Wireless LAN Deployment Best Practices

Wireless LAN Deployment Best Practices Michael Boman IT Security Researcher & Developer http://proxy.11a.nu | proxy@11a.nu

What We Will Cover
Wireless Concepts
Security Issues with Wireless Networks
Attacks against Wireless Networks
Countermeasures
Q & A

Wireless Basics
802.11 - “WiFi” networks are typically implemented as either a standalone network solution, or to extend the capabilities of an existing wired network.
The most common wireless configurations found today are:
Ad Hoc
Infrastructure modes

Terminology
Frame – data transmitted by the physical medium
Access point – a device attached to wired network providing wireless access to users
Service set – a series of access points working in conjunction to provide access
SSID – string identifying a service set
BSSID – MAC address of AP in question

The different 802.11 Standards
802.11b
Operating in the 2.4 GHz band
Maximum theoretical data rate of 11 Mbps
In a typical office environment, its maximum range is 75 meters at the lowest speed, but at higher speed its range is about 30 meters.

802.11a
Operating in the 5 GHz band
In a typical office environment, its maximum range is 50 meters at the lowest speed, but at higher speed, the range is less than 25 meters.

802.11g
Operating in the 2.4 GHz band
Backward compatibility with 802.11b

802.11i
Supplemental draft standard is intended to improve WLAN security.
Describes the encrypted transmission of data between systems of 802.11a and 802.11b WLANs.
Defines new encryption key protocols including the Temporal Key Integrity Protocol (TKIP) and the Advanced Encryption Standard (AES).

802.1X
IEEE standard for access control for wireless and wired LANs, 802.1X provides a means of authenticating and authorizing devices to attach to a LAN port.
This standard defines the Extensible Authentication Protocol (EAP), which uses a central authentication server to authenticate each user on the network.

Concepts of the 802.11 MAC layer
Three types of frames
Management
Access control: authentication, association
Media detection: beaconing, probing
Data
Transmit higher layer data to or from access point
Control
Acknowledge receipt of data frames
Reserve media for long frame exchanges

Concepts of the 802.11 MAC layer
Client authenticates to a service set
Before access, not throughout
Shared secret key or no key
Client associates to an access point
Clients disassociate with an AP, re-associate with another as they move

Ad Hoc Networks
Also referred to as “Independent Basic Service Set” (IBSS)
Provides peer-to-peer communication links between two or more wireless devices without the use of an AP
This is the default setting on most wireless cards

Ad Hoc mode or IBSS configuration CELL Wireless Laptop Computers

Infrastructure Networks
Also known as “Basic Service Set” (BSS)
Requires an Access Point and at least one wireless client
Connections are initiated with the proper Service Set Identifier (SSID) - Shared secret manually entered on the AP and each client (Not scalable)
Sometimes Wired Equivalent Privacy (WEP) encryption keys are also configured (Used about 30% of the time)

Infrastructure mode or BSS configuration Wireless Access Point Wireless Laptop Computer Wireless Laptop Computer Internal LAN

Security Issues

Antenna Signal
Walls and doors do not provide sufficient containment of the wireless signal. An Access Point (AP) placed inside a typical office can transmit a signal anywhere up to 300 meters.
100 meters in any direction will usually put you on a road, in a neighboring office or parking lot.
Vertical threats such as offices above and below should also be taken into consideration when selecting your AP’s location.
Hackers will War-Drive at lunch looking for AP’s used in conference rooms.

Antenna Signal
An attacker can compensate your weak signal by using a directional antenna and/or amplifier
At DefCon 13 earlier this month, a group of enthusiasts was able to set up an un-amplified 802.11 network at a distance of 201 km.

802.11 Design Flaws
MGMT, CTRL frames not encrypted
Can be spoofed w/o knowledge of WEP key
Weak authentication of station
Easy to get access to wireless medium
No authentication of AP to station
Can prove an AP is legitimate
Limited # of stations can use a single AP
We can overflow an AP to prevent wireless access

SSID
Some believe that by using a complicated SSID an unauthorized user will have difficulty in gaining access to their AP.
SSID’s are passed in the clear, even when WEP is enabled.
It is a trivial matter to download free software off the Internet that is designed to intercept SSID’s from a wireless communication session.

