Let’s Get Cooking with ChefSpeaker:Matt Ray Senior Technical Evangelist  ‣ matt@opscode.com  ‣ @mattray                   ...
AgendaChef 101Getting StartedCooking with Chef           Copyright © 2011 Opscode, Inc - All Rights Reserved   2
Developer, SysAdmin, Hacker,Community ManagerMany biz & dev environmentsOpscode: Training, Services &Evangelism           ...
Developers?Systems Administrators?                                                                 http://www.flickr.com/ph...
The Opscode Platform  is our Chef Server    http://www.opscode.com          Copyright © 2011 Opscode, Inc - All Rights Res...
Copyright © 2011 Opscode, Inc - All Rights Reserved                            6http://www.brooklynstreetart.com/theBlog/w...
Copyright © 2011 Opscode, Inc - All Rights Reserved   7
Chef enables infrastructure as code  Manage configuration as idempotent Resources.  Put them together in Recipes.  Track it...
At a High Level...‣ A library for configuration management‣ A configuration management system‣ A systems integration platfor...
Fully automated Infrastructure    Copyright © 2011 Opscode, Inc - All Rights Reserved   10
PrinciplesIdempotentData-drivenSane defaultsHackabilityTMTOWTDI             Copyright © 2011 Opscode, Inc - All Rights Res...
Multiple applications of an operation do not  change the result         Copyright © 2011 Opscode, Inc - All Rights Reserve...
We start with APIs, you     supply data        Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/...
option :json_attribs,    :short => "-j JSON_ATTRIBS",    :long => "--json-attributes JSON_ATTRIBS",    :description => "Lo...
Open source and  community     Copyright © 2011 Opscode, Inc - All Rights Reserved   15
Copyright © 2011 Opscode, Inc - All Rights Reserved   16
Tim Toady is a Perl      motto      Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos/lida...
The world moves pretty fastPrimitivesEnable YOUKnow your systems                http://www.flickr.com/photos/gi/518613153/s...
You better be ready!Sysadmins are programmersYou need a 3GL                http://www.flickr.com/photos/gi/518613153/sizes/...
Do I need to know Ruby?A littleSimple syntaxComplex as you scale              Copyright © 2011 Opscode, Inc - All Rights R...
A Tour of Chef    Copyright © 2011 Opscode, Inc - All Rights Reserved   21
Chef Client runs on your        systems         Copyright © 2011 Opscode, Inc - All Rights Reserved   22
Chef Client runs on your        systems                         ohai!         Copyright © 2011 Opscode, Inc - All Rights R...
Clients talk to a Chef       Server        Copyright © 2011 Opscode, Inc - All Rights Reserved   24
Opscode Platformthe central, highly scalable, multi-tenant configuration service from Opscode...         a hosted Chef Serv...
Clients authenticate   with RSA keys       Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/phot...
Chef Server                    Chef Server                                         API                                    ...
RESTful API w/ JSON    responses       Copyright © 2011 Opscode, Inc - All Rights Reserved   28
Chef can also stand alone - Chef Solo      Copyright © 2011 Opscode, Inc - All Rights Reserved   29
We call each system you   configure a Node        Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.co...
Nodes have Attributes                                          Kernel info!{  "kernel": {    "machine": "x86_64",    "name...
Attributes are         Searchable$ knife search node ‘platform:mac_os_x’  search(:node, ‘platform:mac_os_x’)              ...
Nodes have a Run ListWhat Roles or Recipes to apply          in Order           Copyright © 2011 Opscode, Inc - All Rights...
Nodes have a Run List% knife node show web01-prod.example.com -r{  "run_list": [    "role[production]",    "role[webserver...
Nodes have Roles     Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos/laenulfean/37439804...
RolesDescribe the node  ‣   webserver  ‣   dbserver  ‣   monitoring  ‣   ... etc                   Copyright © 2011 Opscod...
Roles have a Run ListWhat Roles or Recipes to apply          in Order           Copyright © 2011 Opscode, Inc - All Rights...
name "webserver"description "Systems that serve HTTP traffic"run_list(  "role[base]",                                     ...
