The Real Time Web with XMPP
   an Introduction to Strophe.js




                               Jack Moffitt
              ...
What is XMPP?
eXtensible Messaging and
  Presence Protocol
Why XMPP?
HTTP APIs are great
HTTP polling sucks
Real time is different
XMPP basics
XMPP network
XMPP addressing
example.com
jack@example.com
jack@example.com/home
jack@example.com/work
jack@example.com/7a29d835f9c
XMPP protocol
XML
XML streams
XML stanzas
<message/>
<presence/>
<iq/>
<message/>
<message
    from=’juliet@book.lit/home’
    to=’romeo@book.lit’
    type=’chat’>
 <body>
  Wherefore art thou, Romeo?
 </...
<message
    from=’juliet@book.lit/home’
    to=’romeo@book.lit’
    type=’chat’>
 <body>
  Wherefore art thou, Romeo?
 </...
<message
    from=’juliet@book.lit/home’
    to=’romeo@book.lit’
    type=’chat’>
 <body>
  Wherefore art thou, Romeo?
 </...
<message
    from=’juliet@book.lit/home’
    to=’romeo@book.lit’
    type=’chat’>
 <body>
  Wherefore art thou, Romeo?
 </...
<message
   from=’juliet@book.lit/home’
   to=’romeo@book.lit’
   type=’chat’>
 <body>
  Wherefore art thou, Romeo?
 </bod...
<presence/>
<presence
  type=‘away’>
 <show>away</show>
 <status>At JSConf 2009</status>
</presence>
<presence
    type=‘away’>
 <show>away</show>
 <status>At JSConf 2009</status>
</presence>
<presence
    type=‘away’>
 <show>away</show>
 <status>At JSConf 2009</status>
</presence>
<presence
    type=‘away’>
 <show>away</show>
 <status>At JSConf 2009</status>
</presence>
<iq/>
<iq
    to=‘book.lit’
    type=’get’
    id=’disco:1’>
 <query xmlns=’disco#info’/>
</iq>
<iq
    to=‘book.lit’
    type=’get’
    id=’disco:1’>
 <query xmlns=’disco#info’/>
</iq>
<iq
    to=‘book.lit’
    type=’get’
    id=’disco:1’>
 <query xmlns=’disco#info’/>
</iq>
<iq
    to=‘book.lit’
    type=’get’
    id=’disco:1’>
 <query xmlns=’disco#info’/>
</iq>
<iq
    to=‘book.lit’
    type=’get’
    id=’disco:1’>
 <query xmlns=’disco#info’/>
</iq>
<iq
    to=’romeo@book.lit/home’
    from=‘book.lit’
    type=’result’
    id=’disco:1’>
 <query xmlns=’disco#info’>
   <i...
<iq
    to=’romeo@book.lit/home’
    from=‘book.lit’
    type=’result’
    id=’disco:1’>
 <query xmlns=’disco#info’>
   <i...
<iq
    to=’romeo@book.lit/home’
    from=‘book.lit’
    type=’result’
    id=’disco:1’>
 <query xmlns=’disco#info’>
   <i...
<iq
    to=’romeo@book.lit/home’
    from=‘book.lit’
    type=’result’
    id=’disco:1’>
 <query xmlns=’disco#info’>
   <i...
XMPP and the Web
Sites using XMPP on the Web
BOSH

 Bidirectional streams
Over Synchronous Http
Long polling
Normal polling




 Long polling
What is Strophe?
XMPP client library
JavaScript
Real time Web applications
Fully documented
Highly optimized
Well tested
Built for Chesspark
StanzIQ and Speeqe
also used by
   Seesmic
  Yammer
Neuros OSD
First steps
Managing connections
Connecting
var connection =
new Strophe.Connection(URL);
connection.connect(
   jid,
   password,
   callback
);
user@domain

Strophe lets server
  assign resource
user@domain/resource

Strophe requests a specific
        resource
domain or domain/resource

    Strophe will try
  SASL ANONYMOUS
The connection callback
Strophe reports status
connecting
   authenticating
authentication failed
     connected
   disconnecting
   disconnected
function on_status(status) {
   if (status == Strophe.Status.CONNECTED) {
       // send initial presence
       // query ...
Sending data
connection.send(xml);
Disconnecting
connection.disconnect();
All about events
Event driven
Interaction events
Timed events
Stanza events
Examples
User clicks send button

$(‘#send’).click(function () {
    // build message stanza
    // send message
});
Display incoming messages
Add a handler

connection.addHandler(
   on_message,
   null,
   “message”,
   “chat”
);
Respond to matched stanzas

function on_message(msg) {
   // extract message body
   // display text

    return true;
}
Dealing with IQ stanzas
Answering incoming IQs

connection.addHandler(
   on_iq_version,
   “jabber:iq:version”,
   “iq”,
   “get”
);
Getting responses

connection.addHandler(
   on_version,
   null,
   “iq”,
   null,
   “disco-1”
);
Timed handlers

connection.addTimedHandler(
   100,
   send_flood
);
Building stanzas
Strophe.Builder
Almost always returns
   Strophe.Builder
Allows function chaining
    just like jQuery
var stanza = new Strophe.Builder(
   “message”,
   {“to”: “someone@jabber.org”,
    “type”: “chat”}
);
Chainable methods
Adding a child

c(name, attrs)
Adding text content

  t(“some text”)
Adding pre-made children

    cnode(element)
Modifying attributes

 attrs(new_attrs)
Traversing the tree

       up()
Examples
new Strophe.Builder(
   “message”,
   {“to”: “someone@jabber.org”,
    “type”: “chat”}
).c(“body”).t(“Hello, World!”);
new Strophe.Builder(
    “message”,
    {“to”: “...”, “type”: “chat”}
).c(“body”).t(“Hi”)
.up()
.c(“html”,
   {“xmlns”: “....
Convenience functions
$pres(attrs)
$msg(attrs)
 $iq(attrs)
Send available presence

       $pres()
Build a message

$msg({“to”: “someone@jabber.org”,
      “type”: “chat”})
 .c(“body”).t(“XMPP rocks!”)
Unchainable methods
calling stanza.toString() produces

“<message to=‘someone@jabber.org’
          type=‘chat’/>”
stanza.tree() produces a DOM tree
Hello, Server!

 an application
Plugins!
Strophe.addNamespace(
  ‘XHTML_IM’,
  ‘http://jabber.org/protocol/xhtml-im’
);
Strophe.addConnectionPlugin(
  ‘myplugin’,
   {
     init: function (conn) { ... }
   }
);
Identi.ca microblogging
The Future
XPath matching with Strophe
conn.addHandler(
“/message[@from=‘you@foo.com’
  and @type=‘chat’]”,
 function (elem) {...});
The multi-session problem
http://code.stanziq.com/strophe

      http://metajack.im

      jack@collecta.com
