Implementation of Digital Filters

                Elena Punskaya
         www-sigproc.eng.cam.ac.uk/~op205


            ...
Filter Implementation

• Discussed: How to design digital filters

          • How do you implement them in
            pr...
Direct form I Implementation


 Any FIR/IIR Filter



                                            If N≠M just put
        ...
Constraints


However, one usually has severe
  – speed constraints
  – power constraints



       direct implementation ...
Addressing speed/power concerns


• Reduce total number of operations

• In particular, multiplications might take longer ...
Advantages of the Alternative Structures

• For each given transfer function, there are many
  potential realization struc...
Structures for FIR Filters
• Implementation of FIR filters is far more straightforward
  than IIR filters

• General FIR f...
Linear Phase FIR with symmetric taps

• However, FIR filters are often designed to have linear
  phase, and the symmetry i...
Structure of IIR Filters*

   • We are interested in implementing

   • Direct Form I implementation




                 ...
Parallel Structure of IIR Filter


• The idea: rewrite         as a sum of filters




• Parallel Structure for K = 2




...
Example 1: Parallel Structure of IIR Filter

• Consider the following transfer function




• Partial fraction expansion l...
Example 1: Parallel Structure of IIR Filter

• Recombine the last two terms




                  parallel structure with ...
Example 2: Parallel Structure of IIR Filter

• Consider the following transfer function




• The denominator admits 3 roo...
General Procedure to Obtain a Parallel Structure


  • Decompose H(z) using a partial fraction expansion

  • Combine any ...
Main Characteristics of the Parallel Structure

•   Simple to implement

•   Sometimes has an advantage over the cascade r...
Cascade Structure of IIR Filter

• The idea: rewrite the transfer function as a product of filters




• Cascade Structure...
Back to Example 1: Cascade Structure


• The following transfer function was considered




• Decompose as




           ...
Back to Example 2: Cascade Structure

• The following transfer function was considered




• The denominator admits 3 root...
General Procedure to Obtain Cascade Structure


  • Compute the poles and zeros of H(z)

  • Combine any pair of complex c...
Sensitivity to coefficient quantisation

• The filter coefficients are quantised
              errors in coefficient value...
Example: Sensitivity to coefficient quantisation

• Direct form filter would have the following denominator
  polynomial i...
Useful Tips

• Each complex root, with its inevitable conjugate, can
  be implemented by a single second-order section

• ...
Filters with Zeros on the Unit Circle

• Many filters (FIR and IIR) have zeros on the unit
  circle
• Biquadratic section ...
Feedback Structure of IIR Filter

Two filters H1(z) and H2(z) in a feedback structure




       Transfer function of a fe...
Example: Feedback Structure Transfer Function

 More complex structure




Similar technique:
  feedback network


  outpu...
Example: Feedback Structure Transfer Function

Quite complex




A far simpler way: to rearrange the system so that it
   ...
IIR Direct Forms


• Direct From I –
  considered already




• Direct Form II – standard alternative



                 ...
Direct Form II

Implementing transfer function



Set it as a cascade of two:




                     can be realized wit...
Direct Form II
                                               parallel
Putting it all together
                           ...
Example of Direct Form II realisation

Consider the third-order IIR transfer function




feedback




                   ...
Finite-Precision Number Representation



•   In a computer, numbers are represented as combinations of a finite
    numbe...
Fixed-point representation

The magnitude of the number is expressed in powers of 2, with the
binary point separating posi...
Overflow


• If the result of any calculation in the filter exceeds its
  number range          overflow occurs.

• By def...
Strategies to avoid overflow


Two strategies exist

• scaling - to ensure that values can never (or hardly
  ever) overfl...
Saturation arithmetic


• First, the results of all calculations are to full precision.
  For example, the addition of 2 (...
Saturation arithmetic

Instead of merely masking the true result to a (B,A),
overflow is detected and the maximum possible...
Scaling


l1 scaling
Assume that the input to a filter is bounded by

Then its output is bounded by



             where ...
l1 scaling

  Bounded input                bounded output



  If the maximum permissible output magnitude is D,
  overflo...
Alternative scaling



The input signal which gives rise to the largest
possible output is unlikely to occur in practice, ...
l2 scaling

Choose less conservative scaling based on the scale
factor




          which is the root mean square impulse...
Frequency-response scaling

Suppose frequency response of the filter is

  a sine wave of frequency ω and peak amplitude C...
Application of scaling to cascade and parallel
                     realisations
•   At each step, you must compute the im...
Roundoff (quantisation) noise generation

The output of a multiplier has more bits than its inputs
(for example, a 16 by 1...
Roundoff (quantisation) noise assumptions


• It is often assumed that the quantisation noise at
  each multiplier output ...
Roundoff (quantisation) noise in FIR and IIR filters

As a result:

• The quantisation noise from the multipliers of an FI...
Roundoff (quantisation) noise


Roundooff noise level is affected by data
wordlengths, filter response, filter structure a...
Limit cycles
Zero-input limit cycles are self-sustaining oscillations, caused by the
rounding of the results of computatio...
Limit cycles

•   Limit cycles are troublesome in some applications, especially
    with short data wordlengths, where the...
Deadbands

•   Consider a simple digital low-pass filter such as is commonly
    used for smoothing:

•   The transfer fun...
Coefficient quantisation


• In a previous section we showed that the cascade
  form is much less sensitive to coefficient...
Coefficient quantisation

•   A traditional way to study the relative merits of different filter
    structures was to ana...
Coefficient quantisation


•   In dedicated hardware, such as custom ICs, where there are
    significant benefits from re...
53
Thank you!