% knife role show webserver{  "name": "webserver",  "default_attributes": {    "apache": {                                ...
Roles are Searchable$ knife search role ‘max_children:50’  search(:role, ‘max_children:50’)              Copyright © 2011 ...
Chef managesResources on Nodes      Copyright © 2011 Opscode, Inc - All Rights Reserved   41
Resources...   Declare a description of the state a part of the node should be in‣ Have a type                 package "ap...
Resources take action  through Providers       Copyright © 2011 Opscode, Inc - All Rights Reserved   43
Providers...    Know how to actually perform the actions specified by a resource.                                         A...
ResourcesPlatformProvider http://www.flickr.com/photos/acurbelo/2628837104/sizes/o/
Chef::Platform:ubuntu    => {   :default => {     :package => Chef::Provider::Package::Apt,     :service => Chef::Provider...
Recipes are lists of   Resources      http://www.flickr.com/photos/roadsidepictures/2478953342/sizes/o/           Copyright...
Recipes...              Apply resources in the order they are specified                                      package "apach...
Order Matters    Copyright © 2011 Opscode, Inc - All Rights Reserved   49
Recipes are just Ruby!    extra_packages = case node[:platform]      when "ubuntu","debian"        %w{          ruby1.8   ...
Cookbooks arepackages for Recipes       Copyright © 2011 Opscode, Inc - All Rights Reserved   51
CookbooksDistributableInfrastructure as CodeVersion control repository             Copyright © 2011 Opscode, Inc - All Rig...
Common Cookbook ComponentsRecipesAssets (files/templates)AttributesMetadata            Copyright © 2011 Opscode, Inc - All ...
Cookbook assetsFiles  ‣ Static assets  ‣ Downloaded via cookbook_file  ‣ File specificityTemplates  ‣ Dynamic assets  ‣ ERB ...
CookbooksAttributes ‣ Node attributes ‣ default, normal, override    default[:apache][:listen_ports] = [ "80","443" ]    d...
Cookbooks  Metadatacookbooks/django/metadata.rbmaintainer         "Opscode, Inc."maintainer_email   "cookbooks@opscode.com...
Cookbooks are  shareable! cookbooks.opscode.com      Copyright © 2011 Opscode, Inc - All Rights Reserved   57
Data bags store arbitrary data    Copyright © 2011 Opscode, Inc - All Rights Reserved   58
A user data bag item...% knife data bag show users mray{  "comment": "Matt Ray",  "groups": "sysadmin",  "ssh_keys": "ssh-...
Data Bags are        Searchable$ knife search users ‘shell:/bin/bash’     search(:users, ‘/bin/bash’)              Copyrig...
bash_users = search(:users, shell:/bin/bash)   bash_users.each do |u|     user u[id] do       uid u[id]       shell "/usr/...
Environments manageversioned infrastructure         Copyright © 2011 Opscode, Inc - All Rights Reserved   62
JSON or Ruby DSL and     Versionedname "dev"description "The development environment"cookbook_versions  "couchdb" => "11.0...
Command-line API  utility, Knife       http://www.flickr.com/photos/myklroventine/3474391066/     Copyright © 2011 Opscode,...
Nodes, Roles, DataBags are Searchable% knife search node “role:webserver” search(:users, “group:sysadmins”)             Co...
http://www.flickr.com/photos/38299630@N05/3635356091/   Copyright © 2011 Opscode, Inc - All Rights Reserved   66
Getting Started    Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos/rowens27/3163470179/ ...
Debian                                                                  Mac OS X                                 SuSE     ...
RubyCopyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos/thisisbossi/3526698689/   69
Today’s ExamplesOpscode PlatformMac OS X 10.6.6Ubuntu 10.04RubyGems             Copyright © 2011 Opscode, Inc - All Rights...
The Opscode Platform  is our Chef Server    http://www.opscode.com          Copyright © 2011 Opscode, Inc - All Rights Res...
