Service Oriented Development with Windows Communication Foundation Jason Townsend

Jason Townsend
President, Bartlesville .NET User Group
Sr. Analyst, ConocoPhillips
11+ Years Development Experience
Father of 4 beautiful children
Competitive Sailor

Evolution of Service Orientation

Object-Oriented
Polymorphism
Lets you treat derived class members just like their parent class' members.
Process of using an operator or function in different ways for different set of inputs given.
The ability of objects belonging to different types to respond to method calls of the same name, each one according to an appropriate type-specific behavior.
Encapsulation
Often used interchangeably with information hiding.
Reduces software development risk by shifting the code's dependency on an uncertain implementation (design decision) onto a well-defined interface.
Subclassing
Subclass is a class that inherits some properties from its superclass.

Component-Based
Interface-based
Insists that Interfaces are to be added to components.
The entire system is thus viewed as Components and the interfaces that helps them to coact.
Dynamic Loading
Dynamic loading is a mechanism by which a computer program can, at runtime, load a library (or other binary) into memory, retrieve the addresses of functions and variables contained in the library, execute those functions or access those variables, and unload the library from memory.
Runtime Metadata
Enabled the ability to build systems that dynamically loaded and bound to new functionality at runtime.

Service-Oriented
Message-based
Communication is made by the sending of messages to recipients.
Forms of messages include function invocation, signals, and data packets.
Schema and Contract
Use schema to describe the structure of messages
Use contract to define acceptable message exchange patterns.
Binding via Policy
Use policy to define service semantics used for binding.

Tenets of Service Orientation

Boundaries are Explicit
Based on the underlying concept of encapsulation, this tenet specifies the publishing and consumption of functionality as sets of services that abstract their underlying implementation.
With WCF, the attribute-based programming enables developers to explicitly define external service contracts. Without explicitly defining these, nothing within the class will be exposed publicly.
WCF provides an opt-in model for explicitly defining service boundaries.

Autonomous Evolution
Services are Autonomous.
Autonomy
We design the system to support the inevitable evolution of the service’s implementation over time. As we build our services, we need to assume that their internal implementation will evolve (become versioned) over time and that our services as well as the services on which we depend could change location at (almost) any time.

Share Schema & Contract, Not Class
Services share schema and contract, not class.
This is how ASMX works.
Service publishes a contract (WSDL, XSD)
No types are shared between service and its client (by default)
Neither service requires knowledge of each others’ internal workings in order to exchange data.

Compatibility Based on Policy
Service compatibility is determined based on policy.
Services communicate through dynamically negotiated communications channels that support the necessary semantics.
Service policy statements created automatically based on configuration, class attributes, and method signatures.
Client channels automatically configured via retrieved service policy.

Why Service Orientation?
Facilitates loosely coupled standards based integration.
Enables independence in deployment, versioning, and management of the client (caller) and the server (called).
Promotes reuse of application investments over time.

WCF Design Goals

WS-*
Used as a reference to many web service based standards covering topics such as:
XML Specifications
Messaging Specifications
Metadata Exchange Specifications
Security Specifications
Privacy
Reliable Messaging Specifications
Resource Specifications
Web Services Interoperability organization (WS-I) Specifications
Business Process Specifications
Transaction Specifications
Management Specifications

XML Specifications
XML (eXtensible Markup Language)
XML Namespaces
XML Schema
XPath
XQuery
XML Information Set
XInclude
XML Pointer

Messaging Specifications
Simple Object Access Protocol (SOAP)
SOAP Message Transmission Optimization Mechanism
WS-Notification
WS-BaseNotification
WS-Topics
WS-BrokeredNotification
WS-Addressing
WS-Transfer
WS-Eventing
WS-Enumeration

Metadata Exchange Specifications
WS-Policy
WS-PolicyAssertions
WS-PolicyAttachment
WS-Discovery
WS-Inspection
WS-MetadataExchange
Universal Description, Discovery, and Integration (UDDI)
WSDL 2.0 Core
WSDL 2.0 SOAP Binding
Web Services Semantics (WSDL-S)
WS-Resource Framework (WSRF)