Access Control
Access Control at the MAC (Media Access Control)
Most administrators feel that MAC layer filtering provides adequate security by allowing clients with non-restricted MAC addresses to connect to the wireless network.
MAC addresses are passed in the clear
MAC addresses can easily be changed

Wired Equivalent Privacy (WEP)
Should be “What on Earth does this Protect”
Provides encryption to data frames only
Probably fine on small, limited use networks
Don’t depend on it for data security
WEP gives administrators a false sense of security.

Wired Equivalent Privacy (WEP)
Even when WEP is properly configured and deployed on a wireless network, it is still a trivial matter to break the encryption and gain access to the AP.
WEP keys are static and configured manually (Not a scaleable solution)
WEP requires the same secret key be shared by all wireless users within the cell
Free software on the Internet is available that is used to crack the encryption

Wi-Fi Protected Access (WPA)
The Wi-Fi Alliance put together WPA as a data encryption method for 802.11 wireless LANs.
WPA is an pre-standard version of 802.11i utilizing the Temporal Key Integrity Protocol (TKIP), which fixes the problems of WEP (including using dynamic keys).
WPA will serve until the 802.11i standard is ratified.

Extensible Authentication Protocol (EAP)
EAP is an 802.1X standard that allows developers to pass security authentication data between RADIUS and the access point (AP) and wireless client.
EAP has a number of variants, including:
EAP MD5
EAP-Tunneled TLS (EAP-TTLS)
Lightweight EAP (LEAP)
Protected EAP (PEAP).

User Network Access Controls
One area that is commonly overlooked is the ability to regulate internal network access.
Most users have varying levels of access to internal resources.
All wireless users could potentially be entering the network by the same wireless AP.

Business Risks of Wireless LANs
A wireless attacker could affect you business in the following ways:
Ability to destroy data
Ability to steal proprietary data from client workstations and servers
Disruption of network service through corruption of network devices
RISK: Inability to meet core business and customer needs that could lead to loss of revenue

Security Risks INTRODUCED by Wireless Technology
Rogue Access Points
Clients Communicating in Ad Hoc Mode
Computerworld survey estimate at least 30 percent of businesses have rogue wireless LANs.

Rogue Device Threat
Can make your network vulnerable…
Even with a secure wireless network
Even if you have no wireless network
Both Access Points and Clients are dangerous
Goal
Protect network jacks
Identify unauthorized wireless devices

Placing an AP on the inside of your network will extend its access past any physical barriers or controls.
AP are small and only take a few minutes to connect to your internal network
The level of sophistication needed to install an AP is low
Rogue Access Points

Denial of Service
A user with malicious intent could configure a client to bombard the AP with thousands of connection requests eventually leading to the complete shutdown of the targeted AP.
RF noise generation – Arc Welder – homemade jamming device
Eventual saturation of RF devices – Bluetooth, 802.11b and g devices, etc.

Security Risks of Wireless LANs
Easier for unauthorized devices to attach to wireless network
Don’t need physical access
Many organizations don’t apply security
Presence of free wireless hacking tools
Internal systems are usually not as secure as external or DMZ systems

Wireless is insecure by its very nature The point?

Tools of the Trade

Hardware Wireless Card and Antenna

Hardware
War-Driving Rig – Laptop, wireless card and Antenna

Software
Types of Monitoring tools
Stumbling
Sniffing
Handheld
Hacking tools
WEP Cracking
ARP Spoofing

Stumbling Tools
Stumbling tools identify the presence of wireless networks. They look for beacons from access points, and also broadcast client probes and wait for access points to respond.

Sniffing Tools
Sniffing tools capture the traffic from a wireless network and can view the data passed across the air.

Handheld Tools
Handheld tools are more portable and provide wireless network identification and network status monitoring.

Hacking Tools
Hacking tools are for pointed attacks to gain access to secured wireless networks.

