INTRODUCTION TO FULL TOUCH UIFOR SERIES 40Andreas Jakl [@mopius]Technology Wizard, Nokia 1     © 2012 Nokia Introduction t...
CONTENTS• Introduction     – Platforms & Versions• New features for developers     –   UI     –   LWUIT     –   Text Input...
WHAT’S NEW?              Productivity Tools                                                                    Documentati...
PLATFORMSAPI Differences: bit.ly/S40Apis5th Ed., FP1    6th Ed., Lite            6th Ed.               6th Ed., FP1       ...
DP 2.0 – NEW APIS         Full touch                                        Virtual                                 Multip...
NOKIA IDE FOR JAVA ME(NetBeans is supported as well)         Integrated SDK + Toolchain                                   ...
USER INTERFACE7   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
UX GUIDELINES• Design    – Layouts    – Interaction patterns    – Icon templates    – developer.nokia.com/Design/8      © ...
FULL TOUCH UI                                                                                     View title              ...
ICONCOMMAND                                                                                                         Action...
Example: JavaTouchUSING: ICONCOMMANDpublic class JavaFTMidlet extends MIDlet implements CommandListener {    private Form ...
CATEGORYBAR• View switching     – One element always highlighted     – Mandatory & automatic back button• Icons     – Max:...
CATEGORYBAR• Back     – Traditional back Command in Form          – Visible w/o CategoryBar                               ...
Example: JavaTouchUSING: CATEGORYBAR     public class JavaFTMidlet extends MIDlet implements CommandListener, ElementListe...
Example: JavaTouchORIENTATION• Portrait (default)     – Nokia-MIDlet-App-Orientation:       portrait• Landscape: landscape...
Example: JavaTouchORIENTATION     – Adapt content orientation       to phone / display       public void displayOrientatio...
Example: PaintAppSTATUS ZONE• Show status zone in full screen app     public class MainCanvas extends Canvas     {        ...
LWUIT• Stylable UI Components     – From Oracle: lwuit.java.net• Optimized for Nokia     – Native look & feel     – Uses N...
TEXT INPUT19   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
VIRTUAL KEYBOARD• Use on-screen keyboard on Canvas      – Creates keyPressed() callbacks                                  ...
Example: PaintAppUSING: VIRTUAL KEYBOARD• Show keyboard     CustomKeyboardControl vkbControl = VirtualKeyboard.getCustomKe...
Example: PaintAppUSING: VIRTUAL KEYBOARD     public class MainCanvas extends Canvas implements KeyboardVisibilityListener ...
TEXTEDITOR• Text entry on a Canvas (custom UI)      – MIDP: only fullscreen TextBox      – Create own editor – not easy!• ...
Example: CanvasTextEditorUSING: TEXT EDITOR• Create text editor with Canvas as parent     // Create the text editor: no in...
Example: CanvasTextEditorUSING: TEXT EDITOR• Show & hide text editor in the Canvas     protected void pointerPressed(int x...
Example: CanvasTextEditorUSING: TEXT EDITOR• Draw text when TextEditor not active / visible     protected void paint(Graph...
TOUCH INPUT27   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
Example: KeyAnalyzerAUTOMATIC KEY SIMULATION• No touch handling in Canvas?     – Drag gestures      automatically trigger ...
TOUCH GESTURES• Use in: Canvas-/CustomItem-based classes      – Optional: combine with Frame Animator API (kinetic scrolli...
Example: PaintAppUSING: GESTURES• Register as gesture listener      public class MainCanvas extends Canvas implements Gest...
Example: PaintAppUSING: GESTURES• Handling gesturespublic void gestureAction(Object container, GestureInteractiveZone gest...
MULTIPOINT TOUCH• Single touch     – Canvas.pointerPressed() part of MIDP     – Only tracks 1st touch point• Multipoint To...
Example: PaintAppUSING: MULTIPOINT TOUCH• Number of touch points                                                          ...
Example: PaintAppUSING: MULTIPOINT TOUCH• Handling touch events     public void pointersChanged(int[] pointerIds) {       ...
TOUCH SIMULATION• Record multipoint touch gestures     – One touchpoint at a time• Replay35      © 2012 Nokia Introduction...
SENSORS36   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
SENSORS• JSR 256 Sensor API     – Generic: designed also for temperature, blood pressure, etc.     – Also available on Sym...
FINDING SENSORS          Application                      SensorManager                           SensorInfo       Connect...
SENSOR VALUES• Modes     – Synchronous        – Poll sensor        – Example: accelerometer in game loop     – Asynchronou...
