Introduction to CLIPS Expert System Presentation Transcript

  • 1. CLIPS: Expert System Shell Motaz K. Saad College of IT – CS Dept.
  • 2. What is expert system?
    • AN EXPERT SYSTEM (ES) IS A COMPUTER PROGRAM DESIGNED TO SIMULATE THE PROBLEM-SOLVING BEHAVIOR OF AN EXPERT IN A NARROW DOMAIN OR DISCIPLINE.
  • 3. What is expert system? ARTIFICIAL INTELLIGENCE PROGRAMS Exhibit intelligent behavior by skillful application of heuristics make domain knowledge explicit and separate from the rest of the system KNOWLEDGE-BASED SYSTEMS Apply expert knowledge to difficult, real world problems EXPERT SYSTEMS
  • 4. The structure of an expert system KNOWLEDGE BASE Domain Knowledge INFERENCE ENGINE General problem-solving knowledge FACTS RULES INTERPRETER SCHEDULER
  • 5. Facts and Rules
    • A fact is a piece of information such as (color green)
    • Facts on their own are of only limited use.
    • The application of rules is necessary to develop a program capable of some useful function.
  • 6. Rules
    • A rule is a formal way of specifying a recommendation, directive, or advice
    • A rule is expressed as
    • IF premise THEN conclusion
    • or
    • IF condition THEN action
  • 7. Drawing inferences from rules
    • Forward chaining
      • In forward chaining, the reasoning proceeds from the IF part of the rule to the THEN part.
    • Backward chaining
      • In backward chaining, the reasoning proceeds from the THEN part to the IF part.
  • 8. Expert system building tool
    • Programming language
      • An expert system can be implemented using a general purpose programming language. However, the programming languages LISP and PROLOG are typically used in expert systems implementation, in particular Artificial Intelligence applications. This is due to their capabilities in handling symbolic data efficiently.
    • Shells
      • A shell consists mainly of an inference engine and an editor to assist developers in building their knowledge base.
  • 9. Shells vs. Programming languages
  • 10. Shells vs. Programming languages
  • 11. CLIPS: Expert System Shell
    • Rule-based expert systems are often known as production systems (CLIPS actually stands for C Language Integrated Production System).
  • 12. The CLIPS Programming Tool
    • History of CLIPS
      • Influenced by OPS5 and ART
      • Implemented in C for efficiency and portability
      • Developed by NASA, distributed & supported by COSMIC
      • Runs on PC, Mac, also under UNIX and VAX VMS
    • CLIPS provides mechanisms for expert systems
      • A top-level interpreter
      • Production rule interpreter
      • Object oriented programming language
      • LISP-like procedural language
  • 13. Components of CLIPS
    • Rule-Based Language
      • Can create a fact list
      • Can create a rule set
      • An inference engine matches facts against rules
    • Object-Oriented Language
      • Can define classes
      • Can create different sets of instances
      • Special forms allow you to interface rules and objects
  • 14. Defining Facts
    • Facts can be asserted
      • CLIPS> (assert (today is sunday))
      • <Fact-0>
    • Facts can be listed
      • CLIPS> (facts)
      • f-0 (today is sunday)
    • Facts can be retracted
      • CLIPS> (retract 0)
      • CLIPS> (facts)
  • 15. Managing Facts
    • Clearing all facts
      • CLIPS> (clear)
      • CLIPS> (facts)
    • Grouping facts - typically in a file (“today.clp”)
      • (deffacts today ; can be cleared with (undeffacts today)
        • (today is sunday)
        • (weather is warm)
      • )
    • After loading facts, assert with (reset)
  • 16. Defining Rules
    • Rules have the following structure
      • (defrule rule-name optional-comment
        • optional-declaration
        • condition
        • ...
        • condition
        • =>
        • action
        • ...
        • action
      • )
  • 17. An Example CLIPS Rule
    • (defrule sunday “Things to do on Sunday”
      • (salience 0) ; salience in the interval [-10000, 10000]
      • (today is Sunday)
      • (weather is sunny)
      • =>
      • (assert (chore wash car))
      • (assert (chore chop wood))
    • )
    • So, if fact list contains conditions, add assertions
  • 18. Getting the Rules Started
    • The reset command creates a special fact
      • CLIPS> (load “today.clp”)
      • CLIPS> (facts)
      • CLIPS> (reset)
      • CLIPS> (facts)
      • f-0 (initial-fact) ...
