Today's malware aint what you think

Roger A. Grimes InfoWorld

Presenter BIO
Roger A. Grimes
CPA, CISSP, CEH, CISA, TICSA, MCSE: Security, yada, yada
InfoWorld Contributing Editor, Security Columnist, Product Reviewer, and Blogger
23-year Windows security consultant, instructor, and author
Author of seven books on computer security, including:
Windows Vista Security: Security Vista Against Malicious Attacks (Wiley, 2007)
Professional Windows Desktop and Server Hardening (Dec. 2005)
Malicious Mobile Code: Virus Protection for Windows (O’Reilly, 2001)
Honeypots for Windows (Apress, December 2004)
Author of over 300 national magazine articles on computer security
Principal Security Architect for Microsoft InfoSec ACE Team

Roger’s Books

Presentation Summary
Quick History of Past Malware Threats
Today's Threats
Anatomy of Today's Cyber Attack
Malware Examples
Best Defenses

Malware Has Been Around Since The Beginning of Computers
Most early malware were network worms
Late 1960’s – John Conway’s Game of LifeCore Wars
Imp
1971, Creeper worm was written by Bob Thomas of the BBN (Bulletin Board Network)
(First PC, Altair 8800, 1974)
IBM Christmas worm –Dec. 1987
Robert Morris Worm –Nov. 1988
Historic Malware Trends

(Apple computer invented 1976)
1982 - Richard Skrenta, Jr. a 9th grade high school student, a Core War fan, wrote a 400-line Apple II boot virus , called Elk Cloner
Spread around the world
Every 50 th boot would present message
No virus scanners or cleaners at this time
(IBM PC introduced in late 1981)
1986 – Pakistani Brain – first IBM-compatible virus
1987 – Stoned, Jerusalem, Cascade (encrypted), Lehigh
Historic Malware Trends First PC Viruses – Boot Viruses

Boot Viruses
Even though they made up just a few percent of the malware programs, they accounted for most of the infections
March 1992 – Michelangelo
Executable Viruses
Some Trojan Horse Programs
Some Worms, but not many
Most malware programs were not intentionally malicious
Historic Malware Trends Early PC Malware

1985 – Macro viruses
1998 – HTML viruses
2001 – Code Red – IIS worm
2003 – SQL Slammer
Fastest exploit to date – 10 minutes to infect world
2003 – MS Blaster
In 99.9999% of cases, patch was available before exploit was released
Historic Malware Trends PC Malware Hits Mainstream

From 1999 to late 2006, about 90% of malware attacks arrived via email
VBScript, Javascript
Malicious file attachments
Rogue embedded links
Spam
MIME-type mismatches
Social-engineering methods
Melissa, I love you worm
Historic Malware Trends Email wormsviruses

Still, most were not intentionally malicious
Those were the days!
Historic Malware Trends Email wormsviruses

Run an up-to-date antivirus program
Run a host-based firewall that prevents unauthorized outbound connections
Be fully patched
Visit only trusted web sites
Careful opening unexpected documents
Use other programs and OSs to remain safe
Current Malware Trends Conventional Defense Wisdom

AV is not all that accurate and cannot be relied upon
Host-based firewalls really don’t work most of the time
Nobody fully patches
Trusted web sites are how you get infected
Many attacks work cross-platform or don’t care about OS or app
Targeted spearphishing makes determining what documents you should open hard to do
Current Malware Trends Sadly...

Malware and hacking is worst than ever!
Even though we already do all the recommended stuff
Current Malware Trends Sadly...

Mostly trojans, worms, and downloaders
Professionally written
Development forks, teams
Criminally-motivated
Bots & botnets
Tens of millions of PCs “owned” at any one time
Designed To Get Money
Steal passwords, identity info, DDoS attacks
Mostly asks for permission to run and user responds “YES”
Current Malware Landscape New Malware Model

Cybercriminals are stealing tens of millions (at least) of dollars every day
2009 Verizon Data Breach report found that 91 percent of all compromised records in 2008 was attributed to organized criminal activity .
Current Malware Landscape Criminally Motivated

Cybercriminals are stealing tens of millions (at least) of dollars every day
2009 Verizon Data Breach report found that 91 percent of all compromised records in 2008 was attributed to organized criminal activity .
“ On the brighter side, we are happy to report that these efforts with law enforcement led to arrests in at least 15 cases.”
Current Malware Landscape Criminally Motivated

User visits “innocent” infected web site
Contains simple Javascript redirector
Prompts user to install fake program
Anti-virus scanner, patch, codec, malformed PDF, etc.
First program is a small downloader
Starts the malware process
Provides bot control
Dials home for more instructions
Current Malware Landscape Most Common Malware Cycle

Only Visit Trusted web sites
Good advice?

