C/C++ Linux System Programming <ul><ul><li>Session 16 </li></ul></ul><ul><ul><li>User-space System Programming </li></ul><...
Outline <ul><li>Filesystem concepts </li></ul><ul><li>File I/O Ops </li></ul>
Filesystem <ul><li>Traditionally: An abstraction for storage device access </li></ul><ul><li>Why? </li></ul><ul><ul><li>Co...
VFS  <ul><li>Wider-range abstraction:  </li></ul><ul><ul><li>special FS, different types of disk FS, network FS </li></ul>...
Mounts <ul><li>Superblocks – filesystem control block </li></ul><ul><li>Mount point </li></ul><ul><li>Syscalls </li></ul><...
FS Objects and Metadata <ul><li>Inode – file control block </li></ul><ul><ul><li>A unique ID </li></ul></ul><ul><ul><li>Ac...
Journaling <ul><li>Problem: </li></ul><ul><ul><li>operations on metadata are non-atomic, can be interrupted by power loss ...
Disk Cache <ul><li>Buffers </li></ul><ul><li>Page cache </li></ul><ul><li>Writeback – pdflush </li></ul><ul><li>Read-ahead...
File Descriptors <ul><li>Descriptors – index into process file table </li></ul><ul><li>int open(const char *pathname, int ...
File I/O modes <ul><li>int fcntl(int fd, int cmd, long arg); // F_SETFL </li></ul><ul><li>Nonblocking: If not ready, EAGAI...
More File control <ul><li>int unlink(const char *pathname); </li></ul><ul><li>int truncate(const char *path, off_t length)...
Descriptor I/O <ul><li>ssize_t read(int fd, void *buf, size_t count); </li></ul><ul><li>ssize_t write(int fd, const void *...
IO Vectors <ul><li>ssize_t readv(int fd, const struct iovec *iov, int iovcnt); </li></ul><ul><li>ssize_t writev(int fd, co...
int echo_main(int argc, char **argv) { struct iovec io[argc]; struct iovec *cur_io = io; char *arg; char *p; ... while (1)...
Memory Mapped file <ul><li>void *mmap(void *start, size_t length, int prot, int flags, int fd, off_t offset); </li></ul><u...
Locking <ul><li>Mandatory Locking (BSD) </li></ul><ul><ul><li>~S_IXGRP | SGID ( + mount flag MS_MANDLOCK) </li></ul></ul><...
Advisory Locking <ul><li>int flock(int fd, int operation); // LOCK_SH, LOCK_EX, LOCK_UN </li></ul><ul><li>int lockf(int fd...
#ifdef F_SETLK #ifndef SEEK_SET #define SEEK_SET 0 #endif struct flock lock_data; lock_data.l_type = F_WRLCK; lock_data.l_...
Buffered I/O <ul><li>Streams:  Buffer I/O and write to kernel at once </li></ul><ul><ul><li>Better alignment </li></ul></u...
I/O <ul><li>size_t fread(void *ptr, size_t size, size_t nmemb, FILE *stream); </li></ul><ul><li>size_t fwrite(const void *...
Behind the Scenes <ul><li>Inherently thread-safe </li></ul><ul><li>To do your own locking (of the stream, not the file) </...
Errors <ul><li>int feof(FILE *stream); </li></ul><ul><li>int ferror(FILE *stream); </li></ul><ul><li>void clearerr(FILE *s...
Positioning <ul><li>int fseek(FILE *stream, long offset, int whence); </li></ul><ul><li>long ftell(FILE *stream); </li></u...
Metadata <ul><li>int fstat(int fd, struct stat *buf); </li></ul><ul><li>int stat(const char *path, struct stat *buf); </li...
Directory Streams <ul><li>A directory is a file whose entries are other inodes </li></ul><ul><li>DIR *opendir(const char *...
static pid_list *scan_proc_pids(inode_list *ilist) { DIR *d; struct dirent *de; pid_t pid; pid_list *plist; xchdir(&quot;/...
I/O Multiplexing <ul><li>int select(int nfds, fd_set *readfds, fd_set *writefds, fd_set *exceptfds, struct timeval *timeou...
Epoll  <ul><li>Decouple interest set registration from poll </li></ul><ul><ul><li>+: O(1) on the wait </li></ul></ul><ul><...

IOCTL <ul><li>Device / special file control </li></ul><ul><li>int ioctl(int d, int request, ...); </li></ul><ul><li>Reques...
Filesystem events <ul><li>int inotify_init(void); // desc, need close </li></ul><ul><li>int inotify_add_watch(int fd, cons...
int inotifyd_main(int argc UNUSED_PARAM, char **argv) { unsigned mask = IN_ALL_EVENTS; // assume we want all events struct...
Asynchronous I/O <ul><li>Only on O_DIRECT </li></ul>struct aiocb { int aio_filedes;  /* file descriptor * int aio_lio_opco...
