  • 1. Design and Testing for longer battery life in Android Devices & ApplicationsMoe Tanabian
  • 2. Batteries in Mobile Devices – Why are they important? Battery life: second most important purchase decision factor for tablets Cost of the device 65% Battery Life 51% Operating System(Apple iOS, Android, Windows) 40% Compatibility with other eq. you own 32% Cost/Contract flexibility of 3G service 32% Large screen size (i.e. the size of an iPad) 31% Positive reviews (e.g. other users, CNET) 31% Weight 28% How it looks , feels 26% Number of available apps 23% The brand of manufacturer 22% Manufacturer’s tech support 21% Number of ports (e.g. USB, headphone jack, etc.) 19% Ability to play Adobe Flash content 19% Accessories available 16% Has camera(s) 15% Ability to watch HD video 13% Has slide-out keyboard 13% Ability to hold in one hand 12%Based on 3,835 US online customers who would consider buying a tablet(multiple responses accepted, Source: North American Technologies, Customer Technology Survey 01/2011 2
  • 3. Outline What influences Battery Life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 3
  • 4. The 3 influencing elements on Battery Life – The Battery, The Hardware, and TheSoftware BATTERY HARDWARE SOFTWARE 1 2 3 4
  • 5. The Battery 1 Source: http://www.ifixit.com/ 5
  • 6. Batteries in Mobile Devices – Evaluating batteriesWhen we describe a battery and how appropriate it is for a particulardevice and application, we use three metrics to define the battery: n  Energy density (Power per weight unit, e.g. mA hour per Pound) n  Number of charging cycles the battery can take n  Charge rate n  Discharge rate 6
  • 7. Batteries in Mobile Devices – Battery ChemistryThere are three types of batteries that are extensively in use today, andeach provides certain strengths and weaknesses for different type ofdevices: n  Nickel Cadmium (NiCd): Strength: mature battery technology, has been around for long. Weakness: low energy density (Wh/Kg). Application: long battery life, high discharge rate and price economy are priority. n  Nickel Metal Hybrid (NiMH): Strength: more advanced Nickel based battery technology, compared to NiCd has higher energy density Weakness: shorter cycle life Application: Larger portable devices, Military 7
  • 8. Batteries in Mobile Devices – Battery Chemistry n  Lithium Ion (Li-ion): Strength: The newest and fastest growing battery technology. Li-ion batteries are smaller and lighter (higher energy density) Weakness: they are more expensive Application: the main type of battery used in mobile devices and handsets today - Li-ion battery with steady current within its dominated C can provide 700 charge Lithium Ion Polymer (Li-ion Polymer): A lower version of Li-ion battery with smaller profile and more simplified packaging. It has the same energy density as Li-ion batteries. 8
  • 9. Batteries in Mobile Devices – Battery Chemistry comparison chart NiCd NiMH Li-ion Li-ion polymer Gravimetric Energy 45-80 60-120 110-160 100-130 Density(Wh/kg) Internal Resistance 100 to 2001 200 to 3001 150 to 2501 200 to 3001 (includes peripheral 6V pack 6V pack 7.2V pack 7.2V pack circuits) in m Ω Cycle Life (to 80% of initial 15002 300 to 5002,3 500 to 10003 300 to 500 capacity) Fast Charge Time 1h typical 2-4h 2-4h 2-4h Overcharge Tolerance moderate low very low low Self-discharge / 20%4 30%4 10%5 ~10%5 Month (room tem perature) Cell Voltage (nom inal) 1.25V 6 1.25V 6 3.6V 3.6V Load Current - peak 20C 5C >2C >2C - best result 1C 0.5C or low er 1C or low er 1C or low er Operating -40 to -20 to -20 to 0 to Temperature (discharge only) 60°C 60°C 60°C 60°C Maintenance Requirement 30 to 60 days 60 to 90 days not req. not req. Commercial use since 1950 1990 1991 1999 Source: Batteries in a portable world by Isidor Buchmann 9
  • 10. Batteries in Mobile Devices – Discharge profiles of NiCd and NiMH batteries Source: Batteries in a portable world by Isidor Buchmann 10
  • 11. Batteries in Mobile Devices – Discharge characteristics of Li-ion batterySource: Batteries in a portable world by Isidor Buchmann 11
  • 12. Batteries in Mobile Devices – An electric model for a battery Ri Voc Cl Rl Voc: open circuit voltage Battery Ri : internal resistance Cl : load capacitance Rl : load resistance Source: Batteries in a portable world by Isidor Buchmann 12
