<ul><ul><li>6.1 Capturing the Energy in Light 6.2 The Calvin Cycle </li></ul></ul><ul><ul><li>Created by   Stacey Odum </l...
Photosynthesis  = process by which a cell captures the energy in sunlight and uses it to make food.  Plants, algae, and so...
Solar Cell
Water Carbon Dioxide Sun Light Oxygen Photosynthesis Sugar Cellular Respiration Energy - ATP
Chloroplasts in Elodea (Lab)

Autotrophs   make their own food, and most use photosynthesis to do it. * Plants are the most common, but algae and some b...
Photosynthesis  (Simply Summarized) Leaves of plants have  chloroplasts  that are filled with chlorophyll, which capture t...
Photosynthesis Equation: CO 2    + H 2 O + light energy  -> Sugar (glucose)  +   O 2 More Detailed Equation: Using Light E...
Biochemical Pathway  =   Series of linked chemical reactions , in which the  product  of one reaction is consumed (used as...
The Photosynthesis Reactions: 1.  Light Reactions   are the first set of reactions in photosynthesis. Background informati...

* Light is absorbed in the  membranes  of  thylakoids  founds in chloroplasts. -  Grana  = stacks of flat thylakoids. -  S...
The Light Reaction in the Thylakoid Membrane
Electron Transport System of the light reactions. *  Photosystem  = cluster of pigment molecules grouped in the thylakoid ...
FIVE   STEPS  of the  Electron Transport System <ul><li>Light excites electrons in the chlorophyll  a  molecules of photos...
Restoring Photosystem II Electrons  by splitting  Water  Molecules : * Enzyme splits water to  protons, electrons, & oxyge...
Chemiosmosis  = a process in light reactions that synthesizes (makes) ATP.  * Protons produced from the water splitting bu...
The Light Reaction in the Thylakoid Membrane Primary electron acceptor Primary electron acceptor Photosystem II Electron T...
2. The  Calvin Cycle   =  second set of reactions  (pathway), producing organic compounds from the stored energy of ATP an...
Three Steps of the Calvin Cycle : a. CO 2  combines with RuBP to form two molecules of PGA. b. Each molecule of PGA is con...
The Two Processes Visualized
Alternative Pathways * First, remember that C 3  Plants are those that  only  use the Calvin Cycle to fix carbon. - They a...
C 4  Pathway  – use an enzyme which fixes CO 2  into compounds with  4  carbons, which are then transported to other cells...
Rate  of Photosynthesis  *  Increases as either light intensity or CO 2  increase, but eventually plateaus at a maximum. *...

Cellular Respiration
Upcoming SlideShare
Loading in …5
×

Photosynthesis

19,291 views
19,061 views

Published on

This PowerPoint presentation focuses on capturing the energy in light and the Calvin Cycle. Colorful diagrams and illustrations appear throughout the presentation and the following topics are addressed:

* Plant Cell Structure
* Photosynthesis Equations
* Biochemical Pathways
* 5 Steps of the Electron Transport System
* 3 Steps of the Calvin Cycle

This presentation was created by Stacey Odum in Richmond County, GA.

Published in: Economy & Finance, Technology
4 Comments
7 Likes
Statistics
Notes
No Downloads
Views
Total views
19,291
On SlideShare
0
From Embeds
0
Number of Embeds
127
Actions
Shares
0
Downloads
934
Comments
4
Likes
7
Embeds 0
No embeds

