Varnish, the high performance valhalla?                        Kings of Code 2011
JEROEN VAN DIJK∂ CTO @ Enrise∂ Email : jeroen@enrise.com∂ Twitter: @neorey∂ Open source addict                            ...
JEROEN VAN DIJK∂ CTO @ Enrise∂ Email : jeroen@enrise.com∂ Twitter: @neorey∂ Open source addict                            ...
THE ENRISE RESTAURANT                        3
THE ENRISE RESTAURANT∂ We want to prepare the best dishes                                       3
THE ENRISE RESTAURANT∂ We want to prepare the best dishes∂ With the best ingredients                                       3
THE ENRISE RESTAURANT∂ We want to prepare the best dishes∂ With the best ingredients∂ To create a magical client experienc...
BEFORE WE START   WHO KNOWS   RFC 2616?                  4
BEFORE WE START   WHO KNOWS     HTTP?                  5
BEFORE WE START    WHO THINKS   HE/SHE KNOWS       HTTP?                  6
STANDARD PROXY∂ Wikipedia : Proxy                      7
REVERSE PROXY∂ Wikipedia : Reverse proxy                              8
REVERSE PROXY∂ Wikipedia : Reverse proxy                              8
REVERSE PROXIES∂ Wikipedia : Reverse proxy                              9
REVERSE PROXIES∂ Wikipedia : Reverse proxy                              9
REVERSE PROXIES∂ Wikipedia : Reverse proxy                              9
WHAT IS VARNISH? (1)∂ NOT a webserver!                       10
WHAT IS VARNISH? (1)∂ Caching reverse proxy∂ NOT a webserver!                          10
WHAT IS VARNISH? (1)∂ Caching reverse proxy∂ Load balancer∂ NOT a webserver!                          10
WHAT IS VARNISH? (1)∂ Caching reverse proxy∂ Load balancer∂ Fail over system∂ NOT a webserver!                          10
WHAT IS VARNISH? (1)∂ Caching reverse proxy∂ Load balancer∂ Fail over system∂ HTTP Accelerator∂ NOT a webserver!          ...
WHAT IS VARNISH? (2)                       11
WHAT IS VARNISH? (2)∂ Originally built for a Norwegian newspaper                                               11
WHAT IS VARNISH? (2)∂ Originally built for a Norwegian newspaper∂ > 545k new hostnames in December 2010  § NetCraft month...
WHAT IS VARNISH? (2)∂ Originally built for a Norwegian newspaper∂ > 545k new hostnames in December 2010  § NetCraft month...
WHAT IS VARNISH? (3)∂ Scaling limitations currently unknown                                          12
WHAT IS VARNISH? (3)∂ Designed for 64bit architecture∂ Scaling limitations currently unknown                              ...
WHAT IS VARNISH? (3)∂ Designed for 64bit architecture∂ Highly scalable∂ Scaling limitations currently unknown             ...
WHAT IS VARNISH? (3)∂ Designed for 64bit architecture∂ Highly scalable  §Varnish in front of Varnish(es)∂ Scaling limitat...
WHAT IS VARNISH? (3)∂ Designed for 64bit architecture∂ Highly scalable  §Varnish in front of Varnish(es)∂ Perfect browser...
WHAT IS VARNISH? (3)∂ Designed for 64bit architecture∂ Highly scalable  §Varnish in front of Varnish(es)∂ Perfect browser...
INTERNALS (1)∂ Possible request paths                           13
INTERNALS (2)∂ Optimal request path                         14
INTERNALS (3)∂ Caching request path                         15
INTERNALS (4)∂ Prevent caching                    16
INTERNALS (5)∂ Bypassing Varnish                      17
INTERNALS (6)∂ Errors or issueing restarts                                18
VARNISH CONFIGURATION LANGUAGE (1)∂ Compiled to C when run                                     19
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Compiled to C when run                  ...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Compiled to C when run      ...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (1)∂ 11 subroutines (vcl_recv, vcl_hash, etc ...)∂ Backend(s)∂ Directors (random, round rob...
