My presentation of Storm at the Bay Area Hadoop User Group on January 18th, 2012.

Published in: Technology
1 Comment
  • How to monetize your searching skills and make money working from home pretty easy, using computer, internet and a little of your time. Complete guidance at
    I came across this site quite randomly 4 months ago, registered, and till now I receive payments on a weekly basis.
    Are you sure you want to  Yes  No
    Your message goes here
No Downloads
Total Views
On Slideshare
From Embeds
Number of Embeds
Embeds 0
No embeds

No notes for slide


  1. 1. StormDistributed and fault-tolerant realtime computation Nathan Marz Twitter
  2. 2. Basic info• Open sourced September 19th• Implementation is 12,000 lines of code• Used by over 25 companies• >2280 watchers on Github (most watched JVM project)• Very active mailing list • >1700 messages • >520 members
  3. 3. Hadoop Batch computationDistributed Fault-tolerant
  4. 4. Storm Realtime computationDistributed Fault-tolerant
  5. 5. Hadoop• Large, finite jobs• Process a lot of data at once• High latency
  6. 6. Storm• Infinite computations called topologies• Process infinite streams of data• Tuple-at-a-time computational model• Low latency
  7. 7. Before StormQueues Workers
  8. 8. Example (simplified)
  9. 9. ExampleWorkers schemify tweets and append to Hadoop
  10. 10. ExampleWorkers update statistics on URLs byincrementing counters in Cassandra
  11. 11. Problems• Scaling is painful• Poor fault-tolerance• Coding is tedious
  12. 12. What we want• Guaranteed data processing• Horizontal scalability• Fault-tolerance• No intermediate message brokers!• Higher level abstraction than message passing• “Just works”
  13. 13. StormGuaranteed data processingHorizontal scalabilityFault-toleranceNo intermediate message brokers!Higher level abstraction than message passing“Just works”
  14. 14. Use cases Stream Distributed Continuousprocessing RPC computation
  15. 15. Storm Cluster
  16. 16. Storm ClusterMaster node (similar to Hadoop JobTracker)
  17. 17. Storm ClusterUsed for cluster coordination
  18. 18. Storm Cluster Run worker processes
  19. 19. Starting a topology
  20. 20. Killing a topology
  21. 21. Concepts• Streams• Spouts• Bolts• Topologies
  22. 22. StreamsTuple Tuple Tuple Tuple Tuple Tuple Tuple Unbounded sequence of tuples
  23. 23. SpoutsSource of streams
  24. 24. Spout examples• Read from Kestrel queue• Read from Twitter streaming API
  25. 25. BoltsProcesses input streams and produces new streams
  26. 26. Bolts• Functions• Filters• Aggregation• Joins• Talk to databases
  27. 27. TopologyNetwork of spouts and bolts
  28. 28. TasksSpouts and bolts execute asmany tasks across the cluster
  29. 29. Task executionTasks are spread across the cluster
  30. 30. Task executionTasks are spread across the cluster
  31. 31. Stream groupingWhen a tuple is emitted, which task does it go to?
  32. 32. Stream grouping• Shuffle grouping: pick a random task• Fields grouping: mod hashing on a subset of tuple fields• All grouping: send to all tasks• Global grouping: pick task with lowest id
  33. 33. Topologyshuffle [“id1”, “id2”] shuffle[“url”] shuffle all
  34. 34. Streaming word countTopologyBuilder is used to construct topologies in Java
  35. 35. Streaming word countDefine a spout in the topology with parallelism of 5 tasks
  36. 36. Streaming word countSplit sentences into words with parallelism of 8 tasks
  37. 37. Streaming word countConsumer decides what data it receives and how it gets groupedSplit sentences into words with parallelism of 8 tasks
  38. 38. Streaming word count Create a word count stream
  39. 39. Streaming word count
  40. 40. Streaming word count
  41. 41. Streaming word count Submitting topology to a cluster
  42. 42. Streaming word count Running topology in local mode
  43. 43. Demo
  44. 44. Distributed RPCData flow for Distributed RPC
  45. 45. DRPC ExampleComputing “reach” of a URL on the fly
  46. 46. ReachReach is the number of unique people exposed to a URL on Twitter
  47. 47. Computing reach Follower Distinct Tweeter Follower follower Follower DistinctURL Tweeter follower Count Reach Follower Follower Distinct Tweeter follower Follower
  48. 48. Reach topology
  49. 49. Reach topology
  50. 50. Reach topology
  51. 51. Reach topology Keep set of followers for each request id in memory
  52. 52. Reach topology Update followers set when receive a new follower
  53. 53. Reach topology Emit partial count after receiving all followers for a request id
  54. 54. Demo
  55. 55. Guaranteeing message processing “Tuple tree”
  56. 56. Guaranteeing message processing• A spout tuple is not fully processed until all tuples in the tree have been completed
  57. 57. Guaranteeing message processing• If the tuple tree is not completed within a specified timeout, the spout tuple is replayed
  58. 58. Guaranteeing message processing Reliability API
  59. 59. Guaranteeing message processing“Anchoring” creates a new edge in the tuple tree
  60. 60. Guaranteeing message processing Marks a single node in the tree as complete
  61. 61. Guaranteeing message processing• Storm tracks tuple trees for you in an extremely efficient way
  62. 62. Transactional topologiesHow do you do idempotent counting with an at least once delivery guarantee?
  63. 63. Transactional topologies Won’t you overcount?
  64. 64. Transactional topologies Transactional topologies solve this problem
  65. 65. Transactional topologiesBuilt completely on top of Storm’s primitives of streams, spouts, and bolts
  66. 66. Transactional topologiesBatch 1 Batch 2 Batch 3 Process small batches of tuples
  67. 67. Transactional topologiesBatch 1 Batch 2 Batch 3 If a batch fails, replay the whole batch
  68. 68. Transactional topologiesBatch 1 Batch 2 Batch 3 Once a batch is completed, commit the batch
  69. 69. Transactional topologiesBatch 1 Batch 2 Batch 3Bolts can optionally implement “commit” method
  70. 70. Transactional topologiesCommit 1 Commit 1 Commit 2 Commit 3 Commit 4 Commit 4 Commits are ordered. If there’s a failure during commit, the whole batch + commit is retried
  71. 71. Example
  72. 72. Example New instance of this object for every transaction attempt
  73. 73. Example Aggregate the count for this batch
  74. 74. Example Only update database if transaction ids differ
  75. 75. Example This enables idempotency since commits are ordered
  76. 76. Example (Credit goes to Kafka guys for figuring out this trick)
  77. 77. Transactional topologiesMultiple batches can be processed in parallel,but commits are guaranteed to be ordered
  78. 78. Transactional topologies• Will be available in next version of Storm (0.7.0)• Requires a source queue that can replay identical batches of messages• Aiming for first TransactionalSpout implementation to use Kafka
  79. 79. Storm UI
  80. 80. Storm on EC2 One-click deploy tool
  81. 81. Starter code Example topologies
  82. 82. Documentation
  83. 83. Ecosystem• Scala, JRuby, and Clojure DSL’s• Kestrel, AMQP, JMS, and other spout adapters• Serializers• Multilang adapters• Cassandra, MongoDB integration
  84. 84. Questions?
