From Tube to Chip Presentation by Mindy McAdams Thursday, Week 13
In 1895, French scientist Jean B. Perrin  discovered that “ cathode rays ” were negatively charged particles.  Between 189...
The Vacuum Tube <ul><li>John Ambrose  Fleming , an Englishman, was one of Thomas Edison’s assistants </li></ul><ul><li>Lat...
Vacuum Tube 1904 <ul><li>Fleming calls his diode a  thermionic valve  (it used  heat  to control the flow of electricity) ...
<ul><li>1906:  Lee De Forest’s Audion (the one above c. 1912) is also called a  triode   </li></ul>Diode Triode
The Computer Connection <ul><li>The ENIAC contained more than 18,000 triode vacuum tubes  </li></ul><ul><li>Programs had t...
The ENIAC computer, University of Pennsylvania, 1945
Size: over 100 feet long, filling a 30 ft. x 50 ft. room.  Height: 10 feet. Depth: about 3 feet. Weight:  about 30 tons.  ...
Television also used vacuum tubes <ul><li>1923:  Vladimir  Zworykin  (b. 1889) applies for a patent on his electronic tele...
You could build (and repair) your own TV set

Early Computers <ul><li>The ENIAC was funded by the U.S. government </li></ul><ul><li>Built at the University of Pennsylva...
Early Computers (2) <ul><li>Before, during and after ENIAC, others were also building big computers </li></ul><ul><ul><li>...
Whirlwind <ul><li>Developed at the Massachusetts Institute of Technology (MIT); team led by Jay Forrester </li></ul><ul><l...
Whirlwind used approximately 5,000 vacuum tubes. It took 3 years to build and first went online in 1951. Budget: $1 millio...
Open Access <ul><li>Enormous costs = public benefits </li></ul><ul><li>Because the U.S. government had funded much of the ...
Next Step: The Transistor <ul><li>Invented at Bell Labs in 1947 </li></ul><ul><li>Replaced the glass vacuum tube </li></ul...
[1954]
Edwin Howard Armstrong and the first portable radio, 1923
Transistor <ul><li>Functions as a switch (on / off) </li></ul><ul><li>Made of semiconductor material such as germanium or ...
Bell Labs <ul><li>Founded in 1925 (AT&T and Western Electric) </li></ul><ul><li>1947:  Invents the  transistor </li></ul><...
Integrated Circuits <ul><li>1958:  First integrated circuit (IC) invented by Jack Kilby at  Texas Instruments,  a manufact...
Integrated Circuits (2) <ul><li>The old way: One  separate  piece of germanium for each component (e.g., transistors, resi...
<ul><li>1961:  The U.S. Patent Office awards the first patent on an integrated circuit to Robert  Noyce , co-founder of  F...
And then came … <ul><li>1968:  Robert Noyce and two other top engineers resigned from Fairchild Semiconductor </li></ul><u...
The Microprocessor <ul><li>Busicom, a Japanese company, had  designed  12 chips for its next-generation programmable calcu...
Texas Instruments handheld calculator (c. 1975) Busicom handheld calculator (1972)
The Microprocessor (2) <ul><li>1969:  Busicom chose Hoff’s solution over its own 12-chip design </li></ul><ul><li>Intel gr...
The Microprocessor (3) <ul><li>Top:  Intel’s 4004 integrated CPU – “a microcomputer on a chip” (1971) </li></ul><ul><li>In...
<ul><li>Digital Equipment Corp. (DEC) challenged IBM’s dominance of the computer industry of with smaller “minicomputers” ...
1975:   The MITS Altair 8800 Based on the Intel 8080 CPU World’s first “personal” computer
Two guys in Boston sent a letter to the Altair's inventor, asking if he would be interested in selling their BASIC program...
<ul><li>Apple-1: Demonstrated in April 1976 at the Homebrew Computer Club in Palo Alto, Calif. </li></ul><ul><li>Went on s...
<ul><li>IBM was actually quite late to the market: 1981 </li></ul><ul><li>Price: $1,995 </li></ul>
From Tube to Chip Presentation by Mindy McAdams University of Florida
