Designing well known websites with ADF Rich Faces

  1. 2. Extreme Faces Makeover – Inject ADF Faces Rich Client Components into Your Old Wrinkled Applications Maiko Rocha, George Maggessy Fusion Middleware Architecture Team Oracle OpenWorld 2009 Unconference Sessions, ADF Track * (*)TM & 2008 Warner Bros. Entertainment Inc. All Rights Reserved.
  2. 3. Agenda <ul><li>A little introduction to ADF Faces </li></ul><ul><li>Stretching & flowing </li></ul><ul><li>Building Blocks </li></ul><ul><li>Use cases </li></ul><ul><li>Q & A, more info </li></ul>
  3. 4. JSF Key Concepts <ul><li>UI Component </li></ul><ul><ul><li>JSF is component based </li></ul></ul><ul><li>Managed Beans & Backing Beans </li></ul><ul><ul><li>Encapsulates Application Logic, Data and Component Properties </li></ul></ul><ul><li>Expression Language </li></ul><ul><ul><li>Binding data to the UI </li></ul></ul><ul><li>Navigation Case </li></ul><ul><ul><li>The rules that govern page flow </li></ul></ul><ul><li>Lifecycle </li></ul><ul><ul><li>Cycle of creation, validation, data-binding and business service interactions of a page </li></ul></ul>
  4. 5. How Oracle Improves JSF <ul><li>ADF Faces Components </li></ul><ul><ul><li>More components </li></ul></ul><ul><ul><li>Better components </li></ul></ul><ul><li>Templating </li></ul><ul><li>ADF Task Flow </li></ul><ul><ul><li>Extended JSF controller </li></ul></ul><ul><li>Page fragments </li></ul><ul><li>Page regions </li></ul><ul><li>Reusable flows </li></ul><Insert Picture Here>
  5. 6. ADF Rich Faces Origins <ul><li>Support Fusion Applications UI requirements </li></ul>
  6. 7. Stretching and Flowing
  7. 8. ADF Faces likes to No browser vertical scrollbar!! <ul><li>Maximize usage of viewable area </li></ul><ul><ul><li>Use tabs, accordions, menus and popups to virtually expand your viewable area </li></ul></ul>stretch
  8. 9. Stretching & flowing <ul><li>Browsers are unreliable; not robust: </li></ul><ul><ul><li>Some things can stretch others must flow </li></ul></ul><ul><ul><li>% dimensions mean different things </li></ul></ul><ul><ul><li>Don’t be a slave to the browsers, avoid inlineStyle like the plague! </li></ul></ul><ul><li>Highly recommended that you build your layouts like this: </li></ul><ul><ul><li>Use a stretchable outer frame </li></ul></ul><ul><ul><li>Inside this frame, have flowing islands (e.g. scrollable areas) </li></ul></ul><ul><ul><li>Do not attempt to stretch something vertically in a flowing island! </li></ul></ul><ul><li>Need custom styling? </li></ul><ul><ul><li>Find a declarative approach (theme, hint, other attribute) </li></ul></ul><ul><ul><ul><li>e.g. make the page dark blue with af:document’s theme=&quot;dark&quot; </li></ul></ul></ul><ul><ul><li>Use the styleClass attribute ( global selectors ) </li></ul></ul><ul><ul><li>Organizations can use a custom skin (to change how a component looks or just to make custom global selectors) </li></ul></ul>http://www.oracle.com/technology/products/adf/patterns/layoutBestPractices.html
  9. 10. Stretching & flowing <ul><li>W3C CSS Box model makes it hard to combine margins, borders, and padding with width and height dimensions. </li></ul><ul><ul><li>Some browsers are experimenting with a proposed CSS3 “box-sizing” style to override how it works. </li></ul></ul><ul><li>Workarounds include nesting multiple components to achieve desired effect. </li></ul><ul><li>Problem is similar to an Internet Explorer 7 bogus horizontal scroll bar bug 6374088 </li></ul>
