Deploying Fully Automated, Highly AvailableDjango Application Stacks with Chef       schisamo@opscode.com          www.ops...
Who am I?
Who am I?•   Seth Chisamore    Senior Technical Consultant/Evangelist    Opscode, Inc.
Who am I?•   Seth Chisamore    Senior Technical Consultant/Evangelist    Opscode, Inc.•   Project lead for many Opscode sp...
Who are you? http://www.flickr.com/photos/timyates/2854357446/sizes/l/
Who are you?•   System administrators?                              http://www.flickr.com/photos/timyates/2854357446/sizes...
Who are you?•   System administrators?•   Developers?                              http://www.flickr.com/photos/timyates/2...
Who are you?•   System administrators?•   Developers?•   “Business” People?                              http://www.flickr...
What are we talking      about?     http://www.flickr.com/photos/peterkaminski/2174679908/
Agendahttp://www.flickr.com/photos/koalazymonkey/3590953001/
Agenda•   How’s and Why’s                      http://www.flickr.com/photos/koalazymonkey/3590953001/
Agenda•   How’s and Why’s•   Chef 101                      http://www.flickr.com/photos/koalazymonkey/3590953001/
Agenda•   How’s and Why’s•   Chef 101•   Deploying n-tier Django app stacks    with Chef                                  ...
Agenda•   How’s and Why’s•   Chef 101•   Deploying n-tier Django app stacks    with Chef•   Leveraging the same Chef code ...
Infrastructure as Code
A technical domainrevolving aroundbuilding andmanaginginfrastructureprogrammatically
Enable the reconstruction   of the business fromnothing but a source coderepository, an application  data backup, and bare...
ConfigurationManagement
ConfigurationManagement
System Integration     http://www.flickr.com/photos/opalsson/3773629074/
The Chef Framework   With thanks (and apologies) to Stephen Nelson-Smith
The Chef Framework
The Chef Framework•   Idempotent
The Chef Framework•   Idempotent•   Library & Primitives
The Chef Framework•   Idempotent•   Library & Primitives•   Flexibility
The Chef Framework•   Idempotent•   Library & Primitives•   Flexibility•   Reasonability
The Chef Framework•   Idempotent•   Library & Primitives•   Flexibility•   Reasonability•   TIMTOWTDI
Multiple applications of an operation do not  change the result
We start with APIs, you     supply data
Defaults are sane, but  easily changed
There is more than one     way to do it
The Chef Tool(s) With thanks (and apologies) to Stephen Nelson-Smith
The Chef Tool(s)
The Chef Tool(s)•   ohai
The Chef Tool(s)•   ohai•   chef-client
The Chef Tool(s)•   ohai•   chef-client•   knife
The Chef Tool(s)•   ohai•   chef-client•   knife•   shef
The Chef APIWith thanks (and apologies) to Stephen Nelson-Smith
The Chef API
The Chef API•   Fat Client/Thin Server
The Chef API•   Fat Client/Thin Server•   RESTful API w/ JSON
The Chef API•   Fat Client/Thin Server•   RESTful API w/ JSON•   Search Service
The Chef API•   Fat Client/Thin Server•   RESTful API w/ JSON•   Search Service•   Derivative Services (mash-up your    in...
The Chef Community   With thanks (and apologies) to Stephen Nelson-Smith
The Chef Community
The Chef Community•   Apache License, Version 2.0
The Chef Community•   Apache License, Version 2.0•   360+ Individual contributors
The Chef Community•   Apache License, Version 2.0•   360+ Individual contributors•   70+ Corporate contributors
The Chef Community•   Apache License, Version 2.0•   360+ Individual contributors•   70+ Corporate contributors    •   Del...
The Chef Community•   Apache License, Version 2.0•   360+ Individual contributors•   70+ Corporate contributors    •   Del...
The Chef Community•   Apache License, Version 2.0•   360+ Individual contributors•   70+ Corporate contributors    •   Del...
Chef client runs on your        systems
Clients talk to a Chef       server
Clients authenticate with        RSA keys
Each system youconfigure is a managed         node
Nodes have attributes{  "kernel": {    "machine": "x86_64",    "name": "Darwin",    "os": "Darwin",    "version": "Darwin ...
Nodes are Searchableknife search node ‘platform:mac_os_x’ search(:node, ‘platform:mac_os_x’)
Chef Enables Infrastructure as Code                       package "haproxy" do                        action :install     ...
Chef managesResources on Nodes
Chef Resourcespackage "haproxy" do action :installendtemplate "/etc/haproxy/haproxy.cfg" do source "haproxy.cfg.erb" owner...
Chef Resources                   package "haproxy" do                    action :install                   end•   Have a t...
Chef Resources                   package "haproxy" do                    action :install                   end•   Have a t...
Chef Resources                       package "haproxy" do                        action :install                       end...
Chef Resources                                      package "haproxy" do                                       action :ins...
Chef Resources                                      package "haproxy" do                                       action :ins...
