Ajax Applications with JSF2 and New RichFaces 4 at JAX 2011

  1. 1. Ajax Applications with JSF 2 and New RichFaces 4 Max Katz, Exadel May 5, 2011
  2. 2. ExadelMax Katz● Senior Systems Engineer at Exadel● JSF,RichFaces, Java EE consulting, and training● Manages exadel.org – Exadels open source projects and community● Community manager for gotiggr.com – tool for creating and sharing interactive web and mobile HTML prototypes
  3. 3. Exadel 4 Summer 2011 Author of Lead-author ofPractical RichFaces Practical RichFaces, 2/e (Apress) (Apress, June 2011)
  4. 4. Exadel PublishedApril 11, 2011
  5. 5. ExadelExadel is a global softwareengineering company.● Founded in 1998, headquarters in San Francisco Bay Area● 7 development offices in Europe● 350+ employees
  6. 6. Exadel Exadel Offices Ekaterinburg Moscow Minsk Homyel 5 KharkovMunich Donetsk
  7. 7. ExadelOpen Source with JBoss
  8. 8. ExadelExadel Products● exadel.org ◦ Flamingo ◦ Fiji ◦ jsf4birt ◦ JavaFX Plug-in for Eclipse● gotiggr.com– build and share HTML prototypes
  9. 9. ExadelExadel Services● Professional services● Rich enterprise application development● Eclipse development● Custom rich component development● Mobile development● Training
  10. 10. ExadelThe Plan Is Simple1) Ajax features in JSF 22) The new RichFaces 4
  11. 11. ExadelJavaServer Faces™ (JSF) is the standard component- based user interface (UI) framework for the Java EE (5 & 6) platform JSF 1.2 Java EE 5 JSF 2 Java EE 6
  12. 12. ExadelJSF 2● JSF 2 is a major upgrade over JSF 1.x● Many features, ideas taken from projects such as Seam, and RichFaces, and others
  13. 13. ExadelJSF 2 new features● Facelets ● New scopes● Composite ◦ Flash, View, components custom● Implicit ● Configuration navigation via annotations● GET ● Bean Validation support support ◦ h:link, h:button ● Basic Ajax● Resource loading
  14. 14. ExadelJSF 2 <f:ajax>● Very basic Ajax functionality● Greatly inspired by RichFaces 3 <a4j:support> tag● Ajax in JSF in 3 easy steps: 1. Sending an Ajax request 2.Partial view processing 3.Partial view rendering
  15. 15. Exadel<h:form> <h:input value="#{bean.word}"/> <h:commandButton> <f:ajax event="click" 1 execute="@form" 2 listener="#{bean.ajaxListener}" render="out1 out2"/> 3 </h:commandButton> <h:input value="#{bean.text}" id="out1"/> <h:input value="#{bean.phrase}" id="out2"/></h:form>
  16. 16. Exadel<h:form> <h:input value="#{bean.word}"/> <h:selectOneMenu value="#{bean.selected}"> <f:selectItems value="#{bean.items}"/> <f:ajax event="change" 1 execute="@form" 2 listener="#{bean.ajaxListener}" render="@form"/> 3 </h:commandButton> <h:input value="#{bean.text}" id="out1"/> <h:input value="#{bean.phrase}" id="out2"/></h:form>
  17. 17. Exadel Attribute ValueImportant Event on which to fire the<f:ajax> event Ajax requestattributes @all @this (default) @form execute @none ids EL @all @this @form render @none (default) ids EL
  18. 18. Exadel Thats good, but where doyou get rich components and more?A rich component framework is still(?) needed to build real-world Ajax applications.
  19. 19. ExadelRichFaces 4 is a lightweight,open source framework for JSF 2
  20. 20. ExadelRichFaces 4 – rich JSF framework ● UI components ◦ a4j:* tag library (core) ◦ rich:* tag library (UI) ◦ Components JavaScript API ● Skins ● Client-side validation (Bean Validation based) ● CDK – Component Development Kit
  21. 21. ExadelRichFaces 4 100% built on top of JSF2, just extends functionality in JSF 2
  22. 22. ExadelRichFaces 4 JavaScript is now entirelybased on the popular jQuery library
  23. 23. ExadelRichFaces 4● All components are reviewed for consistency, usability● Redesigned following semantic HTML principles● Server-side and client-side performance optimization● Strict code clean-up and review
  24. 24. ExadelRichFaces 4 Zero-configuration.Just drop RichFaces into the application.