  10. 11. Building Blocks
  11. 12. Reusable content building blocks <ul><li>Page Templates </li></ul><ul><ul><li>Allow you to create entire page layouts using individual components. </li></ul></ul><ul><li>Declarative Components </li></ul><ul><ul><li>Allow you to assemble existing, individual UI components into one composite, reusable component. </li></ul></ul><ul><li>ADF Regions / Task Flows </li></ul><ul><ul><li>Encapsulate business logic, process flow, and UI components all in one package, which can then be reused throughout the application. </li></ul></ul><ul><li>All of them can be packaged as ADF Libraries. </li></ul>
  12. 13. Layout building blocks <ul><li>af:panelStretchLayout </li></ul><ul><ul><li>Stretched frame with top, start, center, end, bottom </li></ul></ul><ul><li>af:panelSplitter </li></ul><ul><ul><li>Stretched box divided into 2 user-modifiable sections </li></ul></ul><ul><li>af:panelDashboard </li></ul><ul><ul><li>Stretched tiled structure of boxes </li></ul></ul><ul><li>af:panelGroupLayout </li></ul><ul><ul><li>Series of components - default, horizontal, vertical, scroll structures </li></ul></ul><ul><li>af:panelBorderLayout </li></ul><ul><ul><li>Flowing frame with top, start, center, end, bottom, and more </li></ul></ul><ul><li>trh:tableLayout/trh:rowLayout/trh:cellFormat </li></ul><ul><ul><li>Flowing raw HTML table structure </li></ul></ul>
  13. 14. Layout building blocks
  14. 15. Headers <ul><li>af:panelBox </li></ul><ul><ul><li>Group box or side container </li></ul></ul><ul><li>af:panelHeader </li></ul><ul><ul><li>Fancy header structure (see facets) </li></ul></ul><ul><ul><li>Many levels (size attribute) </li></ul></ul><ul><li>af:showDetailHeader </li></ul><ul><ul><li>Just like af:panelHeader but collapsible </li></ul></ul><ul><li>af:showDetail </li></ul><ul><ul><li>Collapsible too but simpler structure </li></ul></ul><ul><li>af:panelAccordion </li></ul><ul><ul><li>Show one or many collapsible areas (af:showDetailItem) </li></ul></ul>
  15. 16. Headers
  16. 17. Tabs <ul><li>af:navigationPane (hint=&quot;tabs&quot;) </li></ul><ul><ul><li>Gives only a tab bar </li></ul></ul><ul><ul><li>Use af:commandNavigationItem for each tab </li></ul></ul><ul><ul><li>Use af:decorativeBox (with theme=&quot;…&quot;) to construct the body </li></ul></ul><ul><ul><li>Can use one page per tab selection or dynamically update what is shown in the browser (e.g. with af:switcher) </li></ul></ul><ul><li>af:panelTabbed </li></ul><ul><ul><li>Gives a tab bar and tab body </li></ul></ul><ul><ul><li>af:showDetailItem (also used in af:panelAccordion) </li></ul></ul>
  17. 18. Tabs
  18. 19. Organizing items <ul><li>Organizing labels & fields: </li></ul><ul><ul><li>af:panelFormLayout </li></ul></ul><ul><ul><li>Specify the # of columns and rows per column </li></ul></ul><ul><ul><li>Can configure labelWidth and fieldWidth </li></ul></ul><ul><ul><li>Typically contains af:input* and af:select* components </li></ul></ul><ul><ul><li>For other kinds of content, use af:panelLabelAndMessage if: </li></ul></ul><ul><ul><ul><li>There is no explicit label, or </li></ul></ul></ul><ul><ul><ul><li>Need multiple fields per label </li></ul></ul></ul><ul><ul><li>Use af:group if you need to separate sections </li></ul></ul><ul><li>Bulleted or ordered lists </li></ul><ul><ul><li>af:panelList </li></ul></ul>
  19. 20. Organizing items
