Building Semantic Web Portals with WebML

  1. 1. Building Semantic Web Portals with WebML Marco Brambilla and Federico M. Facca ICWE 2007 Como, 20th July 2007 http://home.dei.polimi.it/mbrambil http://twitter.com/MarcoBrambi http://www.slideshare.net/mbrambil
  2. 2. Agenda <ul><li>Introduction </li></ul><ul><ul><li>Requirements for metamodels of Semantic Web applications </li></ul></ul><ul><li>Extending WebML towards Semantic Web </li></ul><ul><ul><li>Evolving existing primitives </li></ul></ul><ul><ul><li>New Advanced units for ontology querying </li></ul></ul><ul><ul><li>Primitives for Ontology management </li></ul></ul><ul><ul><li>Example of Usage of Advanced Units </li></ul></ul><ul><li>Case Study Example </li></ul><ul><li>Implementation expirience </li></ul><ul><li>Conclusions & Future Works </li></ul>
  3. 3. Introduction <ul><li>Model-driven techniques aims to reduce the cost of design and implementation of software </li></ul><ul><li>The Semantic Web can benefit from Web Engineering field and viceversa </li></ul><ul><ul><li>there’s a lack of well engineered solution in SW </li></ul></ul><ul><ul><li>SW technologies provide more “flexibility” and allow complex reasoning task </li></ul></ul><ul><ul><li>Some effort have been already done: HERA, SHDM, … </li></ul></ul><ul><li>A Web Portal is a Web site providing personalization to to its visitors and designed to use distributed data sources </li></ul><ul><ul><li>One of the assumptions of Semantic Web is the use of distributed data sources and reuse of existing ones </li></ul></ul>
  4. 4. Introduction Requirements for metamodels of Semantic Web applications <ul><li>Support of semantic languages (OWL, RDF, WSML, …) </li></ul><ul><li>Models should be “semantic” </li></ul><ul><ul><li>i.e., grant self-annotation and explicit semantic annotation extraction </li></ul></ul><ul><li>Allow for flexible integration of heterogeneous sources and applications </li></ul><ul><li>Transformations towards a semantic query language </li></ul><ul><ul><li>allowing for inference, verification, query on schema and instances </li></ul></ul><ul><li>Allow for (semi-)automatic annotation of generated Web pages </li></ul><ul><li>Support the import and reference of remote ontologies </li></ul><ul><ul><li>reuse and sharing of the knowledge </li></ul></ul>
  5. 5. Extending WebML towards Semantic Web <ul><li>WebML methodology extended to support the new requirements </li></ul>+ Reuse of existing ontological data source + Specialized units for advanced queries over semantic data and annotation extraction
  6. 6. Extending WebML towards Semantic Web <ul><li>WebML methodology extended to support the new requirements </li></ul>
  7. 7. Extending WebML towards Semantic Web Evolving existing primitives <ul><li>Existing units can be adapted for direct access to ontology </li></ul><ul><ul><li>Changes in their “semantic” (query both on schemas and instances ) </li></ul></ul>instance uri class uri e.g. mf:Artist no input class uri e.g. vin:RedWine […] […] […] […]
  8. 8. Extending WebML towards Semantic Web New Advanced units for ontology querying Is x subproperty of y? Or: find subproperties/ find superproperties The list of URIs where property p has value v Or: find values/ find properties Is x property of y? Or: find the properties/ find the class Is x an instance of y? Or: find instances/ find classes Is x subclass of y? Or: find subclasses/ find superclasses
  9. 9. Extending WebML towards Semantic Web New Advanced units for ontology querying class uri instance uris instace uri classes uris instace & class uri boolean
  10. 10. Extending WebML towards Semantic Web Primitives for Ontology management <ul><li>Ontology composition: union, intersection, difference </li></ul><ul><li>Ontology importing: for direct query of existing ontologies </li></ul><ul><li>Semantic description extraction: for extracting semantic annotation of contents / pages </li></ul>
  11. 11. Extending WebML towards Semantic Web Example of Usage of Advanced Units The value submitted in the form is passed to the HasPropertyValue unit that extracts a set of URIs of instances (albums or artists) with mm:soundsLike property equal to Val. The InstanceOf unit that checks if they are instances of the class Artist. The URIs are then shown in a list of Artists.
  12. 12. Case Study Example
  13. 13. Implementation expirience <ul><li>Current extension is for RDF/OWL and uses SPARQL queries </li></ul><ul><li>New set of runtime components created to support semantic data sources based on Jena API and Pellet </li></ul><ul><li>Modeling environment extended for the use of the new units </li></ul>
  14. 14. Implementation expirience
  15. 15. Implementation expirience <ul><li>The automatic code generation phase is based on the generation of configuration files for the generic components </li></ul><ul><li>The transformation from design time descriptor to runtime descriptor is based on XSLT </li></ul>Design Time Descriptor Runtime Descriptor <SWINDEXUNIT class=&quot;mf:Track&quot; id=&quot;swinu1&quot; name=&quot;Tracks&quot; ontology=&quot;onto1&quot;> <DisplayedProperties property=&quot;mf:title&quot;/> <DisplayedProperties property=&quot;mf:descripion&quot;/> <SortProperties order=&quot;ascending&quot; property=&quot;mf:title&quot;/> <Filter boolean=&quot;or&quot;> <FilterCondition id=&quot;fselector1&quot; property=&quot;mf:playedBy&quot; predicate=&quot;eq&quot; name=&quot;Artist&quot;/> </Filter> </SWINDEXUNIT> <descriptor service=&quot;org.webml.onto. SWIndexUnitService&quot;> <onto>onto1</onto> ... <input-params> <input-param type=&quot;mm:Artist&quot; name=&quot;swdau2.rdf:ID&quot; /> </input-params> ... <query type=&quot;SELECT&quot;> SELECT DISTINCT ?instance ?p1 ?p2 WHERE {?instance rdf:type mm:Track . ?instance mm:title ?p1 . ?instance mm:descriptor ?p2 . ?instance mm:playedBy ?fs1 . FILTER (?fs1 = $swdau2.rdf:ID$)} ORDER BY DESC(?p1) </query> </descriptor>
  16. 16. Conclusions & Future Works <ul><li>Good abstractions are still valid even when new technologies become available </li></ul><ul><li>Schema querying become relevant in the context of Semantic Web and Models should provide support for it </li></ul><ul><li>Semantic Web introduces new query “types” and metamodels for Web applications should deal with this </li></ul><ul><li>Our solution is missing a real integration layer for better allowing seamless integration of the different datasources </li></ul><ul><li>Current implementations suffers performance issue when executed the first time </li></ul>
  17. 17. Thanks for the attention! <ul><li>For comments or questions: </li></ul><ul><ul><li>Marco Brambilla </li></ul></ul><ul><ul><li>Politecnico di Milano </li></ul></ul><ul><ul><li>Dipartimento di Elettronica e Informazione </li></ul></ul><ul><ul><li>[email_address] </li></ul></ul><ul><ul><li>Resources: </li></ul></ul><ul><ul><li>http://home.dei.polimi.it/mbrambil </li></ul></ul><ul><ul><li>http://marcobrambi.blogspot.com </li></ul></ul><ul><ul><li>http://twitter.com/MarcoBrambi </li></ul></ul>http://home.dei.polimi.it/mbrambil http://twitter.com/MarcoBrambi http://www.slideshare.net/mbrambil

×