  • 13. Batteries in Mobile Devices – Smart Battery packs Smart battery pack should be able to report: -  Battery’s State of Charge (SoC) -  State of Health -  Battery’s chemistry They come in different complexities: -  Single Wire Bus Terminal -  SMBus based on a bi-directional two wire I2C data communication Source: Batteries in a portable world by Isidor Buchmann 13
  • 14. The Hardware 2 Source: http://www.ifixit.com/ 14
  • 15. Power consumption measurement approaches – component, device level n  In this method, the device power consumption is the aggregate of measured power consumption of each subsystem Component level n  This method is more accurate, and the results are more reproducible; it is often used by device OEMs n  It take more effort and it is more expensive n  Detailed device HW and SW documentation is needed n  The power is measured at the aggregate point of battery connection in thisDevice (Application) method; power consumption is measured for different device use cases level n  This method is easier, and more practical for most cases; it is widely used by network operators n  Since the results may vary from run to run, it is necessary to repeat the test runs to achieve statistical significance and stability 15
  • 16. Power consumption measurement approaches – component level Power is measured at every important component: RF, Processors, Mem, Screen (An LTE device) RF Frontend Wi-Fi, for other Audio Magnetic RF Bluetooth globally Codec sensor supported Transceiver Transceivers bands (*assumed 10 GPS Accelerometer Gyroscope bands) Receiver 10* X Power Amp Bank 10 X LPF Baseband Application Bank Processor Memory FDD/TDD LTE 1X / EVDO (Flash, RAM) HSPA(+) RF Transceiver PowerAmp MDM 96XX LTE DC-HSPA, Graphics LPF Bank Display DOrB, EDGE Very High Power user High Power user Moderate Power user For component level measurement, power is measured in relevant device main states: Idle, Suspended and Active 16
  • 17. The Software 3 Source: http://www.ifixit.com/ 17
  • 18. Design for power efficiency – Android Power Management Applications Application 1 Application 2 Application 3 Wl = newWakeLock(…) Wl.acquire() Wl.release() POWER MANAGER APP Android.os.PowerManager Android.os.Power Framework Android.Server.PowerManagerService Libraries LIBRARIES /lib/hardware/power.c (User Space) Linux Kernel Linux Power Management Power Manager Source: http://www.kandroid.org/online-pdk/guide/power_management.html 18
  • 19. Android Power Manager states – Suspended, Idle, Active n  All device states written to RAM / Application processor is idle n  Communication processor on low level activity only to Suspended receive calls, SMS, etc n  Other components are tuned off by power manager n  A device spends significant amount of time in Idle state A modern mobile device can be in n  Device is fully awake but no application is active one of the three n  Main power consuming components in this state are:power consumption Idle Cellular radio, Graphics module, display and CPU states n  At least one application is running n  Device battery consumption depends on what usage Active scenario it is being used under (web browsing, email, voice call, etc) 19
  • 20. Outline What influences the battery life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 20
  • 21. Power consumption profiling for different subsystems – test cases n  Measurement of backlight at minimum and maximum intensity in mW n  Complete WHITE screen Display subsystem n  Complete BLACK screen n  White noise screen for benchmarking different Graphics chip sets and LCDs n  A good test: Downloading a file with random data content via HTTP n  Shielded device test to benchmark effect of signal strength on power Network subsystem consumption and throughput - a 2mm think metal shielded box that can drop the signal strength by 10dBm for cellular and 2dBm drop for Wi-Fi n  A benchmark that causes a good spectrum of utilization of the CPU and the memory from highly CPU bound to highly memory bound e.g. SPEC CPU2000 CPU and RAM n  A series of READ and WRITE operations for measuring power impact of internal NAND flash and SD card. E.g. copying a file with random data n  Audio playback of a music file: e.g. a sample of 12.3MiB, for 10 minutes at 44.1 KHz MP3 file stored on internal NAND flash and SD card Audio subsystem n  Need to include cellular radio power into account since the device needs to be ready to receive calls, SMS n  Different scenarios: device Idle, device running a GPS app, Satellite acquisition, navigation and guidance GPS n  In smartphones, the GPS power consumption is minimal compared to other subsystems and can be skipped 21