  20. 21. Popups <ul><li>af:popup - wrapper for inline popping-up content </li></ul><ul><li>af:dialog - ask for something </li></ul><ul><li>af:panelWindow - show something </li></ul><ul><li>af:noteWindow - tooltip boxes </li></ul><ul><li>af:showPopupBehavior </li></ul><ul><ul><li>Declaratively show a popup </li></ul></ul><ul><li>JSF messaging framework </li></ul><ul><ul><li>Component or page-level alerts, e.g. validation </li></ul></ul><ul><li>External browser windows aka “dialog framework” </li></ul>
  21. 22. Popups
  22. 23. Menus & toolbars <ul><li>af:toolbox </li></ul><ul><ul><li>wrapper for menu bars and toolbars </li></ul></ul><ul><ul><li>af:group - use one per row </li></ul></ul><ul><li>af:toolbar </li></ul><ul><ul><li>af:commandToolbarButton </li></ul></ul><ul><ul><li>af:group - separators between groups of items </li></ul></ul><ul><li>af:menuBar </li></ul><ul><ul><li>af:menu - nest for submenus </li></ul></ul><ul><ul><ul><li>af:commandMenuItem </li></ul></ul></ul><ul><ul><ul><li>af:goMenuItem </li></ul></ul></ul><ul><ul><li>af:group - separators between groups of items </li></ul></ul>
  23. 24. Menus & toolbars
  24. 25. <Insert Picture Here> Exploring layout use cases
  25. 26. Use case: series of boxes Variation 1 of 6 - Flowing
  26. 27. Use case: series of boxes Variation 2 of 6 - Stretch the 1st box
  27. 28. Use case: series of boxes Variation 3 of 6 - Stretch the 2nd box
  28. 29. Use case: series of boxes Variation 4 of 6 - Stretch the 3rd box
  29. 30. Use case: series of boxes Variation 5 of 6 - Stretch all evenly
  30. 31. Use case: series of boxes Variation 6 of 6 - Stretch 1st 2 evenly
  31. 32. Deconstructing Facebook Outer shell: three row layout Inner shell: three column layout Custom Components Warning! Browser Scrollbar
  32. 33. Reconstructing Facebook - Components From Facebook… … to ADF Faces.
  33. 34. Reconstructing Facebook - Layout panelGroupLayout = vertical outer shell: template + panelStretchLayout inner shell: template + nested panelSplitters center area:panelGroupLayout = scroll
  34. 35. Deconstructing Yahoo! Mail Outer shell: two column layout Inner shell: two row layout Custom Components
  35. 36. Deconstructing Yahoo! Mail Attention! We are NOT making any money with those ads.
  36. 37. Reconstructing Y! Mail - Components From Yahoo! Mail… … to ADF Faces.
  37. 38. Reconstructing Y! Mail - Layout outer shell: template + panelStretchLayout top content navigation center top content: panelStretchLayout center top Home Task Flow: panelStretchLayout bottom Calendar Template Panel Dashboard Panel Group Layout: Vertical center Inbox Task Flow: panelStretchLayout bottom Calendar Template Panel Splitter: Horizontal (Ad on the right) Panel Splitter: Vertical (Emails)
  38. 39. <Insert Picture Here> <ul><li>Q & A </li></ul><ul><li>More info: </li></ul><ul><li>Rich Enterprise Applications Home Page: http:// rea .oracle.com/ </li></ul><ul><li>ADF Faces Online Demo (components, skins, layout): http:// jdevadf .oracle.com/ adf - richclient -demo/faces/index. jspx </li></ul><ul><li>ADF Faces Rich Client on OTN: http://www.oracle.com/technology/products/ adf / adffaces /index.html </li></ul><ul><li>ADF Functional Patterns and Best Practices: http://www.oracle.com/technology/products/ adf /patterns/index.html </li></ul><ul><li>Forum: http://forums.oracle.com/forums/forum. jspa ? forumID =83 </li></ul><ul><li>Gamertags: </li></ul><ul><ul><li>Maiko Rocha……...: toscomor (XBL,PSN) </li></ul></ul><ul><ul><li>George Magessy…: gmaggess (XBL,PSN) </li></ul></ul>

×
