SharePoint & jQuery – What I Wish I Would Have Known When I Started…Mark Rackley – Solutions Architect /SharePoint Practic...
Agenda• jQuery Overview• jQuery & SharePoint – What’s the  Point?• Deployment, Maintenance, Upgrades• SPServices• Developm...
What is jQuery?• JavaScript utility library• Quickly write interactive and USABLE  applications• You don’t have to deploy ...
What Skills do I need?• JavaScript (duh)• CSS, XML• A development background   – It IS code   – Uses development construct...
SharePoint & jQuery? Why?Resolves many common SharePoint complaints without          having to crack open Visual Studio
SharePoint & jQuery? Why?        “It looks like SharePoint”
SharePoint & jQuery? Why?            “That’s SharePoint?”
SharePoint & jQuery? Why?   “I’m so sorry… SharePoint can’t do that out of the box”
SharePoint & jQuery? Why?           “Sure, no problem”
SharePoint & jQuery? Why? “That will take 3 weeks???” becomes “2 days? Awesome! I love you… here, please accept this bonus...
jQuery makes your SharePoint    applications USABLE
Common Myths• It’s not secureBusted… It uses SharePoint’s security. All scripts run withprivileges of current user• It doe...
Yeah but…• I can’t interact with SharePoint Lists and  Libraries without screen scrapingYou can call Web Services with Jav...
So… jQuery MUST be…
Not So Fast…• It does “expose” business logic to user if they dig around• It executes on the client side and can perform s...
Deployment Options
Deployment options• Folders in SPD / Visual Studio Module• File System  – Deployed with a WSP (don’t think of manually    ...
Deployment options• Document Library  – Easily modify scripts  – Keep track of changes with Metadata  – Recover from screw...
Deployment options
Reference Options• ScriptLink      • MasterPages, Delegate Controls, Web Parts, Controls, Custom        Pages      • Ensur...
Reference Options• Custom Action       • Loads Script on every page       • Works in sandbox<?xml version="1.0" encoding="...
Maintenance Best Practice• Don’t add script directly in your Master Pages  – Difficult to maintain  – Must make modificati...
Moving Between Environments andUpgrading to 2010• It just works… (woo hoo)  – Uses list names and not GUIDs so no issues  ...
jQuery is anothertool for theSharePointDeveloper’s toolkitUnderstand thelimitationsUse it wisely
Development Basics• jQuery methods are executed using jQuery() or $()• $(document).ready() is your “main()”   – Don’t HAVE...
Development Basics• $(‘#elementID’).html() gets the raw html within an element  (great for divs, spans, tables, table cell...
SharePoint Form Fields//Text / Date Fields$(“input[title=’Field Display Name’]”).val();//LookUp / Choice Fields (be aware ...
SPServices• jQuery library to execute SharePoint’s Web  Services  –   Get List Items  –   Add/Update List Items  –   Creat...
SPServices• Works identical in SharePoint 2007 and  SharePoint 2010• Runs with permissions of current user• Communicate ac...
SPServices - FYI• Use internal field names• Returned values have “ows_” in front of field  names  $(this).attr("ows_Title"...
SPServices GetListItems
SPServices UpdateListItems
Development Tips• Develop for performance  – Limit rows returned using CAML  – Avoid screen scraping (Use SPServices)  – D...
Don’t abuse the DOM!It’s expensive to search the Document Object Model (DOM)              <select id=“MySelect”></select> ...
Debugging… ugh.. It ain’t pretty• Alerts.. Alerts.. Alerts.. Alerts…• Developer Tools   – Set breakpoints   – Evaluate exp...
Debugging… Common Errors• Usually it means your library didn’t get loaded   – Object Expected   – Object doesn’t support m...
DEMOS
So, what’s the deal?
”Fast Food” Development•   You don’t have to be a SharePoint Guru•   It’s Cheap•   It’s Quick•   It’s Easy•   It gets the ...
”Fast Food” Development•   Don’t abuse it, You’ll pay for it later•   Limited choices•   There are healthier options•   Ad...
Getting Started…• A Dummies Guide to SharePoint and jQuery  – http://bit.ly/jQueryForDummies• SPServices  – http://spservi...
More jQuery Resources• jQuery Pocket Reference  – http://oreilly.com/catalog/0636920016182• CSS Pocket Refernce  – http://...
Questions?      Don’t drink the      haterade…Mark Rackleymrackley@juniper-strategy.comwww.twitter.com/mrackleywww.sharepo...
Upcoming SlideShare
Loading in...5
×

SPSDenver - SharePoint & jQuery - What I wish I would have known

2,129

Published on

SharePoint & jQuery - Introduction and Best Practic

Published in: Technology
0 Comments
2 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
2,129
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
0
Comments
0
Likes
2
Embeds 0
No embeds

No notes for slide

Transcript of "SPSDenver - SharePoint & jQuery - What I wish I would have known"