  25. 25. ExadelRichFaces 4 New client-side validation based on Bean Validation (JSR 303)
  26. 26. ExadelRichFaces 4 New, and easy to use CDK (Component Development Kit), allows quickly to build yourown custom rich components
  27. 27. ExadelRichFaces 4Run on: Tomcat 6/7, Resin,JBoss AS 6/7, GlassFish 3.x, WebLogic(run on any server when JSF 2 application can be deployed)
  28. 28. ExadelRichFaces 4 Run on: Google App Engine (GAE), Amazon EC2, CloudBees
  29. 29. ExadelRichFaces 4 JSF implementations: Mojarra or Myfaces
  30. 30. ExadelRichFaces 4 Any browser
  31. 31. ExadelRichFaces 4 Tooling support through JBoss Tools, IntelliJ, NetBeans
  32. 32. Exadel RichFaces versions Version JSF 1.1 JSF 1.2 JSF 2RichFaces 3.1.x •RichFaces 3.3.3* • •RichFaces 4 •* Note: RichFaces 3.3.3 has basic JSF 2 support
  33. 33. ExadelRichFaces history2005: started by Alexander Smirnov2005-2007: Developed by Exadel Ajax4jsf - open source, free RichFaces - commercial2007: JBoss takes over Exadel team continues to develop the framework, project is known as RichFaces
  34. 34. ExadelRichFaces 4 Lets look at RichFaces features in more detail...
  35. 35. ExadelRichFaces 4 core – sending an Ajax request● a4j:ajax● a4j:commandButton● a4j:commandLink● a4j:jsFunction● a4j:poll● a4j:push
  36. 36. ExadelRichFaces 4Its important to say it again, RichFaces only extends and upgrades JSF 2...
  37. 37. Exadel RichFaces <a4j:ajax> ● 100% based on standard <f:ajax> ● Just replace f: with a4j: and get exactly the same functionality ● But, you get extra features...<h:commandButton> <f:ajax execute="@form" render="output"/></h:commandButton><h:commandButton> <a4j:ajax execute="@form" render="output"/></h:commandButton>
  38. 38. Exadel <a4j:ajax> attributesFeature/Attribute Description JavaScript to execute before Ajaxonbegin request JavaScript to execute after responseonbeforedomupdate comes back but before DOM updateoncomplete JavaScript to execute after DOM update Allows to skip JSF phases whenbypassUpdates validatinglimitRender Turns off all auto-rendered panelsstatus Status to display during Ajax requestAjax queue Advanced RichFaces client queue
  39. 39. Exadel <a4j:commandButton/Link> – Ajax button/link/* standard button with f:ajax */<h:commandButton value="Save" action="#{bean.action}"> <f:ajax execute="@form" render="output"/></h:commandButton>/* RichFaces button */<a4j:commandButton value="Save" render="output" action="#{bean.action}" />
  40. 40. ExadelWhen using standard JSF button:<h:form> <h:inputText> <h:selectOneMenu> Need to set <h:commandButton> execute=”@form” <f:ajax execute="@form"/> (or execute=”id1 id2”) </h:commandButton><h:form>When using RichFaces button:<h:form> RichFaces default <h:inputText> <h:selectOneMenu> value for <a4j:commandButton/> button/link<h:form> execute=”@form”
  41. 41. Exadel <a4j:jsFunction> – send Ajax request from any JavaScript function, HTML event<table> ... <td onmouseover="update(yellow)"/> ...</table><h:form> <a4j:jsFunction name="update" action="#{bean.change}" render="..."> <a4j:param value="param1" assignTo="#{bean.color}"/> </a4j:jsFunction></h:form>
  42. 42. Exadel <a4j:poll> – periodically send an Ajax request<a4j:poll interval="1000" action="#{bean.count}" render="output" enabled="#{bean.pollEnabled}" /><h:panelGrid id="output">...</h:panelGrid>
  43. 43. Exadel <a4j:push> ● Server-side events are pushed to client using Comet or WebSockets. ● Implemented using Atmosphere ● Providesexcellent integration with EE containers, and advanced messaging services<a4j:push address="topic@chat" ondataavailable="alert(event.rf.data)" />
