Common Security Services –Consolidation Patterns for LegacyComponentsStefan VLADOVSOFTWARE AG20.09.2011 OSGi Alliance Marketing © 2008-2010 . 1 PageCOPYRIGHT © 2008-2011 OSGi Alliance. All Rights Reserved All Rights Reserved

OSGi Server platform• Our focus: • Enterprise JAVA applications and servers • Migrating heavy legacy components to OSGi • Components are tightly bound to core JAVA APIs • Not well suited for the OSGi world Page 2 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Speaking of JAVA APIs…• Java Authentication and Authorization Service • JAAS class loading problems • Key points • Plugging login module bundles • Preserving backward compatibility • Configuration challenges • RFP 123 – JAAS Integration Page 3 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

JAAS Core functionality• Focus on the authentication part of JAAS• Frontend • Consumers of login capabilities• Backend • Providers of login capabilities• Configuration • Exposing dynamic JAAS configuration • Retain backward compatibility Page 4 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

General design• We are focusing on the following JAAS framework artifacts • Login modules • Ensure dynamic OSGi disposal of login module bundles • Proxy loading mechanism to cope with JAAS limitations • Login contexts • Control of login context creation • Try to facilitate login module classloading • Configuration • Provide own JAAS configuration implementation tied to wrapped login modules • Expose the configuration through standard OSGi API Page 5 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Overview Configuration Managed ServiceConfigurator Admin Service Factory LoginContextFactoryImpl Login ContextLogin Consumer Factory Service Managed Configuration (Realms) Login Module Factory JAAS Extender (Generic Login Module Factory Implementations) True OSGi Login Module BundleLogin Provider Login Module Login Module Login Module Libraries Factory Impl Implementation Page 6 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Login Consumer• Access the JAAS through a LoginContextFactory:interface LoginContextFactory { LoginContext createLoginContext(String realm, Subject subject, CallbackHandler handler);}• Benefits: • Control and influence the creation of login contexts • It really feels like to OSGi way communication between modules Page 7 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Login Consumer• Legacy support:LoginContext context = new LoginContext(…);• Notes: • Products are used to this API • The proxy login module should be on the bootstrap classpath or on the thread context classpath when the context is created by the JAAS framework Page 8 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Login Module Provider• Login Module Factoryinterface LoginModuleFactory { LoginModule createLoginModule();}• Notes: • Allows creation of custom login module implementations through the whiteboard architectural pattern • OSGi aware providers may implement and register own login module factories and have full control over the instantiation of login modules Page 9 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Login Module Provider• Login Module Libraries: • Login module extender bundle will automatically register declared login modules in bundle manifests (under the Jaas-ModuleClass header) • Convenience for providers that wish to restrain from dependencies to the OSGi API. • Using Extender pattern to plug libraries into the Whiteboard (cool eh?) Page 10 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Configuration• JAAS Realm configuration • Realm name • List of module entries. Each entry consists of: • Module name • Flag: required, sufficient, requisite, optional • Set of key=value options. Page 11 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Configuration• Managed JAAS configuration: • Replace the standard JAAS configuration • Exposed through the OSGi service registry • Merge with standard JAAS configuration file (using central configuration) • Wrap configured login modules in proxy login modules (ClassLoader aware about delegates) Page 12 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Configuration• Using the Configuration Admin service to provide access to the JAAS configuration dynamically, through OSGi API • JAAS application configuration entries are pushed to the Managed configuration when they have the „jaas.config.pid “ persistent identificator • Although the Configuration Admin service offers very basic API for managing the JAAS configuration it has its benefits – Configuration will be available through any generic tool / UI that supports the Configuration Admin • A dedicated Realm configuration service should be evaluated in the future. Page 13 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Bundle structure JAAS API BUNDLE JAAS BUNDLE - LoginContextFactory <iface> Implementations - LoginModuleFactory <iface> Login module registry (Whiteboard) Managed Configuration Configure JAAS EXTENDER BUNDLE - LoginModuleBundleTracker JAAS PROXY JAAS PARSER BUNDLE - ProxyLoginModule - ConfigurationAdmin Service Tracker Page 14 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved

Out of scope• User Admin service – We want to stay focused only on the pure JAAS API. Adopters are free to use whatever security component they want, on top of JAAS.• We are currently working on providing a common SSO service in an OSGi server environment.• Prototyping with OpenID and SAML Page 15 OSGi Alliance Community Event 2011© 2008-2011. All Rights Reserved
