Unit testing: unitils & dbmaintain

Unit testing unitils - dbmaintain Filip Neven

Presentation goal Demonstrate the added value Unitils can give to your projects

Unitils ‘Mission statement’
Provide a good testing environment
Remove boilerplate code
Automate stuff where possible
Help applying best practices

Why Unitils?
Tackle complexity of persistence layer testing
Many practical problems
A lot of boilerplate code required
Offer all kinds of useful functionalities
Assertion using reflection
Mock objects

Agenda
History
Features by example
Persistence layer testing
Reflection assert
Database maintenance
Mock objects
Unitils design
Roadmap & summary

Introduction
Originates from Ordina Testing & QA task force (2005)
Brainstorm
Testing guidelines: www.unitils.org/guidelines.html
Supporting code
 Unitils open source project

Features
JPA
Hibernate
Automatic database maintenance
DbMaintain
General testing utilities
Reflection assert
Spring integration
Mock objects

Important to test persistence layer
Queries are often complex
Two separated parts -> mismatches more likely
Testing persistence is difficult
Test database
Provide test data
Lot of boilerplate code required
Depends on technology: Plain old JDBC, ORM, spring

Persistence layer testing guidelines
Need control over database & test data
Test database
Empty database
Small dataset per group of related tests
Typically one dataset per test class

Separate developer schema’s
Separate schema per developer
Develop in isolation
Test in isolation

Persistence layer testing – DAO example public class UserDao { @PersistenceContext private EntityManager entityManager; public List<User> findByLastName(String lastName) { return entityManager.createQuery( “ select u from User u where u.lastName = :lastName”) .setParameter(“lastName”, lastName) .getResultList(); } // ... }

Persistence layer testing – test example @DataSet @JpaEntityManagerFactory (persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto (userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals ("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Loading test data - example @DataSet @JpaEntityManagerFactory(persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto(userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Loading test data
@DataSet
Dbunit dataset is loaded before each test
Tables are cleared first
Default file: same package & name as class
UserDaoTest.xml: <?xml version='1.0' encoding='UTF-8'?> <dataset [… XSD declaration …]> <user id="1" userName="johnDoe" /> <user id="2" userName="janeRoe" /> <user id="3" userName="janeDoe" /> </dataset>  Put database in known state before each test

Loading test data - possibilities
Custom file name
Method - specific data set
Load multiple datasets
@DataSet("UserData.xml") public class UserDaoTest extends UnitilsJUnit4 { @DataSet("UserData-adminUser.xml") public void testFindAdminUsers() { @DataSet({"ReferenceData.xml", "UserData.xml"}) public class UserDaoTest extends UnitilsJUnit4 {

Loading test data - XSD
XSD for validation & auto completion
Automatically generated by Unitils
<?xml version='1.0' encoding='UTF-8'?> <dataset xmlns:xsi="http://www.w3.org/2001/XMLSchema- instance" xsi:noNamespaceSchemaLocation="<path to dataset.xsd file>" > <user id="1" userName="johnDoe" age="54"/> <user id="2" userName="janeRoe" lastName="Roe"/> <user id="3" userName="janeDoe" firstName="Jane"/> </dataset>

Loading test data – multi-schema support
Multi – schema dataset support
<?xml version='1.0' encoding='UTF-8'?> <dataset xmlns:schema1="SCHEMA1" xmlns:schema2="SCHEMA2" > < schema1 :user id="1" userName="johnDoe" age="54"/> < schema2 :user id="2" userName="janeRoe" lastName="Roe"/> </dataset>

Loading test data – dbunit issues
Solve annoying dbunit issue
With Unitils: <?xml version='1.0' encoding='UTF-8'?> <dataset [… namespace declaration …]> <user id="1" userName="johnDoe" lastName="Roe"/> <user id="2" userName="janeRoe"/> </dataset> With plain dbunit: <?xml version='1.0' encoding='UTF-8'?> <dataset [… namespace declaration …]> <user id="1" userName="johnDoe" lastName="Roe" /> <user id="2" userName="janeRoe" lastName=“[null]"/> </dataset> When using dbunit directly, this is not possible: Once you’ve used a column, you must use it in every record

