  • 1. Using Zend_Tool to Establish Your Project's Skeleton DFW Apache LAMP Group presented by Jeremy Brown, ZCE 1 Feb 2010
  • 2. Housekeeping
  • 3. Who Am I?
    • Jeremy Brown, Zend Certified Engineer (ZCE)
    • Have been using PHP since 1999 (PHP 3)
    • Have been using Zend Framework since 2008 (version 1.0.4)
    • Software Architect / Team Lead at Spear One (spearone.com)
  • 4. Contact Information
    • Blog: notmessenger.com
    • Twitter: twitter.com/notmessenger
    • Email: jeremy@notmessenger.com
    • IRC: #zftalk and #dallasphp (irc.freenode.net)
  • 5. Where to find this presentation
    • On my blog
      • notmessenger.com/presentations
    • Slideshare.net
      • <insert link here>
  • 6. How to provide feedback
    • Via Joind.in
      • http://joind.in/event/view/136
  • 7. Your turn – who are you?
    • How many of you have heard of Zend Framework before?
  • 8. Your turn – who are you?
    • How many of you have heard of Zend Framework before?
    • How many of you have played with it a little bit?
  • 9. Your turn – who are you?
    • How many of you have heard of Zend Framework before?
    • How many of you have played with it a little bit?
    • How many of you use it in a project or on a regular basis?
  • 10. Groundwork
  • 11. What is Zend Framework
    • An open source, object-oriented web application framework implemented in PHP 5
    • All components are fully object-oriented PHP 5 and are E_STRICT compliant
    • Use-at-will architecture with loosely-coupled components and minimal interdependencies
    • Provides individual components for many common requirements in web application development
  • 12. So what is Zend_Tool?
    • Zend_Tool is both rapid application development (RAD) tools as well as a framework for exposing your own set of tooling needs to the Zend_Tool user interface.
  • 13. So what is Zend_Tool?
    • Zend_Tool is both rapid application development (RAD) tools as well as a framework for exposing your own set of tooling needs to the Zend_Tool user interface.
    • No, really, what is Zend_Tool?
  • 14. Basic structure of a ZF application … OR…
  • 15. Where’s the beef?
    • Main Classes & APIs:
      • Zend_Tool_Framework
        • The component responsible for dispatching tooling requests
      • Zend_Tool_Project
        • The component responsible for exposing the “project specific” tooling capabilities
    Inspired by talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 16. Where’s the beef?
    • Main Classes & APIs:
      • Zend_Tool_Framework
        • The component responsible for dispatching tooling requests
      • Zend_Tool_Project
        • The component responsible for exposing the “project specific” tooling capabilities
    • And the gravy…
    • Supporting Classes & APIs:
      • Zend_CodeGenerator
      • Zend_Reflection
    Inspired by talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 17. Zend_Tool_Framework
  • 18. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework
      • Dispatch-style framework, designed to abstract enough system internals to make extensibility easy
        • “ Flexibility of the tooling dispatch over speed of tooling dispatch”
      • Broken down into logical sub-parts:
        • Client
        • Client storage & configuration
        • Loader
        • Provider & Provider Repository
        • Manifest, Manifest Repository & Metadata
        • System (Built-in) Providers
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 19. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework_Client
      • Responsibilities:
        • Request Object
        • Response Object
        • Interactivity support
        • Setting up the system registry containing all required objects
        • The actual dispatch()-ing
      • First implementation of Zend_Tool_Framework_Client_Console
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 20. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework_Client_Storage & Zend_Tool_Framework_Client_Config
      • Responsibilities:
        • Allowing clients to specify configuration values for the system and providers to use
        • Allowing clients to store artifacts on the filesystem that the system and providers can consume
          • Custom profile files
          • Provider-specific file formats and metadata
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 21. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework_Loader
      • Responsibilities:
        • Load files provided
        • Search for classes defined that implement:
          • Zend_Tool_Framework_Manifest_Interface
          • Zend_Tool_Framework_Provider_Interface
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 22. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework_Provider & Provider Registry
      • Responsibilities:
        • An interface for defining via a class, dispatch-able actions and “specialties”
          • (Similar to how Action Controllers define actions)
        • Registry to maintain instances of all providers available
        • Parsing of provider classes for dispatch-able “signatures”
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 23. Zend_Tool_Framework sub-parts
