Linux Architecture <ul><ul><li>By:- </li></ul></ul><ul><ul><li>BOSS Team Member </li></ul></ul><ul><ul><li>CDAC-chennai </...
Linux Internal <ul><li>Introduction  </li></ul><ul><li>Kernel  </li></ul><ul><li>Process Management </li></ul><ul><li>Memo...
Introduction <ul><li>Operating System is a software designed to control the hardware of a system in order to allow users a...
Components of Linux System <ul><li>Architecture of the GNU/Linux operating system </li></ul>
Components of a Linux System (Cont.)‏ <ul><li>When Linux is running in main memory,the it is divided in to two parts  1) U...
The Linux Kernel <ul><li>Kernel is a resource manager whether resource being managed is a  process,memory,hardware device....
Linux Kernel <ul><li>Types of Kernel </li></ul><ul><li>Monolithic Kernel.  (e.g. Linux kernel)‏ </li></ul><ul><li>Micro ke...
Structure of monolithic and micro-kernel-based operating systems <ul><li>Monolithic kernel  Micro Kernel </li></ul>
Linux Kernel 2.6.x <ul><li>Characteristics that differ between the Linux kernel and other Unix variants: </li></ul><ul><li...
Linux Kernel <ul><li>Kernel version naming convention:  Linux kernel currently consists of four numbers  A.B.C[.D] </li></...
Linux kernel <ul><li>Block diagram of Linux Kernel. </li></ul>
Linux Kernel- System Call Interface <ul><li>System call is the mechanism used by an application program to request service...
Linux Kernel-Process Management <ul><li>Process is a program in execution. </li></ul><ul><li>Process is represented in OS ...
Linux Kernel-Process Management <ul><li>Linux kernel stores the list of process in a circular doubly linked list called ta...
Linux Kernel-Process Management <ul><li>Thread is a unit of execution or objects of activity within process. </li></ul><ul...
Linux Kernel-Process Management <ul><li>Process state is defined in part of current activity of that process  </li></ul><u...
Linux Kernel-Memory Management <ul><li>Computer memory layout: </li></ul>
Linux Kernel-Memory Management <ul><li>Linux’s physical memory-management system deals with allocating and freeing pages, ...
Splitting of Memory in a Buddy Heap
Managing Physical Memory <ul><li>The page allocator allocates and frees all physical pages; it can allocate ranges of phys...
Virtual Memory <ul><li>The VM system maintains the address space visible to each process:  It creates pages of virtual mem...
File System <ul><li>A file system is the methods and data structures that an  operating system uses to keep track of files...
Filesystem <ul><li>The Virtual Filesystem (also known as Virtual Filesystem Switch or VFS) is a kernel software layer that...
Filesystem <ul><li>file object stores information about the interaction between an open file and a process. This informati...
Filesystem maintenance <ul><li>Filesystems checked at boot up </li></ul><ul><li>Maintaining consistency with  fsck , e2fsc...
Device Driver <ul><li>Device drivers take on a special role in the Linux kernel. They are distinct “black boxes” that make...
Network stack <ul><li>The network stack, by design, follows a layered architecture modeled after the protocols themselves....
Architecture-dependent code <ul><li>While much of Linux is independent of the architecture on which it runs, there are ele...
<ul><ul><li>  Thank You </li></ul></ul>