  • 22. Power consumption profiling for different subsystems – test cases Test cases for Display component 22
  • 23. Measuring power consumption – multi-core devices Multi-core devices can be more power efficient than single core devices 23
  • 24. Video call test case: a capture all test for device level benchmarking Device (Application) levelpower consumption and benchmarking of several devices Multi-device benchmarking For multi device benchmarking, video call application utilizes many of important components of a mobile device, given that: n  Hardware specifications of the devices under test are similar n  Same application is used for video calling, or at least call features are close or identical such as video resolutions, bandwidth utilization, etc n  Test conditions need to be standardized and similar for every device to make the results reliable and reproducible 24
  • 25. Power consumption measurement approaches – device level Device (Application) level Number of tests runs required N = t x f x nt N : The total number of required power readings (Rule of thumb for stable test results N >= 10K) t : Duration of sample collection (min) f : number of samples collected per second nt : Number of test runs 25
  • 26. Power consumption measurement – the cloud effect Device (Application) level The cloud effect can hinder power consumption measurement accuracyIssue: Cloud services can change their behavior and these changes havesignificant implications on power consumption of the device: Example: whenplaying a YouTube™ video, the server often adjusts the resolution based onthe client’s capabilities and the connection throughputIssue: Many smartphone applications constantly and in an ad-hoc wayexchange data with backend servers that are not user driven or usercontrollable. Example: Google MapSolution: Re-create the use scenario in a controlled lab environmentIn Android: To recreate the input sequence of actions, while running the realcloud based test, use captured user input interactions traces: /dev/input/event*Android kernel can re-run the sequence by reading this information 26
  • 27. Outline What influences the battery life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 27
  • 28. Predictive methods– Two Predictive methods are based on building mathematicalPower Consumption models for each major component of the device n  A formula is built to predict Device Power consumption as a function of power consumption of each component Models based on real device n  Through a series of measurements, power consumption factor of each component is determined and the model is calibrated measurements n  The model then can be used to estimate device power consumption of an application or task based on the time periods each component is “ON” n  The Discharge behavior of the battery is determined Models Training n  Each component’s power consumption factor is determined based on its the based on Battery % it decreases energy level of the battery for a period of time e.g. 15min – Discharge states and the model is calibrated based on this factor n  The model then can be used to estimate device power consumption of an application or task based on the time periods each component is “ON” 28
  • 29. Predictive methods– Model calibration based on real device measurement1.  Identify major components to be included in the model e.g. Display2.  Identify the System Variable (SV) Σ SV x βsv β: System Variable factor corresponding to each component SV: System Variable value e.g. screen brightness intensity3.  Build the device power consumption model as a function of all the SVs4.  In a series of measurements, isolate Current sensing resistor each major component and measure Battery / Power supply Stabilizing Capacitor the power consumption factor directly5.  Use the model to predict power consumption of the different use cases and tasks in your applications Device Source: Google, U. of Michigan 29
  • 30. Predictive methods– Model calibration based on battery Discharge State ∆1.  Identify major components to be included in the model e.g. Display2.  Identify the System Variable (SV) corresponding to each component e.g. screen intensity3.  Build the device power consumption model as a function of all the SVs4.  In a series of measurements, isolate (Delta E) each major component and determine the power consumption factor based on the battery SoC (vi) P x (t1-t2) = E x (SOC(V1) – SOC(V2))5.  Use the model to predict power P: AVG Power consumption in time t1-t2 consumption of the different use E: Rated battery energy capacity SOC(Vi): Battery State of Charge at voltage Vi cases and tasks in your applications Source: Google, U. of Michigan 30