    • Zend_Tool_Framework_Manifest & Manifest Repository
      • Responsibilities:
        • Manifest can supply a collection of providers, actions and/or metadata
        • Registry provides a way to search for metadata in the manifest
    • Zend_Tool_Framework_Metadata
      • Responsibilities:
        • Primary use case is to attach “data about data” to instance of a specific client, provider, or action
          • ex: alternate names for each provider based on the command line naming scheme, OR short names (p for profile)
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 24. Zend_Tool_Project
  • 25. Zend_Tool_Project sub-parts
    • Zend_Tool_Project_Profile
      • Responsibilities:
        • loading, parsing, serializing and storing a profile file
        • Top most node in a “resource tree”
    • Zend_Tool_Project_Profile_Resource
      • Responsibilities:
        • The class most responsible for the “where” question of project modeling
        • The class most responsible for implementing a node in a “resource tree”
        • Extends Resource_Container which is a RecursiveIterator (tree fundamentals)
        • Can create new Resources at specific locations
        • Can find resources by name and attribute sets
        • Each contains a Zend_Project_Context object
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 26. Zend_Tool_Project sub-parts
    • Zend_Tool_Project_Context
      • Responsibilities:
        • The class most responsible for the “what” part of project modeling
        • It is assigned to a Zend_Tool_Project_Profile_Resource object
        • Example contexts:
          • Controller file
          • View script directory
          • View script file
          • Model file
          • Action method
    From talk by Ralph Schindler of Zend, at ZendCon 2009 http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 27. Putting it all together
  • 28. Putting it all together
    • Zend_Tool_Framework looks for providers, by default, on the include_path
      • It recursivly iterates all include path directories and opens all files that end with “Manifest.php” or “Provider.php”
      • All classes in these files are inspected if they implement either Zend_Tool_Framework_Provider_Interface or Zend_Tool_Framework_Manifest_ProviderManifestable
    • Zend_Tool_Project is consumed by Zend_Tool_Framework
      • This allows Zend_Tool_Project to be only concerned with “project” problems
      • This also allows Zend_Tool_Framework to focus on the problem of knowing which requests are good, and knowing how to dispatch said request
    • Zend_Tool_Framework provides a client to the user
  • 29. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com
    • http://framework.zend.com/manual/en
    • http://framework.zend.com/manual/1.10/en/zend.tool.html
    • http://framework.zend.com/manual/1.10/en/zend.tool.framework.html
    • http://framework.zend.com/manual/1.10/en/zend.tool.project.html
    • http://framework.zend.com/manual/1.10/en/zend.codegenerator.html
    • http://framework.zend.com/manual/1.10/en/zend.reflection.html
    • http://www.slideshare.net/ZendCon/zendtool-practical-use-and-extending
  • 30. Setting things up
  • 31. Install Zend Framework
    • Download Zend Framework
      • From website (http://framework.zend.com)
      • SVN
      • Zend Server
      • From PEAR channel (http://pear.zfcampus.org/)
    • Install it
      • How?
      • Where?
        • For purpose of this presentation, have installed it at C:endFramework-1.9.7
  • 32. Prepare Zend_Tool
  • 33. Understanding the CLI Tool
    • /bin/zf.sh and /bin/zf.bat
      • Operating system specific client wrappers
        • Responsible for finding the proper php.exe, finding the zf.php file, and passing on the client request
    • /bin/zf.php
      • Responsible for:
        • handling the understanding of your environment
        • construction of proper include path
        • passing what is provided on the command line to the proper library component for dispatching
  • 34. Accessing the CLI Tool
    • Two things have to be true:
      • zf.sh/zf.bat is reachable from your system path.
        • This is the ability to call ‘zf’ from anywhere on your command line, regardless of what your current working directory is.
      • ZendFramework/library is in your include path
    • So how do we === true?
  • 35. Make zf.sh/zf.bat reachable from system path
    • Manual’s recommendation:
      • Copy zf.sh/zf.bat and zf.php into the same directory as your PHP binary
        • For *nix, usually:
          • /usr/bin/
          • /usr/local/bin/
          • /usr/local/ZendServer/bin/
          • /Applications/ZendServer/bin
        • For Windows, usually:
          • C:PHP
          • C:Program FilesendServerin
          • C:WAMPPHPin
  • 36. Make zf.sh/zf.bat reachable from system path
    • My recommendation:
      • Create an Alias to zf.sh/zf.bat
        • For *nix:
          • alias zf &quot;/usr/local/Zend/ZendFramework-1.9.7/bin/zf.sh&quot;
          • alias zf &quot;/YOUR_PATH_HERE/bin/zf.sh&quot;
        • For Windows:
          • doskey zf=C:ENDFR~1.7inzf.bat
      • However….
        • On Windows, I could not get the arguments passed to ‘zf’ to be passed along, so….
