Frequency Tables <ul><li>Ms. Carter </li></ul><ul><li>Leaving Certificate </li></ul>
Tally Marks <ul><li>Tally marks are a way to count things in groups of five. </li></ul><ul><li>You draw four vertical line...
Example:  Counting Apples
Tally Marks
You tally now!
Frequency Table
What type of jobs use frequency tables?
EXAMPLE
The marks awarded for an assignment set for a Year 8 class of 20 students were as follows:      6     7     5     7     7 ...
Solutions to Exercise 1.3 Result 3 Heads 2 Heads 1 Head 0 Heads Tally Frequency 3 11 9 2

Stem-and-Leaf Diagrams and Stemplots A  S & L diagram  represents data by seperating each value into two parts: the stem (...
To make a Stemplot, follow these steps: The following stem-and-leaf plot shows the record of wins for the Eastern Conferen...
Back-to-Back S & L This S & L Diagram compares two data sets.
Histograms H. break the range of values of a variable into classes and display only the count or per cent of the observati...
The following frequency table shows the times, in minutes, spent by a group of woman in a boutique. Draw a histogram of th...
Distribution of Data
Symmetric Distribution If the values smaller and larger than its midpoint are mirror images of each other
Negatively Skewered Distribution Also known as a skewered left distribution.
Positively Skewered Distribution Also known as a skewered right distribution.
What are Variables? Variables are things that we measure, control, or manipulate in research. They differ in many respects...
Looking for Links <ul><li>Correlations and Associations </li></ul>
National Institutes of Health (NIH) <ul><li>Sedentary activities (like Tv watching) are associated with an increase in obe...
News Reporters love to tell stories about the latest links! Such as.. Does having her first baby later in life cause a wom...
‘ Count Cricket Chirps to Gauge Temperature’ ( Garden Gate ) ) What you have to do! 1. find a cricket 2. count the number ...

Table 18-1  Cricket Chirps and Temperature Data (Excerpt) No. of Chirps in 15 sec Temperature (in degrees Fahrenheit) 18 5...
To make a Stemplot, follow these steps: The following stem-and-leaf plot shows the record of wins for the Eastern Conferen...
Bivariate Data
<ul><li>Two variables </li></ul><ul><li>Tied or paired together </li></ul><ul><li>Two - dimensional data </li></ul><ul><li...
Lets see another example!
A Press Release by Ohio State University Medical Center The headline says that... “ aspirin can prevent polyps in colon ca...
Raw Data for this Study <ul><ul><li>ID NO. 22292  GROUP=ASPIRIN  DEVELOPED POLYPS=NO </li></ul></ul><ul><ul><li>(635 LINES...
Scatter Plots <ul><li>Bivariate Numerical Data </li></ul><ul><li>Two Dimensions </li></ul><ul><li>Horizontal dimension (x-...
Scatter Plot of cricket chirps versus outdoor temperature.
Interpreting a Scatterplot <ul><li>you do this by looking for trends in the data as you go from left to right. </li></ul>
<ul><li>Positive linear relationship </li></ul><ul><li>Proportional relationship </li></ul><ul><li>As x increases (moves r...
<ul><li>Negative linear relationship </li></ul><ul><li>Inverse relationship </li></ul><ul><li>As x increases, y decreases ...
<ul><li>If the data don’t seem to resemble any kind of line (even a vague one) this means that no linear relationship exis...
Positive Linear Relationship as the cricket chirps increase so does the temperature aswell.
Q. 3 Page 6 AQA GSCE  Age of Car Value of Car (£)
Q. 4
Q 5. Point A B C D E F G H I J Days abs ent 1 2 3 4 5 6 7 8 9 10 No. of peop p 30 50 36 8 36 28 16 58 34 42
Q. 6
Q. 7
Quantifying the Relationship <ul><li>Quantify or measure the extent and nature of the relationship. </li></ul>
We have already seen how to measure the direction of a linear relationship BUT you will also have to decide on the STRENGT...
Correlation Coefficient <ul><li>Measures the strength and direction of the linear relationship between x and y (or the ver...
Calculating the C.C. <ul><li>It is represented by the letter  r </li></ul><ul><li>It has a value between - 1 and 1 </li></...
<ul><li>If r is close to 1, then there is a  strong positive correlation  between two sets of data. </li></ul><ul><li>If r...
Types of Correlation
It is important you state the Direction and the Strength of a Correlation Correlation Coefficient = 0.99  Correlation coef...
A positive correlation means that high values of one variable are associated with high values of a second variable . The r...
Correlation Coefficient = - 0.99  Correlation Coefficient = - 0.5
A negative correlation or relationship means that high values of one variable are associated with low values of a second v...
No CORRELATION Correlation Coefficient = -.16
8.2 Scatter Plots Aus. Book Q. 3
Q. 4
Q. 7
Using your calculator to calculate the C.C!
Correlation Coefficient  Before doing this on the calculator, the class should do a scatter graph using the data in the ta...