What has trusted ever meant anyway?
How do I know I can trust it?
Do those “seals of approval” mean anything?
Current Malware Landscape Trusted Web Sites?

What has trusted ever meant anyway?
How do I know I can trust it?
Do those “seals of approval” mean anything?
Me, I feel safer on a pay-for-view porn site!!
Current Malware Landscape Trusted Web Sites?

77 percent of web sites with malicious code are legitimate sites that have been compromised
61 percent of the top 100 sites either hosted malicious content or contained a masked redirect to lure unsuspecting victims to malicious
37 percent of malicious Web/HTTP attacks included data-stealing code
57 percent of data-stealing attacks are conducted over the Web
Current Malware Landscape Innocently Infected Web Sites

How?
Web site itself compromised
Misconfiguration
Vulnerability
Allows user postings
Malicious ads from legitimate ad services
Malicious sponsored ads on search engines
Poisoned search engine results
Web site codelets created by bad guys to go malicious one day

Tens of Millions of Malicious Web Sites
Look real, but completely malicious
Often taken there by OS or app help program or search engine
Promote product that is nothing but malicious
Have entire teams of people dedicated to promoting product on “independent” blogs, review magazines, etc.
Ex: You must have this codec to watch these car racing videos on YouTube
Current Malware Landscape Some aren’t so Innocent!

Poisoned Ad Services
You name the major web site and it has probably hosted malicious ads
Ads posted by web site owner, marketing firm hired by web site, compromised ad service, or hacking
Avast - the most compromised services are Yahoo’s yieldmanager.com and Fox’s fimserve.com
Responsible for more than 50% of poisoned ads
Doubleclick.net too
http://blog.avast.com/2010/02/18/ads-poisoning-%e2%80%93-jsprontexi/

Poisoned Cartoons?
King Features, a newspaper comic distributor was hacked
King Feature distributes online comics to about 50 different newspapers
Online readers were prompted to download a malicious PDF
http://voices.washingtonpost.com/securityfix/2009/12/hackers_exploit_adobe_reader_f.html

Search Engine Poisoning
Bad guys create web sites that are very attractive to search engine bot crawlers (e.g. lots of links with lots of keywords)
It is not uncommon to find malicious links in 15% to 20% of the first 100 results from a search
Some of the most popular searches will return 90%
Malicious web sites are generated are often generated on the fly, changed only by a single keyword in the URL
http://www.cyveillanceblog.com/general-cyberintel/malware-google-search-results

SEO Kits
Poisoned search engine results often created by Search Engine Optimization (SEO) kits
Kits download must popular search engine requests from the search engines themselves (e.g. googletrends)
Then generate web site on the fly with those keywords and images
Generates thousands of web sites with those keywords and link to each other
http://www.sophos.com/sophos/docs/eng/papers/sophos-seo-insights.pdf

Sponsored Ads
Search engines often host sponsored ads that redirect to malicious sites and code
Nearly all search engines involved
Certainly the ones you use are
Due to malware companies posing as legitimate companies and switching up ads or legitimate web sites being infected that paid for legitimate ad time

Sponsored Ads

Many Infected Host Providers Are Slow To Respond
Example: ThePlanet.com
Stopbadware.org notifies ThePlanet when they note an infected web site hosted by ThePlanet
Averages 12K-20K infected sites a month
1 month after reporting, 12K of reported web sites remain infected
4.5K remain infected after 7 months

