Android Hacks,Variants, Tricks and     ResourcesEmbedded Systems Conference SV 2012         Karim Yaghmour         @karimy...
These slides are made available to you under a Creative Commons          Delivered and/or customized byShare-Alike 3.0 lic...
About●   Author of:●   Introduced Linux Trace Toolkit in 1999●   Originated Adeos and relayfs (kernel/relay.c)●   Training...
Agenda●   AOSPs limitations●   Tearing AOSP apart●   Forks●   Ports●   Mods●   Melding with “Classic” Linux Stack●   Headl...
AOSPs limits●   Rigid●   Closed dev model●   Fits Googles prerogatives●   Excludes a lot of stuff●   ... IOW, doesnt alway...
Tearing AOSP apart●   Forks●   Ports●   Mods●   Melds                                 6
Forks●   Cyanogenmod●   Replicant●   MIUI●   Cyborgstack                          7
Cyanogenmod●   After-market handset firmware●   Requires rooted phone●   http://www.cyanogenmod.com●   Advertized features...
9
●   More interestingly:    ●   http://wiki.cyanogenmod.com/    ●   https://github.com/CyanogenMod    ●   Includes Busybox ...
Replicant●   Android distro that is 100% Free Software●   http://replicant.us/●   Includes FDroid free software app store ...
MIUI●   Closed-source fork with slick UI enhancements●   Many translations●   http://en.miui.com/●   Advertized features: ...
13
CyborgstackA truly open, no holds barred Android-based distro              www.cyborgstack.org   “Boldly go where no droid...
What the AOSP does                     15
Where Cyborgstack is going                        16
Goals●   Truly Open development community●   Nothing is off limits    ●   Accept things which will likely never make it to...
Whats there?●   glibc-based rootfs add-ons●   LTTng●   “Headless Android”●   BusyBox                                  18
Ports●   RIM Playbook●   BlueStacks●   Alien Dalvik                           19
RIM Playbook               20
BlueStacks             21
Alien Dalvik (Myriad Group)                       22
Mods●   XDA Developers●   ...                            23
Melding with “Classic” Linux stack1. Rationale2. Roadblocks3. Where do I start?4. Coexistence Approaches5. Been there done...
1. Rationale“Android took GNU out the back door, shot him in the head, and ran away withthe penguin” -- Surely from Tarant...
2. Roadblocks●   Filesystem    ●   Android is non-FHS-compliant●   C library    ●   Bionic vs. glibc●   Interconnect fabri...
3. Where do I start?●   Android-side:    ●   AOSP●   “Linux”-side:    ●   Traditional distro        –   Ubuntu, Fedora, De...
4. Coexistence Approaches●   Single filesystem    ●   Build system integration    ●   Build-time aggregation    ●   Image ...
29
5. Been there done that●   BusyBox in CyanogenMod●   Gstreamer vs. Stagefright●   Dont know how they do it:    ●     Alien...
6. Unresolved / Uncharted●   Binder from glibc●   Intent <-> DBUS bridge●   Running Android apps in X●   Running X apps in...
7. Tools●   GNU cross-development toolchain:    ●   gcc - compiler    ●   as - assembler    ●   ld - linker    ●   gdb/gdb...
8. Embedded Linux Workspace●   Need to organize the components used during    cross-platform development. Workspace layout...
8.1. Workspace env. vars. script●   Complete workspace script (devex)    export PROJECT=emblinux    export PRJROOT=/home/k...
9. Basic root filesystem structure●   Unix FS structured for multi-user systems●   Some directories not necessary for embe...
●   Non-essential multi-user dirs:    ●   /home, /mnt, /opt, /root●   Depends on bootloader:    ●   /boot●   Traditionally...
●   What are all these binaries directories for?    ●   /bin     =>   Essential binaries for user and admin    ●   /sbin  ...
●   To start working on rootfs:    $ cd ${PRJROOT}/rootfs●   Create core rootfs directories:    $ mkdir bin lib sbin usr v...
10. Libraries1.glibc2.uClibc                           39
10.1. glibc●   glibc components:    ●   Actual shared libraries:        –   Format: libLIB_NAME-GLIBC_VER.so        –   Ex...
●   For target, need:    ●   The actual shared libs    ●   The major revision version symbolic links●   Also need dynamic ...
●   Most important components:    ●   ld     =>   the dynamic linker    ●   libc   =>   the C library    ●   libm =>     t...
●   Copying all libraries:    $ cp -d [CODESOURCERY_DIR]/arm-none-linux-gnueabi/libc/lib/*     > ${PRJROOT}/rootfs/lib●   ...
10.2. uClibc●   Same naming conventions as glibc●   Implements most of the glibc components:    ●   ld, libc, libcrypt, li...
11. Main system applications●   Unix systems rely on a common set of commands●   Standard distros have one binary per comm...
11.1. BusyBox●   Main package used in embedded Linux to provide    core set of Unix commands: busybox.net     [, [[, acpid...
●   Download BusyBox (1.18.3) to your $    {PRJROOT}/sysapps directory and extract it there.●   Move to the directory for ...
48
●   “Busybox Settings”:    ●   “Build Options” -> Cross-compiler prefix:               ${TARGET}-    ●   “Installation Opt...
12. Demos●   All:    ●   AOSP    ●   BYO glibc-based rootfs●   Demo 1: BusyBox●   Demo 2: Client-Server app talking throug...
12.1. Demo 1 - BusyBox●   Configure, build and “install” BusyBox●   Get it copied into final RAM disk image●   Modify AOSP...
12.2. Demo 2 – Client/Server                        52
12.3. Demo 3 – LTTng●   Patch kernel●   Cross-build ltt-ctl●   Modify AOSP to log to LTTng                                ...
Headless Android               +                    =“And then GNU came back for revenge ...”-- Tarantinos sequel         ...
Androids display architecture                         55
How to decapitate Android●   Disable:    ●   SurfaceFlinger    ●   WindowManager    ●   WallpaperService    ●   InputMetho...
Whats in there?●   Most everything Android gives you:    ●   No UX    ●   Fully-integrated Eclipse IDE    ●   SDK/NDK    ●...
Thank you ...karim.yaghmour@opersys.com     @karimyaghmour                         58
