High Availability Solutions for
           MySQL


Lenz Grimmer
<lenz@grimmer.com>
2008-08-29
DrupalCon 2008, Szeged, Hung...
Agenda
●   High Availability in General
●   MySQL Replication
●   MySQL Cluster
●   DRBD
●   Links/Tools
Why High Availability Matters
●   Downtime is expensive
●   You miss $$$
●   Your Boss complains
●   New Site visitors won...
What Is HA Clustering?

●   One service goes down → others take
    over its work
●   IP address takeover, service takeove...
Split-Brain
●   Communications failures can lead to
    separated partitions of the cluster
●   If those partitions each t...
Eliminating the SPOF
●   Identify what will fail
    ●   Disks
●   Find out what can fail
    ●   Network cables
    ●   O...
Rules of High Availability
●   Prepare for failure
●   Keep it simple, stupid (KISS)
●   Complexity is the enemy of reliab...
MySQL Replication
●   One-way, statement-based
●   One Master, many Slaves
●   Asynchronous – Slaves can lag
●   Master ma...
MySQL Replication Overview
        Read & Write


            Web/App
             Server
                                ...
Replication Topologies
Master > Slave                          Master > Slaves




Master > Slave > Slaves            Mast...
Replication & HA
●   Combined with Heartbeat
●   Virtual IP takeover
●   Slave gets promoted to Master
●   Side benefits: ...
Master-Master Replication
●   Useful for easier failover
●   Not suitable for load-balancing
    ●   Writes still end up o...
MySQL Cluster

●   Shared nothing
●   Automatic partitioning
●   Distributed Fragments
●   Synchronous replication
●   Fas...
MySQL Cluster
●   In-memory tables
●   Not suitable for all query patterns
●   Not suitable for large datasets
●   Latency...
DRBD
●   Distributed Replicated Block Device
●   “Raid-1 over network”
●   Synchronous block replication
●   Automatic res...
DRBD & Heartbeat
●   Heartbeat mounts file system on
    failover (passive node becomes active)
●   Data only accessible o...
MySQL Replication &   MySQL, Heartbeat &    MySQL
                  Requirements       MySQL Replication       Heartbeat  ...
Related tools / Links
●   Linux Heartbeat
    http://linux-ha.org/
●   DRBD
    http:/drbd.org/
●   Linux Cluster Informat...
Tools/Links
●   MySQL Multi-Master Replication
    Manager
    http://code.google.com/p/mysql-master-master/
●   Maatkit
 ...
Q&A




Questions, Comments?
Thank you!
Lenz Grimmer <lenz@grimmer.com>
Drupal Con My Sql Ha 2008 08 29
Upcoming SlideShare
Loading in...5
×

Drupal Con My Sql Ha 2008 08 29

1,332

Published on

0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
1,332
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
15
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

Drupal Con My Sql Ha 2008 08 29

  1. 1. High Availability Solutions for MySQL Lenz Grimmer <lenz@grimmer.com> 2008-08-29 DrupalCon 2008, Szeged, Hungary
  2. 2. Agenda ● High Availability in General ● MySQL Replication ● MySQL Cluster ● DRBD ● Links/Tools
  3. 3. Why High Availability Matters ● Downtime is expensive ● You miss $$$ ● Your Boss complains ● New Site visitors won't come back
  4. 4. What Is HA Clustering? ● One service goes down → others take over its work ● IP address takeover, service takeover ● Not designed for high-performance ● Not designed for high troughput (load balancing)
  5. 5. Split-Brain ● Communications failures can lead to separated partitions of the cluster ● If those partitions each try and take control of the cluster, then it's called a split-brain condition ● If this happens, then bad things will happen http://linux-ha.org/BadThingsWillHappen ● Use Fencing or Moderatation/Arbitration to avoid it
  6. 6. Eliminating the SPOF ● Identify what will fail ● Disks ● Find out what can fail ● Network cables ● OOM ● Power supplies
  7. 7. Rules of High Availability ● Prepare for failure ● Keep it simple, stupid (KISS) ● Complexity is the enemy of reliability ● Test your setup frequently
  8. 8. MySQL Replication ● One-way, statement-based ● One Master, many Slaves ● Asynchronous – Slaves can lag ● Master maintains binary logs & index ● Easy to set up ● Built into MySQL ● Replication is single-threaded
  9. 9. MySQL Replication Overview Read & Write Web/App Server Write Relay Log mysqld I/O SQL Thread Thread Index & Binlogs Daten Replication Binlog Data mysqld MySQL Master MySQL Slave
  10. 10. Replication Topologies Master > Slave Master > Slaves Master > Slave > Slaves Masters > Slave (Multi-Source) Ring (Multi-Master) Master < > Master (Multi-Master)
  11. 11. Replication & HA ● Combined with Heartbeat ● Virtual IP takeover ● Slave gets promoted to Master ● Side benefits: load balancing & backup ● Tricky to fail back ● No automatic conflict resolution ● Proper failover needs to be scripted
  12. 12. Master-Master Replication ● Useful for easier failover ● Not suitable for load-balancing ● Writes still end up on both machines ● Neither machine has the authorative data ● Don't write to both masters! ● Use Sharding or Partitioning instead (e.g. MySQL Proxy)
  13. 13. MySQL Cluster ● Shared nothing ● Automatic partitioning ● Distributed Fragments ● Synchronous replication ● Fast automatic fail-over of data nodes ● Automatic resynchronization ● Transparent to Application ● Supports Transactions
  14. 14. MySQL Cluster ● In-memory tables ● Not suitable for all query patterns ● Not suitable for large datasets ● Latency matters ● Can be combined with MySQL Replication
  15. 15. DRBD ● Distributed Replicated Block Device ● “Raid-1 over network” ● Synchronous block replication ● Automatic resync on recover ● Application-agnostic ● Can mask local I/O errors ● Active/passive configuration
  16. 16. DRBD & Heartbeat ● Heartbeat mounts file system on failover (passive node becomes active) ● Data only accessible on the active node ● (LVM snapshots can work around this) ● Increased I/O Latency ● Failover is “cold” (fsck, log recovery, buffers/caches)
  17. 17. MySQL Replication & MySQL, Heartbeat & MySQL Requirements MySQL Replication Heartbeat DRBD Cluster Automated IP Failover No Yes Yes No Automated DB Availability Failover No No Yes Yes Typical Failover time Varies Varies < 30s < 3s Auto resync of data No No Yes Yes Geographic MySQL redundancy Yes Yes MySQL Replication Replication Built-in load Scalability balancing MySQL Replication MySQL Replication MySQL Replication Yes Read-intensive Yes Yes MySQL Replication Yes Write-intensive No No Possible Yes #Nodes/Cluster Master/Slave(s) Master/Slave(s) Active/Passive 255
  18. 18. Related tools / Links ● Linux Heartbeat http://linux-ha.org/ ● DRBD http:/drbd.org/ ● Linux Cluster Information Center http://www.lcic.org/ha.html ● Red Hat Cluster Suite http://www.redhat.com/cluster_suite/ ● Sun Open High Availability Cluster http://opensolaris.org/os/project/ha-mysql/
  19. 19. Tools/Links ● MySQL Multi-Master Replication Manager http://code.google.com/p/mysql-master-master/ ● Maatkit http://maatkit.sourceforge.net/ ● Mon – scheduler and alert management http://www.kernel.org/software/mon/ ● Continuent Tungsten Replicator https://community.continuent.com/community/tungsten-replicator
  20. 20. Q&A Questions, Comments?
  21. 21. Thank you! Lenz Grimmer <lenz@grimmer.com>
