How To: Hot Application DeploymentDuring RuntimeGerd Kachel (gerd.kachel@kachel.biz)kachel GmbHSeptember 21, 2011         ...
Problem Space• What is the scope?   •   Set of bundle which form an application.   •   Running multiple applications at on...
Instruments of Bundle Lifecycle• Interface BundleContext   •   public Bundle installBundle(String location);• Interface Bu...
Maintaining Applications    Application                             install() and                     Start   start() each...
Maintaining Applications: Pitfalls    Application                                          install()                      ...
Maintaining Applications: Pitfalls    Application                                      install()                      Star...
Maintaining Applications: Pitfalls    Application                                       start() bundle                    ...
Maintaining Applications: Pitfalls    Application                                    start() bundle                      S...
Maintaining Applications: Pitfalls    Application                         Other application will                          ...
Maintaining Applications: Pitfalls    Application                             Other application      Bundle 1             ...
Maintaining Applications: BestPractice• Overall: Take care of bundle and package versions• Start application:   •   first ...
Roots Application Manager• Free available for private, academic, and commercial  use• Implements introduced best practice ...
Application Provided in Folder• Boot application starts application manager• Application manager starts pre-installed othe...
Bundles and Properties
Bundles
Application Configuration by PropertyFile
Summary•   Bundle lifecycle instruments introduced•   Managing of multiple applications at runtime discussed•   Best pract...
Upcoming SlideShare
Loading in...5
×

How to: Hot application deployment during runtime - Gerd Kachel

1,340

Published on

The talk tackles the problem of adding/removing applications at runtime in an OSGi-based product solution, e.g. an application server. The problem occurs any time you have a running solution, and you are not allowed to stop your solution for a moment. Thereby, an application is a well defined set of bundles. Such a set of bundles have to be added or be removed consistently in a running system. Best practice guidelines are given to solve this kind of problems for your solution. Patterns for starting and stopping of bundles during runtime are provided including loading and unloading of application bundles dynamically. A special focus is set on bundle start order execution at runtime. Guidelines how to avoid duplicated as well as unresolved bundles are given. Finally, an application loader implementation which is freely available is shortly introduced.

Published in: Technology, Business
0 Comments
1 Like
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
1,340
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
105
Comments
0
Likes
1
Embeds 0
No embeds

No notes for slide

How to: Hot application deployment during runtime - Gerd Kachel

  1. 1. How To: Hot Application DeploymentDuring RuntimeGerd Kachel (gerd.kachel@kachel.biz)kachel GmbHSeptember 21, 2011 OSGi Alliance Marketing © 2008-2010 . 1 PageCOPYRIGHT © 2008-2011 OSGi Alliance. All Rights Reserved All Rights Reserved
  2. 2. Problem Space• What is the scope? • Set of bundle which form an application. • Running multiple applications at one time. • Install and start applications at runtime. • Stop and uninstall applications at runtime. • Solutions with large uptime.• What is not the scope? • Configuration of start and stop of an static OSGi solution. • Application admin service.
  3. 3. Instruments of Bundle Lifecycle• Interface BundleContext • public Bundle installBundle(String location);• Interface Bundle • public void start(); • public int getState(); • public void stop(); • public void uninstall();
  4. 4. Maintaining Applications Application install() and Start start() each Bundle 1 bundle Bundle 2 ... Bundle n stop() and Stop uninstall() each bundle
  5. 5. Maintaining Applications: Pitfalls Application install() Start bundle Bundle 1 Bundle 2 ... Bundle n Bundle is already installed!
  6. 6. Maintaining Applications: Pitfalls Application install() Start bundle Bundle 1 Bundle 2 ... Be aware of Bundle n overlapping bundles in applications!
  7. 7. Maintaining Applications: Pitfalls Application start() bundle Start Bundle 1 Bundle 2 ... Bundle n Required bundles are not started (installed)!
  8. 8. Maintaining Applications: Pitfalls Application start() bundle Start Bundle 1 Bundle 2 ... Bundle n Bundle started but not used by application! (reason: bundle/package versioning)
  9. 9. Maintaining Applications: Pitfalls Application Other application will not work! Bundle 1 (reason:overlapping) Bundle 2 ... Bundle n stop() bundle Stop
  10. 10. Maintaining Applications: Pitfalls Application Other application Bundle 1 will not work! Bundle 2 (overlapping) ... Bundle n uninstall() Stop bundle
  11. 11. Maintaining Applications: BestPractice• Overall: Take care of bundle and package versions• Start application: • first install all bundles of an application then start bundles • use the right start order of bundles • don’t install and start bundles already installed by other running applications• Stop application: • first stop all bundles of an application then uninstall • use the right stop order of bundles for optimized application shut down • don’t stop and uninstall bundles in use by other running applications• Build application manager: • performs start/stop of all applications • keeps track of bundle overlapping between applications • application prepares information to application manager about application bundle relationship and bundle order • use it also for pre-installed applications for system start and shutdown
  12. 12. Roots Application Manager• Free available for private, academic, and commercial use• Implements introduced best practice methods• Provides application management at runtime via service• Manages start/shutdown of system• Manages application orders• See http://kachel.biz/files/public-docs/Software/Roots/ for RootsApplicationManager*.zip• Use support@kachel.biz for feedback or help
  13. 13. Application Provided in Folder• Boot application starts application manager• Application manager starts pre-installed other applications• Runtime application maintained by service or graphical console
  14. 14. Bundles and Properties
  15. 15. Bundles
  16. 16. Application Configuration by PropertyFile
  17. 17. Summary• Bundle lifecycle instruments introduced• Managing of multiple applications at runtime discussed• Best practice provided• Free available implementation shortly introduced
