HTML5 vs           Native Android   Smart Enterprises for the Future                      Suzanne Alexandra           Andr...
@suzalex@motodev#html5vsnative
where well play tonight
2011: Mobile exceeds PCs                           business insider http://read.bi/LX1kgl
2012: Mobile ubiquity   "We now live and always will live in a multi-device world,   where companies and consumers choose ...
Native Android                  Mobile middleware                      four tracks            HTML5, JavaScript           ...
Hybrid         Experience                  CostNative                                        Web         Performance      ...
Enterprise class apps   Real mobile experiences that challenge the processing   power, memory and display of the best mobi...
Native Android
What is native? android sdk                   android ndk (c/c++)    renderscript
Native apps run here
Key technology benefitsNative user experience      Integrate with android platformBest hardware integration   More discove...
image from gallerycamera   microphone                              capturing photo                          app widget,   ...
Key business benefitsLow barrier to entry         Reuse app functionalityDistribute through markets   Rich ecosystem, weal...
Cloud to device messagingPush a message, from your app serverTo Googles messaging serverTo the deviceDevice then contacts ...
Google Play             Easy to upload             Easy to update             Malware checks             Device or fea...
Market filtering   <?xml version="1.0" encoding="utf-8"?>   <manifest ... >   <uses-sdk android:minSdkVersion="8"         ...
But the cost?Development and design*           $250,000But, allow 1.5x – 2x              $375,000Then repeat, multiple pla...
The platforms                        Native Android      Cross-platform          No      User interface         High      ...
Mobile HTML5
Financial Times                             One app,                             many Android devicesvideo http://bit.ly/j...
Cross platform                            Android smartphoneiOS           Android tablet
Graceful degradation<canvas>Your browser is not supported</canvas>                              Feature detection         ...
Canvas<canvas id="canvas" width="838" height="220"></canvas>
Geolocationnavigator.geolocation.getCurrentPosition                       ( function ( position ) { … } );
Offline access … app cache                        CACHE MANIFEST                        index.html                        ...
Web socketsvar connection =  new WebSocket(ws://html5rocks.websocket.org);
Web workers        var worker = new Worker(worker.js);
Challenge: layoutsdesktop 1600 px                       tablet 800 / 1280 px                     smartphone 320 / 480 px
Responsive design Tiles on a flexible grid Media queries to check device  @media Think differently about content Beginn...
Challenge: interaction                         touch and gesture,                             tap and swipe
Touch and gesture Touch is instant, but click has ~300ms delay You also need swipe Basically, you need a touch libraryf...
Now.What about security?
A few tips Make sure the device is password protected and encrypted. Store locally only a small subset of enterprise dat...
How HTML5 and Chrome help                                   Origin                                   X-Frame-Options      ...
And one more thing         App updates are pushed out instantly             on your server -- no waiting
Browser comparison                     Android Browser          Google Chrome Feature              Android 1.5+           ...
The platforms                   Native Android            HTML5 Cross-platform          No                   Yes User inte...
Wheres it all going?The business model also changes as the revenue streamsgenerated from app stores diminish, causing vend...
Lets talk         @suzalex         @motodevdeveloper.motorola.com/enterprise
thanks · graciasdeveloper.motorola.com/enterprise
LEGALLICENSE NOTICESExcept where noted, sample source code written by Motorola Mobility Inc. and provided to you is licens...