        • Ended up modifying the environment variable PATH to include C:endFramework-1.9.7in
  • 37. Add ZendFramework/library to include_path
    • Manual’s recommendation:
      • Determine what your current include_path value is and add the contents of ZendFramework/library to one of these locations
      • Alternative option to above:
        • For *nix:
          • In a location included in your current include_path, create a symbolic link to the location of ZendFramework/library
        • For Windows:
          • Modify the environment variable PATH to include C:PATH_TO_ZENDFRAMEWORKin
          • Alter your php.ini file and modify include_path directive to include C:PATH_TO_ZENDFRAMEWORKlibrary
  • 38. Add ZendFramework/library to include_path
    • My recommendation:
      • Use special environment variable(s) to tell zf.php the location of ZendFramework/library
      • They are:
        • ZEND_TOOL_INCLUDE_PATH_PREPEND
          • Will prepend the value of this environment variable to the system (php.ini) include_path before loading the client
        • ZEND_TOOL_INCLUDE_PATH
          • Completely replaces the system include_path with the one specified
      • How to do this:
        • For *nix:
          • setenv ZEND_TOOL_INCLUDE_PATH_PREPEND /usr/local/Zend/ZendFramework-1.9.7/library/
        • For Windows:
          • set ZEND_TOOL_INCLUDE_PATH_PREPEND=C:ENDFR~1.7library
  • 39. Other settable environment variables
    • ZF_HOME
    • ZF_STORAGE_DIR
    • ZF_CONFIG_FILE
    • ZF_INCLUDE_PATH
    • ZF_INCLUDE_PATH_PREPEND
    • Can be found at http://framework.zend.com/manual/en/zend.tool.usage.cli.html
  • 40. Did I set it up correctly?
    • To verify that the previous steps worked correctly, enter ‘zf’ at the command line. Should expect to see something similar to:
  • 41. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/manual/1.10/en/zend.tool.framework.html
    • http://framework.zend.com/manual/1.10/en/zend.tool.usage.cli.html
    • http://framework.zend.com/manual/1.10/en/zend.tool.extending.html
    • http://en.wikipedia.org/wiki/Alias_%28command%29
    • http://www.unix.com/windows-dos-issues-discussions/74664-what-dos-equivalent-alias-command.html
  • 42. Enough with the setup – I’m here for some coding!
  • 43. Few basic things
    • zf --help
    • zf show version
    • zf show version
    • zf show version -n 0
    • zf show version.major-part
    • zf show version -m minor -n 0
  • 44. Create project
    • Provide a path:
      • zf create project demo
    • Be prompted for path:
      • zf create project
  • 45. Create project
    • Provide a path:
      • zf create project demo
    • Be prompted for path:
      • zf create project
    • Can now run:
      • zf show project
      • zf show profile
  • 46. Create Controller
    • Provide a controller name:
      • zf create controller <controllername>
    • Be prompted for a controller name:
      • zf create controller
  • 47. Create Controller Actions
    • zf create action <actioname> <controllername>
      • Will throw a Fatal Error if <controllername> does not exist
  • 48. Create views
    • zf create view <controllername> <actionname>
      • <actionname> is really only for the name of the View Script – a new action is NOT created in the controller
  • 49. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/manual/en/zend.tool.project.create-a-project.html
    • http://framework.zend.com/manual/en/zend.tool.project.providers.html
    • http://ralphschindler.com/wiki/index.php/Using_Zend_Tool
  • 50. Extending Zend_Tool
  • 51. How Zend_Tool finds your Providers
    • Remember that:
    • Zend_Tool_Framework looks for providers, by default, on the include_path
      • It recursivly iterates all include path directories and opens all files that end with “Manifest.php” or “Provider.php”
      • All classes in these files are inspected if they implement either Zend_Tool_Framework_Provider_Interface or Zend_Tool_Framework_Manifest_ProviderManifestable
  • 52. How Zend_Tool finds your Providers
    • The following naming rules apply on how you can access the providers that were found by the IncludePathLoader:
      • The last part of your classname split by underscore is used for the provider name, e.g. “My_Provider_Hello” leads to your provider being accessible by the name “hello”
      • If your provider has a method getName() it will be used instead of the previous method to determine the name
      • If your provider has “Provider” as suffix, e.g. it is called “My_HelloProvider”, it will be stripped from the name so that the provider will be called “hello”.
    • Note: The IncludePathLoader does not follow symlinks. This means you cannot link provider functionality into your include paths, they have to be physically present in the include paths.