No notes for slide

Photosynthesis

  1. 1. <ul><ul><li>6.1 Capturing the Energy in Light 6.2 The Calvin Cycle </li></ul></ul><ul><ul><li>Created by Stacey Odum </li></ul></ul>Photosynthesis
  2. 2. Photosynthesis = process by which a cell captures the energy in sunlight and uses it to make food. Plants, algae, and some bacteria use this process. Like a Solar Powered Calculator with light capturing cells
  3. 3. Solar Cell
  4. 4. Water Carbon Dioxide Sun Light Oxygen Photosynthesis Sugar Cellular Respiration Energy - ATP
  5. 5. Chloroplasts in Elodea (Lab)
  6. 7. Autotrophs make their own food, and most use photosynthesis to do it. * Plants are the most common, but algae and some bacteria use it. * All life depends on autotrophs (directly or indirectly) for food. * Nearly all living things obtain energy either directly (like plants) or indirectly (like heterotrophs that eat plants) from the sun’s energy captured during photosynthesis.
  7. 8. Photosynthesis (Simply Summarized) Leaves of plants have chloroplasts that are filled with chlorophyll, which capture the energy from the sunlight). * Water enters through the roots. * CO 2 enters through stomata openings on the underside of the leaves. * Water and CO 2 move to the chloroplasts. * Chemical reactions there, produce (O 2 ) and sugars like glucose (C 6 H 12 O 6 ). * Cells then use the energy in the sugars (carbohydrates) to function.
  8. 9. Photosynthesis Equation: CO 2 + H 2 O + light energy -> Sugar (glucose) + O 2 More Detailed Equation: Using Light Energy carbon dioxide water “yields glucose oxygen 6CO 2 + 6H 2 O -> C 6 H 12 O 6 + 6O 2
  9. 10. Biochemical Pathway = Series of linked chemical reactions , in which the product of one reaction is consumed (used as the reactant ) in the next reaction. * The two stages of photosynthesis involve biochemical pathways. * Also, the final products of plant photosynthesis (sugar and oxygen) are used by animals for another process called cellular respiration. The products of respiration are carbon dioxide and water, which plants need for photosynthesis, so both processes create a balance in the atmosphere.
  10. 11. The Photosynthesis Reactions: 1. Light Reactions are the first set of reactions in photosynthesis. Background information about light: Sunlight appears white, but really many colors. Visible Spectrum = the light waves we can see. Wavelength = distance between wave crests (Different wavelengths reflected as different colors.) (Objects absorb and reflect certain waves.)
  11. 13. * Light is absorbed in the membranes of thylakoids founds in chloroplasts. - Grana = stacks of flat thylakoids. - Stroma = the solution surrounding the thylakoids. - Chlorophylls = pigments, which absorb violet, blue, red, yet reflect green. - Pigment = a compound that absorbs light waves. (Chlorophyll “ a ” is directly involved in light reactions. - Accessory Pigments = indirectly assist other pigments. ( Chlorophyll “ b ” is an accessory pigment assisting “ a ”.) Carotenoids are other accessory pigments (yellow, orange, brown, etc.) (They absorb blue and green light.) (In the fall, plant leaves turn color because they lose chlorophylls, which reflect green light.)
  12. 14. The Light Reaction in the Thylakoid Membrane
  13. 15. Electron Transport System of the light reactions. * Photosystem = cluster of pigment molecules grouped in the thylakoid membrane. ( Two types : Photosystem II and Photosystem I , each with different roles.) - Note the order of II and then I in the light reaction diagram. * Accessory pigment molecules start the light reactions by absorbing light energy . (It is passed to other pigment molecules until it reaches chlorophyll a molecules.) * Then a FIVE STEP process occurs . . . . . . . .
  14. 16. FIVE STEPS of the Electron Transport System <ul><li>Light excites electrons in the chlorophyll a molecules of photosystem II . (O xidation reaction, since it loses an electron.) </li></ul><ul><li>These electrons move to and are accepted by a primary electron acceptor . ( This is a reduction reaction.) </li></ul><ul><li>The electrons are then transferred along a series of molecules called an electron transport chain . </li></ul><ul><li>Light excites electrons in chlorophyll a molecules of photosystem I . </li></ul><ul><li>Electrons from Photosystem I are transferred along a second chain. (The chain ends as they combine with organic NADP + and H + making NADPH.) </li></ul>
  15. 17. Restoring Photosystem II Electrons by splitting Water Molecules : * Enzyme splits water to protons, electrons, & oxygen 2H 2 O -> 4H + + 4 e - + O 2 So oxygen is a by-product of light reactions, and not used in the rest of photosynthesis. (The oxygen is used by other organisms for cellular respiration.)
  16. 18. Chemiosmosis = a process in light reactions that synthesizes (makes) ATP. * Protons produced from the water splitting build up inside the thylakoid, and they then move down their gradient to the outside. * ATP Synthase is a multifunctional protein serving as an enzyme and carrier protein. It uses the energy of the moving protons to add a phosphate group to ADP and make ATP (A primary chemical energy storage molecule for energy currency in the cell.) * ATP and the NADPH provide energy for the second set of photosynthesis reactions, called the Calvin Cycle .
  17. 19. The Light Reaction in the Thylakoid Membrane Primary electron acceptor Primary electron acceptor Photosystem II Electron Transport Chain Photosystem I Electron Transport Chain Animation here: http://www.stolaf.edu/people/giannini/flashanimat/metabolism/photosynthesis.swf
  18. 20. 2. The Calvin Cycle = second set of reactions (pathway), producing organic compounds from the stored energy of ATP and NADPH. * Occurs in the stroma of the chloroplast. * Carbon Fixation : C atoms from CO 2 are bonded (“fixed”) into organic compounds. (amino acids, lipids, and carbohydrates like glucose, fructose) (Note: These compounds are not directly produced by photosynthesis.)
  19. 21. Three Steps of the Calvin Cycle : a. CO 2 combines with RuBP to form two molecules of PGA. b. Each molecule of PGA is converted into a molecule of PGAL. c. Most of the PGAL is converted back into RuBP, but some PGAL can be used later to make different organic compounds. * RuBP = five-carbon carbohydrate. * PGA and PGAL are both three-carbon molecule * C 3 Plants (produce the 3-Carbon PGA), and use only the Calvin Cycle for carbon fixation.
  20. 22. The Two Processes Visualized
  21. 23. Alternative Pathways * First, remember that C 3 Plants are those that only use the Calvin Cycle to fix carbon. - They are called C 3 plants, since they fix CO 2 into a compound with 3 carbons (PGAL). * Others in hot, dry climates supplement the Calvin cycle with alternatives (C 4 or CAM), because their stomata openings in the leaves must close to preserve moisture, so the amount of CO 2 they absorb is reduced.
  22. 24. C 4 Pathway – use an enzyme which fixes CO 2 into compounds with 4 carbons, which are then transported to other cells where CO 2 is available to then use the Calvin Cycle. (corn, sugar cane, are examples) CAM Pathway – These plants open the stomata only at night to reduce water loss. They take in and fix it into compounds, which then release it during the day for use in the Calvin Cycle. (cactuses, pineapples, etc.)
  23. 25. Rate of Photosynthesis * Increases as either light intensity or CO 2 increase, but eventually plateaus at a maximum. * Increases as the temperature increases, up to a certain temperature. (Beyond a certain high temperature, the rate of photosynthesis decreases.)
  24. 27. Cellular Respiration

×