Bulletproof Hosting
Many companies advertise on the promise that they will keep your web site up no matter what you do with it
The Russian Business Network is number one in this space
McColo was #2 before 2008 takedown
Plenty of competition
Located in countries without appropriate laws
Current Malware Landscape Not-So Innocently Infected Web Sites

Bulletproof Hosting -Examples
Current Malware Landscape Not-So Innocently Infected Web Sites

Current Malware Landscape New Malware Model Steps

Infect or Exploit
Modify system to gain control
Phone “home” to get code update
Repeat this step 1-20 times
Modify host and spread to create bot net
Steal information -financial, passwords, etc.
Able to bypass any authentication method
When finished, self-delete, cover up tracks
Current Malware Landscape New Malware Model Steps

Self-healing bot nets
Intended to live only a few hours
Auto-updating
Design To Hide
Millions of malicious links on social networking sites
Some of the biggest users of Facebook, Myspace, and Twitter
Current Malware Landscape New Malware Model (con’t)

Silent Drive-by-Downloads and one-click and your owned traps used to be the way people got infected
Require unpatched software and vulnerabilities
UAC and other browser protections make this harder to do
Still happens, but now in the minority
OS patching is nearly 100% now
App patching could be better
Malware writers are mostly targeting unpatched Internet browser apps now

In most cases, people are tricked into intentionally installing a malware program
99% of the risk in most environments
Occasionally, a roving worm, like Conficker, becomes Ms. Popularity for a few days or months

Vuls. trending down since 1H 2007
Current Malware Landscape Known Vulnerabilities Going Down Year-after-Year
Figures for all reporting vendors

Even OS and Browser Vulnerabilities Are Flat
Current Malware Landscape Known Vulnerabilities Going Down Year-after-Year
From MS SIR 8

Especially in the browser space
Every new browser vendor promises to make the perfectly secure browser that apparently Microsoft cannot seem to make
Later on I’ll tell you how it doesn’t matter at all anyway
Current Malware Landscape Still Plenty of Vulnerabilities

Firefox – 169
Apple Safari – 94
Internet Explorer – 45
Google Chrome – 41
Opera - 25
Current Malware Landscape Number of Browser Vulnerabilities in 2009
From SymantecSecunia

Firefox – 52
3.0-15, 3.5-18, 3.6-19
Apple Safari 4– 17
Internet Explorer 8 – 21
Google Chrome – 28
Opera – 6
Of all browsers Symantec analyzed in 2009, Safari had the longest window of exposure (the time between the release of exploit code for a vulnerability and a vendor releasing a patch), with a 13-day average; IE, FF, and Opera had the shortest windows of exposure, avg 1 day.
Current Malware Landscape Number of Browser Vulnerabilities in 2010 (so far)

The way almost all your users are getting infected is direct action trojans
Current Malware Landscape But Vulns Don’t Matter All That Much

By a huge percentage, trojans are number one!
Current Malware Landscape Trojans Are #1! (From Microsoft SIR 8) Exploits Trojans Trojans

Current Malware Landscape But Worms are more frequent on work computers (From Microsoft SIR 8)

Trojan program looks “really, really” authentic
Coming from legitimate web sites, spam, phishing attacks
Bad guy often buys ads on search engines or “poisons” search engine results
Certain keywords are more likely to bring up malware than legitimate web sites
Bad guys use the latest news (e.g. earthquake, celebrity event, etc.)
Often accidentally redirected to malware sites by legitimate trusted software
Why Are They So Prevalent?

Tricking End Users Antivirus 2010

In one year, Google found over 11,000 web sites offering fake AV scanners
1,462 unique new installer programs per day
20% detection rate by real AV
1 hr – median time redirection web site is up before hackers move on
In SIR 8, Microsoft said its security products cleaned fake anti-virus related malware from 7.8 million computers in the second half of 2009.
Fake AV Stats – from Google

Apparently worry about copyright infringement

Millions of new programs created every year
Challenging for pure definition scanners to keep up
No antivirus scanner will ever be perfect
Check out http://www.virustotal.com/estadisticas.html
Why Are They So Prevalent?

