    WebML for OMG WebML for OMG Presentation Transcript

    • Experiences and requirements for a User Interaction Modeling Language
      Marco Brambilla @marcobrambi
      Politecnico di Milano and WebRatio
      Stefano Butti @stebutti
      WebRatio
      OMG Technical Meeting, ADTF, Salt Lake City, June 22nd, 2011
    • Agenda
      2
      WebML: Web Modeling Language
      History
      Language
      Metamodel
      Relation to other standards
      Industrial Experience
      WebRatio
      Users
      Projects
      Requirements for a Web UI Language
      Discussion
      RFC or RFP
      Consensus and partners
    • 1. WebML
    • WebML: purpose
      4
      A visual modeling language (DSL) ...
      Oriented to the high level design
      Incorporating all the details that are needed for refined specification
      ... Effective and essential ...
      Including only the concepts relevant to the domain
      No overhead because of verbose notation or orthogonality
      ... For user interaction design ...
      Page contents
      Navigation paths and UI events
      ... Within web applications
      Born bottom-up from the features of dynamic web applications
    • WebML: role and positioning
      Process:
      BPMN
      User Interaction:
      WebML
      Contents:
      ER, class, ..
      Style:
      CSS, ...
      BPMN model
      Backend:
      SoaML, WSDL..
      Services
      5
    • The WebML notation: example
      Two pages
      Retrieval of session data (CurrentUser)
      Review Page
      Lists of (prefered) artists
      Links to artist details
      Albums Page
      List of albums of selected artist
      Checkbox and deletion of albums
    • WebML: content publishing units
      7
      A WebML unit is the atomic information publishing element
      A “view” defined upon a container of objects:
      The instances of an concept
      Based on a complex selection condition (called selector)
      A unit may need some input and produces some output
      Input is required to compute the unit itself (params of the selector)
      Output can be used to compute other unit(s)
    • WebML: Links
      Source
      Destination
      Links in WebML have 3 purposes
      Describe navigation paths
      Transport parameters between units
      Activate computation of units and execution of side effects
      Normally, links are rendered as one or more anchors/buttons based on the dataset and semantics of the source unit
      Various behaviours are allowed (automatic, asynchronous, transport ..)
      Transportlinks: onlycarryparameters, no navigationnor side effects
    • WebML: CRUD operation units
      9
      Execution of CRUD operations
      Simple failure/success model of operations
      Success: green “OK link” is navigated
      Failure: red “KO link” is navigated
      Chains of operations can be defined
      Control dictated by links
      Basic control flow elements available (loop, switch)
    • WebML units: coverage
      Content publishing
      Data Index MultiData Entry Scroller Multichoice HierarchicalIndex
      Session management Web Services
      Login Logout Get Set Request-Response ….
      CRUD Operations
      Create Modify Delete Connect Disconnect
      10
    • WebML foundation and extensibility
      11
      The language foundations
      Basic set of units
      Connection to a content model for data retrieval and management
      Links for control and data flow
      Page computation algorithms for execution semantics
      The page content is automatically calculated also in case of complex topologies
      Incoming links and dependencies among units are considered
      The language is open
      New units and operations can be specified
      For implementing ad-hoc business logics
    • WebML metamodel
      12
      Language metamodel available
      As UML diagrams (MagicDraw)
      As ECORE (EMF) models written in Eclipse Modeling Tools
      Excerpt / overview:
    • WebML metamodel
      13
    • 2. WebRatio
    • What is WebRatio
      15
      An Eclipse-based development environment allowing:
      Modeling: ER + WebML + BPMN
      100% code generation of standard JEE applications
      Clear separation between design time and run time
      No proprietary runtime
      Quick and agile development cycles
      Extending the generation rules
      Defining new presentation styles
      Defining new components
      Versioning, teamwork, full lifecycle mgt
    • Who are the user of WebRatio
      16
      Business Process
      Analyst
      (*) 4 days
      (*) 15 days
      Application Analyst /WebRatio Modeler
      Model editor
      Application Model(ER + WebML)
      Process Model
      (BPMN)
      Standard Java
      Web application
      Generation rules
      Custom Model Components
      (Java, API ,…)
      Layout Templates(HTML, CSS, JavaScript, ...)
      Web
      Designer
      Java
      Programmer
      (*) Learning time
      (*) 5 days
      (*) 5 days
    • A broad spectrum of possible applications
      17
      Document Management
      Customer Information Mgt
      Sales and LeadManagement
      Web Content Management
      Knowledge Management
      CustomerRelationshipManagement
      Learning Management
      Partner Relationship Mgt
      Knowledge Support
      Marketing Resources Mgt
      Project Management
      Web Customer
      Services
      Business Intelligence
      Supply Chain Management
      B2C/B2B
      E-Commerce
      Enterprise Resource Planning
      Web Front-End of accounting sys.
      Financial Services
      Supplier Relationship Mgt
      Payment Services Orchestration
      Corporate Operations
      Human Capital Management
      Product Life Cycle Management
      Front-Office Process Mgt
    • Summary
      WebRatio is
      now at its 6th major release
      in the market since 2001
      WebRatio customers
      100+ companies and 500+ users
      in Italy, Europe and South America
      WebRatio partners
      40+ software houses and system integrators
      300+ universities worldwide, 12.000+ students
    • 3. Requirements and discussion
    • Modeling and standardization gap
      20
      A perceived gap in the standardization efforts
      User interaction has been overlooked in modeling proposals
      Previous attempts failed because of:
      Low usability and effectiveness of notation
      Missing solid implementations with vendors support
    • Lesson learned (so far)
      21
      Reasons for the success of the current notation
      Extremely compact (no useless overhead)
      Effective (allows to model exactly what users want)
      Efficient (grants high reusability of model fragments)
      Easy to learn (very low learning curve)
      Comprehensive (covers most of the web interaction needs)
      Open and extensible (for covering any ad hoc logic)
      Perceived missing aspects
      Appropriate management of client-side logics, RIAs (Rich Internet Applications), AJAX, complex user events
      Full-fledged support to UML class diagrams (esp. methods)
    • WebML in the OMG framework
      22
      Exploit the possible relations with
      BPMN -- Already in place
      Class diagrams
      SoaML
      Other standards?
      Support the standardization
      Refine the metamodel
      Implement appropriate injectors to MOF-compliant models
    • WebML standardization effort
      23
      Gather interest and consensus
      From vendors and users
      Open to changes, extensions, integration
      Establish a joint effort / strategy
      Decide scope
      Possible options:
      Only Web
      Web + Mobile
      Generic Graphical UI
      Decide RFP vs. RFC
      Pros and cons
    • Thanks