VARNISH CONFIGURATION LANGUAGE (2) if (req.request == “GET” &&      req.url ~ “.(gif|jpg|jpeg|bmp|png|ico)$”) {      unset...
VARNISH CONFIGURATION LANGUAGE (3)if (req.http.cookie) {    set req.http.Cookie = regsuball(req.http.Cookie,   "__utm.=[^;...
VARNISH CONFIGURATION LANGUAGE (4)backend default {  .host="192.168.1.10";  .port="8080";  .probe={    .url=”/test.php”;  ...
VARNISH CONFIGURATION LANGUAGE (5)director balance random {  { .backend = default; .weight = 1; }  { .backend = second; .w...
VARNISH CONFIGURATION LANGUAGE (6)if (obj.hits > 0) {   #if hit add hit count   set resp.http.X-Cache = "HIT-" obj.hits;} ...
VARNISHING WORDPRESS (1)                           25
VARNISHING WORDPRESS (1)∂ Siege on standard WordPress homepage                                     25
VARNISHING WORDPRESS (1)∂ Siege on standard WordPress homepage  §No Varnish                                     25
VARNISHING WORDPRESS (1)∂ Siege on standard WordPress homepage  §No Varnish  §Default Varnish installation              ...
VARNISHING WORDPRESS (1)∂ Siege on standard WordPress homepage  §No Varnish  §Default Varnish installation  §Custom VCL...
VARNISHING WORDPRESS (2)∂ No Varnish                           26
VARNISHING WORDPRESS (2)∂ No Varnish                           26
VARNISHING WORDPRESS (2)∂ No Varnish                           26
VARNISHING WORDPRESS (3)∂ Default Varnish                           27
VARNISHING WORDPRESS (3)∂ Default Varnish                           27
VARNISHING WORDPRESS (3)∂ Default Varnish                           27
VARNISHING WORDPRESS (4)# Drop any cookies sent to WordPress.sub vcl_recv {  unset req.http.cookie;}# Drop any cookies Wor...
VARNISHING WORDPRESS (5)∂ Custom Varnish                           29
VARNISHING WORDPRESS (5)∂ Custom Varnish                           29
VARNISHING WORDPRESS (5)∂ Custom Varnish                           29
OTHER PITFALLS                 30
OTHER PITFALLS∂ Accept headers  §application/vnd.kingsofcode.speakers+xml;  §return “Vary: Accept” header               ...
OTHER PITFALLS∂ Accept headers  §application/vnd.kingsofcode.speakers+xml;  §return “Vary: Accept” header∂ Accept-encodi...
OTHER PITFALLS∂ Accept headers  §application/vnd.kingsofcode.speakers+xml;  §return “Vary: Accept” header∂ Accept-encodi...
EDGE SIDE INCLUDES (1)∂ Markup language∂ Co-authored Akamai, IBM, Oracle & more∂ Extensive features∂ Very powerful for con...
EDGE SIDE INCLUDES (2)∂ if ... else   § <esi:choose><esi:when> ... <esi:otherwise>∂ Variables   § <esi:assign> and <esi:...
EDGE SIDE INCLUDES (3)if (req.url ~ "^/url/to/esi/snippets") {   unset beresp.http.set-cookie;}## enable esi on header fro...
EDGE SIDE INCLUDES (4)∂ Where are the ESI’s?                         34
EDGE SIDE INCLUDES (5)∂ Different TTL’s for content snippets                                         35
TOOLS∂Varnishstat∂Varnishsizes∂Varnishtop∂Varnishadm∂Varnishlog∂ You can’t go without                         36
VARNISHLOG∂ Log hits  § varnishlog -o VCL_Call hit | grep RxURL∂ Log misses  § varnishlog -i TxURL                      ...
VARNISHLOG∂ Request of a gif image by client                                     38
VARNISHLOG∂ Request of a gif image by client                                     38
VARNISHLOG∂ Request of a gif image by client                                     38
VARNISHLOG∂ Request of a gif image by client                                     38
CAVEATS∂ Unsuitable for 32 bit∂ Beware of cookie monster applications∂ Check your API design∂ Avoid large files∂ Minimize c...
∂ Questions? Thank you!