“ Zero-day” exploits becoming more common
One attack program can have 20 exploit vectors
DNS tricks
Poisoning, hosts file manipulation
Sound-alikes
One-offs (everything unique for each victim)
Millions of malware programs each year
Symantec reported 2.8 M malware programs in 09
More than legitimate programs
Current Malware Landscape Infection or Exploit

Known Malware Detection Rates Not Bad
www.virusbulletin.com
Dozens of AV scanners routinely detect 100% of the known malware programs in the wild with zero false-positives
Awarded VB100
Why Are They So Prevalent? Malware Is Hiding Better

First-Day Malware Detection Rates Could Be Improved
www.av-test.org (Dec. 2009)
Brand new threats were released and tested
Best products detected malware 98% of the time, blocked 95% of the time
Average product was 70-90% effective
Sounds good until you realize that out of 100 users in your network, at least two of them will be presented with a trojan program that is not detected as malicious
Now multiple that by the size of your user base, especially over time

How Does Malware Hide?
Early Techniques:
Encrypted – hide the malware so it can’t be scanned
Oligomorphic - multi. encryption/decryption engines
Polymorphic - random encryption/decryption
Metamorphic - mutates malware body, looks for compiler on host and re-compiles malware on-the-fly

Today’s Techniques:
HTML Encoding/Obfuscation
Character set (e.g. UTF-8, UTF-7, Unicode) encoding
Compression (e.g. multi-compressed zip files)
Packers, Multi-packers
SSL/TLS/encryption for travel and communications
Why Are They So Prevalent? New Malware Is Hiding Even Better

Language encoding (e.g. simplified Chinese)
Transfer encoding (e.g. chunked, token-extension)
Packet fragmentation, time-outs
Password protected files
Embedded code (e.g. RTF links)
Embedded in thick content (e.g. PDF, Flash, MS-Office objects)

Dynamic DNS names
Dynamic IP addressing
One-time URLs (unique per victim)
Self-deleting malware
Delete and come back when needed

Responsible for up to nearly 50% of all successful web-based attacks.
Current Malware Landscape Adobe Acrobat Malware Is a Huge Problem

Usually arrives in email
Sender has internal details
Most captured from company’s public web site and news
Other times, obviously has insider knowledge of project or detal
Often target senior executives
Project document, pending lawsuit, child support inc.
Common scam: Target accounting to infect the payroll transfer transaction computer
Defense: That computer should not be connected to the normal network or used for anything else, highly guarded and secured
Current Malware Landscape Targeted Spearphishing

Can arrive in email
Current Malware Landscape Adobe Acrobat Malware Example

Prompts User to Save Another “PDF” file

Can be prevented by modifying one setting

Most attacks several years old.
Current Malware Landscape Do You Patch Office?

More than half (56.2 percent) of the attacks affected Office program installations that had not been updated since 2003.
Most of these attacks involved Office 2003 users who had not applied a single service pack or other security update since the original release of Office 2003 in October 2003.
Current Malware Landscape Do You Patch Office?

CAN-SPAM Act of 2003 took down spam!
Current Malware Landscape

25% - Percentage of spam when CAN-SPAM Act was passed
Current Malware Landscape Spam stats

Spam is most of our email
88% according to Symantec
93% according to MessageLabs
95 percent of user-generated comments to blogs, chat rooms and message boards are spam or malicious. (Websense 2009 report)
Spearphishing for targeted attacks increasing greatly
85% of spam is sent by bots from innocently infected computers (Symantec)
20% of all spam sent in March 2010 used TLS (MessageLabs)
Current Malware Landscape Spam stats

Spammers bypass CAPTCHAs, by:
OCR – recognize the symbols
VCR – recognize the voice
Paying third world country employees to manually answer
Freelancer.com - dozens of such projects are bid on every week.
80 cents to $1.20 for each 1,000 deciphered boxes or about $6 every 15 days for the average worker
Current Malware Landscape Spammers Still Abusing Free Web Mail

Per MessageLabs
Hundreds of billions of spams are sent each day
85% from spambots, 90% from the top five bots
Rustock – largest current botnet with 2.4M hosts, responsible for 1/3 rd of all spam
Grum- Responsible for 24% of all spam
Mega-D – Responsible for 18% of all spam
Top spam bots vary according to measurer, but Rustock always gets #1 spot
Current Malware Landscape Bot Nets and Spam

