Built-in query caching for all PHP MySQL extensions/APIs

MySQL native driver for PHP: The query cache plugin

mysqlnd_qc: The query cache plugin Ulf Wendel, Andrey Hristov MySQL Connectors Team Sun Microsystems

Table of Contents
At a glance
Key Features
Basic Usage
Architecture
MySQLnd Plugins
Cache Architecture
Storage handler
Usage
Advanced Usage
Configuration

Key Features
Transparent: no user API changes
supports ext/mysqli
supports PDO_MYSQL
supports ext/mysql
Invalidation: TTL, custom
Per query TTL (Time to Live)
custom: user callbacks
Storage handler: build-in, custom
Default (Hash), APC, Memcache
custom: user callbacks

Possibly asked questions
Can stale data be served?
Sure, it is Time to live (TTL) by default! But you can implement your own invalidation strategy.
Which PHP versions are supported?
PHP 5.3.3-dev or newer. At the time of writing the query cache is in prototype stage.
Where can I get it?
http://forge.mysql.com/wiki/MySQLnd_Query_Cache_Plugin_for_PHP

Only buffered queries can be cached
ext/mysqli
mysqli_query()
mysqli_real_query() + mysqli_store_result()
PDO_MYSQL
PDO::query() if PDO::ATTR_EMULATE_PREPARES = 1
(this is the default)
ext/mysql
mysql_query()

Uncachable queries
ext/mysqli
mysqli_real_query() + mysqli_use_result()
mysqli_query() + MYSQLI_ASYNC
mysqli_stmt_*()
PDO_MYSQL
PDO::query() if PDO::ATTR_EMULATE_PREPARES = 0
ext/mysql
mysql_unbuffered_query()

Benchmarks?
Please run your own!
Too many variables, sorry... for now ;-)
Chart compares handler – no more

f Basic Usage $mysqli = new mysqli($host, $user, $passwd, $db, $port, $socket);; // Cached: SQL hint used $res = $mysqli->query("/*qc=on*/" . "SELECT id, label FROM test"); var_dump($res->fetch_all(MYSQLI_ASSOC)); $res->free(); SQL hint /*qc=on*/ to control caching // Uncached: no SQL hint $res = $mysqli->query("SELECT id, label FROM test"); var_dump($res->fetch_all(MYSQLI_ASSOC)); $res->free();

Installation
Download source
http://forge.mysql.com/wiki/MySQLnd_Query_Cache_Plugin_for_PHP
Copy extension into PHP 5.3.3+ source tree
cp -R query_cache my_php/ext/mysqlnd_qc
Enable query cache and build
./buildconf --force
./configure --help | grep mysql
./configure --help | grep qc
make clean && make

Compared to MySQL Server Cache
Different location!
Less work for the server
Shorter distance to the app (round trip times)
Scale by client
No server overload
Less sophisticated invalidation (stale data!)

Compared to Memcache
Memcache is no cache
Memcache is a storage medium
Often used for storing cached data
We offer a Memcache storage handler
Application vs. driver based caching
almost no application changes needed
caching of raw data instead of processed data

Table of Contents
At a glance
Key Features
Basic Usage
Architecture
MySQLnd Plugins
Cache Architecture
Storage handler
Usage
Customization
Configuration

How PHP connects to MySQL PHP MySQL Server Library: implements MySQL Client-Server Protocol PHP API for PHP applications MySQL native driver for PHP / MySQL Client Library

Inside PHP (on the C level!) PHP Extensions Zend Engine PDO ext/mysql ext/mysqli SAPI PDO_MYSQL PDO_XYZ MySQL Client Library (libmysql) or MySQL native driver for PHP (default as of PHP 5.3)

PHP 5.3.2: mysqlnd plugin interface <?php /* Any PHP MySQL application */ ?> ext/*mysql* ext/*mysql* Plugin MySQL native driver for PHP C plugins operate transparently: no user API changes

“Object-orientation” in mysqlnd <?php mysqli_query($link, … ); ?> Inside mysqlnd: “objects” of data and function pointer mysqlnd_connection connection_methods host user password ... connection_methods query() store_result() use_result() free_result() ...

