Migrating MVC to the  Front-end using    Backbone JS         Martin Drapeau     CTO & Co-founder Planbox            Feb 20...
AGILE PROJECT MANAGEMENTBased onSCRUM              Martin Drapeau Feb 2012
AGILE PROJECT MANAGEMENTCloud SAAStrying to solvea bigproblem...               Martin Drapeau Feb 2012
Source: www.solutionsiq.comMartin Drapeau Feb 2012
DEMO TIME!   Martin Drapeau Feb 2012
AGILE PROJECT MANAGEMENT   Built on LAMP         Martin Drapeau Feb 2012
AGILE PROJECT MANAGEMENTWe usepopularframeworks                Martin Drapeau Feb 2012
AGILE PROJECT MANAGEMENTSingle PageApplicationVery dynamic                  Martin Drapeau Feb 2012
AGILE PROJECT MANAGEMENT                     Client     http://www.planbox.com/plan                                       ...
The Problem    Martin Drapeau Feb 2012
MVC in the Back-endHTML      • HTML generated in PHP   HTMLHTML      • AJAX to update page            fragments          •...
MVC in the Back-end        ABC    Change of A requires update of B and C.    Why does the back-end have to do that?       ...
MVC in the Back-end          does not scale for         Dynamic Web AppsWHY?• Where do I write that code? PHP or JS?• Can ...
The Solution    Martin Drapeau Feb 2012
Move MVC to Front-end Let’s write our code in Javascript!              Martin Drapeau Feb 2012
Ground RulesBack-end• Becomes a REST API. Talks JSON.Front-end• Handles UI interactions.• Replicates data models.• Replica...
Choose a FrameworkRequirements:• Lightweight - fast to load & mobile friendly• Extendible• jQuery Friendly• Open Source• C...
Contenders (back in Nov 2010)      • SproutCore             A widget framework, too big and constraining!      • Javascrip...
Backbone JS   Martin Drapeau Feb 2012
Backbone.js gives structure to web applicationsby providing models with key-value binding and  custom events, collections ...
Backbone’s Take on MVC• Data and presentation are decoupled:    – “stop tying your data to the DOM”• Models use the Pub/Su...
Model – attributes and eventsvar story = new Backbone.Model({    id:1,    name:"As a coder I want MVC in the front-end",  ...
Collection – model IDs and Underscore JSvar stories = new Backbone.Collection([{     id:1,     name:"As a coder I want MVC...
Collection – event bubblingstories.bind("add", function(collection, model) {    console.log("Story #"+model.id+" added to ...
Collection – ordered or unorderedstories.pluck(points); // Returns [21, 33, 5]stories.comparator = function(modelA, modelB...
Collection – fetch from server with AJAXstories.url = "/api/get_stories"; // REST API// Preprocess JSON before creating mo...
View – Render a modelUse of extend to create a new Class.StoryView = Backbone.View.extend({    className: "story",    rend...
View – HTML template (Underscore JS)<script type="text/template" id="story_template">    <label>#<%=id%></label>    <input...
View – User interactioninitialize: function() {    var view = this, model = view.model;    model.bind("change", view.rende...
Client/Server Sync Loop   1.   Push changes to server   2.   Receive acknowledgement   3.   Set attribute change on data m...
Event Payload – options argumentThe options argument can be used as an event payload.Use it not to render unnecessarily.sa...
View – Render a collectionStoriesView = Backbone.View.extend({    tagName: "ul",    className: "stories",    initialize: f...
Other Backbone Artefacts• Sync  – Handles client/server communication  – Uses jQuery (or Zepto) $.ajax  – Follows CRUD (Mo...
Backbone JS    got Planboxed   Martin Drapeau Feb 2012
No CRUD - Rich verbs mapping to API• A story model has:  –   save  www.planbox.com/api/update_story  –   move  www.planb...
Local Persistence in URL  • State of page is saved in URL’s hash tag using    JSON (quotes are stripped)                  ...
Model SelectionNikModel = Backbone.Model.extend({    selected: false,    select: function(options) {        options || (op...
Selection in CollectionNikCollection = Backbone.Collection.extend({    model: NikModel,    select: function(model, options...
Collection Filtering// Argument filters is a hash of attributes and their// allowed values. For example: filters.type = [b...
Sort DOM Against Collection     DOM                                            Collection                                 ...
Cascading Events – Model bound to Collection  • Summary Model listens to changes on Stories Collection  • Keeps sums of po...
Custom Widgets• All widgets are custom    –   Ligthweight and flexible    –   Fast to load    –   No jQuery UI with large ...
Backbone Auto-complete Widgetvar collection = new Backbone.Collection([    {id:"AB", name:"Alberta"},    {id:"BC", name:"B...
Real Time – No page reload• Polling server at 15 second interval  (Tried COMET but was overkill)• Change history Collectio...
DeploymentBuild procedure     – Javascript files are minified and collated     – Version is automatically incremented     ...
The Result   Martin Drapeau Feb 2012
3rd Party Libraries        Application Load Size                                          JS fileGzipped Size (KB) Content...
Benefits of MVC in front-end• Decouple back-end and front-end  – The API becomes the back-end contract (and    performance...
Benefits of MVC in front-end• Release anytime   – Majority of code changes are in UI   – Changes happen faster in front-en...
AcknowledgementsMathieu Dumais-Savard  Sébastien Giroux  Jeremy Ashkenas   js-montreal.org       Martin Drapeau Feb 2012
References & LinksJavascript Frameworks•   Backbone JS http://documentcloud.github.com/backbone/•   JavascriptMVC http://j...
Questions?   Martin Drapeau Feb 2012
Upcoming SlideShare
Loading in...5
×

Planbox Backbone MVC

7,434

Published on

Migrating MVC to the Front-end using Backbone JS.

Planbox is a single-page web application for Agile project management. It was built using the traditional MVC stack with CodeIgniter (PHP) and jQuery (Javascript). AJAX was heavily used to update DOM elements to offer a dynamic user experience. UX logic code quickly became spread across Javascript and PHP. The application code base quickly became unmanageable and scaling functionality became difficult. Things had to change.

A decision was made to change architecture: bring all the UX logic in the front-end, and turn the back-end into an engine in charge of business logic.

This talk is about this experience. How we moved the MVC stack from the back-end to the front-end. How we used Backbone JS as the foundation of our front-end framework and built on top. How the backend became a black-box with a Restful API. What lessons we learned, what benefits we gained, and what reflections we made about the future of MVC in Javascript.