Example: MovingBallUSING: SENSORS• Establish sensor connection     // Find all acceleration sensors, the contextType is le...
LOCATION41   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
Example: mapExampleCELL ID POSITIONING• Approximate location using cell ID      – Online: ~ 3-10 kB per request• Specifica...
NOKIA MAPS API•    Maps•    Search•    (Reverse) Geocoding•    Routing•    Sharing: convert to URL•    KML         www.dev...
ADD MAPS LIBRARY TO PROJECTS• NetBeans     – Project properties → Build       Libraries and Resources → Add       Library ...
Example: mapExampleUSING: MAPS     public class MapMidlet extends MIDlet implements GeocodeRequestListener {         priva...
MIXED STUFF46   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
OTHER NEW FULL TOUCH APIS• Font      – Support for light font style• Locale      – Adapt to changes of phone language at r...
COMPATIBILITY48   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
COMPATIBILITY?• Source & binary compatible    – xx years old Java ME apps run on      full touch phones!• Downwards compat...
PORTING TO TOUCH• All Java ME apps should run on full touch phone      – High-Level UI           –   Adapts automatically ...
Example: RpsGamePORTING                                                                              Touch and typeNon-tou...
DYNAMIC API USAGE• Single code base for different phones     – Code that uses new APIs         – Externalize to extra clas...
Example: PaintAppEXAMPLE: PINCH GESTURE• Gesture API     – Available in Touch & Type     – Full Touch adds Pinch gesture  ...
EXAMPLE: OPTIONAL MULTITOUCH                                                                                              ...
Example: PaintAppEXAMPLE: API AVAILABILITY• No System property for the API version?     – Check Class availability     – C...
MONETIZATION56   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
SERIES 40 – APP DOWNLOADS     Millions   1.400                1.200                1.000                 800              ...
IN APP PURCHASING• Phones     – Nokia Asha 200, 201, 202, 203     – Nokia Asha 302, 303, 305, 306, 311     – Nokia 110, 11...
IN APP ADVERTISING• 3rd party APIs• Recommended     – inneractive: www.inner-active.com/Nokia      Java ME + Qt + WP     –...
RESOURCES & TIPS60   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
TIPS & SDK RELEASE NOTES• Emulator – Recommended     – Only 32 bit JRE!• NetBeans 7.x experience     – Don’t choose Featur...
TIPS• Reference problems when importing apps      – Project Properties → Platform →        Nokia SDK 2.0 for Java      – S...
TIPS• App not deployed?     – Make sure Nokia Suite has connection to phone     – Check if deployment method set in projec...
CODE EXAMPLES• Nokia IDE      – Nokia Hub → Nokia Series 40        Code Examples• Online      – bit.ly/JavaMeExamples• Emu...
REMOTE DEVICE ACCESS• Free for Nokia Developer users• Deploy & Test apps     – www.developer.nokia.com/Devices/      Remot...
GET STARTED• Overview     – www.developer.nokia.com/Develop/Java/Getting_started/• Downloads     – SDK: www.developer.noki...
EXERCISES67   © 2012 Nokia Introduction to Full Touch UI for Series 40 v2.0.3 August 29, 2012 Andreas Jakl
Monkey3D StartMONKEYTOUCH 3D• Add Touch support to the Monkey3D app     – Register for DRAG and PINCH gestures     – Rotat...
Monkey3D SolutionSOLUTION: MONKEYTOUCH     Register member in ViewerCanvas     /** Handle pinch and drag gestures. */     ...
Monkey3D SolutionSOLUTION: MONKEYTOUCH     Implement gesture call-back method public void gestureAction(Object container, ...
Monkey3D StartMONKEYTOUCH 3D #2• Add automatic screen orientation• Show status zone71    © 2012 Nokia Introduction to Full...
Monkey3D SolutionSOLUTION: MONKEYTOUCH2     Add attribute to application descriptor     Nokia-MIDlet-App-Orientation: manu...
Monkey3D SolutionSOLUTION: MONKEYTOUCH2     Implement orientation call-back method     public void displayOrientationChang...
CarRace StartCARRACE 3D• Add acceleration sensor control     – Find acceleration sensor & open connection in       RaceCan...
CarRace SolutionSOLUTION: CARRACE 3D     Register member in RaceCanvas     /** Acceleration sensor connection. */     priv...
CarRace SolutionSOLUTION: CARRACE 3D     Process sensor data and apply to the car     private void processSensors()     { ...
Example Apps                                                                     Download all code examples               ...