RubyGems Installationcd /tmpwget http://production.cf.rubygems.org/rubygems/rubygems-1.3.7.tgz -O- | tar zxf -cd rubygems-...
apt.opscode.com     Copyright © 2011 Opscode, Inc - All Rights Reserved   73
ELFF Yum Repo    Copyright © 2011 Opscode, Inc - All Rights Reserved   74
Create Chef Repository% git clone git://github.com/opscode/chef-repo.git% cd chef-repo% ls -ladrwxr-xr-x 13 mray staff    ...
Copyright © 2011 Opscode, Inc - All Rights Reserved   76
Setup User Environment cp USERNAME.pem ~/chef-repo/.chef cp ORG-validator.pem ~/chef-repo/.chef cp knife.rb ~/chef-repo/.c...
Configure Knife% cat .chef/knife.rbcurrent_dir = File.dirname(__FILE__)log_level                :infolog_location          ...
Explore Knife’s sub-    commands       Copyright © 2011 Opscode, Inc - All Rights Reserved   79
Knife Sub-commandsknife NOUN verb NOUN (options) knife       client list knife       node show morbo.local knife       rol...
Configure Chef on           workstation% knife configure client /etc/chefINFO: Creating client configurationINFO: Writing c...
Chef::Configlog_level        :infolog_location     STDOUTchef_server_url https://api.opscode.com/organizations/osconvalidat...
Download getting-         started cookbook% knife cookbook site vendor getting-startedINFO: Downloading getting-started fr...
Copyright © 2011 Opscode, Inc - All Rights Reserved   84
git checkout -b chef-vendor-#{name_args[0]}         Copyright © 2011 Opscode, Inc - All Rights Reserved   85
Upload getting-started    to Chef Server% knife cookbook upload getting-startedINFO: Saving getting-startedINFO: Validatin...
Apply getting-started    Recipe to workstation% knife node run list add morbo.local "recipe[getting-started]"{  "run_list"...
Run chef-client!% sudo chef-client[Thu, 08 Jul 2010 21:35:49 -0600] INFO:                               Starting Chef Run[...
Inside the getting-started cookbook      Copyright © 2011 Opscode, Inc - All Rights Reserved   89
http://www.flickr.com/photos/38299630@N05/3635356091/   Copyright © 2011 Opscode, Inc - All Rights Reserved   90
Cooking with Chef      Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos/mr_t_in_dc/330563...
remote_file                                         linkcookbook_file                                                     ...
Resources haveparameters and actions        Copyright © 2011 Opscode, Inc - All Rights Reserved   93
Resource Parameters and ActionsMost resources have defaultsDefaults are sane  ‣ http://wiki.opscode.com/display/chef/Resou...
packages        package "apache2" do          action :install        endActions: install, upgrade, remove, purge          ...
Package shortcutsMap to providersgem_packagedpkg_packagerpm_packageAnd more!              Copyright © 2011 Opscode, Inc - ...
services         service "apache2" do           action [ :enable, :start ]         endActions: enable, disable, start, sto...
init script capabilities   service "apache2" do     supports(       :status => true,       :restart => true,       :reload...
filesfile "/etc/chef/client.rb" do  owner "root"  group "root"  mode 0644  action :createend  Actions: create, delete, touc...
file content!file "/tmp/example" do  content "This is a file!"endfile "/tmp/example2" do  content IO.read("/etc/hosts")end ...
remote_fileremote_file "/tmp/nginx-0.7.67.tar.gz" do  source "http://sysoev.ru/nginx/nginx-0.7.67.tar.gz"  action :create_i...
cookbook_filecookbook_file "/etc/perl/CPAN/Config.pm" do  source "Config-5.10.1.pm"  owner "root"  group "root"  mode 0644e...
templatetemplate "/etc/apache2/ports.conf" do  source "ports.conf.erb"  owner "root"  group "root"  mode 0644end          ...
local templatestemplate "/tmp/config.conf" do  local true  source "/tmp/config.conf.erb"end          Copyright © 2011 Opsc...
templates are ERB<% node[:apache][:listen_ports].each do |port| -%>Listen <%= port %>NameVirtualHost *:<%= port %><% end -...