SHARP EL-W531 Mode  1  1 2 (x,y) 5  DATA 12  (x,y)  24  DATA 21  (x,y)  24  DATA 15  (x,y)  25  DATA RCL  r  x y 2 2 12 21...
Correlation Coefficient by Calculator This will show the table on the right on the screen. When all the data items are inp...
Scatter Plot of cricket chirps versus outdoor temperature.
Correlation of 0.98!
Correlation versus Causation
<ul><li>The amount of fuel burned by a car depends on the size of its engine, since bigger engines burn more petrol. We sa...
<ul><li>If two variables are found to be either associated or correlated, that doesn’t necessarily mean that a cause-and-e...
<ul><li>During 1980 and 2000 there was a large increase in sales of calculators and computers! </li></ul><ul><li>There was...
NO!!!! Production Costs Decreased Cost of Production was a third variable causing the other two to increase. We call this ...
Linear Regression <ul><li>Line of Best Fit </li></ul>
<ul><li>After you’ve found a relationship between two variables  </li></ul><ul><li>and you have some way of quantifying th...
<ul><li>1. Draw a Scatter Plot. </li></ul><ul><li>2. If graph suggests a linear relationship.. </li></ul><ul><li>3. Calcul...
Because you have a strong correlation be it positive or negative you know that x is correlated with y. If you know the slo...
Drawing by Eye <ul><li>Draw the line so there are roughly equal points above and below the line. </li></ul>
Drawing by Eye Two <ul><li>Draw a vertical line that splits the points up into two equal sized groups.  If there are an od...
<ul><li>Draw a cross or marker at the midpoint of each of the two groups.  The midpoint is the location found in steps 2 a...
Step 1
Step 2
Step 3
Step 4
Step 5
Now Calculate Line! i.e. what is the formula for the line? i.e. what is the formula for the line?
<ul><li>Equation: y = mx + c </li></ul><ul><li>M = slope y2-y2/x2-x1 where (x1,y1) and (x2,y2) are points on the line of b...
Q. 3  AQA GSCE
Q. 5
Q. 6
Q. 9 Active Maths 0.98
Q. 10 0.90
Exercise 1.7 QUESTION 4 (ii)0.96 (iii) Strong Positive Correlation (v) y = 4x + 6 (vi) € 18, 000

Q. 5 <ul><li>(ii) 1.00 </li></ul><ul><li>(iv) Perfect positive correlation </li></ul><ul><li>(v) y = 11/7 (x-51/7) </li></ul>

Q. 6 <ul><li>(ii) 0.99 </li></ul><ul><li>(iii)Near - perfect positive correlation </li></ul><ul><li>(v) y = 2.5 x + 14 </l...
Let’s Sum up! <ul><li>Types of Sampling </li></ul><ul><li>Populations and Samples </li></ul><ul><li>Types of Sampling </li...
<ul><li>Frequency Tables </li></ul><ul><li>Stem-and-Leaf Diagram </li></ul><ul><li>Back-toBack S & L </li></ul><ul><li>His...
<ul><li>Scatter Graph </li></ul><ul><ul><li>Correlation </li></ul></ul><ul><ul><li>Correlation Coefficent </li></ul></ul><...