  • 53. Example Custom Provider
  • 54. Minimum code needed… /My/Provider/Slide54Provider.php
  • 55. …but we really need some more The previous example illustrates being able to make your newly-created custom provider to be seen by Zend_Tool_Framework, but it really isn’t able to expose any Provider capabilities. What you need instead is: /My/Provider/Slide55Provider.php
  • 56. Provide alternate name for Provider /My/Provider/Slide56Provider.php
  • 57. Example Custom Manifest
  • 58. Minimum code needed /My/Manifest/Slide58Manifest.php
  • 59. Let’s do more with Providers
  • 60. Passing variables to a Provider /My/Provider/Slide60.php
    • Examples of how to call this provider:
      • zf say slide60
      • zf say slide60 Jason
      • zf say slide60 --name Jason
  • 61. Prompt user for input /My/Provider/Slide61.php
  • 62. Pretendability /My/Provider/Slide62.php
    • Examples of how to call this provider:
      • zf say slide62
      • zf --pretend say slide62
  • 63. Verbose /My/Provider/Slide63.php
    • Examples of how to call this provider:
      • zf say slide63
      • zf --verbose say slide63
  • 64. Debug /My/Provider/Slide64.php
    • Examples of how to call this provider:
      • zf say slide64
      • zf --debug say slide64
  • 65. Multiple arguments /My/Provider/Slide65.php
  • 66. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/manual/en/zend.tool.extending.html
    • http://framework.zend.com/manual/en/zend.tool.framework.writing-providers.html
  • 67. Customizing Zend_Tool Console Client
  • 68. Customizing Zend_Tool Console Client
    • Zend_Tool_Framework allows developers to store information, provider-specific configuration values, and custom files in a special location on the developers machine.
    • Items of discussion:
      • Home Directory
      • Local Storage
      • User Configuration
  • 69. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/manual/1.10/en/zend.tool.framework.extending.html
    • http://framework.zend.com/manual/en/zend.tool.framework.writing-providers.html
  • 70. Putting our Providers to work
  • 71. Keep profile up-to-date $this->_loadProfile(); $this->_storeProfile();
  • 72. Context Can extend Zend_Tool_Project_Context_Filesystem_File and Zend_Tool_Project_Context_Filesystem_Directory to create context classes. $profile = $this->_loadProfile(); $modelsDirectory = $profile->search('ModelsDirectory'); $modelFile = $modelsDirectory->createResource('ModelFile'); $modelFile->getContext()->setModelName($name); Excerpts from Zend Webinar presented by Ralph Schindler of Zend http://www.zend.com/en/webinar/framework/webinar-zend-tool-20090630.flv
  • 73. Zend_CodeGenerator Excerpts from Zend Webinar presented by Ralph Schindler of Zend http://www.zend.com/en/webinar/framework/webinar-zend-tool-20090630.flv
  • 74. Integration with Zend_Application Excerpts from Zend Webinar presented by Ralph Schindler of Zend http://www.zend.com/en/webinar/framework/webinar-zend-tool-20090630.flv
  • 75. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/manual/en/zend.tool.extending.html
    • http://www.zend.com/en/webinar/framework/webinar-zend-tool-20090630.flv
  • 76. Where do things go from here?
  • 77. Known plans
  • 78. Roadmap
    • Zend Framework 1.10 offers
      • Model Provider
      • Form Provider
      • DbTable Provider
      • DbAdapter configuration
      • Layout enabling and creation
      • Custom Profiles
      • Improved Module Provider
      • … and more!
    • In the works
      • Web interface
      • Better documentation
    • Have hopes for
      • Apache configuration code generator
  • 79. Using for your own needs
  • 80. The sky’s the limit
    • Don’t have to use it for just a “project”
    • How Spear One has begun, and plans, on using Zend_Tool
  • 81. Improving Zend_Tool
  • 82. Public Service Announcement
    • Play with it and use it
    • Submit bugs and feature requests
      • http://framework.zend.com/issues/browse/ZF/component/10380
    • Get involved in the community
      • Write a blog post
      • Visit #zftalk on irc.freenode.net
      • Become a contributor
        • Fix bugs
        • Implement new feature set
        • Improve documentation
  • 83. Additional Resources
    • In relation to the information presented in this section
    • http://framework.zend.com/issues/browse/ZF/component/10380
    • http://framework.zend.com/issues/browse/ZF-7940
    • http://ralphschindler.com/wiki/index.php/Using_Zend_Tool
  • 84. Thank you!
  • 85. Contact Information
    • Blog: notmessenger.com
    • Twitter: twitter.com/notmessenger
    • Email: jeremy@notmessenger.com
    • IRC: #zftalk and #dallasphp
    • Where to find presentation
      • notmessenger.com/presentations
      • <insert slideshare.net link here>
    • Please rate this talk on Joind.in
      • http://joind.in/event/view/136