  44. 44. ExadelRichFace 4 core – advancedrendering features● <a4j:outputPanel>● limitRender attribute● render=”{bean.renderList}”
  45. 45. Exadel <a4j:outputPanel> – auto rendered panel<h:selectOneMenu value="#{bean.fruit}"> <a4j:ajax listener="#{bean.change}"/></<h:selectOneMenu><a4j:outputPanel ajaxRendered="true"> <h:panelGrid> ... </h:panelGrid> Rendered on every</a4j:outputPanel> Ajax request
  46. 46. Exadel Advanced rendering options: limitRender<a4j:commandButton render="output"/><a4j:commandButton render="output" limitRender="true"/><h:panelGrid id="output"> Turns off all auto rendered panels,... only renders what is set in current</h:panelGrid> render<a4j:outputPanel ajaxRendered="true">...</a4j:outputPanel>
  47. 47. Exadel render=”#{bean.renderList}”JSF RichFaces1) Ajax request sent 1) Ajax request sent2) Component ids to be 2) Component ids to rendered resolved be rendered3) Component ids are resolved rendered into the page 3) Component ids4) 2nd Ajax request is sent. are rendered In this request the components (resolved in step 2 are sent with request) will be rendered
  48. 48. ExadelRichFace 4 core – advancedexecute features● <a4j:region>● bypassUpdates attribute
  49. 49. Exadel<a4j:region> – declarativelydefine execute region<h:form> Execute <a4j:region> options: <h:inputText /> ● @all <h:inputText /> ● @this <a4j:commandButton execute="@region"/> ● @form <a4j:region></h:form> ● @none ● ids<h:form> ● EL <a4j:region> ● @region <h:inputText /> <h:inputText /> <a4j:commandButton /> <a4j:region></h:form>
  50. 50. ExadelSkippingphaseswhenvalidating1.Restore View2.Apply Request Values3.Process Validation4.Update Model5.Invoke Application6.Render Response <h:inputText id="name" value="#{bean.name}"/> <a4j:ajax event="blur" bypassUpdates="true"/> </h:inputText> <rich:message for="name"/>
  51. 51. Exadel JavaScript interactions<h:commandLink value="Link" <f:ajax onevent="ajaxEvent();"></h:commandLink> Called three times: 1) begin 2) success 3) complete<a4j:commandLink value="Link" onbegin="ajaxOnBegin()" onbeforedomupdate="ajaxOnBeforeDomUpdate()" oncomplete="ajaxOnComplete()"></a4j:commandLink> Events are separated for easier development
  52. 52. ExadelJSF 2 queue● JSF2 has very basic queue functionality● Events are queued and fired one at a time● Only one request is processed on the server at a time
  53. 53. ExadelRichFaces queue upgrades● Combine requests from one or more components● Delay firing Ajax request● Cancel DOM updates if “similar” request was fired● Define queue as: ◦ Global (all views have queue) ◦ View-based ◦ Form-based ◦ Named (used by particular components only)
  54. 54. Exadel <a4j:queue> – “combining” events from the same component<a4j:queue requestDelay="2000"/>…<a4j:commandButton value="Button A1"/><a4j:commandButton value="Button AB"/>Events (clicks) from the same componentare “combined” which results in just one requestfrom a component being sent. Prevents sending multiplerequest from the same component.
  55. 55. Exadel <a4j:queue> – “combining” events from different components<a4j:queue requestDelay="2000"/>...<a4j:commandButton> <a4j:attachQueue requestGroupingId="ajaxGroup"/></a4j:commmandButton><a4j:commandButton> <a4j:attachQueue requestGroupingId="ajaxGroup"/></a4j:commmandButton>
  56. 56. Exadel <a4j:queue> delay<a4j:queue requestDelay="2000"/>... Delay request by 2 seconds<a4j:commandButton value="Button1"/><a4j:commandButton value="Button2"/><a4j:queue requestDelay="2000"/>... Overwrite default<a4j:commandButton> delay request by 1 second <a4j:attachQueue requestDelay="1000"/></a4j:commmandButton><a4j:commandButton />Delay is a “wait” to combine similar events (events from thesame components) together.