Security Specifications
WS-Security
XML Signature
XML Encryption
XML Key Management (XKMS)
WS-SecureConversation
WS-SecurityPolicy
WS-Trust
WS-Federation
WS-Federation Active Requestor Profile
WS-Federation Passive Requestor Profile
Web Services Security Kerberos Binding
Web Single Sign-On Interoperability Profile
Web Single Sign-On Metadata Exchange Protocol
Security Assertion Markup Language (SAML)
XACML

Privacy
P3P
Reliable Messaging
WS-ReliableMessaging
WS-Reliability
WS-RM Policy Assertion

Resource Specifications
Web Services Resource Framework
WS-BaseFaults
WS-ServiceGroup
WS-ResourceProperties
WS-ResourceLifetime
WS-Transfer
Resource Representation SOAP Header Block

Web Services Interoperability Organization (WS-I) Specifications
WS-I Basic Profile
WS-I Basic Security Profile
Simple Soap Binding Profile

Business Process Specifications
WS-BPEL
WS-CDL
Web Services Choreography Interface
WS-Choreography
XML Process Definition Language

Transaction Specifications
WS-BusinessActivity
WS-AtomicTransaction
WS-Coordination
WS-CAF
WS-Transaction
WS-Context
WS-CF

Management Specifications
WS-Management
WS-Management Catalog
WS-ResourceTransfer
WSDM

WCF Make WS-* Easy
Binding selection abstracts WS-* internals
WCF has Oasis Standard Bindings (3.5)
Single Object model for
Transports
Choreographies
Message Exchange Patterns (MEPs)
Etc…

REST
Focus is on the URI
HTTP GET http://dog.com/dogs.id/12
HTTP POST http://dog.com/updateDog
GET is special, other verbs are application specific
GET verb always means “View It”
PUT/POST/DELETE mean “Do It” but depend on client implementation
Content Type is the data model
XML
JSON
Binary
Etc...
Support built on via WCF extensibility points

WS-* versus REST
Which is better?
Each has strengths:
REST: proliferation of clients, easy to understand
Flash
Silverlight
Javascript
Etc…
WS-*: rich Messaging Exchange patterns, Topologies, and Choreographies

WCF Architecture (Application)

Messaging
WS Security Channel
WS Reliable Messaging Channel
Encoders: Binary/MTOM/Text/XML
HTTP Channel
TCP Channel
Transaction Flow Channel
NamedPipe Channel
MSMQ Channel

Communicating through Messages
Messages travel between communication parties
Messages can be grouped into different message exchange patterns (MEPs)
MEPs can be implemented synchronously or asynchronously
WCF supports different MEPs
WCF MEPs implemented by different kinds of channels

Channel Shaping (Message Exchange Patterns)
Possible mismatch:
Physical transport
Logical message exchange patterns
Channel shapes implemented in transport bindings
Express support for Message Exchange Patterns
WCF ServiceModel analyzes contract
Which channel shapes will be supported?
ServiceChannelFactory.BuildChannelFactory and DispatcherBuilder.GetSupportedChannelTypes have the details

Contracts
Service Contract
Operations
Behaviors
Communication Shape
Data Contract
Schema and Versioning Strategy
Message Contract
Application specific headers and unwrapped body content
Policy and Binding

Contracts (Request-Reply)
Most commonly used MEP
It is easy to use and looks natural
R/R can be implemented in WCF by several approaches
Parameter list
DataContract
MessageContract
Message
Mind the “public face” of contracts, i.e. the metadata

Contracts (One-Way)
One Way operations smell more feasible when decoupling is goal
No return values, rather void
Use IsOneWay property of OperationContract
OneWay operations can still block
Not really fire-and-forget semantics

Contracts (Duplex)
Having peer communication parties
Blurring the line between client and server
Use CallbackContract property of ServiceContract
Operations in contracts can be one-way, but need no to be
If using non-one-way beware of threading issues

Contracts (Streaming)
Buffered communication can be very expensive with large data
WCF offers streamed transfer
Contract parameters must have certain shape
Use Message, IXmlSerializable or System.IO.Stream or derivate as type
Use MessageContract
Headers will be buffered
Body as System.IO.Stream will be streamed
Only works with appropriate binding

Transport Protocols (Bindings)
HTTP
TCP
MSMQ
More can be added through built-in extension points.

