  1. 1. OAuth: A Question of Trust
  2. 2. About Me • Lorna Jane Mitchell • Twitter: @lornajane • Web: http://lornajane.net 2
  3. 3. If OAuth is the answer, what was the question?
  4. 4. OAuth username: lornajane password: qwerty 4
  5. 5. OAuth Hi, I’m lornajane 5
  6. 6. Two Kinds of OAuth • OAuth 1 • in use on many systems • many steps: ’the oauth dance’ • encryption overhead (so use a lib) • OAuth 2 • requires SSL • fewer steps • recognises trust • recommended for new systems 6
  7. 7. OAuth 2: Performance over Paranoia
  8. 8. OAuth2 Relationships 8
  9. 9. OAuth2 Relationships 9
  10. 10. Before We BeginRegister for an API key and capture: • application name • callback URL(s) to use • descriptione.g. http://joind.in/user/apikey 10
  11. 11. OAuth2 Endpoints Application Website API Client api key registration auth endpoint callback URL user grant/revoke access resource endpoint resources 11
  12. 12. Establishing TrustWe need an authorisation grant for the assistant to be able to accessuser data 12
  13. 13. Authorisation Grants
  14. 14. Authorisation Grant: Many ChoicesHow we authorise a third party: • authorisation code • implicit • resource owner credentials • client credentials • ... potentially further extensions 14
  15. 15. Authorisation CodeUse for: server-side appsFlow: we send user to application to grant access, recieve a code inreturn. Then exchange code for access tokenFeatures: user never sees access token 15
  16. 16. Authorisation Code Process client_id redirect_url type scope state 16
  17. 17. Authorisation Code ProcessUser must be able to visit the site and revoke later 17
  18. 18. Authorisation Code Process code code state 18
  19. 19. Authorisation Code Process client_key client_secret code code access token access_token 19
  20. 20. Implicit GrantUse for: client-side appsFlow: we send user to application to grant access, recieve an accesstoken in returnFeatures: super-simple 20
  21. 21. Implicit Process client_id redirect_url type scope state 21
  22. 22. Implicit ProcessUser must be able to visit the site and revoke later 22
  23. 23. Implicit Process access token access_token state 23
  24. 24. Resource Owner CredentialsUse for: trusted consumers, such as same-provider apps or a script theuser writes themselvesFlow: user gives username and password to app, app exchanges foraccess token and does not storeFeatures: saves sending user to the main site and back 24
  25. 25. Resource Owner Credentials Process username, username, password password 25
  26. 26. Resource Owner Credentials Process access token 26
  27. 27. Client CredentialsUse for: privileged consumersFlow: client credentials act as an authorsation grant, access token isreturnedFeatures: ideal for applications with more than per-user-data accessrights 27
  28. 28. Client Credentials Process hai access token 28
  29. 29. How to Choose Grant TypeWhat will be consuming this data?It isn’t unusual for applications to support some or all of these grant types 29
  30. 30. You have an access token, now what?
  31. 31. Using Access TokensWith the access token, include it in an Authorization header:Authorization: OAuth db141c50adb74b22 31
  32. 32. Using Access TokensWith the access token, include it in an Authorization header:Authorization: OAuth db141c50adb74b22Everything you already knew about web APIs now applies as normal 31
  33. 33. Refresh TokensSome applications will give you two tokens • access token (shorter expiry) • refresh token (longer expiry)The refresh token is an authorisation grant in its own right, to be usedwhen the access token has expired 32
  34. 34. What about access control?
  35. 35. ScopeConsumers will request a given set of permissions, usually called scopeUsers usually only get to accept, or not 34
  36. 36. HTTPS (a vital OAuth2 ingredient)
  37. 37. HTTPSHTTPS is HTTP over SSL/TLS (Secure Socket Layer/Transport LayerSecurity)Basically, we encrypt the pipe! 36
  38. 38. OAuth 1
  39. 39. About OAuth 1In a nutshell: • Had its own encryption: needed a library/extension • Involved many steps, therefore many request/response roundtrips • leading to the phrase ’oauth dance’ • Solved exactly the same problem • Had a single oauth endpoint 38
  40. 40. OAuth 1 Process • Step 0: Register as a consumer • Step 1: Get a request token • Step 2: Send the user to authenticate • Step 3: Swap their verification for an access token • Step 4: Consume data 39
  41. 41. OAuth Today
  42. 42. OAuth Today • New project? Use OAuth 2 • OAuth 1 is complicated and needs PECL extension • OAuth 2 requires SSL, and decision-making 41
  43. 43. Resources and Further Reading • OAuth2 Spec: http://tools.ietf.org/html/draft-ietf-oauth-v2 • Great introductory article: http://hueniverse.com/2010/05/introducing-oauth-2-0/ • Images from http://thenounproject.org 42
  44. 44. Thanks!
  45. 45. Thanks https://joind.in/6232 @lornajane http://lornajane.net 44