  57. 57. Exadel <a4j:queue> – ignoring “stale” responses<a4j:queue requestDelay="2000 ingoreDupResponses="true"/><h:inputText value="#{bean.state}"> <a4j:ajax event="keyup" listener="#{bean.load}" render="states"/></h:inputText>
  58. 58. ExadelRichFace 4 core – moreadvanced features● <a4j:status>● <a4j:param>● <a4j:log>● JavaScript interactions
  59. 59. Exadel <a4j:status> – Ajax request status<a4j:status name="ajaxStatus"> <f:facet name="start"> <h:graphicImage value="ajaxStatus.jpg"/> </f:facet></a4j:status><h:form> <a4j:commandButton status="ajaxStatus"/></h:form>
  60. 60. Exadel <a4j:param> ● Similar to <f:param> but simpler as it also assigns the value to a bean property automatically<a4j:commandButton value="Save"> <a4j:param name="#{bean.product}" value="1009"/></a4j:commandButton>@ManagedBeanpublic class Bean { private String product; // getter and setter}
  61. 61. Exadel<a4j:log> – Ajax requestinformation● Levels: ◦ debug, info, warn, error
  62. 62. ExadelRichFaces UI components● Output, panels● Input● Menu● Data iteration● Tree● Drag and drop● Client side validation● Miscellaneous
  63. 63. Exadelrich:tabrich:accordionrich:progressBar
  64. 64. ExadelMore rich output, panels● rich:panel● rich:togglePanel● rich:popupPanel● rich:collapsiblePanel● rich:toolTip
  65. 65. Exadelrich:calendarrich:inplaceInputrich:inputNumberSliderrich:autocomplete
  66. 66. ExadelMore rich input● rich:inputNumberSpinner● rich:inplaceSelect● rich:select● rich:fileUpload
  67. 67. Exadelrich:panelMenurich:toolBarrich:dropDownMenu
  68. 68. Exadelrich:dataTablerich:dataTable withrich:collapsibleSubTablerich:dataScroller
  69. 69. Exadel Partial table update render="@column" render="@header"render="@row" render="@body" render="@footer" render="cellId" To render from outside the table: render="tableId@header" render="tableId@body" render="tableId@footer"
  70. 70. Exadel Partial table updaterender="tableId:rows(bean.rowsSet)"render="tableId:rows(bean.rowsSet):cellId"
  71. 71. ExadelMore rich data iteration● a4j:repeat● rich:extendedDataTable● rich:collapsibleSubTable● rich:list ◦ list | ordered | definition● rich:dataGrid● rich:column ◦ Column and row spanning ◦ Filtering, sorting
  72. 72. Exadelrich:tree
  73. 73. ExadelDrag and drop
  74. 74. ExadelClient-side validation based on Bean Validation (JSR 303) New in RichFaces 4
  75. 75. Exadel Bean Validation (JSR 303) ● JSF 2 has support for Bean Validation (server-side)public class Bean { @Pattern(regexp="...") private String email;}<h:inputText id="email" value="#{bean.email}"> <a4j:ajax event="blur"/></h:inputText><rich:message for="email"/>
  76. 76. Exadel RichFaces client validation <rich:validator>public class Bean { @Pattern(regexp="...") private String email;}<h:inputText id="email" value="#{bean.email}"> <rich:validator/></h:inputText><rich:message for="email"/>
  77. 77. Exadel RichFaces <rich:graphValidator><rich:graphValidator value="#{bean}" id="gv"> ... <h:inputText value="#{bean.password1}"/> <h:inputText value="#{bean.password2}"/> <rich:message for="email" for="gv"/></rich:graphValidator>@Size(min=5,max=15,message="...")private String password1;@Size(min=5,max=15,message="...")private String password2;@AssertTrue(message="Passwords dont match")public boolean isPasswordsEquals() { return password1.equals(password1);}
  78. 78. Exadel RichFaces client functions Function Descriptionrich:client(id) Returns component client idrich:element(id) Returns DOM element Returns RichFaces client componentrich:component(id) instance to call JS API methodrich:isUserInRole(role) Returns if the user has specified role Returns component instance for givenrich:findComponent(id) short id
  79. 79. ExadelMany RichFaces componentsprovide client-side JavaScript API<rich:popupPanel> JavaScript APIMethod name Description Return the top co-ordinate for the position ofgetTop() the pop-up panel. Return the left co-ordinate for the position ofgetLeft() the pop-up panel. Move the pop-up panel to the co-ordinatesmoveTo(top,left) specified with the top and left parameters. Resize the pop-up panel to the size specifiedresize(width,height) with the width and height parameters.show() Show the pop-up panel.hide() Hide the pop-up panel.