Bindings (Request-Reply)
Almost all out-of-the-box bindings support request-reply
MSMQ-based bindings do not
For all bindings and MEPs:
Beware of default min/max values on binding elements for e.g. message sizes and buffers and timeouts
Beware of possible throttles on service behavior

Bindings (One-Way)
All bindings support one-way operations
Use OneWayBindingElement for custom bindings to shape channel
Performs a message-level shape change
Can take a IDuplexSessionChannel or a IRequestChannel and expose it as a IOutputChannel, or conversely it can take a IDuplexSessionChannel or a IReplyChannel and expose it as a IInputChannel

Bindings (Duplex)
Duplex out-of-the-box
netTcp
wsDualHttp
netNamedPipe
netPeerTcp
Manual duplex session-less, e.g.
<compositeDuplex />
<oneWay />
<binaryMessageEncoding />
<httpTransport />

Bindings (Streaming)
Enable streaming on the baked-in bindings
All standard bindings besides MSMQ-based
Enable streaming on the transport binding element, e.g.
<httpTransport transferMode=„Streamed“ />
Possible transferMode values
Buffered
Streamed
StreamedRequest
StreamedResponse
Only transport security and no reliable sessions allowed

MSMQ Transport
MSMQ is different – always has been
Duplex Message Exchange Pattern over MSMQ-based binding can be achieved manually:
Leverage message headers
Access headers through OperationContext in user code
Access headers through message inspectors in ServiceModel extensions
Use GUID to correlate messages

Service Runtime
Throttling Behavior
Error Behavior
Metadata Behavior
Instance Behavior
Message Inspection
Transaction Behavior
Dispatch Behavior
Concurrency Behavior
Parameter Filtering

WCF Reliability and Transactions
End-to-End Reliable Messaging
In-Order guarantees
Exactly once guarantees
Transport-Independent Sessions
Integration with ASP.NET Sessions in IIS-Hosted compatibility mode
Transactions
Guaranteed atomic success or failure across services

WCF Instancing, Concurrency, and Sessions
Service classes can be instantiated
Singleton
Per-Call
Per-Session
Shareable
Service code can be either:
Single-threaded
Re-entrant
Multi-threaded

WCF Security
Claims based end-to-end security
Secure end-to-end message exchanges
Secure access to resources
Record resource access requests
X509, Username/Password, Kerberos, SAML, and custom credentials
Message Security
Confidentiality and Integrity
Transport or Message Level
Access to resources
Authentication and Authorization

Hosting and Activation
Windows Activation Service/IIS
.EXE
Windows Services
COM+

WCF Offers Features You Need
Logging
Tracing
Instance Control
Throttling
Rich Configuration
Extensibility
Hosting Options
And More….

WCF Summary
WCF is the future of distributed computing
It combines the best of all existing Microsoft distributed computing stacks
It uses WS-* standards for interoperability and .NET value-add for performance and integration with existing solutions.

Further Resources
My Blog
http://www.okcodemonkey.com
Linkedin
http://www.linkedin.com/in/okcodemonkey
Bartlesville .NET User Group
http://www.bdnug.com
Twitter
http://twitter.com/okcodemonkey
Email
[email_address]

Key Terms

Message
A message is a self-contained unit of data that may consist of several parts, including a body and headers.

Service
A service is a construct that exposes one or more endpoints, with each endpoint exposing one or more service operations.

Endpoint
An endpoint is a construct at which messages are sent or received (or both). It comprises a location (an address) that defines where messages can be sent, a specification of the communication mechanism (a binding) that described how messages should be sent, and a definition for a set of messages that can be sent or received (or both) at that location (a service contract) that describes what message can be sent.
An WCF service is exposed to the world as a collection of endpoints.

Application Endpoint
An endpoint exposed by the application and that corresponds to a service contract implemented by the application.

Infrastructure Endpoint
An endpoint that is exposed by the infrastructure to facilitate functionality that is needed or provided by the service that does not relate to a service contract. For example, a service might have an infrastructure endpoint that provides metadata information.