Plugins as “Proxies” or “Decorators” <?php mysqli_query($link, … ); ?> Plugins replace or extend internal mysqlnd objects connection_methods query() store_result() use_result() free_result() ... Plugin query() store_result() use_result() free_result() ... mysqlnd_connection connection_methods host user password ...

Plugins can change everything
Connection methods
sending queries, fetching results
metadata access
utility calls
Prepared Statement methods
sending queries, fetching results
…
Network calls
send and fetch raw MySQL protocol data

C level support for Plugins
API calls
Plugin registration
management of function tables
Piggybacking data
via connection object
via result set object
via statistics hash

Query cache: proxy-style plugin Cache MySQL <?php /* Any PHP MySQL application */ ?> ext/*mysql* ext/*mysql* mysqlnd mysqlnd Cache miss: record wire data, cache hit: replay Query Cache Plugin

Query Cache: Miss mysqlnd orig. mysqlnd_conn object mysqlnd_qc object query() Should cache? Yes! Is cached? No! Activate data recorder query() Send query to MySQL Deactivate recorder Cache wire data Decode data Fetch reply

Query Cache: Hit mysqlnd mysqlnd_qc object query() Should cache? Yes! Is cached? Yes! Fetch data from cache Decode data

Storage handler responsibilities
Storage
Scope: request, process, machine, multi-machine
Location: distance to cache
Replacement strategy
Slam defense strategy
Decide what to cache
Detect SELECT statements
Parse SQL-Hints
Extended statistics
Storage statistics, traces, timings

Cache storage handler (I)
Default (Hash)
Scope: process (single or multiple requests)
Location: same process
User can flush cache
Handler maintains storage statistics
APC
Scope: machine (multiple requests)
Location: local

Cache storage handler (II)
Memcache
Scope: can be shared between machines
Location: can be local or remote
User cannot flush cache
No handler statistics
NOP
No operation
Internal and not exposed to PHP land

Cache storage handler (III)
SQLite
Scope, if using “:memory:”: process (single or multiple requests)
Scope, if using file: single (multiple) machine
Location: can be local or remote
Berkeley DB
theoretically usable via the new SQLite C API compatibility wrapper

Cache storage handler (IV)
User (procedural and object oriented)
It is all up to you!
User (class mysqlnd_qc_handler_default)
Default handler behaviour
Can be specialized by user
User can specialize one, many or all functions
See also extra presentation!

Cache Architecture Summary
Transparent from a user perspective
No user API changes
Works with all user APIs
Stores raw wire data
Pro: Simplicity – low risk of bugs!
Con: Client always needs to decode
Storage handler
Choice of life-span and scope
Choice of distance to client

Cache Miss Client 2...100 Client 2...100 Client 2...100 BTW, plan your cache carefully! What if a shared cache entry expires? Client 1 Client 2...n Cache Hit MySQL Client 2...100 Client 2...100 Client 2...100 Client 1 Client 2...n MySQL

Cache Miss Optimize storage for reuse? Memory consumption versus peak loads Client 1 Client 2 MySQL Client 2...100 Client 2...100 Client 2...100 Client 1 Client 2...n MySQL Cache Miss Cache Hit Client 3..n

Table of Contents
At a glance
Key Features
Basic Usage
Architecture
MySQLnd Plugins
Cache Architecture
Storage handler
Usage
Advanced Usage
Configuration

Customization: user handler
Procedural and OOP interfaces
Control which query gets cached
Control where to store cached data
Implement your own invalidation strategy
Maintain your own statistics

Procedural and OOP user handler
mysqlnd_qc_set_user_handlers()
procedural
you must implement all storage handler functions
extending class mysqlnd_qc_handler_default
object oriented
customize build-in default handler
no need to spezialize all handler functions
implementing interface mysqlnd_qc_handler
object oriented
you must implement all storage handler functions