Current Malware Landscape Popular Botnet Families (From Microsoft SIR 8)

Many commercial bot net kits
Management interfaces
24 x 7 tech support
Bypass any authentication
Made to order
Example: ButterflyMariposa bot net (March 2010)
13 million controlled computers in 190 countries
Run by three non-experts, required very little skill
Bought original bot kit for $300
Current Malware Landscape Bot Nets

Crum - $200 – Creates polymorphic encrypted malware, free updates
Eleonore Exploits Pack –$700 – several exploits including MS, Firefox, Opera, and PDF
Neon – $500- PDFs (including FoxIt), Flash, Snapshot
Adrenaline - $3000- keylogging, theft of digital certificates, encryption of information, anti-detection techniques, cleaning of fingerprints, injection of viral code, etc.
http://malwareint.blogspot.com/2009/08/prices-of-russian-crimeware-part-2.html
Current Malware Landscape Malware Kit Examples

Current Malware Landscape Crime Does Pay

For the most part, we aren’t catching many of the criminals
International jurisdictions, non-compliant countries, no hard evidence, real crimefighting takes time
Users/admins not doing the simple things they should be doing to stop malicious attacks
Attackers don’t need complex, hypervisor attacks to do damage; current attacks doing just fine
Vendors could produce zero-defect software and it would not make a measurable dent in cybercrime
Current Malware Landscape Future Not Looking That Great

The most popular software in a particular category will be successfully attacked the most
Grimes Corollary

The most popular software in a particular category will be successfully attacked the most
Grimes Corollary
Regardless of whether or not Microsoft made it!
Windows, IE, Microsoft Office
PDF over XPS
Apache over IIS
Quicktime over Windows Media Player
ActiveX over Java Applets

AuctionSales Site scams
Selling a car or motorcycle for an unbelievable price with unbelievable terms
“ I’ll give you the best price ever and pay for international shipping”
Send your money to a “trusted, third party”
“ Buyer protection”
Doesn’t care what your OS or browser is
So much for your anti-malware programs
Current Malware Landscape Many Times No Malware Needed

Auction Car Sale Scam Example

Auction Car Sale Example

Lessons To Take Away
Malware usually comes from innocently infected web sites
Visiting only “trusted” web sites is not great advice anymore
Consider investing more in technologies that can mitigate these types of threats
Educate end users about the current state of malware
**If we could educate users to not install fake programs, the majority of the current malware threat would disappear overnight
Current Malware Landscape Forming a Defense

Best End-User Defenses
Don’t be logged in as Administrator or root when surfing the web or reading email
Run up-to-date anti-malware programs
Antivirus, Firewalls, Anti-spam, Anti-phishing, intrusion detection
Fully patch OS and all applications , including browser add-ons (harder than it sounds)
Use good, secure defaults
Fight the Good Fight

Educate end-users to most likely threats
Tell them to learn what their AV software looks like and what it doesn’t
Show them what their patching software looks like
Tell them not to install software offered by their favorite web site
Does your educational content contain this information?
Phish your own users (be the first!)

Use search engines that contain anti-malware abilities (e.g. Bing, Google, etc.)
Use browsers that have anti-malware checkers
Most of the popular ones, but not all
Look for unusual network traffic patterns
Unexpected large transfers, workstation-to-workstation, server-to server
Install honeypots as early warning detectors

Future Defenses
Most countries are starting to work together better (although very slowly)
Ultimately will take rebuilding the Internet
Building in pervasive identity and accountability
Still support anonymity
Will have to be done incrementally
Support End-t0-End Trust initiatives
All needed protocols are already in place
See Trusted Computing Group’s work
Microsoft’s End To End Trust
Current Malware Landscape Forming a Defense

e: roger@banneretcs.com
Current Malware Landscape Questions

http://www.slideshare.net	38
http://dailysafetycheck.com	2
http://www.dailysafetycheck.com	2

Today's malware aint what you think

by Nathan Winters

Accessibility

Categories

Upload Details

Usage Rights

3 Embeds 42

Statistics

Today’s malware aint what you think Presentation Transcript