  80. 80. Exadel Using <rich:component(id)><input type="button" onclick="#{rich:component(popup)}.show();" value="Open" /><rich:popupPanel id="popup"> <h:outputLink value="#" onclick="#{rich:component(popup)}.hide(); return false;"> <h:outputText value="Close"/> </h:outputLink></rich:popupPanel>
  81. 81. ExadelRich miscellaneous● <rich:componentControl>● <rich:hashParam>● <rich:jQuery>
  82. 82. Exadel <rich:componentControl> ● Allows to call JS API on a component in declarative fashion<h:outputLink id="openLink" value="#"> <h:outputText value="Open" /> <rich:componentControl event="click" operation="show" target="popup" /></h:outputLink><rich:popupPanel id="popup">...</rich:popupPanel>
  83. 83. Exadel <rich:hashParam> ● Group client side parameters into a hash map to be passed to component client API<h:commandButton value="Show popup"> <rich:componentControl target="pp" operation="show"> <rich:hashParam> <f:param name="width" value="500" /> <f:param name="height" value="300" /> <f:param name="minWidth" value="300" /> <f:param name="minHeight" value="150" /> </rich:hashParam> </rich:componentControl></h:commandButton
  84. 84. Exadel <rich:jQuery><input type="button" id="changeButton" value="Change title" /><rich:jQuery selector="#changeButton" query="click(function(){ $(#panel #panel_header).text(Capital of Russia);})"/><rich:panel header="Moscow" id="panel"> Moscow is the capital, the most populous ...</rich:panel>
  85. 85. ExadelSkins
  86. 86. ExadelSkins● Lightweight extension on top of CSS● Change look and feel of all rich component with a few minor changes● Can be applied to standard JSF and HTML tags as well
  87. 87. ExadelReady-to-use skins● classic <context-param> <param-name>org.richfaces.skin</param-name>● wine <param-value>ruby</param-value> </context-param>● blueSky● ruby● emeraldTown● deepMarine● plain● japanCherry
  88. 88. Exadel Skin file (just a property file)#ColorsheaderBackgroundColor=#900000headerGradientColor=#DF5858headerTextColor=#FFFFFFheaderWeightFont=boldgeneralBackgroundColor=#f1f1f1generalTextColor=#000000generalSizeFont=11pxgeneralFamilyFont=Arial, Verdana, sans-serifcontrolTextColor=#000000controlBackgroundColor=#ffffffadditionalBackgroundColor=#F9E4E4
  89. 89. ExadelSkins● Modify existing or create your own <context-param> <param-name>org.richfaces.skin</param-name> <param-value>myCoolSkin</param-value> </context-param>● Change skins in runtime <context-param> <param-name>org.richfaces.skin</param-name> <param-value>#{bean.skin}</param-value> </context-param>
  90. 90. Exadel Overwriting skins<style> 1 .rf-p-hr { // your custom style, applied to all panels on // on page } .panelHeader { 2 // custom header style }</style><rich:panel id="panel1">...</rich:panel id="panel2"><rich:panel headerClass="panelHeader">...</rich:panel>
  91. 91. Exadel Skinning standard JSF tags and HTML tagsApply to each control:<h:button style="background-color: #{richSkin.tableBackgroundColor}"/>Apply to all standard controls (JSF and HTML):<context-param> <param-name> org.richfaces.enableControlSkinning </param-name> <param-value>true</param-value></context-param>
  92. 92. Exadel Skinning standard JSF tags and HTML tags<context-param> <param-name> org.richfaces.enableControlSkinningClasses </param-name> <param-value>true</param-value></context-param><div class="rfs-ctn"> <h:panelGrid columns="1"> Can be applied to <h:outputText /> <h:panelGrid>, <rich:panel>, <div> <h:inputText /> Any standard controls inside the <h:commandButton /> container will be skinned using </h:panelGrid> standard controls skinning classes.</div>
  93. 93. Exadel Where can I try the new RichFaces 4?http://richfaces.org/showcase
  94. 94. Exadel How can we help with RichFaces● Web development with RichFaces Training Days● Version 3 to 4 migration JSF 1.2, 2 1-2● Performance tune-up RichFaces 3, 4 1-2 JSF and RichFaces 2-3● Custom component RichFaces 3 to 4 1-2 development● On-site training
  95. 95. ExadelRichFacesRich, flexible, robust, andproven enterprise-levelextension to JSF 2
  96. 96. ExadelThats it for RichFaces, there is one more thing I want to show you.
  97. 97. Exadelhttp://gotiggr.com
  98. 98. Exadel Tiggr Mobile Demo* http://gotiggr.com*Preview version
  99. 99. ExadelTiggr Prototypes Tiggr Mobile● Build and share ● First of a kind, Web- interactive HTML based IDE for building prototypes and deploying hybrid● Highly-interactive, mobile apps define events/actions ● Connect and invoke● View, remote services test in any browser, get feedback
  100. 100. Exadel max@exadel.comThank @maxkatz you! mkblog.exadel.com gotiggr.com

×