Procedural user storage handler void mysqlnd_qc_set_user_handlers( string get_hash_key, string find_query_in_cache, string return_to_cache, string add_query_to_cache_if_not_exists, string query_is_select, string update_cache_stats, string clear_cache ) Yes, this API may be ugly. BUT: Prototype! BUT: See extra presentation for vodoo! mysqlnd_qc_set_user_handlers()

User storage handler interface (I) function get_hash($host_info, $port, $user, $db, $query) { /* returns string */ return $key; } function find($key) { /* returns boolean */ return $found; } function return_to_cache($key) { /* void – leave empty */ } function add($key, $data, $ttl, $runtime, $store_time, $row_count) { /* returns boolean */ return $added_to_cache; }

User storage handler interface (II) function query_is_select($query) { /* returns mixed - boolean false if the query shall not be cached boolean true or double 0 to use mysqlnd_qc.ttl default double >= 0 to set TTL different from mysqlnd_qc.ttl */ return $to_cache_or_not; } function update_stats($key, $run_time, $store_time) { /* void – data to update your per query cache statistics *// } function clear_cache() { /* returns boolean */ return $cache_has_been_flushed; }

Object oriented storage handler
implementing interface mysqlnd_qc_handler
extending mysqlnd_qc_handler_default

API calls
mysqlnd_qc_change_handler()
mysqlnd_qc_clear_cache()
mysqlnd_qc_get_cache_info()
mysqlnd_qc_get_core_stats()
mysqlnd_qc_get_handler()
mysqlnd_qc_get_normalized_query_trace_log()
mysqlnd_qc_get_query_trace_log()
mysqlnd_qc_set_user_handlers()

Changing the storage handler bool mysqlnd_qc_change_handler(string handler) Changes the storage handler. Returns false if the current handler cannot be shutdown or the requested handler cannot be initialized. Failing to change the handler should be considered as a fatal error unless the change fails because the requested handler is unknown.

Procedural user storage handler void mysqlnd_qc_set_user_handlers( string get_hash_key, string find_query_in_cache, string return_to_cache, string add_query_to_cache_if_not_exists, string query_is_select, string update_cache_stats, string clear_cache ) Sets the function names of a user defined storage handler and puts them into use. See also extra presentation!

Available handlers array mysqlnd_qc_get_handlers() Returns a list of available handler and their versions. The handler “default”, “user”, the class “ myslqnd_qc_handler_default” are always available. “ apc” and “memcache” will be reported if support for those handlers has been enabled at compile time.

Flushing the cache The function is not supported by the Memcache handler! bool mysqlnd_qc_clear_cache() Returns true if the handler supports the operation, and has flushed the cache.

Cache info and handler statistics // Run some queries and generate cache hits $res = $mysqli->query("/*qc=1*/" . "SELECT id, label FROM test"); var_dump($res->fetch_all(MYSQLI_ASSOC)); C-based handler cache information and statistics var_dump(mysqlnd_qc_get_cache_info()); array(4) { ["num_entries"]=> int(%d) ["handler"]=> string(7) "default" ["handler_version"]=> string(5) "1.0.0" ["data"]=> array(%d) { ["%s”] => array(2) { [“statistics”] => array(...), [“metadata”] => array(...) } [, ...] }

Cache hits, time statistics and more
Remember: handler specific statistics
Memcache: no statistics at all
APC: no metadata
If available:
num_entries: number of cache entries
[“data”][key][“statistics”] : run/store time statistics
[“data”][key][“statistics”] : cache hits
[“data”][key][“metadata”]: result set meta data

Core statistics php.ini setting: mysqlnd_qc_collect_statistics = 1 array mysqlnd_qc_get_core_statistics() Returns a list 20+ statistics collected by the core of the query cache plugin, if the PHP configuration setting mysqlnd_qc_collect_statistics is set to 1. The statistics are provided by the core and therefore available with all storage handlers and when using user-defined storage handlers. The statistics cover cache accesses, failures, network traffic as well as aggregated run and store times.