Attacks against Wireless Networks

Leeching access
Easy to do
Laptop and wireless card
Scanning tools help, but not required
Hard to track down
Who wants / can afford to triangulate a signal?
Biggest security implication
Joe Kiddie (not Osama) can run scans & exploit hosts
Won’t get traced back to daddy’s cable modem
But admins can “cripple” wireless segment
Rate limiting
Filter naughty packets

Wireless Auto Configuration Algorithm
First, Client builds list of available networks
Send broadcast Probe Request on each channel

Access Points within range respond with Probe Responses

If Probe Responses are received for networks in preferred networks list:
Connect to them in preferred networks list order
Otherwise, if no available networks match preferred networks:
Specific Probe Requests are sent for each preferred network in case networks are “hidden”

If still not associated and there is an ad-hoc network in preferred networks list, create the network and become first node
Use self-assigned IP address (169.X.Y.Z)

Finally, if “Automatically connect to non-preferred networks” is enabled ( disabled by default ), connect to networks in order they were detected
Otherwise, wait for user to select a network
Continue scanning for networks

Attacking Wireless Auto Configuration
Attacker spoofs disassociation frame to victim
Client sends broadcast and specific Probe Requests again
Attacker discovers networks in Preferred Networks list (e.g. linksys, MegaCorp, t-mobile)

Attacker creates a rogue access point with SSID MegaCorp

Victim associates to attacker’s fake network
Even if preferred network was WEP (XP SP 0)
Attacker can supply DHCP, DNS, …, servers

Wireless Auto Configuration Attacks
Join ad-hoc network created by target
Sniff network to discover self-assigned IP (169.X.Y.Z) and attack
Create a more Preferred Network
Spoof disassociation frames to cause clients to restart scanning process
Sniff Probe Requests to discover Preferred Networks
Create a network with SSID from Probe Request
Create a stronger signal for currently associated network
While associated to a network, clients sent Probe Requests for same network to look for stronger signal
You can be 0wned (=compromised) while watching a DVD on a plane!

A Tool to Automate the Attack
Track clients by MAC address
Identify state: scanning/associated
Record preferred networks by capturing Probe Requests
Display signal strength of packets from client
Target specific clients and create a network they will automatically associate to
Compromise client and let them rejoin original network
Connect back out over Internet to attacker
Launch worm inside corporate network
Etc.

Creating An ALL SSIDs Network
Can we attack multiple clients at once?
Want a network that responds to Probe Requests for any SSID
PrismII HostAP mode handles Probe Requests in firmware, doesn’t pass them to driver
Atheros has no firmware, and HAL has been reverse engineered for a fully open-source “firmware” capable of Monitor mode, Host AP

Creating a FishNet
Want a network where we can observe clients in a “fishbowl” environment
Once victims associate to wireless network, will acquire a DHCP address
We run our own DHCP server
We are also the DNS server and router

FishNet Services
When wireless link becomes active, client software activates and attempts to connect, reconnect, etc. without requiring user action
Our custom DNS server replies with our IP address for every query
We also run “trap” web, mail, chat services
Fingerprint client software versions
Steal credentials
Exploit client-side application vulnerabilities

Client-Side Application Vulnerabilities
Recent client-side vulnerabilities
Vulnerability in Plug and Play Could Allow Remote Code Execution and Elevation of Privilege
Vulnerability in JView Profiler Could Allow Remote Code Execution
Vulnerability in Microsoft Color Management Module Could Allow Remote Code Execution
Vulnerability in Server Message Block Could Allow Remote Code Execution
…
Exploits can make use of fingerprinting info

Beating access control
MAC address spoofing
Sniff or brute force legitimate MAC addresses
Return and use those addresses later
Crack WEP key w/ known tools (hours, days)
Or just find one among the multitude of available APs without WEP…

Denial of service
Forge disassociations
Deny an individual station access
Used also to hijack sessions
Forge lots of associations
Saturate an access point
Access point will stop accepting associations
Forge lots of beacon frames
Creates illusion of access points that don’t exist
Can also throw off a war driver seeking access

Session hijacking
Disassociate client
Take over any desired existing network sessions
New venue for known transport session hijacking

Man in the middle
Impersonate an access point
Tamper with data
Pass on to legitimate access point
Implemented SSH, SSL and other MITM also have new venue on 802.11

Home Users Wireless Access Point Hack-me Hack-me

Corporate Networks Accounting Payroll Wireless Access Point Wireless Hacker Switch

ARP Cache Attacks can also be launched against:
Wireless Clients connected to the AP
Wireless Clients and Wired Clients
Wireless Home Users (Couch Networks)
And may other combinations
Corporate Networks

Telecommuters

Countermeasures

SEC- -Y U - R - IT If not you, who? If not now, when? The key to security awareness is embedded in the word security…