  1. 1. SharePoint & jQuery – What I Wish I Would Have Known When I Started…Mark Rackley – Solutions Architect /SharePoint Practice Lead / DeveloperEmail: mrackley@juniper-strategy.comBlog: http://www.sharepointhillbilly.comTwitter: http://www.twitter.com/mrackley
  2. 2. Agenda• jQuery Overview• jQuery & SharePoint – What’s the Point?• Deployment, Maintenance, Upgrades• SPServices• Development & Debugging• Examples 2
  3. 3. What is jQuery?• JavaScript utility library• Quickly write interactive and USABLE applications• You don’t have to deploy assemblies (perfect for tightly controlled environments)
  4. 4. What Skills do I need?• JavaScript (duh)• CSS, XML• A development background – It IS code – Uses development constructs – If you can’t write code, your ability to do magic will be limited to what you can copy/paste• CAML, CAML, CAML… Sorry…• Ability to think outside the box – Use all the pieces together
  5. 5. SharePoint & jQuery? Why?Resolves many common SharePoint complaints without having to crack open Visual Studio
  6. 6. SharePoint & jQuery? Why? “It looks like SharePoint”
  7. 7. SharePoint & jQuery? Why? “That’s SharePoint?”
  8. 8. SharePoint & jQuery? Why? “I’m so sorry… SharePoint can’t do that out of the box”
  9. 9. SharePoint & jQuery? Why? “Sure, no problem”
  10. 10. SharePoint & jQuery? Why? “That will take 3 weeks???” becomes “2 days? Awesome! I love you… here, please accept this bonus for being such a wonderful developer”
  11. 11. jQuery makes your SharePoint applications USABLE
  12. 12. Common Myths• It’s not secureBusted… It uses SharePoint’s security. All scripts run withprivileges of current user• It doesn’t perform wellPlausible… It performs very well if you use it correctly in the rightsituations• I can’t elevate privileges if I need toConfirmed…
  13. 13. Yeah but…• I can’t interact with SharePoint Lists and Libraries without screen scrapingYou can call Web Services with JavaScript (SPServices is awonderful jQuery library that wraps SharePoints Web Servicecalls) and the Client Object Model in 2010• It has no real use in my environment because of “x”Quickly prototype and tweak web parts before writing in VisualStudio. In fact, in some environments it is the only developmentoption.
  14. 14. So… jQuery MUST be…
  15. 15. Not So Fast…• It does “expose” business logic to user if they dig around• It executes on the client side and can perform slow if manipulating larges amounts of data• Be extra careful for external facing applications• You can’t do EVERYTHING with jQuery like… – Timer Jobs – Workflows (although it can eliminate the need for some) – Event Handlers – Elevate Privliges – Easily interact with all business systems• jQuery CAN harm your farm!
  16. 16. Deployment Options
  17. 17. Deployment options• Folders in SPD / Visual Studio Module• File System – Deployed with a WSP (don’t think of manually copying) – Not an option for Office 365 or hosted SharePoint 2010• External Reference – Microsoft Ajax Content Delivery Network (CDN) http://www.asp.net/ajaxlibrary/cdn.ashx
  18. 18. Deployment options• Document Library – Easily modify scripts – Keep track of changes with Metadata – Recover from screw ups with Versioning – Less control, more flexibility versus other options
  19. 19. Deployment options
  20. 20. Reference Options• ScriptLink • MasterPages, Delegate Controls, Web Parts, Controls, Custom Pages • Ensures Script is not loaded multiple times • Renders in the correct place in the markup • Need Visual Studio or SPD • More upfront work• Content Editor Web Part (CEWP) • Quick & Easy • Don’t have to deploy anything • Adds CEWP overhead
  21. 21. Reference Options• Custom Action • Loads Script on every page • Works in sandbox<?xml version="1.0" encoding="utf-8"?><Elements xmlns="http://schemas.microsoft.com/sharepoint/"> <CustomAction ScriptSrc="~sitecollection/SiteAssets/jquery.min.js" Location="ScriptLink" Sequence="100" > </CustomAction></Elements>
  22. 22. Maintenance Best Practice• Don’t add script directly in your Master Pages – Difficult to maintain – Must make modifications in SPD / Visual Studio – Use Custom Action instead• Don’t add scripts directly in your CEWP – Using content link instead of editing the CEWP source. – No reuse
  23. 23. Moving Between Environments andUpgrading to 2010• It just works… (woo hoo) – Uses list names and not GUIDs so no issues moving from dev to prod – For the most part works identical in 2007 and 2010 (I’m sure there’s the occasional issue but I’ve never run into it). – Might want to tweak in 2010 to take advantage of 2010 features (ribbon, modal pop-ups)
  24. 24. jQuery is anothertool for theSharePointDeveloper’s toolkitUnderstand thelimitationsUse it wisely