Verify database contents
@ExpectedDataSet
Verify database contents after test execution
UserDaoTest.testCreateNewUser-expected.xml: <?xml version='1.0' encoding='UTF-8'?> <dataset [… namespace declaration …]> <user id="1" userName="johnDoe"/> </dataset> @ExpectedDataSet public void testCreateNewUser() { // ... }

Transaction support
Run each test in a transaction
Avoid problems with ‘select for update’ or deferred check constraints
Required in some environments
Possible to rollback after each test
Facilitates test isolation: DB stays in original state
Enables using pre-filled test DB
Default behavior: commit after every test
Modify using @Transactional
Powered by spring

Transaction support - example @DataSet @Transactional(TransactionMode.ROLLBACK) @JpaEntityManagerFactory(persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto(userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

JPA integration - example @DataSet @JpaEntityManagerFactory(persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto (userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

JPA integration
@JpaEntityManagerFactory
Create EntityManagerFactory
Connects with unit test database
New EntityManager for each test
Attached to unitils transaction
Powered by spring

JPA integration – persistence providers
Supported persistence providers
Hibernate
Toplink
OpenJPA

JPA integration – mapping test
Entity / database mapping test
Verifies if database structure is in sync with entities
Only works when persistence provider = hibernate
@Test public void testMappingToDatabase() { JpaUnitils.assertMappingWithDatabaseConsistent(); } Found mismatches between Java objects and database tables. Applying DDL statements should resolve the problem: alter table PERSON add column lastName varchar(255); alter table PRODUCT add column barCode varchar(255);

Reflection assert - example @DataSet @JpaEntityManagerFactory(persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto(userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals ("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Reflection assert
ReflectionAssert
assertReflectionEquals(expectedUser, actualUser);
Compares all fields using reflection
Recursively compares inner objects
Loops over collections and arrays
Reports all differences

Reflection assert - leniency
Leniency
Keep your tests maintainable
Only verify what’s relevant for the test
Lenient by default:
Lenient number types
Lenient collection types
Leniency options: assertLenientEquals ( ... )
Lenient order of collections
Ignore java default values (0 or null)

Reflection assert – lenient collection order
Ignore order of collections and arrays
assertReflectionEquals(expectedCollection, actualCollection, ReflectionComparatorMode.LENIENT_ORDER); assertLenientEquals(expectedCollection, actualCollection); Expected users: [ john , jane ] Actual users: [ jane , john ]

Reflection assert – ignore defaults
Ignore java default values: 0 or null
assertReflectionEquals(expectedCollection, actualCollection, ReflectionComparatorMode.IGNORE_DEFAULTS); assertLenientEquals(expectedUser, actualUser); Expected id: 0 first name: Jane last name: null Actual id: 123 first name: Jane last name: Doe

Reflection assert – check property value
Check property value
assertPropertyLenientEquals( " address.houseNr " , 5 , user);
Check property value for all elements in collection
assertPropertyLenientEquals( “ userName " , Arrays.asList( " johnDoe " , " janeDoe " ), users);

Persistence layer testing - example @DataSet @JpaEntityManagerFactory (persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class UserDaoTest extends UnitilsJUnit4 { @PersistenceContext EntityManager entityManager; UserDao userDao; @Before public void init() { JpaUnitils.injectEntityManagerInto (userDao); } @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals ("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Base test class with all plumbing @DataSet @JpaEntityManagerFactory (persistenceUnit=“eshop”, configFiles={“persistence-test.xml”}) public class BaseDaoTest extends UnitilsJUnit4 { @PersistenceContext protected EntityManager entityManager; protected Dao dao = createDao(); @Before public void init() { JpaUnitils.injectEntityManagerInto (dao); } protected abstract DAO createDAO(); }

Test without plumbing public class UserDaoTest extends BaseDaoTest { UserDao userDao = new UserDao(); @Override protected Object getTestedObject() { return userDao; } @Test public void testFindByLastName() { List<User> users = dao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Hibernate support - example @DataSet public class UserDaoTest extends UnitilsJUnit4 { @HibernateSessionFactory(“hibernate-test.cfg.xml”) EntityManagerFactory entityManagerFactory; UserDao userDao; @Before // Instantiate UserDao and inject EntityManagerFactory @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Spring integration – DAO example import org.springframework.orm.hibernate3.support.HibernateDaoSupport; public class UserDao extends HibernateDaoSupport { // ... public List<User> findByLastName(String lastName) { return (Long) getHibernateTemplate().findByNamedParam( "from User u where u.lastName = :lastName", "user", user).get(0); } // ... }