  • 31. Outline What influences the battery life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 31
  • 32. Design for power efficiency – GUI Making GUI more power efficientGUI facilitates most of the user interactions, and since itfully utilizes the screen, it’s a major power consumingpart of the device software.GUI provides INPUT, OUTPUT and HYBRID UIfunctions.Here are factors that design can take into consideration: n  Cognitive latency n  Perceptual capacity n  Hot keys n  User input cache n  Direct GUI power reduction n  Backlight control n  Frame buffer compression 32
  • 33. Design for power efficiency – GUI – Cognitive latency n Reducing Cognitive Latency makes GUI more power efficient: Cognitive n Cognitive latency is the time that the user needs to understand the Latency number of GUI elements present on the screen. If N is the number of element to choose, then: (Hick-Hayman Law) reaction time (sec) = a + b log2N (a, b constant) 33
  • 34. Design for power efficiency – GUI – Cognitive latency A very effective way to reduce cognitive latency is decreasing the number of options from which the user can make a selection. Split Cognitive menu is a good example of a GUI element with low cognitive latency. Latency Time taken to respond (sec) 3 Number of choices on screen 34
  • 35. Design for power efficiency – GUI – Perceptual capacity n Better visibility of the GUI elements being presented to the user lowers required user interaction time Perceptual Capacity n font type n font size n color, n GUI component size n color and optimal contrast ratio 35
  • 36. Design for power efficiency – GUI – other stuff n Hot keys Other stuff n User input cache n Direct GUI power reduction n Backlight control n Frame buffer compression 36
  • 37. Design for power efficiency – proper use of wakelock(), wifilock() PowerManager pm = (PowerManager) getSystemService(Context.POWER_SERVICE); PowerManager.WakeLock wl = pm.newWakeLoc(PowerManager.SCREEN_DIM_WAKE_LOCK, "My Tag"); wl.acquire(); ..screen will stay on during this section.. wl.release(); Flag value CPU Screen Keyboard PARTIAL_WAKE_LOCK On Off Off SCREEN_DIM_WAKE_LOCK On DIM Off SCREEN_BRIGHT_WAKE_LOCK On Bright Off FULL_WAKE_LOCK On Bright Bright ACQUIRE_CAUSES_WAKEUP Forces screen and/or KB to illuminate without waiting for user interaction ON_AFTER_RELEASE User activity timer will be reset. Screen, KB will stay ON a bit longer Source: http://developer.android.com/reference/android/os/PowerManager.html 37
  • 38. Design for power efficiency – proper use of wakelock(), wifilock() n wakelock() wakelock(), n Device battery life significantly affected by the use of wakelock() wifilock()use best practice n Do not acquire wakelock()s unless you ABSOLUTELY need them n When you acquire wakelock()s, use minimum level possible n Make sure you release the lock when you’re done n  wifilock() n  When syncing with the server, use longer periods (less frequent: 1 every hr instead of 1 every 5min) n  Release the lock when you’re done n  Example: A good justification for wifilock() is when downloading large files 38
  • 39. Outline What influences the battery life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 39
  • 40. Setting up a power measurement lab – Lab functions n System to sample voltage, current and power at high Lab functions sampling frequency rates (1000 sample per second and above) n System to host simulated cloud services n Equipment to measure ambient light n Equipment to measure ambient noise 40
  • 41. Setting up a power measurement lab – Voltage, current & power measurement 41
  • 42. Setting up a power measurement lab – Voltage, current & power measurement Monsoon Power Monitor National Instrument LabView Software National Instrument USB-4065 USB DMM 42
  • 43. Setting up a power measurement lab – Measuring ambient light, noise Lux Meter Sound level Meter 43
  • 44. Setting up a power measurement lab – Connecting to the device Current sensing resistor Battery / Power supply Battery adapter Stabilizing Capacitor Copper Conductive adhesive tape 44
  • 45. Outline What influences the battery life? Objective power consumption measurement Predictive methods to measure power consumption Areas to optimize power consumption Setting up a power measurement lab Hands-on Demo 45
  • 46. Thank You!Moe Tanabian @motanabian 46
