Wind Power in Vermont?             Ben Luce, Ph.D    Email: ben.luce@lyndonstate.edu        Version: March 21, 2011
IntroductionThis presentation presents several argumentsto the effect that utility-scale wind powerdevelopment on mountain...
IntroductionThree basic arguments are presented:• The environmental and aesthetic impacts of ridge line  wind are very gre...
Introduction• Some common justifications for utility-scale  wind development in Vermont are:  – Mitigation of Climate Chan...
Introduction• All of these justifications have merit, but are indirect:  They do not address the question of whether wind ...
Introduction• Other common arguments or claims in support  of wind development in Vermont include:  – There are no viable ...
IntroductionThe drivers for wind development in Vermont today are:• Genuine public support for wind.• A short-term outlook...
IntroductionGenuine, major, technical problems with wind generationexist (in the presenter’s opinion):• Impacts on birds, ...
IntroductionThe “intermittency issue” (in the presenter’s opinion):• Claimed problems with “integrating” wind power on the...
Climate Change and US Energy Policy• The following graphs, and a great deal of other data,  make it abundantly clear that ...
Temperature and CO2 levels are tightly correlated,and human activity has dramatically boosted CO2 levels, essentially over...
Global Climate Models (GCMs) reproduce 20th   century warming accurately & appear to   confirm human (anthropogenic) role:...
Wind Generation Outlook• Wind power is a moderately mature  technology, and is expanding rapidly world  wide.• Many large-...
13
The Department of Energy has a plan for 300 gigawatts(equivalent to 120,000 2.5 megawatt turbines) by 2030.Pressure to bui...
Wind Resource Overview• Virtually all of the US commercially viable wind resource is offshore  and in the Midwest.• As the...
AvailableU.S. Wind Resources                                  Resources            Nearly all of the U.S. wind resources  ...
Relative Ranking of State Wind ResourcesSource: Dept. of Energy’s “Wind Powering America” program. These estimates include...
Comparing Vermont’s Wind Resourcewith a Typical Midwest State, or Offshore• It is instructive to compare Vermont’s wind re...
Wind Resource ComparisonIn gigawatts (Note: This data is also from NREL, but this time with no obvious land exclusions, so...
Iowa vs. Vermont                    (approximately to scale) Iowas worst areas for wind potential exceed the potential of...
Iowa       Iowa is mainly laid out in a grid,       right down to the cornfield level.       Siting wind here is relativel...
Add it All Up: How much wind power could be obtained     from onshore Eastern Wind Resources Overall?• Eastern US onshore ...
< 0.1% CO2                                 Reduction                                 Potential                            ...
Wind Resource Conclusions• Ridge line wind is simply not a major renewable energy  source in the Eastern US.• Offshore win...
Wind Resource Consequences• These resource considerations alone of course do not imply that the  more negligible sources, ...
Wind versus Solar• The solar energy resource in the Eastern US is hundreds of  times larger than the commercial wind resou...
Impacts of Ridge Line Wind DevelopmentSome proponents of ridge line wind development resortto the blanket statement that “...
On the same scale as the mountains themselves: (Size-accurate simulation from a proposed site in MA: Very apropos to Vermo...
(Size-accurate Simulation : Susie’s Peak in Clarendon, VT )
(Size Accurate Simulation: Poultney, VT)                                           31
Mars Hill, MaineThis photo shows how developers often portray their projects, if they portray ridge linewind projects at a...
Mars Hill, MaineThis aerial photo, taken during construction of the project, shows more accuratelythe nature of the disrup...
Mars Hill, MaineThis aerial photo, from Google Earth, shows the full extent of the disruption to themountaintop clearly. T...
Kibby Mountain, MaineNote the massive scale of the road beds here (those are full size trees along theroads, not bushes). ...
Kibby Mountain, Maine                        36
Searsburg, VTThis is Vermont’s only operating wind project, constructed through what was a pristinenational forest ridge l...
Tararua, New Zealand (clearing for a 3 MW Turbine)                                                     38
Summary of Impacts• Industrial scale roads and clearings down the  entirety of the ridges  – Extensive blasting and bulldo...
This photo shows what it means tosite wind in Iowa, at least in termsof land impacts. The land impactsare generally much l...
