<Insert Picture Here>MySQL Performance Schema(OSI, 14th Oct, 2012)Mayank PrasadSr. Software Engineer, MySQL-Oracle
Safe Harbor Statement     The following is intended to outline our general product direction. It is     intended for infor...
Agenda                What is Performance Schema                Origin and Development                Design          ...
Why Performance Schema ??                End user: why is my session stuck ?                MySQL developer: why is this...
What is Performance Schema      Performance Schema is a mechanism to give user a consolidated view      in a tabular forma...
Origin and Development      Development was started by Marc Alff and Peter Gulutzan in 2008.      First introduced in MySQ...
Design         A new storage Engine : Performance Schema.         A new database : Performance Schema (with hard-coded DDL...
Design : Instrumentation8Copyright © 2012, Oracle and/or its affiliates. All rights reserved.
Design : Instrumentation contd.       Instrumentation for :                    I/O operations (File I/O, Table I/O, NET I...
Design : Event Waits Instrumentation       Monitored wait events.       Tables & Summary tables.       Instruments naming ...
Design : Event Wait Instrumentation contd.11Copyright © 2012, Oracle and/or its affiliates. All rights reserved.
Design : Event Stage Instrumentation       Instrumented stage events.       Tables and Summary Tables.       Instruments n...
Design : Event Stage Instrumentation contd.13Copyright © 2012, Oracle and/or its affiliates. All rights reserved.
Design : Event Statements Instrumentation       Instrumented statement events.       Tables and Summary Tables.       Inst...
Design : Event Statements Instrumentation                                       contd.15Copyright © 2012, Oracle and/or it...
Nested Events                                                          Statement                                          ...
Nested Events contd.17Copyright © 2012, Oracle and/or its affiliates. All rights reserved.
Design : Timings       Available timers.       Timers setup in Performance       Schema.       Configurable option for any...
Configuration        Compile time:              -DWITH_PERFSCHEMA_STORAGE_ENGINE=1        Server start-up: (enabled in 5.6...
Server Variables         Variables values at the run         time.20Copyright © 2012, Oracle and/or its affiliates. All ri...
Status Variables       Status information of       Performance Schema at run       time.       Used to inspect lost       ...
Tables in Performance Schema        Total 52 tables (only 17 in 5.5)        Main category:        l              setup_tab...
Tables in Performance Schema contd.       setup_consumers23Copyright © 2012, Oracle and/or its affiliates. All rights rese...
Tables in Performance Schema contd.       setup_instruments24Copyright © 2012, Oracle and/or its affiliates. All rights re...
Tables in Performance Schema contd.       events_statements_summary_global_by_event_name25Copyright © 2012, Oracle and/or ...
Example to use PS to diagnose an issue        In a multi threaded scenario, thread_1 is stuck.        l              Find ...
Benefits of Performance Schema       l              Great insight of a running MySQL server.       l              Good gra...
Drawbacks of Performance Schema       Only drawback is impact on performance.       Depends on PS configuration. All enabl...
Whats new in MySQL-5.6       Instrumenting Table I/O.       Instrumenting Table Lock.       Instrumenting NET I/O.       I...
Reference       MySQL documentation:       http://dev.mysql.com/doc/refman/5.6/en/performance-schema.html       PS overhea...
<Insert Picture Here>Thanks for attending!
MySQL at Glance      OSI, October 12-14, Bangalore        Sessions are happening at        10/12 Workshop                 ...