  25. 25. Development Basics• jQuery methods are executed using jQuery() or $()• $(document).ready() is your “main()” – Don’t HAVE to, but easy to quickly locate where script starts• $(‘#elementID’) to interact with any element – Divs, tables, rows, cells, inputs, selects.. Etc.. Etc.. Etc… – <table id=‘myTable’></table> – $(‘#myTable’).append(‘<tr><td>add a row</td></tr>’);• $(‘#elementID’).val() gets values of inputs – <input type=‘text’ id=‘myTextBox’ > – $(‘#myTextBox’).val();• $(‘#elementID’).val([value]) sets the values of inputs – $(‘#myTextBox’).val(‘Hello World’);
  26. 26. Development Basics• $(‘#elementID’).html() gets the raw html within an element (great for divs, spans, tables, table cells, etc.) – <div id=‘myDiv’>Hello World</div> – $(‘#myDiv’).html() = ‘Hello World’• $(‘#elementID’).html(“<html text>”) to set raw html – $(‘#myDiv’).html(‘Hello World! Welcome to SPSSTL!’)• $(‘#elementID’).hide(), $(‘#elementID’).show(), and $(‘#elementID’).toggle() – $(‘#myDiv’).hide() – $(‘#myDiv’).show() – $(‘#myDiv’).toggle()
  27. 27. SharePoint Form Fields//Text / Date Fields$(“input[title=’Field Display Name’]”).val();//LookUp / Choice Fields (be aware of >20 items in Lookup)$(“select[title=’Field Display Name’]”).val();//Is my check box checked?if( $("input[title=’Field Display Name’]").is(:checked)){ alert("its checked");}More information:http://bit.ly/jQueryAndSharePointFields
  28. 28. SPServices• jQuery library to execute SharePoint’s Web Services – Get List Items – Add/Update List Items – Create lists, content types, site columns, etc. – Create document library folders - Create cascading drop down lists - Get user groups and permissions - Potentially call ANY SharePoint Web Service
  29. 29. SPServices• Works identical in SharePoint 2007 and SharePoint 2010• Runs with permissions of current user• Communicate across sites• Works with Anonymous access!
  30. 30. SPServices - FYI• Use internal field names• Returned values have “ows_” in front of field names $(this).attr("ows_Title");• Lookup & People fields – Value returned as “ID;#Value” (1;#Field Value)• Check for new item ID on item add to make sure item added correctly var newID = $(xData.responseXML).find("[nodeName=z:row]").attr("ows_ID");
  31. 31. SPServices GetListItems
  32. 32. SPServices UpdateListItems
  33. 33. Development Tips• Develop for performance – Limit rows returned using CAML – Avoid screen scraping (Use SPServices) – Don’t call web services until the data is needed.• Use those ID’s to your advantage – <td id=‘ListName-4’>• Attributes are awesome – <input type="text" title="list title 4" id="4"> – $(#4).attr("title"); – $(‘input*title=“list title 4”+’).val();
  34. 34. Don’t abuse the DOM!It’s expensive to search the Document Object Model (DOM) <select id=“MySelect”></select> for (i=0;i<=500;i++) { $("#MySelect").append("<option>One Item " + i +"</option>"); }___________________________________________________________________________________________________________________ var options = “”; for (i=0;i<=500;i++) { options += "<option>All Items " + i + "</option>"; } $("#MySelect").append(options);
  35. 35. Debugging… ugh.. It ain’t pretty• Alerts.. Alerts.. Alerts.. Alerts…• Developer Tools – Set breakpoints – Evaluate expressions and variables inline (like REAL debugging!) – Firebug for Firefox • Considered to be best of the free tools out there – IE Developer Tools • Comes installed on IE 8+ • console.log (don’t forget to remove before deploying)
  36. 36. Debugging… Common Errors• Usually it means your library didn’t get loaded – Object Expected – Object doesn’t support method• Make sure you don’t load scripts more than once – Null Object reference• Check your braces• Make sure you end lines with “;”• Check for missing quotesWhen all else fails, delete your script and rebuild it slowly inchunks, testing as you go.
  37. 37. DEMOS
  38. 38. So, what’s the deal?
  39. 39. ”Fast Food” Development• You don’t have to be a SharePoint Guru• It’s Cheap• It’s Quick• It’s Easy• It gets the job done
  40. 40. ”Fast Food” Development• Don’t abuse it, You’ll pay for it later• Limited choices• There are healthier options• Adds page bloat• Can slow your performance
  41. 41. Getting Started…• A Dummies Guide to SharePoint and jQuery – http://bit.ly/jQueryForDummies• SPServices – http://spservices.codeplex.com• Super Awesome 3rd party libraries that integrate well – Modal dialogs - http://www.ericmmartin.com/projects/simplemodal/ – Calendar - http://arshaw.com/fullcalendar/ – Charts - http://g.raphaeljs.com/
  42. 42. More jQuery Resources• jQuery Pocket Reference – http://oreilly.com/catalog/0636920016182• CSS Pocket Refernce – http://oreilly.com/catalog/9780596515058/
  43. 43. Questions? Don’t drink the haterade…Mark Rackleymrackley@juniper-strategy.comwww.twitter.com/mrackleywww.sharepointhillbilly.com 43

×