      • (defrule start
        • (initial-fact)
        • =>
        • (printout t “hello”)
      • )
  • 19. Tracing & Recording Things
    • Watch command can watch facts (and rules)
      • CLIPS> (watch facts)
      • CLIPS> (reset)
      • ==> f-0 (initial-fact)
      • CLIPS> (retract 0)
      • <== f-0 (initial-fact)
    • Contents of dialog window can be sent to file
      • CLIPS> (dribble-on “dribble.clp”) ; any file name will do
      • ...
      • CLIPS> (dribble-off “dribble.clp”)
  • 20. Variables & Pattern Matching
    • Variables make rules more applicable
    • (defrule pick-a-chore
      • (today is ?day)
      • (chore is ?job)
      • =>
      • (assert (do ?job on ?day))
    • )
    • If conditions are matched, then bindings are used
  • 21. Retracting Facts from a Rule
    • (defrule do-a-chore
      • (today is ?day) ; ?day must have a consistent binding
      • ?chore <- (do ?job on ?day)
      • =>
      • (printout t ?job “ done”)
      • (retract ?chore)
    • )
    • We must assign a variable to item for retraction
  • 22. Pattern Matching Details
    • One-to-one matching
      • (do ?job on ?day)
      • (do washing on monday)
    • Use of wild cards
      • (do ? ? monday)
      • (do ? on ?)
      • (do ? ? ?day)
      • (do $?)
      • (do $? monday)
      • (do ?chore $?when)
  • 23. Using Templates
    • (deftemplate student “a student record”
      • (slot name (type STRING))
      • (slot age (type NUMBER) (default 18)))
      • CLIPS> (assert (student (name fred)))
    • (defrule print-a-student
      • (student (name ?name) (age ?age))
      • =>
      • (printout t name? “ is “ ?age)
    • )
  • 24. Defining Functions in CLIPS
    • Uses a LISP or Scheme-like syntax
    • (deffunction function-name (arg ... arg)
      • action ... action)
    • (deffunction hypotenuse (?a ?b)
      • (sqrt (+ (* ?a ?a) (* ?b ?b))))
    • (deffunction initialize ()
      • (clear)
      • (assert (today is sunday)))
  • 25. Defining Classes & Instances
    • Defining the class CAR
    • (defclass car
      • (is-a user)
      • (name)
      • (made-by))
    • Defining an instance of CAR
    • (make-instance corvette of car
      • (made-by chevrolet))
  • 26. Concrete & Abstract Classes
    • Some classes only exist for inheritance purposes
    Person Man Woman Jack Jill
  • 27. Managing Instances
    • Commands to display instances
      • CLIPS> (instances)
      • [corvette] of car
      • CLIPS> (send [corvette] print)
      • [corvette] of car
      • (made-by chevrolet)
    • Command to group instances (in a file)
      • (definstances
        • (corvette of car (made-by chevrolet))
        • (thunderbird of car (made-by ford)))
  • 28. Clearing & Resetting Instances
    • Deleting an instance
      • CLIPS> (send [corvette] delete)
    • Deleting all instances
      • CLIPS> (unmake-instance *)
    • Resetting creates an initial object
      • CLIPS> (reset)
      • CLIPS> (instances)
      • [initial-object] of INITIAL-OBJECT
  • 29. Message Passing
    • The SEND function
      • (send [instance] message arg ... arg)
    • Converting from symbols to names
      • CLIPS> (symbol-to-instance-name corvette)
      • [corvette]
    • This is useful when SENDing from inside a rule
  • 30. Limitations of CLIPS
    • Single level rule sets
      • in LOOPS, you could arrange rule sets in a hierarchy, embedding one rule set inside another
    • Loose coupling of rules and objects
      • rules can communicate with objects via message passing
      • rules cannot easily be embedded in objects, as in Centaur
    • CLIPS has no explicit agenda mechanism
      • the basic control flow is forward chaining
      • to implement other kinds of reasoning you have to manipulate tokens in working memory
  • 31. Alternatives to CLIPS
    • Eclipse
      • has same syntax as CLIPS (both are based on ART)
      • supports goal-driven (i.e., backwards) reasoning
      • has a truth maintenance facility for checking consistency
      • can be integrated with C++ and dBase
      • new extension RETE++ can generate C++ header files
    • NEXPERT OBJECT
      • another rule- and object-based system
      • has facilities for designing graphical interfaces
      • has a ‘script language’ for designing user front-end
      • written in C, runs on many platforms, highly portable
  • 32. The End! http://motaz.saad.googlepages.com
