PSGI and Plack
     Tatsuhiko Miyagawa
 London Perl Workshop 2009
Tatsuhiko Miyagawa

• Japanese, lives in San Francisco
• Works at Six Apart
• 170+ CPAN modules (id:MIYAGAWA)
• @miyagawa
...
Background
Web Frameworks
Maypole Mason Mojo Sledge Catalyst Spoon PageKit
 AxKit Egg Gantry Continuity Solstice Mojolicious
Tripletail Konstrukt Re...
Most of them run on
 mod_perl and CGI
Some run on FastCGI
Some run standalone
Very few supports
  non-blocking
Because:
No common server
environment layers
CGI.pm
Runs “fine” on:
    CGI, FastCGI, mod_perl (1 & 2)
Standalone (with HTTP::Server::Simple)
CGI.pm = LCD
   It’s also Perl core
Catalyst
The most popular framework as of today
Catalyst::Engine::*
            Server abstractions.
Well supported Apache, FCGI and Standalone
                No CGI.pm
CGI.pm
  Jifty, CGI::Application, Spoon


mod_perl centric
Mason, Sledge, PageKit, WebGUI


       Adapters
  Catalyst, Ma...
Problems:
       Duplicated efforts
No fair performance evaluations
Question:
 Can we share
those adapters?
Answer:
HTTP::Engine
HTTP::Engine
Lots of adapters (FCGI, Apache2, POE)
     Clean Request/Response API
Written by Yappo, tokuhirom and others
Problems
Mo[ou]se everywhere
 Mouse is light but still overspec for some env.
Monolithic
All implementations share HTTP::Engine roles
and builders, which is sometimes hard to adapt
      and has less ...
APIs everywhere
Most frameworks have their request/response API
          Sometimes there are gaps.
    Annoying to write ...
Solution
Steal good stuff
from Python/Ruby
WSGI (Python)
   Rack
WSGI (PEP-333)
mod_wsgi, Paste, AppEngine
 Django, CherryPy, Pylons
Rack
Passenger, thin, Unicorn, Heroku
      Rails, Merb, Sinatra
WSGI/Rack
 Completely separate interface
from the actual implementation
Approach
Split HTTP::Engine
 into three parts
Interface
Implementations
    Utilities
PSGI (interface)
Plack::Server (implementations)
      Plack::* (utilities)
Who’s on board
Benjamin Trott, Yuval Kogman, Stevan Little, Shawn M
 Moore, Mark Stosberg, Matt S Trout, Jesse Vincent,
  ...
PSGI
Perl Web Server Gateway Interface
Interface
WARNING
You DON’T need to care about these
 interface details as an app developer.
my $app = sub {
   my $env = shift;
   # ...
   return [ $status, $header, $body ];
};
PSGI application
   code reference
   $app = sub {...};
my $app = sub {
   my $env = shift;
   # ...
   return [ $status, $header, $body ];
};
environment hash
$env: CGI-like env variables
+ psgi.input, psgi.errors etc.
my $app = sub {
   my $env = shift;
   # ...
   return [ $status, $header, $body ];
};
Response
 array ref with three elements
status code, headers (array ref)
and body (IO-like or array ref)
my $app = sub {
   my $env = shift;
   # ...
   return [ $status, $header, $body ];
};
$body
  IO::Handle-like
getline() and close()
IO::Handle-like
       We really envy Python/Ruby
          for built-in iterators
(Perl’s filehandle is also an object, bu...
WARNING
You DON’T need to care about these
 interface details as an app developer.
              Becuase ...
Frameworks
Write an adapter to return
 PSGI application code ref.
(and forget about servers!)
Framework Adapters
  CGI::Application, Catalyst, Maypole
Mason, Squatting, Mojo, HTTP::Engine etc.
Applications
MT::App, WebGUI
use Foo; # is a Catalyst application
Foo->setup_engine(‘PSGI’);
my $app = sub { Foo->run };
Servers
   Set up $env, run the app
and emits response out of $res
Plack
namespace for servers and utilities
Plack::Server
 reference server implementations
  Standalone, FCGI, Apache2, CGI
Standalone, Prefork, AnyEvent, Coro
Very fast
 5000 QPS on standalone
15000 QPS with prefork :)
Utilities
Plackup
Run PSGI app instantly from CLI
     (inspired by rackup)
DEMO
Middleware
my $app = sub {
   my $env = shift;
   return [ $status, $header, $body ];
};

my $mw = sub {
   my $env = shift;
   # do ...
Middleware
Static, AccessLog, ConditionalGET
 ErrorDocument, StackTrace etc.
Plack::Middleware
  reusable and extensible
  Middleware framework
 Plack::Builder DSL in .psgi
my $app = sub {
   return [ $status, $header, $body ];
};

use Plack::Builder;

builder {
  enable “Static”, root => “/htd...
Plack::App::URLMap
    Multiplex multiple apps
 Integrated with Builder DSL
use CatApp;
use CGIApp;

my $c1 = sub { CatApp->run };
my $c2 = sub { CGIApp->run_psgi };

use Plack::Builder;

builder {
...
CGI::PSGI
Easy migration from CGI.pm
CGI::Emulate::PSGI
    CGI::Compile
Easiest migration from CGI scripts (like Registry)
Plack::Request
    like libapreq (Apache::Request)
wrapper APIs for framework developers
use Plack::Request;

my $app = sub {
 my $req = Plack::Request->new(shift);

 my $body = “Hello “ . $req->param(‘n’);
 my ...
Plack::Test
 Unified interface to write tests
with Mock HTTP and Live HTTP
use Plack::Test;
use HTTP::Request::Common;

my $app = sub {
   my $env = shift;
   return [ $status, $header, $body ];
};...
use Plack::Test;
use HTTP::Request::Common;
$Plack::Test::Impl = “Server”;

my $app = sub {
   my $env = shift;
   return ...
Streaming
event loop / long-poll
# Pull streaming for blocking server
use IO::Handle::Util qw(io_from_getline);

my $app = sub {
   my $env = shift;
   my ...
# Push streaming for non-blocking server
use AnyEvent;
use JSON;

my $app = sub {
  my $env = shift;
  return sub {
    my...
Non-blocking servers
AnyEvent, Coro, POE, Danga::Socket
Non-blocking framework
           Tatsumaki
  http://github.com/miyagawa/Tatsumaki
Other Servers
nginx embedded perl
 http://github.com/yappo/nginx-psgi-patchs
mod_psgi
http://github.com/spiritloose/mod_psgi
evpsgi
http://github.com/sekimura/evpsgi
Perlbal plugin
http://github.com/miyagawa/Perlbal-Plugin-PSGI
Cloud
WSGI (PEP-333)
mod_wsgi, Paste, AppEngine
 Django, CherryPy, Pylons
Rack
Passenger, Thin, Unicorn, Heroku
      Rails, Merb, Sinatra
What if GAE Perl
comes with PSGI ...
Summary

• PSGI is an interface, Plack is the code.
• We have many (pretty fast) servers.
• We have adapters and tools for...
http://github.com/miyagawa/Plack
          http://plackperl.org/
http://advent.plackperl.org/ ←NEW!
        irc://irc.perl...
Questions?
