  • 1. NIGHT VISION TECHNOLOGY<br />NIGHT VISION TECHNOLOGY<br />-BY 09BIT059<br />(MIHIKA SHAH)<br />
  • 2. INTRODUCTION<br /><ul><li>The word ‘Night vision’ itself means the ability to see in low light conditions.
  • 3. Humans have poor night vision compared to many other animals.</li></li></ul><li>(Contd...)<br /><ul><li> So we all might have a question in our mind that is this really possible to see in the dark night?
  • 4. The answer is……..YES, we can see in the dark night using the proper equipment made by using this technology.
  • 5. We can see a person standing over 183m away in the dark night.</li></li></ul><li>HISTORY<br /><ul><li>Pre 1940’s: Flares and spot lights were used for operations at night.
  • 6. Due to the nature of these early night vision devices (NVD), they gave away tactical positions.
  • 7. Military scientists began to think of ways to improve night vision to gain a strategic advantage</li></li></ul><li>EARLYDEVELOPMENT<br /><ul><li>The first night vision devices (NVD) were created during World war-II.
  • 8. Functioned by placing an infrared filter over a searchlight.
  • 9. Fighters would use special binoculars to see using the light from the searchlights.
  • 10. Many problems came from this night vision method.</li></li></ul><li>A tank from World War II equipped with a search light used for night combat.<br />
  • 11. HOW DOES IT WORK?<br /><ul><li>The night vision is possible because of two approaches: </li></ul>(1) Sufficient spectral range<br />(2) Sufficient intensity range<br /><ul><li>Two technologies are used for night vision:</li></ul>(1)Thermal Imaging<br />(2)Image Enhancement<br />
  • 12. (Contd…)<br /><ul><li>Infrared light is used to visualize the things in the dark.
  • 13. The amount of energy in a light wave is related to its wavelength: </li></ul>Shorter wavelengths have higher energy. <br /><ul><li>Of visible light, violet has the most energy, and red has the least.
  • 14. Just next to the visible light spectrum is the infrared spectrum. </li></li></ul><li>
  • 15. (Contd…)<br />Infrared light can be split into three categories: <br />Near-infrared (near-IR) –<br /> Closest to visible light, near-IR has wavelengths that range 0.7 to 1.3 micron.<br /><ul><li>Mid-infrared (mid-IR) –</li></ul> Mid-IR has wavelengths ranging from <br />1.3 to 3 microns. <br /> Both near-IR and mid-IR are used by a variety of electronic devices, including remote controls.<br />
  • 16. (Contd…)<br /><ul><li>Thermal-infrared (thermal-IR) – </li></ul>Occupying the largest part of the infrared spectrum, thermal-IR has wavelengths ranging from 3 microns to over 30 microns. <br />
  • 17. THERMAL IMAGING<br /><ul><li>A special lens focuses the infrared light emitted by all of the objects in view.
  • 18. The focused light is scanned by a phased array of infrared-detector elements.
  • 19. The detector elements create a very detailed temperature pattern called a thermogram.
  • 20. It only takes about one-thirtieth of a second for the detector array to obtain the temperature information to make the thermogram.</li></li></ul><li>(Contd…)<br />
  • 21. (Contd…)<br /><ul><li>This information is obtained from several thousand points in the field of view of the detector array.
  • 22. The thermogram created by the detector elements is translated into electric impulses.
  • 23. The impulses are sent to a signal-processing unit, a circuit board with a dedicated chip that translates the information from the elements into data for the display. </li></li></ul><li>(Contd…)<br /><ul><li>The signal-processing unit sends the information to the display, where it appears as various colors depending on the intensity of the infrared emission.
  • 24. The combination of all the impulses from all of the elements creates the image. </li></li></ul><li>In day light<br />In dark night<br />Using thermal imaging<br />
  • 25. IMAGE ENHANCEMENT<br />
  • 26. (Contd…)<br /><ul><li> An image-intensifier tube is used to collect and amplify infrared and visible light.
  • 27. A conventional lens, called the objective lens, captures ambient light and some near-infrared light.
  • 28. The gathered light is sent to the image-intensifier tube.
  • 29. The image-intensifier tube has a photocathode, which is used to convert the photons of light energy into electrons.</li></li></ul><li>(Contd…)<br /><ul><li>A Microscopic plate(MCP) is a tiny glass disk that has millions of microscopic holes in it.
  • 30. The MCP is contained in a vacuum and has metal electrodes on either side of the disc.
  • 31. When the electrons from the photo cathode hit the first electrode of the MCP, they are accelerated into the glass micro-channels by the 5,000-V bursts being sent between the electrode pair.</li></li></ul><li>(Contd..)<br /><ul><li>As electrons pass through the micro channels, they cause thousands of other electrons to be released in each channel using a process called cascaded secondary emission.