Countermeasures
Holistic Approach
Prevention
Identification
Response

Prevention
Create a completely separate wireless security policy
Do a complete Site Survey before placement of AP’s
Wireless networks should always be treated as un-trusted and never placed behind corporate firewalls
Use MAC layer filtering
Be sure to change the SSID from the default value and disable broadcasting if possible

Prevention
Use encryption, even WEP - (Low hanging fruit theory)
Static IP’s vs DHCP
Use third party software for additional security – Authentication, VPN encryption
Use personal Firewall software on and anti-malware your wireless clients systems
Install the latest security patches and firmware updates on you wireless equipment

Prevention
Do regular audits of deployed wireless equipment
Perform regular sweeps for un-authorized wireless equipment
Perform regular Penetration Tests against your whole infrastructure, including the wireless segments (alternative: concentrate on perimeter and wireless segments)

Identification
Deploy Wireless IDS sensors
Identify your signal range – clients with antennas can pick up you signal further away than without one
Periodically scan your facility for rouge access points using the same software attackers are using
Check your internal logs for strange anomalies concerning MAC addresses

Response
Have an adequate response plan in place to deal with malicious activity
Have the ability to log activity of a malicious user to aid in prosecution
Have the ability to control and reconfigure your Access Points on the fly

Countermeasures - Antenna Signal
Proper selection of Antenna – Parabolic, etc.
Attenuate the signal by reducing transmitter power if possible
Ground interior walls (If metal construction)
Thermally Insulate exterior glass using metallic window treatments
Smart positioning of AP’s
Lining closets housing the AP with aluminum foil
Use of metallic paints – Extreme

Countermeasures - SSID
Turn off SSID broadcasting at the AP if possible (Not all AP vendors allow this)
Understand that SSID’s provide “Zero” security
Avoid using a SSID that gives away information about your network. (“TaxNet1” or “Kennedy:Mailroom”)

Countermeasures - MAC ACL
Do not depend on MAC layer filtering as your only security solution for providing secure AP access
Use Intrusion Detection Servers (IDS) to alert you when an excessive number of unsolicited ARP replies are detected on the network
Use the tool “arpwatch” - This tool will provide E-mail notification when IP to MAC bindings change.

Countermeasures - WEP
Proprietary solutions offered by certain vendors are all incorporating dynamic key management into their products. (Cisco, Enterasys, AVAYA, etc.) Be careful not to commit yourself to a single vendor specific solution.
Use IPSec VPN software
EAP/802.1X Extensible Authentication Protocol (EAP) to provide centralized authentication – (RADIUS, etc.) and dynamic key distribution

Countermeasures - User Access Control
Use multiple AP’s to access different segments of the network each with a unique SSID’s.
Use a third party VPN solution to connect the users to the appropriate network segment.
This solution can be used through a single AP for all users. Each user would be routed internally to the appropriate VPN endpoint within the corporate network.

Countermeasures - Access Point (AP)
Update your corporate policy to prohibit the installation an AP without the approval of internal security or the IT department
Always place AP’s outside a firewall, inside a DMZ, or within a sandbox network.
Disable unused ports on the internal switches until needed (especially in conference rooms)
Monitor any new MAC address’s on the internal network that are discovered – “ArpWatch”

Countermeasures - DOS
Shield the perimeter of your building
This will help in two ways:
Help contain your wireless signal within a defined perimeter
Reduce the risk of outside RF interference

Wireless can be Secure
Apply all security features of products
Require Authentication and Authorization and Encryption
Use the same well known network security solutions as wired networks including:
Network segmentation
Use of personal firewalls
Well defined, trainable, and enforceable security policy
Perform Wireless Security Monitoring

Putting it all together Wireless Laptop Computer VPN Gateway Authentication Server Internal LAN With personal Firewall & VPN Software WEP MAC Filtering Unique SSID (If Broadcasting is not disabled) IP Protocol 50,51 UDP port 500 Wireless Access Point Firewall IDS WIDS WIDS

Questions?

http://ahmadrais.blogspot.com	13
http://www.slideshare.net	12
http://www.linkedin.com	5
http://www.brijj.com	3
http://static.slideshare.net	1
http://blackboard.hallmarkcollege.edu	1

Wireless LAN Deployment Best Practices

by Michael Boman

Accessibility

Categories

Upload Details

Usage Rights

6 Embeds 35

Statistics

Wireless LAN Deployment Best Practices Presentation Transcript
