  • 1. Smart Cities Wireless sensor networks Marc Pous, Researcher Jornades Abertis, BDigital, 2011
  • 2.
      • Motivation
      • Sensor networks
      • Applications and companies
      • Future challenges
    of 45
  • 3.
      • Motivation
      • Elements of a sensor network
      • Trends in sensor networks
      • Overview challenges
      • Sensor networks
      • Applications and companies
      • Future challenges
    of 45
  • 4. Source: Fabien Girardin and Josep Blat of 45
  • 5.
    • In 2008, 50% of the world population lived in cities.
    • By 2012, M2M communication will be 20% of the non-video Internet traffic.
    • IPv6
      • Passive  Interactive
      • Deferred  Real-time
      • Object  Service
    Trends in sensor networks of 45
  • 6.
    • Energy harvesting
    • Hardware constraints
    • Security and privacy
    • Interoperability (data and communications)
    Overview challenges of 45
  • 7. Sensor networks of 45
  • 8.
      • Motivation
      • Sensor networks
        • Sensor node architecture
        • Sensor networks topologies
        • Sensor networks communication technologies
        • Sensor networks routing techniques
        • Sensor networks data
      • Applications and companies
      • Future challenges
    of 45
  • 9.
      • A sensor network is a system of one or more sensors that detect, collect and possibly respond to things or events.
      • Large number of sensor nodes, which are densely deployed either inside the phenomenon or very close to it.
      • Inter-connected sensor nodes exchanging sensed data by wired or wireless processing.
    Sensor network architecture of 45
  • 10.
    • A sensor node integrates one or more sensors or actuators , a processor , a communication unit , a power supply and management unit.
    Sensor node architecture Source: Wireless Sensor Networks by Thomas Watteyene of 45
  • 11.
    • Motes
        • A very low cost low power computer
        • Nanotechnology
        • A Radio Link to the outside world
        • Are the building blocks of Wireless Sensor Networks (WSN)
      • The most popular motes probably are:
        • Mica2
        • MicaZ
        • TelosB
    Sensor node architecture of 45
  • 12.
    • Operating systems
    Sensor node architecture of 45 Operating system Sensor node supported platform TinyOS Btnode, Imote, Iris, Mica, Mica2, MicaZ, SenseNode, TelosB, T-Mote Sky, Shimmer Contiki T-Mote Sky, TelosB, MSP430 MCU Mantis OS Mica2, MicaZ, Nymph, TelosB SOS T-Mote Sky, Mica2, MicaZ, TelosB, Cricket Microsoft .NET Micro Imote 2.0
  • 13.
    • Network routing is the process of selecting a path for the relaying of a message from a source device to the intended destination.
    • WSN topology
        • Star topology
        • Tree topology
        • Mesh topology
    Sensor networks topologies of 45
  • 14. Sensor networks routing techniques
    • Routing protocols
        • Flat routing
        • Hierachical routing
        • Geographic routing
        • Mobile Ad Hoc Network (MANET)
          • Ad-hoc On- demand Distance Vector (AODV)
        • IETF Routing Over Low power and Lossy Networks (ROLL)
          • IPv6 Routing Protocol for Low power and Lossy Networks (RPL)
    of 45
  • 15. Sensor networks communication technologies of 45 Bluetooth ZigBee 6LoWPAN Range 10-100 m 10-75 m 10-75 m Owner Bluetooth SIG ZigBee Alliance IETF Application sectors
    • Mobile device interconnectivity
    • PC peripheral connectivity
    • file transfer (OBEX)
    • remote control
    • health care
    • Sensor networks
    • access control
    • home automation
    • Sensor networks
    • Access control
    • home automation
  • 16. Sensor networks communication technologies
    • Communication technologies interoperability
      • Profiles
        • ZigBee
          • Elster Demonstrates ZigBee Interoperability with Smart Energy profile
        • Bluetooth Low Energy
      • Trends
        • Protocol translation gateways
        • Benefits of IPv6
          • The Z-Wave Alliance announced the Z/IP program to drive convergence of Z-Wave and TCP/IP (2007)
          • The ZigBee Alliance and IPSO Alliance Collaborate on ZigBee IP and ZigBee Smart Energy 2.0 (2009-2010)
    of 45
  • 17.
    • Web of Things
    Sensor networks data Source: Vlad Trifa and Dominique Guinard of 45
  • 18.