Cookbook and Template    File Specificity        Copyright © 2011 Opscode, Inc - All Rights Reserved   106
preferences = [  File.join("host-#{fqdn}", "#{file_name}"),  File.join("#{platform}-#{version}", "#{file_name}"),  File.jo...
executeexecute "apt-get update" do  action :runend        Actions: run        Copyright © 2011 Opscode, Inc - All Rights R...
scriptbash "compile_nginx_source" do  cwd "/tmp"  code <<-EOH    tar zxf nginx-0.7.67.tar.gz    cd nginx-0.7.67 && ./confi...
ruby_blockruby_block "save the node" do  block do    node.save  endend        Action: create         Copyright © 2011 Opsc...
scm: git...git "/srv/apps/chef" do  repository "git://github.com/opscode/chef.git"  reference "0.9.6"  action :checkoutend...
...and subversionsubversion "/srv/couchdb" do  repository "http://svn.apache.org/repos/asf/couchdb/trunk"  revision "HEAD"...
deployhttp://wiki.opscode.com/display/chef/Deploy+Resource     Actions: deploy, force_deploy, rollback                    ...
deploy "/srv/radiant" do  repo "git://github.com/radiant/radiant.git"  revision "HEAD"  user "railsdev"  migrate true  mig...
Meta-parameter  madness!    Copyright © 2011 Opscode, Inc - All Rights Reserved   115
action :nothing    Copyright © 2011 Opscode, Inc - All Rights Reserved   116
not_if & only_if     Copyright © 2011 Opscode, Inc - All Rights Reserved   117
execute "runit-hup-init" do  command "telinit q"  only_if "grep ^SV /etc/inittab"  action :nothingendexecute "rabbitmqctl ...
Resource notificationtemplate "nginx.conf" do  path "/etc/nginx/nginx.conf"  source "nginx.conf.erb"  owner "root"  group "...
supports Copyright © 2011 Opscode, Inc - All Rights Reserved   120
Anatomy of a Chef Run        Copyright © 2011 Opscode, Inc - All Rights Reserved   121
Anatomy of a Chef RunNode discoverySet the node nameRegister with server              Copyright © 2011 Opscode, Inc - All ...
Anatomy of a Chef RunBuild node object  ‣ node.saveSynchronize cookbooks  ‣ node.saveConverge  ‣ node.save                ...
Chef Run ConvergenceCompileExecute             Copyright © 2011 Opscode, Inc - All Rights Reserved   124
Development workflow      with Chef       Copyright © 2011 Opscode, Inc - All Rights Reserved   http://www.flickr.com/photos...
Development workflowGather requirementsWrite recipesCommit to repositoryRun Chef in testingRun Chef in production          ...
http://www.flickr.com/photos/38299630@N05/3635356091/   Copyright © 2011 Opscode, Inc - All Rights Reserved   127
Automating the Cloud     with Chef      http://www.flickr.com/photos/46183897@N00/3442880227/sizes/l/                     C...
Add your Cloud    credentials to knife.rb          vi ~/chef-repo/.chef/knife.rb# Cloud credentialsknife[:aws_access_key_i...
Download some              cookbooks% knife cookbook site vendor nagios -dINFO: Downloading nagios from the cookbooks site...
Upload Cookbooks!      knife cookbook upload -a            These run as root, kids.Let’s not blindly trust the upstream to...
Build some roles% vi roles/monitoring.rbname "monitoring"description "Nagios monitoring server"run_list(  "role[base]”,  “...
Upload Roles% knife role from file roles/monitoring.rbWARN: HTTP Request Returned 404 Not Found: Cannot load role         ...
Launch a new    Monitoring Serverknife ec2 server create ‘role[monitoring]’                Copyright © 2011 Opscode, Inc -...
Chef runs on your new         server              sudo chef-clientINFO: Starting Chef Run...INFO: Chef Run complete in 211...
Shef is Chef in IRB      Copyright © 2011 Opscode, Inc - All Rights Reserved   136
Resources/Questionswww.opscode.comIRC and Mailing lists  ‣ irc.freenode.net #chef  ‣ lists.opscode.comTwitter:  ‣ @opscode...