Address
An address specifies the location where messages are received. It is specified as a Uniform Resource Identifier (URI). The URI schema part names the transport mechanism to use to reach the address, such as HTTP and TCP. The hierarchical part of the URI contains a unique location whose format is dependent on the transport mechanism.
The endpoint address enables you to create unique endpoint addresses for each endpoint in a service, or under certain conditions share an address across endpoints. The following example shows an address using the HTTPS protocol with a non-default port:
HTTPS://okcodemonkey:8080/Service/MonkeyService

Binding
A binding defines how an endpoint communicates to the world. It is constructed of a set of components called binding elements that "stack" one on top of the other to create the communication infrastructure. At the very least, a binding defines the transport (such as HTTP or TCP) and the encoding being used (such as text or binary). A binding can contain binding elements that specify details like the security mechanisms used to secure messages, or the message pattern used by an endpoint. For more information, see Configuring Services.

Binding Element
A binding element represents a particular piece of the binding, such as a transport, an encoding, an implementation of an infrastructure-level protocol (such as WS-ReliableMessaging), or any other component of the communication stack.

Behaviors
A behavior is a component that controls various run-time aspects of a service, an endpoint, a particular operation, or a client. Behaviors are grouped according to scope: common behaviors affect all endpoints globally, service behaviors affect only service-related aspects, endpoint behaviors affect only endpoint-related properties, and operation-level behaviors affect particular operations. For example, one service behavior is throttling, which specifies how a service reacts when an excess of messages threaten to overwhelm its handling capabilities. An endpoint behavior, on the other hand, controls only aspects relevant to endpoints, such as how and where to find a security credential.

System-Provided Bindings

Configuration versus Coding
Control of an application can be done either through coding, through configuration, or through a combination of both. Configuration has the advantage of allowing someone other than the developer (for example, a network administrator) to set client and service parameters after the code is written and without having to recompile. Configuration not only enables you to set values like endpoint addresses, but also allows further control by enabling you to add endpoints, bindings, and behaviors. Coding allows the developer to retain strict control over all components of the service or client, and any settings done through the configuration can be inspected and if needed overridden by the code.

Service Operation
A service operation is a procedure defined in a service's code that implements the functionality for an operation. This operation is exposed to clients as methods on a WCF client. The method may return a value, and may take an optional number of arguments, or take no arguments, and return no response. For example, an operation that functions as a simple "Hello" can be used as a notification of a client's presence and to begin a series of operations.

Service Contract
The service contract ties together multiple related operations into a single functional unit. The contract can define service-level settings, such as the namespace of the service, a corresponding callback contract, and other such settings. In most cases, the contract is defined by creating an interface in the programming language of your choice and applying the ServiceContractAttribute attribute to the interface. The actual service code results by implementing the interface.

Operation Contract
An operation contract defines the parameters and return type of an operation. When creating an interface that defines the service contract, you signify an operation contract by applying the OperationContractAttribute attribute to each method definition that is part of the contract. The operations can be modeled as taking a single message and returning a single message, or as taking a set of types and returning a type. In the latter case, the system will determine the format for the messages that need to be exchanged for that operation.

Message Contract
A message contract describes the format of a message. For example, it declares whether message elements should go in headers versus the body, what level of security should be applied to what elements of the message, and so on.

Fault Contract
A fault contract can be associated with a service operation to denote errors that can be returned to the caller. An operation can have zero or more faults associated with it. These errors are SOAP faults that are modeled as exceptions in the programming model.

Data Contract
The data types a service uses must be described in metadata to enable others to interoperate with the service. The descriptions of the data types are known as the data contract, and the types can be used in any part of a message, for example, as parameters or return types. If the service is using only simple types, there is no need to explicitly use data contracts.

Hosting
A service must be hosted in some process. A host is an application that controls the lifetime of the service. Services can be self-hosted or managed by an existing hosting process.

Self-Hosted Service
A self-hosted service is one that runs within a process application that the developer created. The developer controls its lifetime, sets the properties of the service, opens the service (which sets it into a listening mode), and closes the service.