    • XML
      • Binary XML (BXML)
      • Efficient XML Interchange (EXI)
      • Extended Environments Markup Language (EEML)
        • Describes sensors data collected in a structured form
      • SensorML
        • Provides metadata describing sensors, sensor platforms, sensor tasking interfaces as sensor generated data
    • Harmonization of Sensor Standards WG
      • Sensor ontology
        • including IEEE 1451, ANSI N42.42 and CBRN data model, among others
    Sensor networks data of 45
  • 19.
    • Pachube
    Sensor networks data Source: Pachube of 45
  • 20. Applications and companies involved in sensor networks of 45
  • 21.
      • Motivation
      • Sensor networks
      • Applications and companies
        • Energy monitoring
        • Logistics
        • Environmental monitoring
        • Public spaces management
        • Intelligent buildings
        • Traffic control and public transportation
        • Health and personal assistance care monitoring
        • Industrial processes
      • Future challenges
    of 45
  • 22. Applications of sensor networks 1/8
    • Energy monitoring
    of 45 Application What can be sensed? Companies Comments Smart metering
    • Electricity
    • Gas
    • Water
        • Landis Gyr (CH), Itron (UK), Echelon (US), Coronis/Elster (FR, US), Millenial Net (US), Libelium (ES), Sentilla (US), Ember (US), Sensus (US )
    • American model vs European model
    • ZigBee
    • PLC
    Pipe leakage detection and tank or silos level management
    • Oil
    • Water
        • Landis Gyr (CH), Vögtlin (CH), Honeywell (US), Coronis/Elster (FR, US), Sensus (US)
    • BP North Sea platform 2004
    • ZigBee
  • 23.
    • Coronis / Elster
      • Coronis is the creator of Wavenis®
      • Major markets:
        • smart metering, home comfort, alarms, home healthcare, industrial automation, centralized building management
      • 5M of Wavenis-enabled products deployed worldwide in 2010
    Companies in sensor networks of 45
  • 24. Applications of sensor networks 2/8
    • Logistics
    of 45 Application What can be sensed? Companies Comments Control of the state of the merchandise
    • Temperature
    • Humidity
    • etc.
    • Vibration
    • Position (GPS)
        • Crossbow (US), Tiny Node (CH), Libelium (ES), WorldSensing (ES)
    Localization of merchandise and transportation tracking
    • GeoPosition
    • Barcodes/RFID
        • Digi (US), Libelium (ES), GMV (ES), Ubisense
    • Harbors container management
    • RFID
    • ZigBee
  • 25.
    • Digi International
      • Founded in 1985, in United States.
      • Major markets:
        • Monitoring and management of renewable energy
        • Wireless tank monitoring and management
        • Tracking and monitoring of mobile assets
    Companies in sensor networks of 45
  • 26.
    • Environmental monitoring
    Applications of sensor networks 3/8 of 45 Application What can be sensed? Companies Comments Weather stations
    • Temperature
    • Humidity
    • Atmospheric pressure
    • Light intensity
    • CO2 detector
        • Crossbow (US), Arch Rock (Cisco), Urbiotica (ES)
    • Emissions from farms, chemical and industrial processes
    • Forest fires
    Agriculture
    • Soil moisture
    • Fruit diameter
    • Leaf wetness
        • Crossbow (US), E-Senza (UK), Libelium (ES), IRIS (ES)
    • Vineyards
    Marine
    • Temperature
    • Presence of bacteries
    • Sea level
        • MantraCourt (UK), Honeywell (US)
  • 27.
    • Crossbow
      • Created in 1995, in California
      • Major markets:
        • Environmental systems and agriculture
        • Logistics
        • Monitors energy
    Companies in sensor networks of XX
  • 28.
    • Public spaces management
    Applications of sensor networks 4/8 of 45 Application What can be sensed? Companies Comments Structural monitoring
    • Vibrations
    • Displacement detection
    • Temperature
        • MantraCourt (UK)
    • San Francisco bridge
    Garbage collection
    • Container emptiness
    • GeoPosition
        • WorldSensing (ES)
    • Route planner
    Street light systems
    • Presence detection
    • Energy consumption
        • Philips (NE), Echelon (US)
  • 29.
    • Echelon
      • Created in 1988, in United States
      • Major markets:
        • Building automation (LonWorks)
        • Street lighting
        • Industrial automation
        • Transportation automation
    Companies in sensor networks of XX
  • 30.
    • Intelligent buildings
    Applications of sensor networks 5/8 of 45 Application What can be sensed? Companies Comments Home automation
    • Temperature
    • Light detector
    • Presence detectors
    • Energy consumption
        • General Electrics (US), Control4 (US), Greenwave (DK), Hai (US), Echelon (US)
    Building management
    • Access controls
    • HVAC systems
        • Scheneider (GE), Siemens (GE), Philips (NE), enOcean (GE)
  • 31.