  • 32. At the end of the image-intensifier tube, the electrons hit a screen coated with phosphors.
  • 33. These electrons maintain their position in relation to the channel they passed through, which provides a perfect image since the electrons stay in the same alignment as the original photons.</li></li></ul><li>(Contd…)<br /><ul><li>The energy of the electrons causes the phosphors to reach an excited state and release photons.
  • 34. These photons create the image on the screen.
  • 35. The green phosphor image is viewed through another lens, called the ocular lens, which allows you to magnify and focus the image.
  • 36. The NVD may be connected to a monitor to display the image.</li></li></ul><li>GENERATIONS<br /><ul><li> NVDs have been around for more than 50 years. They are categorized by generation.
  • 37. Each substantial change in NVD technology establishes a new generation. </li></li></ul><li>(Contd…)<br />GENERATION- 0<br /><ul><li> Created by US Army.
  • 38. Uses active infrared.
  • 39. A projection unit called IR illuminator is attached with NVD.
  • 40. Use anode in conjunction with cathode to accelerate the electrons.
  • 41. Problems : acceleration causes distortion of image and reduction of the life of the tube.
  • 42. Duplicated by the hostile nations.</li></li></ul><li>(Contd…)<br />GENERATION- 1<br /><ul><li> Uses passive infrared.
  • 43. Uses ambient light provided by the moon and the stars.
  • 44. Doesn’t require a source of projected infrared light.
  • 45. Doesn’t work well on cloudy or moonless nights.
  • 46. Uses same image-intensifier tube technology as Generation-0.
  • 47. Same problems as faced by the Generation-0.</li></li></ul><li>(Contd…)<br />GENERATION- 2<br /><ul><li> Offer improved resolution and performance over Generation-1 devices.
  • 48. Considerably more reliable.
  • 49. Able to see in extreme low light conditions due to the addition of microchannel plate(MCP) to the image-intensifier tube.
  • 50. The images are less distorted and brighter.</li></li></ul><li>(Contd…)<br />GENERATION- 3<br /><ul><li> Currently used by the US Army.
  • 51. Better resolution and sensitivity.
  • 52. Photocathode is made up of Gallium Arsenide- efficient of converting photons to electrons.
  • 53. MCP is coated with an ion barrier.
  • 54. Tube life is increased</li></li></ul><li>(Contd…)<br />GENERATION- 4<br /><ul><li> Known as filmless and gated technology.
  • 55. Shows significant improvement in both high- and low-level light environments.
  • 56. No ion barrier in MCP.
  • 57. Reduced background noise.
  • 58. Enhances signal to noise ratio.
  • 59. Images are less distorted and brighter.</li></li></ul><li>NIGHT VISION DEVICES<br />It can be splitted in three broad categories:<br />Scopes<br />Goggles<br />Cameras<br />
  • 60. (Contd…)<br />SCOPES<br />
  • 61. (Contd…)<br /><ul><li>Normally handheld or mounted on a weapon, scopes are monocular (one eye-piece).
  • 62. Can not be worn like goggles.
  • 63. It is good for when you want to get a better look at a specific object and then return to normal viewing conditions. </li></li></ul><li>(Contd…)<br />GOGGLES<br />
  • 64. (Contd…)<br /><ul><li>While goggles can be handheld, they are most often worn on the head.
  • 65. Goggles are binocular (two eye-pieces) and may have a single lens or stereo lens, depending on the model.
  • 66. Goggles are excellent for constant viewing, such as moving around in a dark building. </li></li></ul><li>(Contd…)<br />CAMERAS<br />
  • 67. (Contd…)<br /><ul><li>Cameras with night-vision technology can send the image to a monitor for display or to a VCR for recording.
  • 68. When night-vision capability is desired in a permanent location, such as on a building.</li></li></ul><li>APPLICATIONS<br /><ul><li>Military
  • 69. Hunting
  • 70. Wildlife observation
  • 71. Surveillance
  • 72. Security
  • 73. Navigation
  • 74. Hidden-object detection
  • 75. Entertainment </li></li></ul><li>(Contd…)<br />AUTOMOBILE<br />BMW's Night Vision with Pedestrian Detection system allows drivers to see what (or who) is down the road -- even on the darkest nights. <br />
  • 76. (Contd…)<br /><ul><li> Dr. Prabhat Ranjan from DA-IICT has used a camera based on Infrared flash in his research on ‘Sensor Networks in wildlife’.</li></li></ul><li>REFERENCES<br /><ul><li>http://en.wikipedia.org/wiki/Night_vision
  • 77. http://electronics.howstuffworks.com
  • 78. http://carl.sandiego.edu</li></li></ul><li>THANK YOU<br />

×