Resources take action through Providers
Chef Providers•   Multiple providers per resource type.•   For example the `package` resource    has providers for: Apt, Y...
Recipes are collections     of Resources
Chef Recipes                                    package "haproxy" do                                     action :install  ...
Chef Recipes•   Recipes can include other   include_recipe                                include_recipe                  ...
Chef Recipes%w{ python python-dev }.each do |pkg| package pkg do  action :install endendpool_members = search("node", "rol...
Chef Recipes                          %w{ python python-dev }.each do |pkg|                           package pkg do      ...
Chef Recipes                            %w{ python python-dev }.each do |pkg|                             package pkg do  ...
Cookbooks arepackages for recipes
Cookbook Metadata•   Cookbooks are like packages.•   Cookbooks have dependencies.
Cookbooks are easy to share.   community.opscode.com
Chef Rolesname "django_cms"description "django cms app server"run_list(  "recipe[mysql::client]",  "recipe[application]")n...
Chef Roles                            name "django_cms"                            description "django cms app server"    ...
Chef Roles                             name "django_cms"                             description "django cms app server"  ...
Chef Roles                                 name "django_cms"                                 description "django cms app s...
Data bags store arbitrary data
Data Bags% knife data bag show apps django_cmsdatabase_master_role: ["django_cms_database_master"]databases:  production: ...
Track it like source code...% git logcommit d640a8c6b370134d7043991894107d806595cc35Author: jtimberman <joshua@opscode.com...
Ponies ,(green )Unicorns and    n-tier oh my!
N-Tier FTW•   Provision
N-Tier FTW              Load BalancerApp Server                     App Server                                            ...
N-Tier FTW              Load Balancer                                            •   ProvisionApp Server                  ...
Chef Enables Systems Integration
Chef Enables Systems Integration•   Chef searches allow nodes to be aware of    each other and self configure
Chef Enables Systems Integration•   Chef searches allow nodes to be aware of    each other and self configure•   A shared ...
Chef Enables Systems Integration•   Chef searches allow nodes to be aware of    each other and self configure•   A shared ...
Chef Enables Systems Integration•   Chef searches allow nodes to be aware of    each other and self configure•   A shared ...
Database Master
Database Master% knife role show django_cms_database_masterdefault_attributes: {}description:       db master for the djan...
Database Master
Database Master•   Install and configure MySQL
Database Master•   Install and configure MySQL•   Create the application database
Database Master•   Install and configure MySQL•   Create the application database•   Grant the application user access
Django App Servers      (1..n)
Django App Servers% knife role show django_cmschef_type:         roledefault_attributes: {}description:       django_cms f...
Django App Servers
Django App Servers•   Deploy the Code
Django App Servers•   Deploy the Code    •   checkout the code with git
Django App Servers•   Deploy the Code    •   checkout the code with git    •   install required packages (os and python)
Django App Servers•   Deploy the Code    •   checkout the code with git    •   install required packages (os and python)  ...
Django App Servers•   Deploy the Code    •   checkout the code with git    •   install required packages (os and python)  ...
Django App Servers•   Deploy the Code    •   checkout the code with git    •   install required packages (os and python)  ...
Django App Servers•   Deploy the Code    •   checkout the code with git    •   install required packages (os and python)  ...
Search for Database Masterresults = search(:node, "role:django_cms_database_master")template "/srv/django_cms/shared/local...
Load Balancer
Load Balancer% knife role show django_cms_load_balancerchef_type:         roledefault_attributes: {}description:       Dja...
Load Balancer•   The balancing pool should grow as more    application servers are brought online
Search for App Serverspool_members = search(:node, "role:django_cms")template "/etc/haproxy/haproxy.cfg" do source "haprox...
One set of codez.... ...to rule them all
Same Code Different Configurations
Same Code Different Configurations•   We can deploy the same app stack on:
Same Code Different Configurations•   We can deploy the same app stack on:    •   a single node or a fully redundant      ...
Same Code Different Configurations•   We can deploy the same app stack on:    •   a single node or a fully redundant      ...
Same Code Different Configurations•   We can deploy the same app stack on:    •   a single node or a fully redundant      ...
Staging/QA - Single Node# launch stack in your data center% knife bootstrap 123.123.3.3   -r ‘role[django_cms_database_mas...
Production - Multi-Machine Cluster% knife ec2 server create   -r ‘role[django_cms_database_master]’% knife ec2 server crea...
Developer Workstation% cat VagrantfileVagrant::Config.run do |config| config.vm.box = base_box config.vm.provision :chef_server...
BONUS: deploy [insert   your favorite webframework here] stacks
Application Cookbook•   Supports the following web stacks:    •   Django    •   Java Webapps    •   Php    •   Rails    • ...
Further Resources & Closing•   www.opscode.com•   wiki.opscode.com•   @opscode, #opschef•   irc.freenode.net, #chef, #chef...
Questions? http://www.flickr.com/photos/oberazzi/318947873/
Thanks!   schisamo@opscode.com      www.opscode.com
