Mechanism Design  Graphical Method
Mechanism Synthesis <ul><li>–  deals with determining the length of all links, gear diameter, cam profile. </li></ul><ul><...
Mechanism Synthesis Type Synthesis The Associated Linkage Concept It is desired to derive various types of mechanisms for ...
Mechanism Synthesis Type Synthesis -  The Associated Linkage Concept (6-Bar) 6-Bar
Limiting Conditions – 4 Bar Mechanism Toggle positions of a crank-rocker mechanism. Links 2 and 3 become collinear.
Transmission Angle – 4 Bar Mechanism The angle between link 3 and link 4 is defined as the transmission angle T 4  =  F 34...
Minimum Transmission Angle – 4 Bar Mechanism Minimum transmission angle occurs when link 2 (crank) becomes collinear with ...
Mechanical Advantage – 4 Bar Mechanism
Mechanical Advantage – 4 Bar Mechanism O 4 B  = 2( O 2 A ) r in  =  r out µ = 60 O , v = 5 O M.A. = 20 µ A B
Mechanism Synthesis Dimensional Synthesis –  this approach is suitable for automatic computation. Once a mechanism is mode...
Graphical Synthesis – Motion Generation Mechanism Two positions, coupler as the output A 1 A 2 B 1 B 2 <ul><li>Draw the li...
Graphical Synthesis – Motion Generation Mechanism Three positions, coupler as the output A 1 A 2 A 3 B 1 B 2 B 3 <ul><li>S...
Graphical Synthesis – Motion Generation Mechanism Adding a Dyad to a non-Grashof mechanism. A 1 A 2 B 1 B 2 O 2 O 4 2 3 4 ...
Graphical Synthesis – Motion Generation Mechanism A 1 A B 1 O 4 O 6 C D O 2 B 3 2 4 5 6 6-Bar Grashof mechanism
Three Position, 6-Bar Grashof ,Motion Generation Mechanism
Three Position, 6-Bar Grashof ,Motion Generation Mechanism
Graphical Synthesis – Motion Generation Mechanism Two positions Grashof 4-Bar mechanism with rocker as the output D 1 C 1 ...
Graphical Synthesis – Motion Generation Mechanism Two positions Grashof 4-Bar mechanism  with rocker as the output D 1 C 1...
Two Position, 4-Bar Grashof  Motion Generation Mechanism
Graphical Synthesis – Motion Generation Mechanism Three positions with specified fixed pivot points, coupler as the output...
Graphical Synthesis – Motion Generation Mechanism C 1 D 1 C 2 C 3 D 2 D 3 O 2 Three positions with specified fixed pivot p...
Graphical Synthesis – Motion Generation Mechanism C 1 D 1 C 2 C 3 D 2 O 2 O ” 2 O ” 4 O ’ 2 O ’ 4 Three positions with spe...
Graphical Synthesis – Motion Generation Mechanism C 1 D 1 C 2 C 3 D 2 O 2 G H D 3 O 4
Graphical Synthesis – Motion Generation Mechanism Three positions with specified fixed pivot points, coupler as the output.
Graphical Synthesis – Path Generation Mechanism Three prescribed points. Design a 4-Bar in such a way that a point on the ...
Graphical Synthesis – Path Generation Mechanism Three prescribed points. Locate moving pivot B by means of kinematic inver...
Graphical Synthesis – Path Generation Mechanism with Prescribed Timing Three prescribed points Timing requirements:  input...
Graphical Synthesis;  Quick – Return Mechanism Advance stroke – mechanism operates under the load. Return stroke – mechani...
Quick – Return Mechanism Consider the two toggle positions of a crank-rocker mechanism. O 4 O 2 B 1 2 3 4 A 1 B 2 A 2 C Lo...
Quick – Return Mechanism O 4 O 2 B 1 2 3 4 A 1 Q = advance / Return = (180 + α) / (180 – α),  Time Ratio B 2 A 2 C α 180 –...
Synthesis of a Quick – Return Mechanism Known or selected;  Rocker angle,  φ Rocker length,  r 4  Time ratio,  Q Determine...
Synthesis of a Quick – Return Mechanism <ul><li>Calculate the length of link 3, AB = r 3  = O 2  B 1  – r 2 </li></ul>O 2 ...