Side Note: On the Performance of Searsburg,and the Selling Off of its Renewable Credits•   The average “capacity factor” o...
Side Note: On the Performance of Searsburg,and the Selling Off of its Renewable Credits•   Selling of the RECs out-of-stat...
Powering Vermont with Wind Power?• It is true that providing much of Vermont’s power with  wind power is possible. This is...
What percentages are being proposed?• Proponents of wind development in Vermont  often state that they are only pursuing p...
What would be required to provide just20% of Vermont’s Power with Wind• Vermont consumes about 6000 gigawatt-hours per  ye...
What would be required to provide 100%of Vermont’s Power with Wind• 2500 MW of wind• This implies about 40 projects of the...
Visual Impact of Turbines• Are Turbines “magnificent” as some claim? How do people  really perceive these devices over the...
Vermont Brand Study• Commissioned by the Vermont State Department of  Tourism• This study thoroughly surveyed the attitude...
49     49
50     50
Top Three words:     “Unspoiled,      Beautiful,     Mountains”(note that “mountains” is first noun         in the ranked ...
Vermont Brand Study• Conclusion: The Vermont Brand Study clearly  suggests that people who vacation in Vermont  deeply val...
Precautionary Principle• The precautionary principle states that in  situations where there is a lack of consensus  about ...
54
55
Impacts on Birds Vermont’s mountains are also home to many  species of songbirds. “Breeding bird surveys have shown that...
Impacts on Birds Mountain ridges generate updrafts used by  migrating raptors. (From: Bildstein 2006).                   ...
Impacts on Birds Claims to the effect that wind turbines have a  negligible impact on birds generally look only  at impac...
Impacts to Bats An endangered species of bat does live in Vermont  (Myotis Sodalis) Myotis Sodalis sounds are difficult ...
Impacts to Bats Recently, Vermonts Endangered Species  Committee and Fish & Wildlife Department  recommended to the Secre...
Impacts to Bats Bats in general are under great stress in the  Northeast, due to White Nose Syndrome. Bats can be killed...
Impacts to Bats•   How are bat mortality issues being handled in Vermont in wind project    permitting?•   Not well. The g...
Impacts to Bats• In a petition to list two bat species as endangered,  the Center for Biological Diversity cited research ...
General Impacts to Wilderness, Wildlife Habitat Fragmentation    The Valleys and many other areas are already highly    ...
Noise and Health Low-frequency noise, including “infrasonic” noise,  from wind turbines may in fact be affecting the heal...
”The noise generated by wind turbines is ratherunusual, containing high levels (over 90 dB SPL) ofvery low frequency sound...
Impacts of Solar Relative to Wind• The impacts of solar development are not  comparable at all to wind development. Solar ...
68
69
Solar Resource in Vermont?• Vermont has about 1.2 million acres of farmland, which  constitutes about 20% of the state (se...
Solar Resource in Vermont? Specifically, taking into account that a 1 kilowatt PV produces about 3 kWh/day on average, and...
Cost of Photovoltaics• The levelized cost of PV power is rapidly approaching “grid parity”,  that is, the point at which P...
PV Cost TrendPV is on track to become fully competitive by 2015.                                                      73
74
Costs of Wind versus Solar•   Wind power has huge hidden costs for transmission:•   “A conservative goal for 5,500 megawat...
Diversion of resources to wind• Imagine what the impact would be on distributed  solar power development if the tens of bi...
Division of Communities• Wind development has and is creating enormous  divisiveness in communities throughout Vermont,  a...
Solar vs. WindLocal vs. Centralized Decision MakingDistributed Solar                        Industrial Wind Can be sited ...
The Trouble with Solar (Utility)The Benefits of Solar (Consumer)Wind Generation and Distribution         Solar Generation ...
Vermont Carbon Footprint (2008)Thousands of tons per year Gasoline/Diesel                                                 ...
Heating Fuels in VermontPercent                     Electricity Wood, Other                     5                10       ...
An Optimal Plan for Reducing VermontsCarbon Footprint?          2010 – 2015                        2015 Forward Internal ...
Vermont’s Existing RenewableEnergy Policies Strong Renewable Energy Targets for utilities No targets for homeowners or b...
The End          84