Spring integration – test example @SpringApplicationContext({“eshop-config.xml”, “test-config.xml”}) @DataSet public class UserDaoTest extends UnitilsJUnit4 { @SpringBean(“userDao”) UserDao userDao; @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Spring integration - configuration eshop-config.xml <bean id="userDao" class="eshop.dao.UserDao"> <property name="sessionFactory" ref="sessionFactory"/> </bean> <bean id="sessionFactory" class="..AnnotationSessionFactoryBean"> <property name="dataSource" ref="dataSource"/> <property name="annotatedClasses"> <list> <value>eshop.model.User</value> </list> </property> </bean> <bean id="dataSource"> … </bean> test-config.xml <bean id="dataSource" class="org.unitils..UnitilsDataSourceFactoryBean"/>

Spring integration
@SpringApplicationContext
Application context is loaded
Typically application & test specific config file
@SpringBean
Inject bean from ApplicationContext into test
Other possibilities
@SpringBeanByName, @SpringBeanByType

Currently still part of unitils (2.2)
Split off into DbMaintain project
1.0 released in february
Will be removed from Unitils

Why automatic database maintenance?
Drawbacks of manual maintenance
Lot of databases – lot to maintain
What was rolled out where?
 Time consuming, error prone

Why automatic database maintenance?
Fully automatic deployments
Enables frequent deployments
Tester / customer can trigger deployment
Shorter feedback cycle
Enables automatic integration tests

Database maintainer – basic usage
Folder with indexed scripts
Database table stores executed scripts info
Rollout: Only apply new scripts
FILE_NAME VERSION LAST_MODIFIED CHECKSUM EXECUTED_AT SUCCEEDED 01_users.sql 1 1206695947921 15a4be468g 2008-09-17 20:23:12 1 02_roles.sql 1 1206695947996 79a5b32g10 2008-09-18 10:15:12 1 DBMAINTAIN_SCRIPTS dbscripts / 01_users.sql / 02_roles.sql

Database maintainer – script organization
Work incremental
Database change = new script
What’s committed cannot be changed
Sequence is strict
dbscripts / incremental / 01_initial / 01_users.sql / 02_sprint1 / 01_roles.sql 02_groups.sql

Hierarchic organization
Organize per release, sprint
dbscripts / incremental / 01_initial / 01_users.sql / 02_sprint1 / 01_roles.sql 02_groups.sql

Incremental / repeatable scripts
Indexed = incremental
Non-indexed = repeatable
Update incremental script  error
Update repeatable script  re-execute
dbscripts / incremental / 01_initial / 01_users.sql / 02_sprint1 / 01_roles.sql 02_groups.sql repeatable / view_users_groups.sql

Database maintainer – post processing
Post-processing scripts
dbscripts / incremental / 01_initial / 01_users.sql / 02_sprint1 / 01_roles.sql 02_groups.sql repeatable / view_users_groups.sql postprocessing / compile_all.sql create_grants.sql

Database maintainer – multi-db
Multi database / db user support
Define different datasources
Usually: same DB – different DB user
Indicate target DB in script name
Use logical name in script: linked to physical DB at execution time
01_products.sql 02_ @users _usergroups.sql

Support for patches
Fix on production branch  merge into DEV
 Not allowed: Not in correct sequence dbscripts / incremental / 01_v1.0 / 01_users.sql / 02_#patch_add_status.sql / 02_v1.1 / 01_roles.sql 02_groups.sql

Support for renames
Rename scripts / folders
Renumber script / folder indexes
Split scripts into folders
Move scripts from separate folders together
 Only limitation: relative sequence scripts can't change

Database maintainer & the SCM
Database setup is put into version control!
Atomic: Source and db modifications
Comitted together
Checked out together
Deployed together
 No temporary failures!