Query back trace php.ini setting: mysqlnd_qc.query_trace = 1 array mysqlnd_qc_get_query_trace_log() Returns a query back trace for every query that has been inspected by the query cache regardless if the query ended up being cached or not. The trace tells you where a query has been issues (see also debug_backtrace()). Together with the back trace you get run and store times and information on if the query has been cached.

Normalized query back trace mysqlnd_qc.collect_normalized_query_trace = 1 array mysqlnd_qc_get_normalized_query_trace_log() Similar to mysqlnd_qc_get_query_trace_log() but with SQL statements normalized and aggregated by the normalized query string. Normalization refers to replacing actual parameters, for example in “WHERE a > 1”, with questionmarks like “ WHERE a > ?”. “WHERE a > ?” will match any value for “?”, for example “1”, “2”, “'abc'” but not other identifiers.

Runtime configuration

Runtime configuration (cont.)

Basics
mysqlnd_qc.ttl
Time to live in seconds
Handler can overrule setting for individual queries
mysqlnd_qc.cache_by_default
Cache every query, even those without SQL hint?
Evaluated by the core, handler cannot overrule!
mysqlnd_qc.cache_no_table
Cache queries with no table name im their meta data, e.g SELECT SLEEP(1)?

Performance
mysqlnd_qc.use_request_time
Use PHP global request time to avoid gettimeofday() system calls?
Pitfall – see APC docs on apc.use_request_time
mysqlnd_qc.time_statistics
Collect run time and store time statistics using gettimeofday() system call?
mysqlnd_qc.std_data_copy
Default handler: copy cached wire data?
EXPERIMENTAL – use default of “0”

Statistics and Slam defense
mysqlnd_qc.collect_statistics
Collect statistics for mysqlnd_qc_get_core_stats()?
mysqlnd_qc.slam_defense
Activates handler based slam defense if available

Query traces
mysqlnd_qc.collect_query_trace
Collect query back traces?
mysqlnd_qc.query_trace_bt_depth
Maximum back trace depth
mysqlnd_qc.collect_normalized_query_trace
Collect aggregated normalized query traces?

APC storage handler
mysqlnd_qc.use_request_time = apc.use_request time
Use the same timer for TTL invalidation
mysqlnd_qc.apc_prefix
Key prefix
APC handler stores data in the APC user cache
Users can manipulate the cache entries!

Memcache storage handler
mysqlnd_qc.memc_server
Memcache server host
Cannot be changed at run time
mysqlnd_qc.memc_port
Memcache server port

SQLite storage handler
mysqlnd_qc.sqlite_data_file
SQLite data file
You should use SQLite as an in-memory storage

Exported PHP constants
MYSQLND_QC_ENABLE_SWITCH
SQL-hint to enable caching, e.g. “qc=on”
Only this exact string will recognized!
MYSQLND_QC_DISABLE_SWITCH
SQL-hint to disable caching, e.g. “qc=off”
Only this exact string will be recognized!
MYSQLND_QC_TTL_SWITCH
SQL-hint for setting per query TTL, e.g. “qc_ttl=”
All constants can be changed as compile time!

Exported PHP classes class mysqlnd_qc_handler_default { public function init() {} public function is_select(...) {} public function get_hash_key(...) {} public function return_to_cache(...) {} public function add_to_cache(...) {} public function find_in_cache(...) {} public function update_cache_stats(...) {} public function get_stats(...) {} public function clear_cache() {} public function shutdown() {} }

Exported PHP interfaces interface mysqlnd_qc_handler { public function is_select(...) {} public function get_hash_key(...) {} public function return_to_cache(...) {} public function add_to_cache(...) {} public function find_in_cache(...) {} public function update_cache_stats(...) {} public function get_stats(...) {} public function clear_cache() {} }

Presentations
A query cache plugin -
this is what you look at ;-)
Query cache plugin benchmark impressions
Dig deeper with QC statistics
Developing user storage handler
Further reading

The End Feedback: ulf.wendel@sun.com The End Feedback: [email_address] , [email_address]