    • EnOcean
      • Created in 2001, in Germany
      • Sensor modules from EnOcean harvest tiny amounts of energy from their surroundings, enabling them to register detected values and transmit them wirelessly.
      • Major markets:
        • Building automation
        • Home automation
      • Torre Espacio de Madrid
        • 4,200 light and blind switches
        • http://www.enocean.com/en/torre-espacio-madrid-spain-2007/
    Companies in sensor networks of 45
  • 32.
    • Transportation
    Applications of sensor networks 6/8 of 45 Application What can be sensed? Companies Comments Traffic monitoring
    • Cameras
    • GeoPosition
    • Speed
        • BitCarrier (ES), WorldSensing (ES), Sensys Networks (US), Nivis (US), Smartgrains (FR), Echelon (US)
    • Traffic jams management
          • Cameras, inductive loops, GPS, Bluetooth detectors, MEMS
    Toll payment
    • RFID (presence)
        • Urbiotica (ES)
    • Teletac
    Smart parking
    • Presence detector
        • Streetline networks (US), World Sensing (ES), Urbiotica (ES)
    • Inductive loops
    • Parking payment through mobile phone
  • 33.
    • Streetline Networks
      • Created in California
      • Major markets:
        • Parking monitoring and management
        • Traffic monitoring
    Companies in sensor networks of 45
  • 34.
    • Health
    Applications of sensor networks 7/8 of 45 Application What can be sensed? Companies Comments Healthcare
    • Blood’s pressure
    • Temperature
    • Sugar in blood
    • etc.
        • Philipps (HO), Coronis (FR), Sensinode (FI)
    • Body sensor network
    Sports and fitness (wellness)
    • Geoposition
    • Speed
    • Calories
    • etc.
        • Dynastream Innovations (CA), Nordic Semiconductor (NO)
    • ANT
    • Nike+
      • Personal care and assistance
    • Gyroscope
    • Accelerometer
        • Sensing & Control (ES)
    • Falling detector
  • 35.
    • Dynastream Innovations
      • Created in 1998, is based in Canada.
      • World leader in the research of inertial and wireless technology. Integrators of ANT technology into sensors.
        • Nike products
          • ANT was born out of the need to develop the very lowest available power solution for Nike’s foot pod to watch communication.
    Companies in sensor networks of 45
  • 36.
    • Industrial monitoring
    Applications of sensor networks 8/8 of 45 Application What can be sensed? Companies Comments Process monitoring
    • Temperature
    • pressure
    • contact closure
    • valve positioning
    • gas detection
    • corrosion detection
    • Optical detector
        • Dust Networks (US), CrossBow (US), SENSICAST(US), Arch Rock (Cisco), E-Senza (GE), Nivis (US), Honeywell (US)
    • Quality of service
    • Time Synchronized Mesh Protocol (TSMP)
    • WirelessHART
    • ISA100.11a
    • Xmesh
    • Sensinet
    Security in processes
    • Camera
    • Gas detector
        • Honeywell (US) , Gastronics (US)
  • 37.
    • Honeywell
      • Created in 1906, in United States
      • Major markets:
        • Metering sensors and Industrial processes
    Companies in sensor networks of 45
  • 38. of 45 Nordic Semiconductors, Atmel Corp EnOcean Dust networks Libelium World Sensing, Sensing & Control, Urbiòtica, Streetline Crossbow Arch Rock (Cisco) Texas Instruments, Freescale Coronis/Elster Digi International
  • 39. Future challenges in sensor networks of 45
  • 40.
      • Motivation
      • Sensor networks
      • Applications and companies
      • Future challenges
        • Efficient energy harvesting
        • Security and privacy
        • Hardware constraints
        • Interoperability
    of 45
  • 41.
    • Efficient energy harvesting
      • Lack of power during some time
      • Consume extremely low power
    Future challenges of 45
  • 42.
    • Security and privacy
      • Security
      • Privacy
      • Dynamic and scalable sensor networks
    Future challenges of 45
  • 43.
    • Hardware constraints
      • Trends to nanotechnology
      • Performance
      • Low production cost
      • Repair
      • Monitoring and real-time control
    Future challenges of 45
  • 44.
    • Interoperability
      • Standardization
      • IP-based sensor networks and the Internet of Things
    Future challenges of 45
  • 45. Moltes gràcies! [email_address] Questions? [email_address]

×