Hosting Process
A hosting process is an application that is designed to host services. These include Internet Information Services (IIS), Windows Activation Services (WAS), and Windows Services. In these hosted scenarios, the host controls the lifetime of the service. For example, using IIS you can set up a virtual directory that contains the service assembly and configuration file. When a message is received, IIS starts the service and controls its lifetime.

Instancing
A service has an instancing model. There are three instancing models: "single," in which a single CLR object services all the clients; "per call," in which a new CLR object is created to handle each client call; and "per session," in which a set of CLR objects are created, one for each separate session. The choice of an instancing model depends on the application requirements and the expected usage pattern of the service.

Client Application
A client application is a program that exchanges messages with one or more endpoints. The client application begins by creating an instance of a WCF client and calling methods of the WCF client. It is important to note that a single application can be both a client and a service.

Channel
A channel is a concrete implementation of a binding element. The binding represents the configuration, and the channel is the implementation associated with that configuration. Therefore, there is a channel associated with each binding element. Channels stack on top of each other to create the concrete implementation of the binding: the channel stack.

WCF Client
A WCF client is a client-application construct that exposes the service operations as methods (in the .NET Framework programming language of your choice, such as Visual Basic or Visual C#). Any application can host a WCF client, including an application that hosts a service. Therefore, it is possible to create a service that includes WCF clients of other services.
A WCF client can be automatically generated by using the ServiceModel Metadata Utility Tool (Svcutil.exe) and pointing it at a running service that publishes metadata.

Metadat
The metadata of a service describes the characteristics of the service that an external entity needs to understand to communicate with the service. Metadata can be consumed by the ServiceModel Metadata Utility Tool (Svcutil.exe) to generate a WCF client and accompanying configuration that a client application can use to interact with the service.
The metadata exposed by the service includes XML schema documents, which define the data contract of the service, and WSDL documents, which describe the methods of the service.
When enabled, metadata for the service is automatically generated by WCF by inspecting the service and its endpoints. To publish metadata from a service, you must explicitly enable the metadata behavior.

Security
Security in WCF includes confidentiality (encryption of messages to prevent eavesdropping), integrity (the means for detection of tampering with the message), authentication (the means for validation of servers and clients), and authorization (the control of access to resources). These functions are provided by either leveraging existing security mechanisms, such as TLS over HTTP (also known as HTTPS), or by implementing one or more of the various WS-* security specifications.

Transport Security Mode
Security can be provided by one of three modes: transport mode, message security mode, and transport with message credential mode. The transport security mode specifies that confidentiality, integrity, and authentication are provided by the transport layer mechanisms (such as HTTPS). When using a transport like HTTPS, this mode has the advantage of being efficient in its performance, and well understood because of its prevalence on the Internet. The disadvantage is that this kind of security is applied separately on each hop in the communication path, making the communication susceptible to a "man in the middle" attack.

Message Security Mode
Message security mode specifies that security is provided by implementing one or more of the security specifications. Each message contains the necessary mechanisms to provide security during its transit, and to enable the receivers to detect tampering and to decrypt the messages. In this sense, the security is encapsulated within every message, providing end-to-end security across multiple hops. Because security information becomes part of the message, it is also possible to include multiple kinds of credentials with the message (these are referred to as claims). This approach also has the advantage of enabling the message to travel securely over any transport, including multiple transports between its origin and destination. The disadvantage of this approach is the complexity of the cryptographic mechanisms employed, resulting in performance implications.

Transport with Message Credential Security Mode
This mode uses the transport layer to provide confidentiality, authentication, and integrity of the messages, while each of the messages can contain multiple credentials (claims) required by the receivers of the message.

WS-*
Shorthand for the growing set of Web Service (WS) specifications, such as WS-Security, WS-ReliableMessaging, and so on, that are implemented in WCF.

http://www.okcodemonkey.com	15
http://geekswithblogs.net	12
http://okcodemonkey.com	12
http://www.slideshare.net	1

Service Oriented Development With Windows Communication Foundation Tulsa Dnug

by Jason Townsend

Accessibility

Categories

Upload Details

Usage Rights

4 Embeds 40

Statistics

Service Oriented Development With Windows Communication Foundation Tulsa Dnug Presentation Transcript