Database script jar
Create jar file with scripts
Self contained: Containing own configuration
Publish scripts as a deliverable just like war or ear

Other dbmaintain operations
markDatabaseAsUpToDate
clearDatabase
cleanDatabase
disableConstraints
updateSequences

DbMaintain execution
Execution using ant
Command line
<updateDatabase scriptLocations= " ... " > <database url= " ... " ... /> </updateDatabase> > dbmaintain updateDatabase eshop-db.jar – config dbmaintain-st.properties

Recreation from scratch
From scratch option
Possible to modify indexed script  triggers from-scratch recreation
No data preservation
Perfect for unit / integration test databases

Unitils integration
Integration with unitils
Auto-maintain unit test schema
Check for script updates before running tests
Make db more ‘test friendly’
Disable constraints
Update sequences

Disable FK & not-null constraints
Why disable FK & not null constraints?
What we need
What we need to write:
<dataset> <user id="1" username="jdoe" /> </dataset> <dataset> <user id="1" username="jdoe" firstname="john" lastname="Doe" role_id="1" company_id="1" /> <role id="1" rolename="admin" /> <company id="1" name=“Agit" /> </dataset>

Database maintenance
DB maintainer
Automatic DB post-processing to make it more test-friendly
Disable foreign key & not null constraints
Increase value of sequences and identity columns
Generate XSD or DTD for dataset definition

Mock objects support
Brand new mock object library
Goals
Create the ‘best of breed’
Define the simplest possible syntax
Promote best practices

Mock objects support example public class AlertServiceTest extends UnitilsJUnit4 { Mock <Scheduler> mockScheduler; Mock <Messenger> mockMessenger; // Test data setup @Test public void testSendScheduledAlerts() { mockScheduler.returns (alerts).getScheduledAlerts(myUser)); alertService.sendScheduledAlerts(); mockMessenger.assertInvoked() .sendMessage(alert1); mockMessenger.assertInvoked() .sendMessage(alert2); } }

Separate behavior definition from verification
Separate behavior definition from verification
Compared to EasyMock: mockScheduler.returns(alerts).getScheduledAlerts(myUser); alertService.sendScheduledAlerts(); mockMessenger.assertInvoked().sendMessage(alert1); mockMessenger.assertInvoked().sendMessage(alert2); expect(mockScheduler).getScheduledAlerts(myUser) .andReturn(alerts); mockMessenger.sendMessage(alert1); mockMessenger.sendMessage(alert2); replay(); alertService.sendScheduledAlerts();

Behavior definition syntax
Simple, consistent syntax
Behavior definition
Invocation asserts
No static imports needed
Compared to EasyMock: mockObject.returns(value).getA(); mockObject.throws(exception).doSomethingInvalid(); mockObject.assertInvoked().doSomething(); expect(mockObject.getA()).andReturn(value); mockObject.doSomethingInvalid(); expectLastCall().andThrow(exception); mockObject.doSomething();

Verify invocations: sequence not important
Strict sequence
mockMessenger. assertInvoked() .sendMessage(alert1); mockMessenger. assertInvoked() .sendMessage(alert2); mockMessenger. assertInvokedInSequence() .sendMessage(alert1); mockMessenger. assertInvokedInSequence() .sendMessage(alert2);

By default all invocations allowed
Default return values: null, empty collection / array
Behavior definitions match multiple times
To match only once:
mockScheduler.returns(alerts).getScheduledAlerts(myUser); mockScheduler.getMock().getScheduledAlerts(); -> returns alerts mockScheduler.getMock().getScheduledAlerts(); -> returns alerts mockScheduler.onceReturns(alerts).getScheduledAlerts(myUser); mockScheduler.getMock().getScheduledAlerts(); -> returns alerts mockScheduler.getMock().getScheduledAlerts(); -> returns null

Relax argument constraints
Mix argument matchers with concrete objects
EasyMock: Mixing not possible
either or mockScheduler.returns(alerts) .getScheduledAlerts( notNull(Date.class), myUser ); expect(mockScheduler).getScheduledAlerts( toDate(“2008/09/18”), myUser ).andReturn(alerts)); expect(mockScheduler).getScheduledAlerts( (Date) notNull(), eq(myUser) ).andReturn(alerts));

Null means ‘I don’t care’
Is same as
mockScheduler.returns(alerts).getScheduledAlerts( null, null ); mockScheduler.returns(alerts) .getScheduledAlerts( (Date)anyObject(), (User)anyObject() );

