesLibrary&quot;&gt;<br /> &lt;property name=&quot;objectOne&quot; ref=&quot;anotherExampleObject&quot;/&gt;<br /> &lt;property name=&quot;objectTwo&quot; ref=&quot;yetAnotherObject&quot;/&gt;<br /> &lt;property name=&quot;IntegerProperty&quot; value=&quot;1&quot;/&gt;<br />&lt;/object&gt;<br />&lt;object id=&quot;anotherExampleObject&quot; type=&quot;Examples.AnotherObject, ExamplesLibrary&quot;/&gt;<br />&lt;object id=&quot;yetAnotherObject&quot; type=&quot;Examples.YetAnotherObject, ExamplesLibrary&quot;/&gt;<br />Properties referring to other objects: often called dependencies or collaborators<br />10 May, 2009<br />12<br />Inversion Of Control - Spring.NET Overview<br />
  13. 13. Usage<br />Now instantiating an <br />ApplicationContext is simple:<br />ID that should appear in object configuration<br />IApplicationContextctx = ContextRegistry.GetContext();<br />ExampleObject person = (ExampleObject)ctx.GetObject(“exampleObject &quot;); <br />10 May, 2009<br />13<br />Inversion Of Control - Spring.NET Overview<br />
  14. 14. Example application<br />10 May, 2009<br />14<br />Inversion Of Control - Spring.NET Overview<br />
  15. 15. Solve the dependencies with Spring.NET IOC<br />Demo<br />10 May, 2009<br />15<br />Inversion Of Control - Spring.NET Overview<br />
  16. 16. 16<br />Inversion Of Control - Spring.NET Overview<br />10 May, 2009<br />http://en.wikipedia.org/wiki/Inversion_of_control<br />http://martinfowler.com/articles/injection.html<br />http://abdullin.com/wiki/inversion-of-control-ioc.html<br />http://www.springframework.net/doc-latest/reference/html/objects.html<br />http://www.developer.com/net/csharp/article.php/3722931/Dependency-Injection-with-SpringNet.htm<br />Resources<br />
  17. 17. 17<br />Inversion Of Control - Spring.NET Overview<br />10 May, 2009<br />
