Survey of Cloud
Hosting Providers

   Michael Peters
    PlusThree, LP
   YAPC::NA 2010
What is "the cloud"?
The definition we'll use for a cloud
hosting provider is a hosting
provider that abstracts away the
h...
Why "the cloud"?
✔Minimal initial capital for a new startup or project
✔Easily make duplicates of servers to scale out
✔Ea...
Why not "the cloud"?
✔Extra strict security requirements (HIPAA, some
PCI Levels)
✔Your application needs access to the ha...
Oodles and Oodles
✔AppEngine (Google)
✔AWS (Amazon)
✔Azure (Microsoft)
✔Rackspace Cloud
✔Linode
✔Engine Yard
✔Prgmr
✔... a...
Oodles and Oodles
✔AppEngine (Google)
✔AWS (Amazon)
✔Azure (Microsoft)
✔Rackspace Cloud
✔Linode
✔Engine Yard
✔Prgmr
✔... a...
Why not...?
 Google's AppEngine
✔Python and Java (JVM) only
✔Very different architecture
✔Your application must be written...
Why not...?
 Microsoft's Azure
✔Fairly New
✔Windows only
  ✔some kind of special windows variant
✔Not a lot of choices in ...
Why not...?
 Engine Yard
✔Ruby on Rails only
Why not...?
 Prgmr
✔Extremely small "slices"
  ✔starts at 64MB RAM, 1.5G storage
  ✔biggest is 4GB RAM, 96G storage
Reference Setup
AWS
http://aws.amazon.com
Composed of lots of different services that
can be combined in different ways.

EC2, S3, EBS, SQ...
AWS
EC2 (Elastic Compute Cloud)
Basically their version of virtual hosts (using
the Xen hypervisor).

Most applications wo...
AWS
EC2 (Elastic Compute Cloud)
Operating Systems
✔Windows
  ✔Server 2003 and 2008
✔Linux
  ✔RHEL, Fedora, OEL, OpenSUSE,
...
AWS
EC2 (Elastic Compute Cloud)
Sizes
✔8 Different sizes in 3 different groups
   ✔standard
   ✔high-memory
   ✔high-cpu
✔...
AWS
EC2 (Elastic Compute Cloud)
Pricing Model
✔On Demand
  ✔Not sure how long you'll need it
✔Reserved
  ✔Can save up to 3...
AWS
EC2 (Elastic Compute Cloud)
Locations
✔Mutiple datacenters in multiple locations
  ✔Northern Virginia
  ✔Northern Cali...
AWS
EC2 (Elastic Compute Cloud)
IP Addresses
✔Instances are limited to 1 (private) IP
Address which is NAT'd to provide pu...
AWS
EC2 (Elastic Compute Cloud)
Elastic Load Balancing
✔Load balance HTTP traffic between EC2
instances.
✔Automatically de...
AWS
EC2 (Elastic Compute Cloud)
Storage
✔Completely ephemeral
✔Plan for failure
✔Not usable for services like a Database o...
AWS
EBS (Elastic Block Storage)
Block level storage volumes that can be
mounted to EC2 instances. Behave like
RAW unformat...
AWS
EBS (Elastic Block Storage)
✔Volume sizes from 1G to 1T
✔Volumes can be moved around EC2 hosts
✔Can't be shared at the...
AWS
EBS (Elastic Block Storage)
Not locally attached, which means every IO
operation is a network operation.

Can be mitig...
AWS
SimpleDB
Non-relational data store (NoSQL).
Automatic scaling, geographically
distributed, zero maintenance, key-value...
AWS
S3 (Simple Storage Service)
Storage of files that are available anywhere
via a URL.

Usable outside of EC2.

Pseudo CD...
AWS
SQS (Simple Queue Service)
Messaging system that can be used by EC2
instances even across zones.

Redundant storage of...
AWS
Cloud Watch
Monitor your EC2 instances to see how they
perform and what resources they are using.