Default argument matching: lenient reflection assert
Copy of objects is taken: If object changed during
test, object at call time is matched
mockMessenger.assertInvoked().sendAlert(new Alert(null, null, ChannelType.EMAIL)); mockMessenger.assertInvoked().sendAlert(new Alert(null, null, ChannelType.SMS));

Feedback
User feedback
Observed scenario
Suggested assert statements
Object contents
Observed scenario: mockScheduler.getScheduledAlerts ...at mydom.AlertService:55 mockMessenger.send(alert1) ...at mydom.AlertService:76 mockMessenger.send(alert2) ...at mydom.AlertService:76 Suggested assert statements: mockMessenger.assertInvoked().send(alert1); mockMessenger.assertInvoked().send(alert2);

Other features
Other features
Use original implementation for some methods
‘ Dummy’ objects
PartialMock <Messenger> mockMessenger; @Dummy Message alert1, alert2;

Mock injection AlertService alertService; Mock<Scheduler> mockScheduler; Mock<Messenger> mockMessenger; @Before public void setUp() { alertService = new AlertService( mockScheduler. getMock() , mockMessenger. getMock() ); }
‘ Manual’ injection

Mock injection @TestedObject AlertService alertService; @InjectIntoByType Mock <Scheduler> mockScheduler ; @InjectIntoByType Mock <Messenger> mockMessenger;
Using unitils injection features

Injection
Injection of any object into any other object
Tested object is default target
Auto-detect target property
@InjectInto (target = “targetObject”, property = “targetProperty”) SomeClass injectedObject; TargetClass targetObject; @InjectInto (property = “targetProperty”) SomeClass injectedObject; @TestedObject TargetClass targetObject; @InjectIntoByType SomeClass byTypeInjectedObject; @InjectIntoByName OtherClass byNameInjectedObject; @TestedObject TargetClass targetObject;

Unitils architecture
Test execution listener
Modules listening to test execution
Annotations used to instruct modules
@DataSet, @SpringBean, @Transactional Test Test Listener Database Module DbUnit Module ... Module

Need to extend base class
org.unitils. UnitilsJUnit3 org.unitils. UnitilsJUnit4 org.unitils. UnitilsTestNG
Use custom test runner (JUnit 4 only)
@RunWith( UnitilsJUnit4TestClassRunner .class)

Modules
DatabaseModule
DbUnitModule
JpaModule
HibernateModule
SpringModule
MockModule
EasyMockModule
InjectModule

Advantages of unitils design
Easily extendable and customizable
Add new modules or switch implementation
Disable modules that you don’t use
Automatically if a dependency cannot be found
Different target environments
Can also be used without spring, hibernate, ...
Free choice of unit test framework
JUnit 3, JUnit 4, TestNG

Spring integration
Spring offers similar testing framework
Abstraction of test framework
Wire test with beans from app-ctx
Run tests in transaction
Upcoming: integration (2.1)
Use spring test with unitils features

Spring integration @ContextConfiguration({“eshop-config.xml”, “test-config.xml”}) @DataSet public class UserDaoTest extends AbstractTransactionalUnitilsJUnit4SpringContextTests { @AutoWired UserDao userDao; @Test public void testFindByLastName() { List<User> users = userDao.findByLastName("Doe"); assertPropertyLenientEquals("userName", Arrays.asList("johnDoe", "janeDoe"), users); } }

Roadmap Q3 2009 Q4 2009 DbMaintain 1.1 Unitils 2.3 Unitils 3.0 Separate modules DbMaintain 1.2 Spring test integration Multi db support Various improvements Maven integration Profiles support

Links
www.unitils.org
Project info
Cookbook (quick start guide)
Tutorial
Forum & issue tracker
Mail me: filip.neven@unitils.org

http://www.varyonic.com	369
http://www.bejug.org	198
http://blog.oxongeek.org	32
http://www.slideshare.net	24
http://www.bejug.be	8
http://bejug.org	2
http://translate.googleusercontent.com	1

Unit testing: unitils & dbmaintain

by nevenfi on Apr 27, 2009

Accessibility

Categories

Upload Details

Usage Rights

7 Embeds 634

Statistics

Unit testing: unitils & dbmaintain Presentation Transcript