Also allows monitor...
AWS - Basic Setup
AWS - Adv Setup
Linode
http://linode.com
Been around since 2003 providing VPS
hosting. One main product: their virtual
hosts ("linodes") u...
Linode
Operating Systems

✔Just Linux
  ✔Arch, RHEL, Fedora, CentOS, OEL,
  OpenSUSE, Ubuntu, Debian, Gentoo,
  Slackware
...
Linode
Sizes
✔10 Different sizes
✔Smallest: 512M RAM, 16G Storage
✔Largest: 20G RAM, 640G Storage
✔Network usage is built-...
Linode
Pricing Model
✔On Demand
  ✔Not sure how long you'll need it
✔Reserved
  ✔Can save up to 15%
Linode
Locations
✔Mutiple datacenters in multiple locations
  ✔Newark, NJ
  ✔Atlanta, GA
  ✔Dallax, TX
  ✔Fremont, CA
  ✔L...
Linode
IP Addresses
✔Instances start out with 2 IP Addresses (1
private, 1 public)
✔Additional IPs can be purchased
   ✔ir...
Linode
Storage
✔Permanent
✔All disks are local with RAID mirroring
✔No need for anything like EBS
✔Since total storage on ...
Linode
Misc
✔Free DNS hosting
  ✔Support for Reverse DNS
✔Customize Installs with "Stack Scripts"
✔Lish web-based console ...
Linode Setup
Rackspace Cloud
http://rackspacecloud.com

Formerley Mosso and then bought Slicehost
in 2008 and rebranded. Halfway betwee...
Rackspace Cloud
Operating Systems

✔Windows
  ✔Server 2003 and 2008 (beta)
✔Linux
  ✔Arch, RHEL, Fedora, OEL, OpenSUSE,
  ...
Rackspace Cloud
Sizes
✔7 Different sizes
✔Smallest: 256M RAM, 10G Storage
✔Largest: 16G RAM, 620G Storage
✔Network usage i...
Rackspace Cloud
Pricing Model
✔On Demand Only
✔Windows is more expensive than Linux
Rackspace Cloud
Locations
✔Mutiple datacenters in multiple locations
  ✔Dallas, TX
  ✔San Antonio, TX
  ✔Chicago, IL
  ✔Pl...
Rackspace Cloud
IP Addresses
✔Instances start out with 2 IP Addresses (1
private, 1 public)
✔Additional IPs can be purchas...
Rackspace Cloud
Storage
✔Permanent
✔All disks are local with RAID mirroring
✔No need for anything like EBS
✔Since total st...
Rackspace Cloud
Misc
✔Free DNS Hosting
  ✔Support for Reverse DNS
✔Can mix dedicated and cloud servers on
the same network
Rackspace Cloud
Cloud Files
✔Similar to AWS ES3
✔Store individual files accessible via URL
✔Can easily upgrade those files...
Rackspace Cloud
Cloud Sites
✔Basic site hosting with automatic failover,
load balancing and storage redundancy.
✔No root a...
Rackspace Setup
Feature Comparison
Feature                   AWS   Linode Rackspace
Linux                     Yes   Yes   Yes
Windows     ...
Feature Comparison
Feature                   AWS      Linode Rackspace
Auto Scaling              Yes      No       No
Clou...
Price Comparison
Feature              AWS                 Linode          Rackspace
256M RAM                              ...
Performance Comparison
I haven't done a comparison myself, but
others have:

http://www.thebitsource.com/featured-
posts/r...
Performance Comparison
5 different benchmarks were carried out
every 3 hours over a week, leading to 56
runs each. The slo...
Performance Comparison
Single Processor Unixbench
Performance Comparison
Multiple Processor Unixbench
Performance Comparison
SQLBench on PostgreSQL
Performance Comparison
Summarizing the benchmarks gives us one
clear winner: Linode. 32-bit gave the
best results on the U...
Conclusions
My personal opinion:

Go with Linode unless you have a good
reason not to. Unless you need:
✔Mixed dedicated a...
